Complete the Installation & Retain Important Features Such as Steering Wheel Controls!
7" Multimedia Receiver Upgrade SolutionThe Aerpro AM8246K package offers a comprehensive head unit upgrade solution that includes an Aerpro AM7X Double DIN 7" Mechless AV Receiver, a Vehicle Specific Installation Kit and a 720P AHD universal reverse camera. Designed specifically for iLoad and iMax 20015-2017 vehicles, this package comes with all the necessary parts to complete the installation and retain important features such as steering wheel controls.
Aerpro AM7X 7" Multimedia Receiver With Wireless CarPlay & Android AutoThe Aerpro AM7X Multimedia Receiver with Wireless Apple CarPlay and Android Auto features a large 7" capacitive touch screen display. The built-in Bluetooth enables hands-free phone calls and wireless audio streaming and the included external microphone provides crystal clear communications. It has a rear USB input which works with Apple CarPlay and Android Auto, as well as a built in AM/FM tuner with RDS and presets. Sound quality is superb with a built in 45W x 4 amplifier, 8 band graphic EQ and time alignment capabilities for precise sound adjustment. If more sound is desired, an amplifier can be added to the system via the 4V/5CH RCA preouts (front + rear + subwoofer). The unit is OEM steering wheel remote ready and has dual reverse camera inputs (720P AHD compatible).
Vehicle-Specific Installation KitThe Aerpro Vehicle Specific Installation Kit is designed to provide a complete solution for upgrading the head unit in iLoad and iMax 20015-2017 vehicles. The kit contains all necessary components for a successful double din installation, including a matte black facia kit, plastic mounting brackets, steering wheel control interface, factory USB and camera retention, antenna adapter and universal SWC patch lead.
720P AHD Surface Mount CameraThe Aerpro 720P AHD Surface Mount Camera produces high definition picture quality. The camera can be used as a front, rear or reverse camera. It features a 150 degree field of view, optional parking guidelines and is IP67 rated. The camera is designed to mount on a flat surface and has an adjustable bracket to enable angle adjustment.
Important Information:
Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
Features:
Includes all the parts required to complete the installation
Retains important vehicle features including steering wheel controls, factory USB and factory reverse camera when applicable
7" Capacitive touch display
Works with Apple CarPlay (wireless and wired)
Supports Android Auto (wireless and wired)
Built-in Bluetooth (A2DP, AVRCP, HFP, PBAP)
AM / FM Tuner with RDS & presets (18FM/12AM)
Dual rear USB inputs (1.5A + 1.5A max charging)
Dual camera input with 1 Aerpro 720P AHD Camera included
Rear A/V input (RCA)
4V / 6CH RCA Preout
MP3 / AAC / FLAC / MPEG 1,2,4 Media formats
8 Band graphic EQ
8 EQ Presets
Subwoofer level control
45W x 4 Max built-in amplifier
Shallow 2-DIN chassis mounting design
External microphone included
Specifications:
LCD Display:Size: 7"Resolution: 1024x600Touch Screen: Capacitive (G+G)
System Specifications:OS System / CPU: Linux 3.4.5 / SPHE8368URAM / Flash Memory: 128MB / 256MB
DIN Size: 2 DIN Short Body
Power Output:Rated Power (4 Ohm @ 14.4 V, 1 kHz, THD 10 %): 4CH x 25WMAX Power (4 Ohm): 4CH x 45W
Media Playback: MP3 / MP4 / AAC / FLAC / Xvid
Device Ports:USB (Rear) Playback Formats: CPAA & MediaUSB2 (Rear) USB Media / Charging - Voltage/Amps: 5V/1.5AUSB MAX Capability: FAT32_32GB
Aux Inputs / Outputs:Rear A/V Input (RCA Type - 3pcs): YesReverse Camera Input: Yes (720P AHD Compatible)Second Camera Input: Yes (720P AHD Compatible)
Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
Bluetooth:Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)Bluetooth Version: V4.2+EDRMicrophone: Built-in & External MicrophoneID3 Tag/Information (Artist, Album, Song): YesHFP Profile (1.2, 1.4 or HD Voice 1.6): HFP 1.6
Tuner:AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)FM Frequency Span (MHz): 87.5-108.0MHz (0.05MHz Step)AM Frequency Span (KHz): 529-1629KHz (9KHz Step)RDS: YesFM Antenna Connector Impedance: 50 OhmFM Tuner Connector: Motorola
RCA Preamp Outputs:RCA Preamp Output: 2-Pair (Front / Rear)Subwoofer RCA Output: YesSubwoofer Level Control: YesPreamp Voltage (1.2,2,4,5,6): 4V p-p
Tone Control:8 Band: 8 Band (50/200/400/800/1K/3K/7K/15K)Loudness: YesLPF - Frequencies (Sub): Yes8 Preset EQs: Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft
Other Features:Steering Wheel Control: Yes, with Aerpro SWC AdaptorOSD Language: EnglishLED Colour (Buttons / Keys): White
Accessories:Power Harness: Yes with ISOAV-In Cable (RCA with Audio L/R, Video In): YesReverse Camera Input: Yes4.2CH Audio Out Cable: YesExternal Microphone: Included
Vehicle-Specific Installation Kit Inclusions:
Facia Kit (Matte Black)
Steering Wheel Control Interface
USB Retention Harness
Antenna Adapter
Universal Patch Lead
AHD Camera Specifications:
Inclusions:720P AHD Surface Mount Camera (wired)6M of Video Cable (RCA) With In-Line Reverse Trigger
Mount Type: Surface Mount
Camera Type: Front, Rear Or Reverse
Image Sensor: Sony 225, 1/3 CMOS AHD
Lens Angle 150 Degree
Aerpro AM8246K Vehicle Compatibility:
Hyundai iLoad (Starex) 2015 - 2017
Hyundai iMax 2016 - 2017
Aerpro AM8246K Kit Inclusions:
Aerpro AM7X 7" Multimedia Receiver With Wireless CarPlay & Android Auto
Vehicle-Specific Installation Kit
720P AHD Surface Mount Camera
Legendary Products & Support From Authorized Dealers
When you choose Aerpro, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Aerpro dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Aerpro's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from Frankies Auto Electrics an authorized Aerpro dealer today!
Legendary Products & Support From Authorized Dealers
When you choose Aerpro, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Aerpro dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Aerpro dealer today!
Legendary Products & Support From Authorized Dealers
When you choose Aerpro, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Aerpro dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Aerpro's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Aerpro dealer today!
Aerpro AM8290K 7″ Multimedia Receiver Upgrade Kit for Porsche (911 996 & Boxster 986)
Transform your driving experience with the Aerpro AM8290K Multimedia Receiver Kit, designed specifically for Porsche 911 (996) 1998–2004 and Boxster (986) 1997–2004 models. This all-in-one package delivers modern technology, premium sound, and seamless integration, while retaining your factory steering wheel controls for a factory-like finish.
Key Benefits for Porsche Owners:
Seamless Smartphone Integration – Enjoy wireless Apple CarPlay & Android Auto, letting you access maps, music, calls, and messages safely from the 7″ touchscreen.
Safer Driving with Reverse Camera – Comes with a 720P AHD universal reverse camera, giving you crystal-clear rear vision for safer parking and reversing.
Crystal-Clear Sound – Built-in 45W x 4 amplifier, 8-band EQ, and subwoofer control let you fine-tune your audio for concert-quality sound.
Retain Factory Controls – Keep your steering wheel controls working as they should, ensuring convenience without compromise.
Future-Ready Connectivity – Dual USB inputs, Bluetooth streaming, and 4V RCA outputs make it easy to expand with amplifiers, subwoofers, or extra cameras.
OEM-Like Fitment – Vehicle-specific facia kit, brackets, and adapters ensure a perfect fit in your Porsche dashboard — no cutting or modifications needed.
Aerpro AM8290K Specifications:
LCD Display:
Size: 7"
Resolution: 1024x600
Touch Screen: Capacitive (G+G)
System Specifications:
OS System / CPU: Linux 3.4.5 / SPHE8368U
RAM / Flash Memory: 128MB / 256MB
DIN Size: 2 DIN Short Body
Power Output
Rated Power (4 Ohm @ 14.4 V, 1 kHz, THD 10 %): 4CH x 25W
MAX Power (4 Ohm): 4CH x 45W
Media Playback: MP3 / MP4 / AAC / FLAC / Xvid
Device Ports
USB (Rear) Playback Formats: CPAA & Media
USB2 (Rear) USB Media / Charging - Voltage/Amps: 5V/1.5A
USB MAX Capability: FAT32_32GB
Aux Inputs / Outputs:
Rear A/V Input (RCA Type - 3pcs): Yes
Reverse Camera Input: Yes (720P AHD Compatible)
Second Camera Input: Yes (720P AHD Compatible)
Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
Bluetooth:
Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)
Bluetooth Version: V4.2+EDR
Microphone: External Microphone
ID3 Tag/Information (Artist, Album, Song): Yes
HFP Profile (1.2, 1.4 or HD Voice 1.6): HFP 1.6
Tuner:
AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)
FM Frequency Span (MHz): 87.5-108.0MHz (0.05MHz Step)
AM Frequency Span (KHz): 529-1629KHz (9KHz Step)
RDS: Yes
FM Antenna Connector Impedance: 50 Ohm
FM Tuner Connector: Motorola
RCA Preamp Outputs:
RCA Preamp Output: 2-Pair (Front / Rear)
Subwoofer RCA Output: Yes
Subwoofer Level Control: Yes
Preamp Voltage (1.2,2,4,5,6): 4V p-p
Tone Control:
8 Band: 8 Band (50/200/400/800/1K/3K/7K/15K)
Loudness: Yes
LPF - Frequencies (Sub): Yes
8 Preset EQs: Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft
Other Features:
Steering Wheel Control: Yes, with Aerpro SWC Adaptor
OSD Language: English
LED Colour (Buttons / Keys): White
Accessories:
Power Harness: Yes, with ISO
AV-In Cable (RCA with Audio L/R, Video In): Yes
Reverse Camera Input: Yes
4.2CH Audio Out Cable: Yes
External Microphone: Included
Vehicle Specific Installation Kit Specifications:
Inclusions:
Facia Kit (Black)
Steering Wheel Control Interface
Radio removal keys
Antenna Adapter
Universal Patch Lead
Feature Highlights:
Includes all the parts required to complete the installation
Retains important vehicle features including steering wheel controls when applicable
7" Capacitive touch display
Works with Apple CarPlay (wireless and wired)
Supports Android Auto (wireless and wired)
Built-in Bluetooth (A2DP, AVRCP, HFP, PBAP)
AM / FM Tuner with RDS & presets (18FM/12AM)
Dual rear USB inputs (1.5A + 1.5A max charging)
Dual camera inputs
Rear A/V input (RCA)
4V / 6CH RCA Preout
MP3 / AAC / FLAC / MPEG 1,2,4 Media formats
8 Band graphic EQ
8 EQ Presets
Subwoofer level control
45W x 4 Max built-in amplifier
Shallow 2-DIN chassis mounting design
External microphone included
Why Choose Aerpro for Your Porsche?
Upgrading your Porsche’s entertainment system is no longer just about replacing a radio — it’s about bringing luxury-level technology into your classic Porsche. With the Aerpro AM8290K, you’ll get modern features, OEM-style integration, and premium sound — all in one complete package built for your vehicle.
Compatible with:
Porsche 911 (996) – 1998 to 2004
Porsche Boxster (986) – 1997 to 2004
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Complete Head Unit Upgrade Solution For Holden Colorado & Trailblazer!
Aerpro AM8298K Head Unit Upgrade KitThe Aerpro AM8298K package offers a comprehensive head unit upgrade solution for Holden Colorado 2017–2020 and Trailblazer 2017-on vehicles. It includes the Aerpro AM7X 7" Mechless AV Receiver with Wireless Apple CarPlay and Android Auto, a Vehicle Specific Installation Kit, and a 720P AHD universal reverse camera. This package ensures seamless integration, retaining important features like steering wheel controls while providing an enhanced multimedia experience.
Important Information:
Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
Suitable for cars with factory 8" MyLink system.
This head unit is sold as a kit which includes:
Aerpro AM7X 7" Multimedia Receiver with Wireless CarPlay and Android Auto
Vehicle Specific Installation Kit
720P AHD Surface Mount Camera
Video:Head Unit Feature Video Inclusions:
Aerpro AM7X 7" Multimedia Receiver
Vehicle Specific Installation Kit
720P AHD Surface Mount Camera
Steering Wheel Control Interface
Reverse Camera Retention Lead
Plastic Mounting Brackets
Universal SWC Patch Lead
Specifications:Aerpro AM7X HEAD UNIT SPECIFICATIONS:
LCD Display:
Size: 7"
Resolution: 1024x600
Touch Screen: Capacitive (G+G)
System Specifications:
OS System / CPU: Linux 3.4.5 / SPHE8368U
RAM / Flash Memory: 128MB / 256MB
DIN Size: 2 DIN Short Body
Power Output:
Rated Power: 4CH x 25W
MAX Power: 4CH x 45W
Media Playback: MP3 / MP4 / AAC / FLAC / Xvid
Device Ports:
USB (Rear) Playback Formats: CPAA & Media
USB2 (Rear) USB Media / Charging - Voltage/Amps: 5V/1.5A
USB MAX Capability: FAT32_32GB
Aux Inputs / Outputs:
Rear A/V Input (RCA Type - 3pcs): Yes
Reverse Camera Input: Yes (720P AHD Compatible)
Second Camera Input: Yes (720P AHD Compatible)
Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
Bluetooth:
Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)
Bluetooth Version: V4.2+EDR
Microphone: External Microphone
Tuner:
AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)
FM Frequency Span: 87.5–108.0MHz
AM Frequency Span: 529–1629KHz
RDS: Yes
FM Antenna Connector Impedance: 50 Ohm
RCA Preamp Outputs:
RCA Preamp Output: 2-Pair (Front / Rear)
Subwoofer RCA Output: Yes
Preamp Voltage: 4V p-p
Tone Control:
8 Band EQ
Loudness: Yes
LPF (Sub): Yes
8 EQ Presets
Other Features:
Steering Wheel Control: Yes (via Aerpro SWC Adaptor)
OSD Language: English
Button LED Colour: White
Vehicle Compatibility:
Holden Colorado 2017–2020
Holden Trailblazer 2017–ON
Legendary Products & Support From Authorized Dealers
When you choose Frankie's BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose Wisely. Buy From Frankie's BrandBeast today!
Provides A Complete Solution For Upgrading!
Multimedia Receiver With Wireless CarPlay & Android AutoThe Aerpro AM8299K package offers a comprehensive head unit upgrade solution that includes an Aerpro AM7X Double DIN 7" Mechless AV Receiver, a Vehicle Specific Installation Kit and a 720P AHD universal reverse camera. Designed specifically for Holden Colorado 2017-2020 & Trailblazer 2017-on vehicles, this package comes with all the necessary parts to complete the installation and retain important features such as steering wheel controls.
Aerpro AM7X 7" Multimedia Receiver with Wireless CarPlay & Android AutoThe Aerpro AM7X Multimedia Receiver with Wireless Apple CarPlay and Android Auto features a large 7" capacitive touch screen display. The built-in Bluetooth enables hands-free phone calls and wireless audio streaming and the included external microphone provides crystal clear communications. It has a rear USB input which works with Apple CarPlay and Android Auto, as well as a built in AM/FM tuner with RDS and presets. Sound quality is superb with a built in 45W x 4 amplifier, 8 band graphic EQ and time alignment capabilities for precise sound adjustment. If more sound is desired, an amplifier can be added to the system via the 4V/5CH RCA preouts (front + rear + subwoofer). The unit is OEM steering wheel remote ready and has dual reverse camera inputs (720P AHD compatible).
Vehicle-Specific Installation KitThe Aerpro Vehicle Specific Installation Kit is designed to provide a complete solution for upgrading the head unit in Holden Colorado 2017-2020 & Trailblazer 2017-on vehicles. The kit contains all necessary components for a successful double din installation, including a black facia kit, plastic mounting brackets, steering wheel control interface (infodapter), reverse camera retention lead, antenna adapter and universal SWC patch lead.
720P AHD Surface Mount CameraThe Aerpro 720P AHD Surface Mount Camera produces high definition picture quality. The camera can be used as a front, rear or reverse camera. It features a 150 degree field of view, optional parking guidelines and is IP67 rated. The camera is designed to mount on a flat surface and has an adjustable bracket to enable angle adjustment.
Important Information:
Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.Suitable for cars with factory 7" MyLink system.
Features:
Includes all the parts required to complete the installation
Retains important vehicle features including steering wheel controls and reverse camera when applicable
Includes integrated buttons for adjusting climate control and various vehicle settings.
Climate Control and Vehicle Information display on aftermarket AV headunit
7" Capacitive touch display
Works with Apple CarPlay (wireless and wired)
Supports Android Auto (wireless and wired)
Built-in Bluetooth (A2DP, AVRCP, HFP, PBAP)
AM / FM Tuner with RDS & presets (18FM/12AM)
Dual rear USB inputs (1.5A + 1.5A max charging)
Dual camera input with 1 Aerpro 720P AHD Camera included
Rear A/V input (RCA)
4V / 6CH RCA Preout
MP3 / AAC / FLAC / MPEG 1,2,4 Media formats
8 Band graphic EQ
8 EQ Presets
Subwoofer level control
45W x 4 Max built-in amplifier
Shallow 2-DIN chassis mounting design
External microphone included
Aerpro AM7X Specifications:
LCD Display:
Size: 7"
Resolution: 1024x600
Touch Screen: Capacitive (G+G)
System Specifications:
OS System / CPU: Linux 3.4.5 / SPHE8368U
RAM / Flash Memory: 128MB / 256MB
DIN Size: 2 DIN Short Body
Power Output
Rated Power (4 Ohm @ 14.4 V, 1 kHz, THD 10 %): 4CH x 25W
MAX Power (4 Ohm): 4CH x 45W
Media Playback: MP3 / MP4 / AAC / FLAC / Xvid
Device Ports
USB (Rear) Playback Formats: CPAA & Media
USB2 (Rear) USB Media / Charging - Voltage/Amps: 5V/1.5A
USB MAX Capability: FAT32_32GB
Aux Inputs / Outputs:
Rear A/V Input (RCA Type - 3pcs): Yes
Reverse Camera Input: Yes (720P AHD Compatible)
Second Camera Input: Yes (720P AHD Compatible)
Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
Bluetooth:
Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)
Bluetooth Version: V4.2+EDR
Microphone: External Microphone
ID3 Tag/Information (Artist, Album, Song): Yes
HFP Profile (1.2, 1.4 or HD Voice 1.6): HFP 1.6
Tuner:
AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)
FM Frequency Span (MHz): 87.5-108.0MHz (0.05MHz Step)
AM Frequency Span (KHz): 529-1629KHz (9KHz Step)
RDS: Yes
FM Antenna Connector Impedance: 50 Ohm
FM Tuner Connector: Motorola
RCA Preamp Outputs:
RCA Preamp Output: 2-Pair (Front / Rear)
Subwoofer RCA Output: Yes
Subwoofer Level Control: Yes
Preamp Voltage (1.2,2,4,5,6): 4V p-p
Tone Control:
8 Band: 8 Band (50/200/400/800/1K/3K/7K/15K)
Loudness: Yes
LPF - Frequencies (Sub): Yes
8 Preset EQs: Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft
Other Features:
Steering Wheel Control: Yes, with Aerpro SWC Adaptor
OSD Language: English
LED Colour (Buttons / Keys): White
Accessories:
Power Harness: Yes with ISO
AV-In Cable (RCA with Audio L/R, Video In): Yes
Reverse Camera Input: Yes
4.2CH Audio Out Cable: Yes
External Microphone: Included
Vehicle-Specific Installation Kit Specifications:
Inclusions:
Facia Kit (Black)
Steering Wheel Control Interface (Infodapter)
Reverse Camera Retention Lead
Antenna Adapter
Universal Patch Lead
AHD Camera Specifications:
Inclusions:
720P AHD Surface Mount Camera (wired)
6M of Video Cable (RCA) with in-line Reverse Trigger
Mount Type: Surface Mount
Camera Type: Front, Rear Or Reverse
Image Sensor: Sony 225, 1/3 CMOS AHD
Lens Angle 150 Degree
Vehicle Compatibility:
Holden Colorado (2017 - 2020)
Holden Trailblazer (2017 - )
Kit Includes:
Aerpro AM7X 7" Multimedia Receiver with Wireless Carplay & Android Auto
Vehicle-Specific Installation Kit
720P AHD Surface Mount Camera
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Frankies BrandBeast's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Frankies BrandBeast dealer today!
Aerpro AM8343K Hyundai i30 GD 2012-2017 Factory Navigation 7 Inch Multimedia Receiver Kit with 720P AHD Camera
A complete 7 inch head unit upgrade kit for the Hyundai i30 GD (2012-2017) with factory navigation, including the Aerpro AM7X wireless Apple CarPlay and Android Auto multimedia receiver, a vehicle-specific installation kit retaining steering wheel controls, factory USB, and factory reverse camera, plus a 720P AHD surface mount camera. Suits factory navigation models only.
Product Overview
The Aerpro AM8343K is a complete head unit upgrade package designed specifically for the Hyundai i30 GD (2012-2017) in vehicles fitted with factory navigation. The kit centres on the Aerpro AM7X 7 inch multimedia receiver featuring wireless and wired Apple CarPlay and Android Auto, a 7 inch capacitive touchscreen (1024 x 600), built-in Bluetooth with A2DP, AVRCP, HFP 1.6, and PBAP, AM/FM tuner with RDS, 45W x 4 max power output, 8 band graphic EQ with time alignment, and 4V 5-channel RCA preouts for amplifier integration.
The vehicle-specific installation kit includes a gloss black fascia kit, plastic mounting brackets, steering wheel control interface, USB retention harness, factory camera retention interface, antenna adaptor, and universal SWC patch lead - retaining steering wheel controls, factory USB, and factory reverse camera where applicable. A 720P AHD surface mount camera with Sony 225 1/3 CMOS sensor, 150° field of view, 6m video cable, and IP67 rating is also included.
Please note this kit is designed for Hyundai i30 GD (2012-2017) vehicles with factory navigation only. Feature retention is head unit dependent.
Features & Benefits
Wireless Apple CarPlay and Android Auto: The AM7X supports both wireless and wired Apple CarPlay and Android Auto for full smartphone integration without a cable connection on compatible devices.
7 Inch Capacitive Touchscreen: A 1024 x 600 resolution glass-on-glass capacitive touchscreen provides a responsive, high-clarity display for navigation, media, and connectivity.
Retains Steering Wheel Controls, Factory USB, and Factory Reverse Camera: The vehicle-specific installation kit includes a SWC interface, USB retention harness, and factory camera retention interface to preserve factory features after the head unit upgrade.
720P AHD Surface Mount Camera Included: A 720P AHD surface mount camera with a Sony 225 1/3 CMOS sensor, 150° field of view, and IP67 water resistance rating is included. The camera can be used as a front, rear, or reverse camera and features an optional parking guidelines overlay.
45W x 4 Max Power with 8 Band EQ and Time Alignment: The AM7X delivers 45W x 4 max power with an 8 band graphic EQ, time alignment, and 4V 5-channel RCA preouts for external amplifier connection.
Factory Navigation Models Only: The AM8343K is designed exclusively for Hyundai i30 GD (2012-2017) vehicles fitted with factory navigation. It is not suitable for non-navigation models.
Technical Specs
Specification
Detail
SKU
AM8343K
Brand
Aerpro
Compatible Vehicle
Hyundai i30 GD 2012-2017 (factory navigation models only)
Kit Inclusions
AM7X Multimedia Receiver, Vehicle Specific Installation Kit, 720P AHD Surface Mount Camera
Display
Screen Size
7 inch
Resolution
1024 x 600
Touchscreen
Capacitive (G+G)
System
OS / CPU
Linux 3.4.5 / SPHE8368U
RAM / Flash Memory
128MB / 256MB
DIN Size
2 DIN Short Body
Power
Rated Power
4CH x 25W (4 Ohm, 14.4V, 1kHz, THD 10%)
Max Power
4CH x 45W (4 Ohm)
Connectivity
Apple CarPlay / Android Auto
Yes - Wireless and Wired
Bluetooth
Yes - V4.2+EDR (A2DP, AVRCP, HFP 1.6, PBAP)
Microphone
External (included)
USB 1 (Rear)
CarPlay, Android Auto and Media
USB 2 (Rear)
Media / Charging - 5V / 1.5A
USB Max Capacity
FAT32 32GB
Rear A/V Input
Yes (RCA, 3 pieces)
Reverse Camera Input
Yes (720P AHD compatible)
Second Camera Input
Yes (720P AHD compatible)
Tuner
AM / FM Tuner
Yes - AM 12 presets (6x2), FM 18 presets (6x3)
FM Frequency Range
87.5-108.0MHz (0.05MHz step)
AM Frequency Range
529-1629KHz (9KHz step)
RDS
Yes
FM Antenna Connector
Motorola / 50 Ohm
RCA Preouts
Preamp Outputs
2 pair (Front / Rear)
Subwoofer Output
Yes
Subwoofer Level Control
Yes
Preamp Voltage
4V p-p
Audio
EQ
8 Band (50/200/400/800/1K/3K/7K/15K Hz)
EQ Presets
Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft
Loudness
Yes
LPF (Subwoofer)
Yes
Media Playback
Audio Formats
MP3, AAC, FLAC
Video Formats
Xvid, MPEG 1/2/4
Installation Kit
Fascia Kit
Gloss Black
Inclusions
SWC Interface, USB Retention Harness, Factory Camera Retention Interface, Antenna Adaptor, Universal SWC Patch Lead, Plastic Mounting Brackets
Steering Wheel Control Retention
Yes
Factory USB Retention
Yes
Factory Camera Retention
Yes (where applicable)
Feature Retention
Head unit dependent
720P AHD Camera
Image Sensor
Sony 225 1/3 CMOS AHD
Resolution
720P AHD
Lens Angle
150°
Mount Type
Surface Mount (adjustable bracket)
Camera Use
Front, Rear or Reverse
Parking Guidelines
Optional
IP Rating
IP67
Cable
6m video cable (RCA) with in-line reverse trigger
What's in the Box
Aerpro AM7X 7 inch Multimedia Receiver
Gloss Black Fascia Kit
Steering Wheel Control Interface
USB Retention Harness
Factory Camera Retention Interface
Antenna Adaptor
Universal SWC Patch Lead
Plastic Mounting Brackets
720P AHD Surface Mount Camera
6m Video Cable (RCA) with In-Line Reverse Trigger
Power Harness (with ISO)
AV-In Cable (RCA with Audio L/R, Video In)
Reverse Camera Input Cable
4.2CH Audio Out Cable
External Microphone
Compatible With
Hyundai i30 GD 2012-2017 (factory navigation models only)
This kit is not suitable for Hyundai i30 GD (2012-2017) models without factory navigation. Feature retention is head unit dependent.
Frequently Asked Questions
Is the AM8343K suitable for Hyundai i30 models without factory navigation?
No. The AM8343K is designed exclusively for Hyundai i30 GD (2012-2017) vehicles fitted with factory navigation. A different kit is required for non-navigation models. Please contact us to confirm the correct kit for your vehicle.
Does this kit include a reverse camera?
Yes. A 720P AHD surface mount camera is included in the kit. The camera features a Sony 225 1/3 CMOS sensor, 150° field of view, IP67 water resistance, optional parking guidelines, and a 6m video cable with in-line reverse trigger. It can be used as a front, rear, or reverse camera.
Does the AM8343K retain steering wheel controls?
Yes. The vehicle-specific installation kit includes a steering wheel control interface and universal SWC patch lead that retains factory SWC functionality. Feature retention is head unit dependent.
Can I connect an external amplifier to the AM7X?
Yes. The AM7X features 4V 5-channel RCA preouts including a dedicated subwoofer output, allowing external amplifiers to be connected to the system. Subwoofer level control is also available.
Does the kit retain the factory USB input?
Yes. A USB retention harness is included in the vehicle-specific installation kit to retain factory USB input functionality. Feature retention is head unit dependent.Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Legendary Products & Support From Authorized Dealers
When you choose Aerpro, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Aerpro dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Aerpro's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Aerpro dealer today!
Legendary Products & Support From Authorized Dealers
When you choose Aerpro, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Aerpro dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Aerpro dealer today!
Legendary Products & Support From Authorized Dealers
When you choose Aerpro, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Aerpro dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Aerpro's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Aerpro dealer today!
Built-In Bluetooth Enables Hands-Free Phone Calls & Wireless Audio Streaming!
Double DIN 7" Mechless AV Receiver With Factory NavigationThe Aerpro AM8387KN package offers a comprehensive head unit upgrade solution that includes an Aerpro AM7X Double DIN 7" Mechless AV Receiver, a Vehicle Specific Installation Kit and a 720P AHD universal reverse camera. Designed for various Subaru vehicles 2015-2020 with Factory Navigation, this package comes with all the necessary parts to complete the installation and retain important features such as steering wheel controls.
Aerpro AM7X 7" Multimedia Receiver With Wireless CarPlay & Android AutoThe Aerpro AM7X Multimedia Receiver with Wireless Apple CarPlay and Android Auto features a large 7" capacitive touch screen display. The built-in Bluetooth enables hands-free phone calls and wireless audio streaming and the included external microphone provides crystal clear communications. It has a rear USB input which works with Apple CarPlay and Android Auto, as well as a built in AM/FM tuner with RDS and presets. Sound quality is superb with a built in 45W x 4 amplifier, 8 band graphic EQ and time alignment capabilities for precise sound adjustment. If more sound is desired, an amplifier can be added to the system via the 4V/5CH RCA preouts (front + rear + subwoofer). The unit is OEM steering wheel remote ready and has dual reverse camera inputs (720P AHD compatible).
Vehicle-Specific Installation KitThe Aerpro Vehicle Specific Installation Kit is designed to provide a complete solution for upgrading the head unit in Various Subaru vehicles 2015-2020 with Factory Navigation. The kit contains all necessary components for a successful double din installation, including a gloss black facia kit, metal mounting brackets, steering wheel control interface, antenna adapter and universal SWC patch lead.
720P AHD Surface Mount CameraThe Aerpro 720P AHD Surface Mount Camera produces high definition picture quality. The camera can be used as a front, rear or reverse camera. It features a 150 degree field of view, optional parking guidelines and is IP67 rated. The camera is designed to mount on a flat surface and has an adjustable bracket to enable angle adjustment.
Important Information:
Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
Only suitable for vehicles that were equipped with factory navigation (not retained)
Features:
Includes all the parts required to complete the installationRetains important vehicle features including steering wheel controls when applicable
7" Capacitive touch display
Works with Apple CarPlay (wireless and wired)
Supports Android Auto (wireless and wired)
Built-in Bluetooth (A2DP, AVRCP, HFP, PBAP)
AM / FM Tuner with RDS & presets (18FM/12AM)
Dual rear USB inputs (1.5A + 1.5A max charging)
Dual camera input with 1 Aerpro 720P AHD Camera included
Rear A/V input (RCA)
4V / 6CH RCA Preout
MP3 / AAC / FLAC / MPEG 1,2,4 Media formats
8 Band graphic EQ
8 EQ Presets
Subwoofer level control
45W x 4 Max built-in amplifier
Shallow 2-DIN chassis mounting design
External microphone included
Aerpro AM7X Specifications:
LCD Display:
Size: 7"
Resolution: 1024x600
Touch Screen: Capacitive (G+G)
System Specifications:
OS System / CPU: Linux 3.4.5 / SPHE8368U
RAM / Flash Memory: 128MB / 256MB
DIN Size: 2 DIN Short Body
Power Output
Rated Power (4 Ohm @ 14.4 V, 1 kHz, THD 10 %): 4CH x 25W
MAX Power (4 Ohm): 4CH x 45W
Media Playback: MP3 / MP4 / AAC / FLAC / Xvid
Device Ports
USB (Rear) Playback Formats: CPAA & Media
USB2 (Rear) USB Media / Charging - Voltage/Amps: 5V/1.5A
USB MAX Capability: FAT32_32GB
Aux Inputs / Outputs:
Rear A/V Input (RCA Type - 3pcs): Yes
Reverse Camera Input: Yes (720P AHD Compatible)
Second Camera Input: Yes (720P AHD Compatible)
Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
Bluetooth:
Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)
Bluetooth Version: V4.2+EDR
Microphone: External Microphone
ID3 Tag/Information (Artist, Album, Song): Yes
HFP Profile (1.2, 1.4 or HD Voice 1.6): HFP 1.6
Tuner:
AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)
FM Frequency Span (MHz): 87.5-108.0MHz (0.05MHz Step)
AM Frequency Span (KHz): 529-1629KHz (9KHz Step)
RDS: Yes
FM Antenna Connector Impedance: 50 Ohm
FM Tuner Connector: Motorola
RCA Preamp Outputs:
RCA Preamp Output: 2-Pair (Front / Rear)
Subwoofer RCA Output: Yes
Subwoofer Level Control: Yes
Preamp Voltage (1.2,2,4,5,6): 4V p-p
Tone Control:
8 Band: 8 Band (50/200/400/800/1K/3K/7K/15K)
Loudness: Yes
LPF - Frequencies (Sub): Yes
8 Preset EQs: Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft
Other Features:
Steering Wheel Control: Yes, with Aerpro SWC Adaptor
OSD Language: English
LED Colour (Buttons / Keys): White
Accessories:
Power Harness: Yes with ISO
AV-In Cable (RCA with Audio L/R, Video In): Yes
Reverse Camera Input: Yes
4.2CH Audio Out Cable: Yes
External Microphone: Included
Vehicle-Specific Installation Kit Specifications:
Inclusions:
Facia Kit (Gloss Black)
Steering Wheel Control Interface
Universal Patch Lead
AHD Camera Specifications:
Inclusions:
720P AHD Surface Mount Camera (wired)
6m of Video Cable (RCA) with in-line Reverse Trigger
Mount Type: Surface Mount
Camera Type: Front, Rear Or Reverse
Image Sensor: Sony 225, 1/3 CMOS AHD
Lens Angle 150 Degree
Vehicle Compatibility:
Subaru Forester SJ (2015 - 2018 )
Subaru Impreza GJ (2015 - 2016)
Subaru Levorg VM (2016 - 2020)
Subaru WRX (2015 - 2021)
Subaru XV GP (2016 - 2017)
Kit Includes:
Aerpro AM7X 7" Multimedia Receiver With Wireless Carplay & Android Auto
Vehicle-Specific Installation Kit
720P AHD Surface Mount Camera
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Frankies BrandBeast's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Frankies BrandBeast dealer today!
Complete the Installation & Retain Important Features Such as Steering Wheel Controls!
7" Multimedia Receiver Upgrade SolutionThe Aerpro AM8529K package offers a comprehensive head unit upgrade solution that includes an Aerpro AM7X Double DIN 7" Mechless AV Receiver, a Vehicle Specific Installation Kit and a 720P AHD universal reverse camera. Designed specifically for Mercedes Sprinter 2007-2018 vehicles, this package comes with all the necessary parts to complete the installation and retain important features such as steering wheel controls.
Aerpro AM7X 7" Multimedia Receiver With Wireless CarPlay & Android AutoThe Aerpro AM7X Multimedia Receiver with Wireless Apple CarPlay and Android Auto features a large 7" capacitive touch screen display. The built-in Bluetooth enables hands-free phone calls and wireless audio streaming and the included external microphone provides crystal clear communications. It has a rear USB input which works with Apple CarPlay and Android Auto, as well as a built in AM/FM tuner with RDS and presets. Sound quality is superb with a built in 45W x 4 amplifier, 8 band graphic EQ and time alignment capabilities for precise sound adjustment. If more sound is desired, an amplifier can be added to the system via the 4V/5CH RCA preouts (front + rear + subwoofer). The unit is OEM steering wheel remote ready and has dual reverse camera inputs (720P AHD compatible).
Vehicle-Specific Installation KitThe Aerpro Vehicle Specific Installation Kit is designed to provide a complete solution for upgrading the head unit in Mercedes Sprinter 2007-2018 vehicles. The kit contains all necessary components for a successful double din installation, including a black facia kit, plastic mounting brackets, steering wheel control interface, antenna adapter and universal SWC patch lead.
720P AHD Surface Mount CameraThe Aerpro 720P AHD Surface Mount Camera produces high definition picture quality. The camera can be used as a front, rear or reverse camera. It features a 150 degree field of view, optional parking guidelines and is IP67 rated. The camera is designed to mount on a flat surface and has an adjustable bracket to enable angle adjustment.
Important Information:
Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
Features:
Includes all the parts required to complete the installation
Retains important vehicle features including steering wheel controls when applicable
7" Capacitive touch display
Works with Apple CarPlay (wireless and wired)
Supports Android Auto (wireless and wired)
Built-in Bluetooth (A2DP, AVRCP, HFP, PBAP)
AM / FM Tuner with RDS & presets (18FM/12AM)
Dual rear USB inputs (1.5A + 1.5A max charging)
Dual camera input with 1 Aerpro 720P AHD Camera included
Rear A/V input (RCA)
4V / 6CH RCA Preout
MP3 / AAC / FLAC / MPEG 1,2,4 Media formats
8 Band graphic EQ
8 EQ Presets
Subwoofer level control
45W x 4 Max built-in amplifier
Shallow 2-DIN chassis mounting design
External microphone included
Aerpro AM7X Specifications:
LCD Display:Size: 7"Resolution: 1024x600Touch Screen: Capacitive (G+G)
System Specifications:OS System / CPU: Linux 3.4.5 / SPHE8368URAM / Flash Memory: 128MB / 256MB
DIN Size: 2 DIN Short Body
Power Output:Rated Power (4 Ohm @ 14.4 V, 1 kHz, THD 10 %): 4CH x 25WMAX Power (4 Ohm): 4CH x 45W
Media Playback: MP3 / MP4 / AAC / FLAC / Xvid
Device Ports:USB (Rear) Playback Formats: CPAA & MediaUSB2 (Rear) USB Media / Charging - Voltage/Amps: 5V/1.5AUSB MAX Capability: FAT32_32GB
Aux Inputs / Outputs:Rear A/V Input (RCA Type - 3pcs): YesReverse Camera Input: Yes (720P AHD Compatible)Second Camera Input: Yes (720P AHD Compatible)
Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
Bluetooth:Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)Bluetooth Version: V4.2+EDRMicrophone: Built-in & External MicrophoneID3 Tag/Information (Artist, Album, Song): YesHFP Profile (1.2, 1.4 or HD Voice 1.6): HFP 1.6
Tuner:AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)FM Frequency Span (MHz): 87.5-108.0MHz (0.05MHz Step)AM Frequency Span (KHz): 529-1629KHz (9KHz Step)RDS: YesFM Antenna Connector Impedance: 50 OhmFM Tuner Connector: Motorola
RCA Preamp Outputs:RCA Preamp Output: 2-Pair (Front / Rear)Subwoofer RCA Output: YesSubwoofer Level Control: YesPreamp Voltage (1.2,2,4,5,6): 4V p-p
Tone Control:8 Band: 8 Band (50/200/400/800/1K/3K/7K/15K)Loudness: YesLPF - Frequencies (Sub): Yes8 Preset EQs: Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft
Other Features:Steering Wheel Control: Yes, with Aerpro SWC AdaptorOSD Language: EnglishLED Colour (Buttons / Keys): White
Accessories:Power Harness: Yes with ISOAV-In Cable (RCA with Audio L/R, Video In): YesReverse Camera Input: Yes4.2CH Audio Out Cable: YesExternal Microphone: Included
Vehicle-Specific Installation Kit Inclusions:
Facia Kit (Black)
Steering Wheel Control Interface
Antenna Adapters
Universal Patch Lead
AHD Camera Specifications:
Inclusions:720P AHD Surface Mount Camera (wired)6M of Video Cable (RCA) With In-Line Reverse Trigger
Mount Type: Surface Mount
Camera Type: Front, Rear Or Reverse
Image Sensor: Sony 225, 1/3 CMOS AHD
Lens Angle 150 Degree
Aerpro AM8529K Vehicle Compatibility:
Mercedes Sprinter (2007 - 2018)
Aerpro AM8529K Kit Inclusions:
Aerpro AM7X 7" Multimedia Receiver With Wireless CarPlay & Android Auto
Vehicle-Specific Installation Kit
720P AHD Surface Mount Camera
Legendary Products & Support From Authorized Dealers
When you choose Aerpro, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Aerpro dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Aerpro's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Aerpro dealer today!
Complete the Installation & Retain Important Features Such as Steering Wheel Controls!
7" Multimedia Receiver Upgrade SolutionThe Aerpro AM8577K package offers a comprehensive head unit upgrade solution that includes an Aerpro AM7X Double DIN 7" Mechless AV Receiver, a Vehicle Specific Installation Kit and a 720P AHD universal reverse camera. Designed specifically for Hyundai i30 GD (2012-2017) vehicles without factory navigation, this package comes with all the necessary parts to complete the installation and retain important features such as steering wheel controls.
Aerpro AM7X 7" Multimedia Receiver With Wireless CarPlay & Android AutoThe Aerpro AM7X Multimedia Receiver with Wireless Apple CarPlay and Android Auto features a large 7" capacitive touch screen display. The built-in Bluetooth enables hands-free phone calls and wireless audio streaming and the included external microphone provides crystal clear communications. It has a rear USB input which works with Apple CarPlay and Android Auto, as well as a built in AM/FM tuner with RDS and presets. Sound quality is superb with a built in 45W x 4 amplifier, 8 band graphic EQ and time alignment capabilities for precise sound adjustment. If more sound is desired, an amplifier can be added to the system via the 4V/5CH RCA preouts (front + rear + subwoofer). The unit is OEM steering wheel remote ready and has dual reverse camera inputs (720P AHD compatible).
Vehicle-Specific Installation KitThe Aerpro Vehicle Specific Installation Kit is designed to provide a complete solution for upgrading the head unit in Hyundai i30 GD (2012-2017) vehicles without factory navigation vehicles. The kit contains all necessary components for a successful double din installation, including a piano black facia kit, plastic mounting brackets, steering wheel control interface, USB retention harness, antenna adapter and universal SWC patch lead.
720P AHD Surface Mount CameraThe Aerpro 720P AHD Surface Mount Camera produces high definition picture quality. The camera can be used as a front, rear or reverse camera. It features a 150 degree field of view, optional parking guidelines and is IP67 rated. The camera is designed to mount on a flat surface and has an adjustable bracket to enable angle adjustment.
Important Information:
Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
Not suitable for vehicles with factory navigation.
Features:
Includes all the parts required to complete the installation
Retains important vehicle features including steering wheel controls, USB, and reverse camera when applicable
7" Capacitive touch display
Works with Apple CarPlay (wireless and wired)
Supports Android Auto (wireless and wired)
Built-in Bluetooth (A2DP, AVRCP, HFP, PBAP)
AM / FM Tuner with RDS & presets (18FM/12AM)
Dual rear USB inputs (1.5A + 1.5A max charging)
Dual camera input with 1 Aerpro 720P AHD Camera included
Rear A/V input (RCA)
4V / 6CH RCA Preout
MP3 / AAC / FLAC / MPEG 1,2,4 Media formats
8 Band graphic EQ
8 EQ Presets
Subwoofer level control
45W x 4 Max built-in amplifier
Shallow 2-DIN chassis mounting design
External microphone included
Specifications:
LCD Display:Size: 7"Resolution: 1024x600Touch Screen: Capacitive (G+G)
System Specifications:OS System / CPU: Linux 3.4.5 / SPHE8368URAM / Flash Memory: 128MB / 256MB
DIN Size: 2 DIN Short Body
Power Output:Rated Power (4 Ohm @ 14.4 V, 1 kHz, THD 10 %): 4CH x 25WMAX Power (4 Ohm): 4CH x 45W
Media Playback: MP3 / MP4 / AAC / FLAC / Xvid
Device Ports:USB (Rear) Playback Formats: CPAA & MediaUSB2 (Rear) USB Media / Charging - Voltage/Amps: 5V/1.5AUSB MAX Capability: FAT32_32GB
Aux Inputs / Outputs:Rear A/V Input (RCA Type - 3pcs): YesReverse Camera Input: Yes (720P AHD Compatible)Second Camera Input: Yes (720P AHD Compatible)
Smartphone Connectivity: CarPlay & Android Auto (Wireless and Wired)
Bluetooth:Bluetooth Built-In: Yes (A2DP, AVRCP, HFP, PBAP)Bluetooth Version: V4.2+EDRMicrophone: Built-in & External MicrophoneID3 Tag/Information (Artist, Album, Song): YesHFP Profile (1.2, 1.4 or HD Voice 1.6): HFP 1.6
Tuner:AM/FM (# of Presets): AM 12 (6X2) / FM 18 (6X3)FM Frequency Span (MHz): 87.5-108.0MHz (0.05MHz Step)AM Frequency Span (KHz): 529-1629KHz (9KHz Step)RDS: YesFM Antenna Connector Impedance: 50 OhmFM Tuner Connector: Motorola
RCA Preamp Outputs:RCA Preamp Output: 2-Pair (Front / Rear)Subwoofer RCA Output: YesSubwoofer Level Control: YesPreamp Voltage (1.2,2,4,5,6): 4V p-p
Tone Control:8 Band: 8 Band (50/200/400/800/1K/3K/7K/15K)Loudness: YesLPF - Frequencies (Sub): Yes8 Preset EQs: Default, Custom, Classic, Rock, Jazz, Electric, Pop, Soft
Other Features:Steering Wheel Control: Yes, with Aerpro SWC AdaptorOSD Language: EnglishLED Colour (Buttons / Keys): White
Accessories:Power Harness: Yes with ISOAV-In Cable (RCA with Audio L/R, Video In): YesReverse Camera Input: Yes4.2CH Audio Out Cable: YesExternal Microphone: Included
Vehicle-Specific Installation Kit Inclusions:
Facia Kit (Piano Black)
Steering Wheel Control Interface
USB Retention harness
Antenna Adapter
Universal Patch Lead
AHD Camera Specifications:
Inclusions:720P AHD Surface Mount Camera (wired)6M of Video Cable (RCA) With In-Line Reverse Trigger
Mount Type: Surface Mount
Camera Type: Front, Rear Or Reverse
Image Sensor: Sony 225, 1/3 CMOS AHD
Lens Angle 150 Degree
Aerpro AM8577K Vehicle Compatibility:
Hyundai i30 2012 - 2017 GD
Aerpro AM8577K Kit Inclusions:
Aerpro AM7X 7" Multimedia Receiver With Wireless CarPlay & Android Auto
Vehicle-Specific Installation Kit
720P AHD Surface Mount Camera
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Legendary Products & Support From Authorized Dealers
When you choose Aerpro, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Aerpro dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Aerpro dealer today!
Legendary Products & Support From Authorized Dealers
When you choose Aerpro, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Aerpro dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Aerpro's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Aerpro dealer today!
