OEX ACX0707 Australian Made 3mm Single Core Automotive Cable Orange 30m Roll OFHC Copper 10A V90 The OEX ACX0707 is a 3mm single core automotive cable in orange, supplied on a 30m roll. Manufactured in Australia from 99.99% oxygen free high conductivity (OFHC) copper, it features a 1.13mm² conductor cross-section and a 10A continuous rating at 30°C, suited to higher-current accessory circuits, lighting runs and general automotive wiring. The orange PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Product overview The ACX0707 is the orange 30m variant in the OEX 3mm single core automotive cable range, sharing the same conductor specification and insulation rating as the other colours in the range. Orange cable is used in automotive and trailer wiring as an additional circuit colour for complex multi-wire harness builds and trailer looms where primary and secondary colours are already allocated, providing further differentiation in installations where a broad colour palette is needed to clearly identify each circuit. At 1.13mm² (17AWG) with a 10A continuous rating, the ACX0707 handles higher-current circuits where the 2mm 5A-rated cable would be undersized. The 16-strand conductor construction provides flexibility for routing through tight spaces and around bends. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C for underbonnet and outdoor-exposed installations. The 30m roll suits workshop jobs and multi-circuit installations without the bulk of a full-length trade roll. Features and benefits 99.99% OFHC copper conductor: Oxygen free high conductivity copper minimises resistance and signal loss across the cable run, maintaining reliable electrical performance in automotive and marine applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. Orange colour coding: Orange provides an additional circuit colour for complex multi-wire harness builds and trailer looms where primary and secondary colours are already allocated, supporting clear circuit differentiation across all wires in the installation. 10A rated at 30°C: Higher current capacity than the 2mm range, suited to lighting circuits, relay feeds, switch wiring and higher-draw accessory circuits in 12V and 24V systems. UV stabilised PVC insulation: Resists degradation in sun-exposed and underbonnet environments. V90 temperature rating: PVC insulation rated for continuous operation at up to 90°C, the standard automotive-grade insulation specification in Australia. 16-strand construction: The 16-strand conductor provides flexibility and resistance to fatigue during installation and in service. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. CAN bus compatible: Meets the signal integrity requirements for use in modern vehicle communication network environments. 30m roll: Workshop-friendly length for multi-circuit jobs without the bulk of a full-length trade roll. Technical specs Specification Detail SKU ACX0707 Brand OEX Cable Type Single Core Automotive Industry Known Size 3mm Conductor Cross Section 1.13mm² Gauge 17AWG Conductor Strands 16 Strand Diameter 0.32mm Conductor Material 99.99% OFHC Copper Amp Rating 10A at 30°C Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Orange Length 30m Weight 0.42kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 30m roll Frequently asked questions What is the difference between the 3mm and 2mm OEX automotive cable? The 3mm cable has a larger conductor cross-section (1.13mm² vs 0.5mm²), a higher amp rating (10A vs 5A at 30°C) and a higher voltage rating (110V vs 100V). It is suited to circuits drawing more current than the 2mm range can safely handle, including lighting circuits, relay feeds and higher-draw accessories. What is the amp rating for this cable? This cable is rated at 10A continuous at 30°C. Ampacity decreases as ambient temperature rises, so applications in high-heat environments such as underbonnet installations should be assessed against the expected operating temperature before use. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for underbonnet and outdoor-exposed installation positions. What does AS/NZS 3808:2000 compliance mean? AS/NZS 3808:2000 is the Australian and New Zealand standard covering insulated conductors and cables for internal wiring of equipment. Compliance confirms the cable meets defined requirements for conductor construction, insulation properties and performance. Is this cable available in other colours or lengths? OEX produces single core automotive cable in a range of colours and roll lengths across both the 2mm and 3mm ranges. Contact us for available colour and length options to suit your specific wiring application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0811 Australian Made 6mm Twin Core Sheathed Automotive Cable Red and Black with Black Outer Sheath 30m Roll OFHC Copper 30A V90 The OEX ACX0811 is a 6mm twin core sheathed automotive cable supplied on a 30m roll. Red and black conductors are enclosed in a common black outer sheath, providing both polarity identification and an additional layer of mechanical and UV protection over a standard figure 8 configuration. At 30A per conductor, this is the highest-rated cable in the OEX sheathed twin core range. Each conductor has a 4.59mm² OFHC copper cross-section with 65-strand construction for flexibility despite the large gauge. The PVC insulation and sheath are UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Covered by a one year warranty. Product overview The ACX0811 is the 6mm variant in the OEX twin core sheathed automotive cable range, stepping up significantly from the 4mm ACX0808 with a larger 4.59mm² conductor cross-section and a 30A continuous rating per conductor. This rating makes the ACX0811 suited to demanding two-wire applications where both positive and negative need to travel together with mechanical and UV protection, including winch and recovery equipment power and return feeds, dual battery and auxiliary battery wiring runs, high-current relay and accessory circuits, and trailer and caravan main supply feeds. The common black outer sheath encloses both conductors and provides protection against abrasion, UV and moisture in exposed installations. The 65-strand construction provides excellent flexibility for routing through tight spaces and around bends despite the larger 6mm gauge, with significantly more strands than the 26-strand 4mm cable. The UV stabilised V90 PVC insulation and sheath handle continuous operating temperatures up to 90°C for underbonnet and outdoor-exposed installations. The 30m roll suits workshop jobs and demanding single-vehicle installations without the bulk of a full-length trade roll. Features and benefits Sheathed twin core construction: Red and black conductors enclosed in a black outer sheath for added mechanical and UV protection and a cleaner finished appearance, suited to exposed runs and locations requiring extra abrasion or weather resistance. Red and black conductors: Conventional polarity colouring for straightforward positive and negative identification without additional marking or tape. OFHC copper conductors: Oxygen free high conductivity copper minimises resistance across the cable run, maintaining reliable electrical performance in high-current automotive and marine applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. 30A rated at 30°C per conductor: The highest rating in the OEX sheathed twin core range, suited to winch feeds, dual battery runs, high-current relay circuits and heavy accessory wiring in 12V and 24V systems drawing up to 30A per conductor. Current carrying capacity reduces at higher ambient temperatures. UV stabilised PVC insulation and sheath: Resists degradation in sun-exposed and outdoor environments, extending the service life of the cable in exposed installation positions. V90 temperature rating (90°C): Insulation and sheath rated for continuous operation at up to 90°C, the standard automotive-grade insulation specification in Australia. 65-strand construction: The 65-strand conductor provides excellent flexibility and resistance to fatigue during installation and in service, maintaining good routing flexibility despite the larger 6mm cable gauge. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. 30m roll: Workshop-friendly length for multi-circuit jobs and demanding single-vehicle installations without the bulk of a full-length trade roll. Technical specs Specification Detail SKU ACX0811 Brand OEX Cable Type Twin Core, Sheathed Industry Known Size 6mm Conductor Cross Section 4.59mm² per conductor Gauge 11AWG Conductor Strands 65 Strand Diameter 0.3mm Conductor Material OFHC Copper Amp Rating 30A at 30°C per conductor Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Conductor Colours Red and black Sheath Colour Black Length 30m Weight 3.77kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 30m roll Frequently asked questions What is the difference between sheathed twin core and figure 8 twin core cable? A sheathed twin core cable encloses two separately insulated conductors inside a common outer sheath, providing an additional layer of mechanical and UV protection. A figure 8 cable bonds two conductors side by side without a separate outer sheath. Sheathed cable is better suited to exposed runs and locations requiring extra abrasion or weather resistance. How does the ACX0811 compare to the ACX0808 and ACX0806? All three are twin core sheathed cables with the same construction and sheath colour. The ACX0806 uses 3mm conductors at 1.13mm² and 10A per conductor. The ACX0808 uses 4mm conductors at 1.84mm² and 15A per conductor. The ACX0811 uses 6mm conductors at 4.59mm² and 30A per conductor, suited to the highest-current two-wire applications including winch feeds and dual battery runs. How do I tell which conductor is positive and which is negative? The red conductor is positive and the black conductor is negative or return, following standard automotive wiring colour convention. What is the amp rating per conductor? Each conductor is rated at 30A continuous at 30°C. Ampacity decreases as ambient temperature rises, so applications in high-heat environments such as underbonnet installations should be assessed against the expected operating temperature before use. Is this cable available in other sizes or lengths? OEX produces twin core sheathed and figure 8 cable in a range of sizes and roll lengths. Contact us for available size and length options to suit your wiring application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0903 Australian Made 6 B&S Single Core Battery Cable Red 30m Roll OFHC Copper 13.36mm² V90 The OEX ACX0903 is a 6 B&S single core battery cable in red, supplied on a 30m roll. With a 13.36mm² OFHC copper conductor across 192 strands, this cable is designed for demanding high-current positive supply applications including heavy battery interconnects, starter motor wiring and main supply runs where low resistance and high current capacity are required. The red insulation colour suits positive supply runs in conventional automotive wiring colour coding. The PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Covered by a one year warranty. Product overview The ACX0903 is the red variant of the OEX 6 B&S single core battery cable range, sharing the same conductor specification and insulation rating as the black ACX0902. Red is the conventional positive wiring colour in automotive and marine electrical installations, making the ACX0903 the natural choice for battery positive supply cables, dual battery main positive feeds, starter motor and alternator positive leads and winch power cables where colour convention supports circuit identification. At 13.36mm² with a 192-strand OFHC copper conductor, the ACX0903 provides significantly lower resistance and higher current-carrying capacity than the 8 B&S range at 7.91mm². This makes it suited to longer battery cable runs and circuits with higher current demand where minimising voltage drop is critical. The 192-strand construction provides exceptional flexibility for routing through tight engine bay and battery compartment spaces. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C for battery and engine bay installations. The 30m roll suits workshop jobs and single-vehicle installations without the bulk of a full-length trade roll. Always verify the required cable size with a licensed auto electrician for your specific application, current load and run length. Features and benefits 6 B&S gauge battery cable: Larger battery cable sizing suited to demanding high-current 12V and 24V positive supply applications where the 8 B&S range would be undersized. Red colour coding for positive supply runs: Red is the conventional positive wiring colour in automotive and marine electrical installations, assisting with circuit identification and reducing wiring errors in high-current battery supply circuits. 13.36mm² conductor cross-section: Significantly larger than the 8 B&S (7.91mm²), providing reduced resistance and higher current-carrying capacity for longer runs and more demanding positive supply circuits. 192-strand construction: Exceptional flexibility for routing through tight engine bay and battery compartment spaces despite the larger cable gauge. OFHC copper conductor: Oxygen free high conductivity copper minimises resistance for efficient current transfer across demanding battery and positive supply circuit applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. UV stabilised PVC insulation: Resists degradation in sun-exposed and engine bay environments. V90 temperature rating (90°C): PVC insulation rated for continuous operation at up to 90°C, suited to battery and engine bay installation environments. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. 30m roll: Workshop-friendly length for single-vehicle and multi-circuit jobs without the bulk of a full-length trade roll. Technical specs Specification Detail SKU ACX0903 Brand OEX Cable Type Single Core Battery Cable Gauge 6 B&S Conductor Cross Section 13.36mm² Conductor Strands 192 Strand Diameter 0.3mm Conductor Material OFHC Copper Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Red Length 30m Weight 4.44kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 30m roll Frequently asked questions What is B&S gauge and how does it differ from AWG or metric sizing? B&S (Brown and Sharpe) is a wire gauge system commonly used in Australian battery and heavy-duty automotive cable. 6 B&S is equivalent to approximately 6 AWG and corresponds to a conductor cross-section of around 13.36mm². It is a standard sizing reference used by Australian auto electricians and suppliers for battery and starter cables. How does 6 B&S compare to 8 B&S? 6 B&S has a significantly larger conductor cross-section (13.36mm² vs 7.91mm²) and more strands (192 vs 112), giving it lower resistance and higher current-carrying capacity. Select 6 B&S for longer runs or circuits with higher current demand than 8 B&S can comfortably handle. Always verify the correct cable size with a licensed auto electrician for your specific application. How does the ACX0903 differ from the ACX0902? Both are 6 B&S single core battery cables with identical conductor and insulation specifications. The ACX0902 is black and suits earth and negative runs. The ACX0903 is red and suits positive supply runs. Select based on the polarity convention of your installation. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for battery and engine bay installation positions. Is this cable available in other sizes or colours? OEX produces battery cable in a range of B&S sizes and colours. Contact us for available size and colour options to suit your specific application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0902 Australian Made 6 B&S Single Core Battery Cable Black 30m Roll OFHC Copper 13.36mm² V90 The OEX ACX0902 is a 6 B&S single core battery cable in black, supplied on a 30m roll. With a 13.36mm² OFHC copper conductor across 192 strands, this cable steps up from the 8 B&S range and is designed for demanding high-current applications including heavy battery interconnects, starter motor wiring and main supply runs where low resistance and high current capacity are required. The PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Covered by a one year warranty. Product overview At 13.36mm² with a 192-strand OFHC copper conductor, the ACX0902 provides significantly lower resistance and higher current-carrying capacity than the 8 B&S range at 7.91mm². This makes it suited to longer battery cable runs, circuits with higher current demand, and applications where minimising voltage drop across the cable is critical. Common applications include battery interconnect and main supply cables, starter motor and alternator wiring, dual battery system main feeds, winch and recovery equipment power cables and heavy-duty accessory wiring requiring a large conductor cross-section. The 192-strand construction provides exceptional flexibility for routing through tight engine bay and battery compartment spaces despite the larger gauge. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C for battery and engine bay installations. The voltage rating of up to 120V is slightly wider than the standard automotive cable range. The 30m roll suits workshop jobs and single-vehicle installations without the bulk of a full-length trade roll. Always verify the required cable size with a licensed auto electrician for your specific application, current load and run length. Features and benefits 6 B&S gauge battery cable: Larger battery cable sizing suited to demanding high-current 12V and 24V applications where the 8 B&S range would be undersized. 13.36mm² conductor cross-section: Significantly larger than the 8 B&S (7.91mm²), providing reduced resistance and higher current-carrying capacity for longer runs and more demanding circuits. 192-strand construction: Exceptional flexibility for routing through tight engine bay and battery compartment spaces despite the larger cable gauge, with more strands than the 8 B&S range for improved handling. OFHC copper conductor: Oxygen free high conductivity copper minimises resistance for efficient current transfer across demanding battery and supply circuit applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. UV stabilised PVC insulation: Resists degradation in sun-exposed and engine bay environments. V90 temperature rating (90°C): PVC insulation rated for continuous operation at up to 90°C, suited to battery and engine bay installation environments. Up to 120V voltage rating: Slightly wider voltage rating than the standard automotive cable range. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. 30m roll: Workshop-friendly length for single-vehicle and multi-circuit jobs without the bulk of a full-length trade roll. Technical specs Specification Detail SKU ACX0902 Brand OEX Cable Type Single Core Battery Cable Gauge 6 B&S Conductor Cross Section 13.36mm² Conductor Strands 192 Strand Diameter 0.3mm Conductor Material OFHC Copper Voltage Rating Up to 120V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Black Length 30m Weight 4.44kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 30m roll Frequently asked questions What is B&S gauge and how does it differ from AWG or metric sizing? B&S (Brown and Sharpe) is a wire gauge system commonly used in Australian battery and heavy-duty automotive cable. 6 B&S is equivalent to approximately 6 AWG and corresponds to a conductor cross-section of around 13.36mm². It is a standard sizing reference used by Australian auto electricians and suppliers for battery and starter cables. How does 6 B&S compare to 8 B&S? 6 B&S has a significantly larger conductor cross-section (13.36mm² vs 7.91mm²) and more strands (192 vs 112), giving it lower resistance and higher current-carrying capacity. Select 6 B&S for longer runs or circuits with higher current demand than 8 B&S can comfortably handle. Always verify the correct cable size with a licensed auto electrician for your specific application. Is a 30m roll sufficient for a single-vehicle installation? The 30m roll suits most single-vehicle heavy-duty battery cable installations including dual battery runs, winch feeds and starter motor wiring. For fleet operations or multiple installations from a single roll, the ACX0902L 100m roll version is available. Contact us for details. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for battery and engine bay installation positions. Is this cable available in other sizes or colours? OEX produces battery cable in a range of B&S sizes and colours. Contact us for available size and colour options to suit your specific application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0708 Australian Made 3mm Single Core Automotive Cable Pink 30m Roll OFHC Copper 10A V90 The OEX ACX0708 is a 3mm single core automotive cable in pink, supplied on a 30m roll. Manufactured in Australia from 99.99% oxygen free high conductivity (OFHC) copper, it features a 1.13mm² conductor cross-section and a 10A continuous rating at 30°C, suited to higher-current accessory circuits, lighting runs and general automotive wiring. The pink PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Product overview The ACX0708 is the pink 30m variant in the OEX 3mm single core automotive cable range, sharing the same conductor specification and insulation rating as the other colours in the range. Pink cable is used in automotive and trailer wiring installations where an expanded colour palette is needed to differentiate circuits in complex multi-wire harness builds and custom vehicle electrical systems where the full standard colour set is already in use. It provides a distinctive identifier in installations requiring a broad range of circuit colours at the 3mm gauge. At 1.13mm² (17AWG) with a 10A continuous rating, the ACX0708 handles higher-current circuits where the 2mm 5A-rated cable would be undersized. The 16-strand conductor construction provides flexibility for routing through tight spaces and around bends. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C for underbonnet and outdoor-exposed installations. The 30m roll suits workshop jobs and multi-circuit installations without the bulk of a full-length trade roll. Features and benefits 99.99% OFHC copper conductor: Oxygen free high conductivity copper minimises resistance and signal loss across the cable run, maintaining reliable electrical performance in automotive and marine applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. Pink colour coding: Pink provides a distinctive additional circuit identifier for complex multi-wire harness builds and custom electrical installations where the standard colour set is already allocated, supporting clear differentiation across all circuits. 10A rated at 30°C: Higher current capacity than the 2mm range, suited to lighting circuits, relay feeds, switch wiring and higher-draw accessory circuits in 12V and 24V systems. UV stabilised PVC insulation: Resists degradation in sun-exposed and underbonnet environments. V90 temperature rating: PVC insulation rated for continuous operation at up to 90°C, the standard automotive-grade insulation specification in Australia. 16-strand construction: The 16-strand conductor provides flexibility and resistance to fatigue during installation and in service. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. CAN bus compatible: Meets the signal integrity requirements for use in modern vehicle communication network environments. 30m roll: Workshop-friendly length for multi-circuit jobs without the bulk of a full-length trade roll. Technical specs Specification Detail SKU ACX0708 Brand OEX Cable Type Single Core Automotive Industry Known Size 3mm Conductor Cross Section 1.13mm² Gauge 17AWG Conductor Strands 16 Strand Diameter 0.32mm Conductor Material 99.99% OFHC Copper Amp Rating 10A at 30°C Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Pink Length 30m Weight 0.42kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 30m roll Frequently asked questions What is the difference between the 3mm and 2mm OEX automotive cable? The 3mm cable has a larger conductor cross-section (1.13mm² vs 0.5mm²), a higher amp rating (10A vs 5A at 30°C) and a higher voltage rating (110V vs 100V). It is suited to circuits drawing more current than the 2mm range can safely handle, including lighting circuits, relay feeds and higher-draw accessories. What is the amp rating for this cable? This cable is rated at 10A continuous at 30°C. Ampacity decreases as ambient temperature rises, so applications in high-heat environments such as underbonnet installations should be assessed against the expected operating temperature before use. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for underbonnet and outdoor-exposed installation positions. What does AS/NZS 3808:2000 compliance mean? AS/NZS 3808:2000 is the Australian and New Zealand standard covering insulated conductors and cables for internal wiring of equipment. Compliance confirms the cable meets defined requirements for conductor construction, insulation properties and performance. Is this cable available in other colours or lengths? OEX produces single core automotive cable in a range of colours and roll lengths across both the 2mm and 3mm ranges. Contact us for available colour and length options to suit your specific wiring application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0928 Australian Made 6 B&S Twin Core Battery Cable Red and Black with Black Outer Sheath 30m Roll OFHC Copper 13.36mm² V90 The OEX ACX0928 is a 6 B&S twin core battery cable with a black outer sheath, supplied on a 30m roll. Red and black conductors each with a 13.36mm² OFHC copper cross-section across 192 strands are enclosed in a common black outer sheath, combining the higher current capacity of 6 B&S battery cable with the convenience of a single protected two-wire run. Rated to V90 (90°C) with UV stabilised PVC insulation and sheath. Compliant with AS/NZS 3808:2000 and RoHS. Covered by a one year warranty. Product overview The ACX0928 steps up from the 8 B&S ACX0927 twin core battery cable with a larger 13.36mm² conductor cross-section and 192 strands per conductor, providing lower resistance and higher current-carrying capacity for longer runs and more demanding dual battery systems, high-capacity winch installations and applications where positive and negative heavy-current feeds need to travel together with protection. The shared black outer sheath routes both conductors in a single neat run, reducing cable management complexity and providing additional mechanical and UV protection compared to two separate single-core cables. At 13.36mm² per conductor with a 192-strand OFHC copper construction, each core provides the high-current capacity of the 6 B&S single core range. The UV stabilised V90 PVC insulation and sheath handle continuous operating temperatures up to 90°C for battery and engine bay installations. The 30m roll suits workshop jobs and single-vehicle heavy-duty installations. Always verify the required cable size with a licensed auto electrician for your specific application, current load and run length. Features and benefits 6 B&S twin core sheathed construction: Red and black conductors in a black outer sheath for clean, protected high-current two-wire runs, combining the current capacity of 6 B&S battery cable with the installation convenience of a single cable. Red and black conductors: Conventional polarity colouring for straightforward positive and negative identification without additional marking or tape. 13.36mm² per conductor: Larger cross-section than the 8 B&S ACX0927 (7.91mm²), providing lower resistance and higher current-carrying capacity for longer runs and more demanding high-current applications. 192-strand construction per conductor: Excellent flexibility for routing through tight engine bay and battery compartment spaces despite the larger conductor gauge. OFHC copper conductors: Oxygen free high conductivity copper minimises resistance for efficient current transfer across high-current battery and supply circuit applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. UV stabilised PVC insulation and sheath: Resists degradation in sun-exposed and engine bay environments, extending the service life of the cable in exposed installation positions. V90 temperature rating (90°C): Insulation and sheath rated for continuous operation at up to 90°C, suited to battery and engine bay installation environments. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. 30m roll: Workshop-friendly length for heavy-duty single-vehicle and multi-circuit installations. Technical specs Specification Detail SKU ACX0928 Brand OEX Cable Type Twin Core Battery Cable, Sheathed Gauge 6 B&S Conductor Cross Section 13.36mm² per conductor Conductor Strands 192 per conductor Strand Diameter 0.3mm Conductor Material OFHC Copper Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Conductor Colours Red and black Sheath Colour Black Length 30m Weight 11.25kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 30m roll Frequently asked questions What is 6 B&S gauge and how does it compare to 8 B&S? 6 B&S (Brown and Sharpe) is equivalent to approximately 6 AWG and corresponds to a conductor cross-section of around 13.36mm² per conductor. It is larger than 8 B&S (7.91mm²), delivering lower resistance and higher current-carrying capacity. Select 6 B&S for longer runs or applications with higher current demand than the 8 B&S ACX0927 can comfortably handle. What is the advantage of twin core battery cable over two separate single core cables? A twin core sheathed cable keeps positive and negative conductors together in a single protected run, resulting in a neater installation with less cable management. The shared outer sheath also provides additional mechanical and UV protection compared to two individual cables routed separately. How do I tell which conductor is positive and which is negative? The red conductor is positive and the black conductor is negative or return, following standard automotive wiring colour convention. What does AS/NZS 3808:2000 compliance mean? AS/NZS 3808:2000 is the Australian and New Zealand standard covering insulated conductors and cables for internal wiring of equipment. Compliance confirms the cable meets defined requirements for conductor construction, insulation properties and performance. Is this cable available in other sizes? OEX produces twin core battery cable in a range of B&S sizes. Contact us for available size options to suit your application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0915 Australian Made 0 B&S Single Core Battery Cable Red 10m Roll OFHC Copper 49.2mm² V90 The OEX ACX0915 is a 0 B&S single core battery cable in red, supplied on a 10m roll. With a 49.2mm² OFHC copper conductor across 696 strands, this is the largest cable in the OEX B&S battery cable range and is engineered for the most extreme high-current positive supply installations including commercial vehicle battery systems, heavy equipment starter motor feeds and high-capacity power distribution where no smaller gauge will suffice. The red insulation colour suits positive supply runs in conventional automotive wiring colour coding. The PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Covered by a one year warranty. Weighs 5.26kg. Product overview The ACX0915 is the red 10m roll variant of the OEX 0 B&S single core battery cable, sharing the same conductor specification and insulation rating as the black ACX0912 (10m) and the red ACX0914 (30m). Red is the conventional positive wiring colour in automotive and marine electrical installations, making the ACX0915 the natural choice for battery positive supply cables on heavy commercial vehicles, high-capacity starter motor and alternator positive leads and industrial and marine main positive power distribution where maximum conductor cross-section is required. At 49.2mm² with a 696-strand OFHC copper conductor, the ACX0915 delivers the lowest resistance and highest current-carrying capacity of any cable in the OEX B&S range. The 696-strand construction delivers remarkable flexibility for routing and termination in heavy commercial installation environments despite the very large gauge. The 10m roll reflects the shorter run lengths typical of heavy commercial installations where this gauge is employed most positive supply connections at this size require only a few metres per run. Always consult a qualified auto electrician or electrical engineer when specifying cable for extreme current applications. Features and benefits 0 B&S gauge the largest in the OEX battery cable range: Maximum current-carrying capacity and minimum resistance for the most extreme high-current positive supply applications in commercial and industrial wiring. Red colour coding for positive supply runs: Red is the conventional positive wiring colour in automotive and marine electrical installations, assisting with circuit identification in extreme high-current commercial battery supply circuits. 49.2mm² conductor cross-section: Significantly larger than 2 B&S (32.17mm²), providing the lowest resistance and highest current-carrying capacity of any cable in the OEX B&S range. 696-strand construction: Remarkable flexibility for a cable of this cross-section, making the ACX0915 manageable to route and terminate in heavy commercial installation environments despite the very large gauge. OFHC copper conductor: Oxygen free high conductivity copper minimises resistance for efficient current transfer across the most extreme current commercial and industrial battery and positive supply circuit applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. UV stabilised PVC insulation: Resists degradation in sun-exposed and engine bay environments. V90 temperature rating (90°C): PVC insulation rated for continuous operation at up to 90°C, suited to battery and engine bay installation environments in commercial and heavy vehicle applications. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. 10m roll: Short-run format suited to heavy commercial battery and starter motor positive supply installations where long roll lengths are not required for this gauge. Technical specs Specification Detail SKU ACX0915 Brand OEX Cable Type Single Core Battery Cable Gauge 0 B&S Conductor Cross Section 49.2mm² Conductor Strands 696 Strand Diameter 0.3mm Conductor Material OFHC Copper Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Red Length 10m Weight 5.26kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 10m roll Frequently asked questions What is 0 B&S gauge? 0 B&S (Brown and Sharpe), also referred to as 1/0 AWG, corresponds to a conductor cross-section of around 49.2mm². It is the largest size in the OEX B&S battery cable range and is used in the most demanding heavy commercial and industrial high-current applications. Always consult a qualified auto electrician or electrical engineer when specifying cable for extreme current applications. How does 0 B&S compare to 2 B&S and 4 B&S? 0 B&S has the largest conductor cross-section in the OEX B&S range at 49.2mm², compared to 2 B&S (32.17mm²) and 4 B&S (20.29mm²). It delivers the lowest resistance and highest current-carrying capacity of any cable in the range, suited to the most extreme commercial and industrial applications. What is the difference between the ACX0915, ACX0914 and ACX0912? All three are 0 B&S single core battery cables with identical conductor and insulation specifications. The ACX0912 is black on a 10m roll for earth and negative runs. The ACX0914 is red on a 30m roll for positive supply runs where trade-length supply is required. The ACX0915 is red on a 10m roll for positive supply runs where a shorter quantity is sufficient. Select based on polarity and quantity requirements. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for battery and engine bay installation positions. Is this cable available in other sizes or colours? OEX produces battery cable in a range of B&S sizes and colours. Contact us for available size and colour options to suit your specific application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0914 Australian Made 0 B&S Single Core Battery Cable Red 30m Roll OFHC Copper 49.2mm² V90 The OEX ACX0914 is a 0 B&S single core battery cable in red, supplied on a 30m roll. With a 49.2mm² OFHC copper conductor across 696 strands, this is the largest cable in the OEX B&S battery cable range and is engineered for the most extreme high-current positive supply installations including commercial vehicle battery systems, heavy equipment starter motor feeds and high-capacity power distribution where no smaller gauge will suffice. The red insulation colour suits positive supply runs in conventional automotive wiring colour coding. The PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Covered by a one year warranty. Weighs 15.78kg. Product overview The ACX0914 is the red variant of the OEX 0 B&S single core battery cable, sharing the same conductor specification and insulation rating as the black ACX0912. Red is the conventional positive wiring colour in automotive and marine electrical installations, making the ACX0914 the natural choice for battery positive supply cables on heavy commercial vehicles, high-capacity starter motor and alternator positive leads, and industrial and marine main positive power distribution where maximum conductor cross-section is required. At 49.2mm² with a 696-strand OFHC copper conductor, the ACX0914 delivers the lowest resistance and highest current-carrying capacity of any cable in the OEX B&S range, sitting above the 2 B&S (32.17mm²) and 4 B&S (20.29mm²) cables. The 696-strand construction delivers remarkable flexibility for a cable of this enormous cross-section, making it manageable to route and terminate in heavy commercial installation environments. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C. The 30m roll suits trade workshops running multiple heavy commercial installations. Always consult a qualified auto electrician or electrical engineer when specifying cable for extreme current applications. Features and benefits 0 B&S gauge — the largest in the OEX battery cable range: Maximum current-carrying capacity and minimum resistance for the most extreme high-current positive supply applications in commercial and industrial wiring where no smaller gauge is sufficient. Red colour coding for positive supply runs: Red is the conventional positive wiring colour in automotive and marine electrical installations, assisting with circuit identification in extreme high-current commercial battery supply circuits. 49.2mm² conductor cross-section: Significantly larger than 2 B&S (32.17mm²), providing the lowest resistance and highest current-carrying capacity of any cable in the OEX B&S range. 696-strand construction: Remarkable flexibility for a cable of this cross-section, making the ACX0914 manageable to route and terminate in heavy commercial installation environments despite the very large gauge. OFHC copper conductor: Oxygen free high conductivity copper minimises resistance for efficient current transfer across the most extreme current commercial and industrial battery and positive supply circuit applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. UV stabilised PVC insulation: Resists degradation in sun-exposed and engine bay environments. V90 temperature rating (90°C): PVC insulation rated for continuous operation at up to 90°C, suited to battery and engine bay installation environments in commercial and heavy vehicle applications. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. 30m roll: Trade-length supply for workshops running multiple heavy commercial installations from a single roll. Technical specs Specification Detail SKU ACX0914 Brand OEX Cable Type Single Core Battery Cable Gauge 0 B&S Conductor Cross Section 49.2mm² Conductor Strands 696 Strand Diameter 0.3mm Conductor Material OFHC Copper Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Red Length 30m Weight 15.78kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 30m roll Frequently asked questions What is 0 B&S gauge? 0 B&S (Brown and Sharpe), also referred to as 1/0 AWG, corresponds to a conductor cross-section of around 49.2mm². It is the largest size in the OEX B&S battery cable range and is used in the most demanding heavy commercial and industrial high-current applications. Always consult a qualified auto electrician or electrical engineer when specifying cable for extreme current applications. How does 0 B&S compare to 2 B&S and 4 B&S? 0 B&S has the largest conductor cross-section in the OEX B&S range at 49.2mm², compared to 2 B&S (32.17mm²) and 4 B&S (20.29mm²). It delivers the lowest resistance and highest current-carrying capacity of any cable in the range, suited to the most extreme commercial and industrial applications where the 2 B&S cable would be insufficient. How does the ACX0914 differ from the ACX0912? Both are 0 B&S single core battery cables with identical conductor and insulation specifications. The ACX0912 is black and supplied on a 10m roll suited to single heavy commercial installations. The ACX0914 is red and supplied on a 30m roll suited to trade workshops running multiple positive supply installations. Select based on polarity requirements and the quantity needed. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for battery and engine bay installation positions. Is this cable available in other sizes or colours? OEX produces battery cable in a range of B&S sizes and colours. Contact us for available size and colour options to suit your specific application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX0912 Australian Made 0 B&S Single Core Battery Cable Black 10m Roll OFHC Copper 49.2mm² V90 The OEX ACX0912 is a 0 B&S single core battery cable in black, supplied on a 10m roll. With a 49.2mm² OFHC copper conductor across 696 strands, this is the largest cable in the OEX B&S battery cable range and is engineered for the most extreme high-current installations including commercial vehicle battery systems, heavy equipment starter motor feeds and high-capacity power distribution where no smaller gauge will suffice. The PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Covered by a one year warranty. Weighs 5.26kg. Product overview At 49.2mm² with a 696-strand OFHC copper conductor, the ACX0912 sits above every other cable in the OEX B&S range, delivering the lowest resistance and highest current-carrying capacity available in the range. It is suited to the most extreme commercial and industrial high-current applications heavy commercial vehicle battery interconnect and main supply cables, high-capacity starter motor and alternator wiring, and industrial and marine main power distribution runs where the 2 B&S (32.17mm²) cable would be insufficient. The 696-strand construction delivers remarkable flexibility for a cable of this enormous cross-section, making it manageable to route and terminate in heavy commercial installation environments. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C for battery and engine bay installations. The 10m roll reflects the shorter run lengths typical of heavy commercial installations where this gauge is employed, and is priced and supplied accordingly. Always consult a qualified auto electrician or electrical engineer when specifying cable for extreme current applications. Features and benefits 0 B&S gauge — the largest in the OEX battery cable range: Maximum current-carrying capacity and minimum resistance for the most extreme high-current commercial and industrial applications where no smaller gauge in the range is sufficient. 49.2mm² conductor cross-section: Significantly larger than 2 B&S (32.17mm²), providing the lowest resistance and highest current-carrying capacity of any cable in the OEX B&S range. 696-strand construction: Remarkable flexibility for a cable of this cross-section, making the ACX0912 manageable to route and terminate in heavy commercial installation environments despite the very large gauge. OFHC copper conductor: Oxygen free high conductivity copper minimises resistance for efficient current transfer across the most extreme current commercial and industrial battery and supply circuit applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. UV stabilised PVC insulation: Resists degradation in sun-exposed and engine bay environments. V90 temperature rating (90°C): PVC insulation rated for continuous operation at up to 90°C, suited to battery and engine bay installation environments in commercial and heavy vehicle applications. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. 10m roll: Short-run format suited to heavy commercial battery and starter motor installations where long roll lengths are not required for this gauge. Technical specs Specification Detail SKU ACX0912 Brand OEX Cable Type Single Core Battery Cable Gauge 0 B&S Conductor Cross Section 49.2mm² Conductor Strands 696 Strand Diameter 0.3mm Conductor Material OFHC Copper Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Black Length 10m Weight 5.26kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 10m roll Frequently asked questions What is 0 B&S gauge? 0 B&S (Brown and Sharpe), also referred to as 1/0 AWG, corresponds to a conductor cross-section of around 49.2mm². It is the largest size in the OEX B&S battery cable range and is used in the most demanding heavy commercial and industrial high-current applications. Always consult a qualified auto electrician or electrical engineer when specifying cable for extreme current applications. How does 0 B&S compare to 2 B&S and 4 B&S? 0 B&S has the largest conductor cross-section in the OEX B&S range at 49.2mm², compared to 2 B&S (32.17mm²) and 4 B&S (20.29mm²). It delivers the lowest resistance and highest current-carrying capacity of any cable in the range, suited to the most extreme commercial and industrial applications where the 2 B&S cable would be insufficient. Why is this cable only supplied on a 10m roll? The 10m roll format reflects the shorter run lengths typical of heavy commercial battery and starter motor installations where 0 B&S is specified. At this cross-section, most installations require only a few metres per connection point, making a 10m roll the practical trade format for this gauge. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for battery and engine bay installation positions. Is this cable available in other sizes or colours? OEX produces battery cable in a range of B&S sizes and colours. Contact us for available size and colour options to suit your specific application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!
