OEX ACX0763L Australian Made 6mm Single Core Automotive Cable Red 100m Roll OFHC Copper 30A V90 The OEX ACX0763L is a 6mm single core automotive cable in red, supplied on a 100m roll. Manufactured in Australia from oxygen free high conductivity (OFHC) copper, it features a 4.59mm² conductor cross-section and a 30A continuous rating at 30°C, suited to higher-demand circuits including winch feeds, heavy accessory wiring, dual battery runs and other applications requiring substantial current-carrying capacity. The red PVC insulation is UV stabilised and rated to V90 (90°C). Compliant with AS/NZS 3808:2000 and RoHS. Product overview The ACX0763L is the red 100m roll variant in the OEX 6mm single core automotive cable range, sharing the same conductor specification and insulation rating as the black ACX0761L. Red is the conventional positive wiring colour in automotive and marine electrical installations, making the ACX0763L the natural choice for positive main feeds, winch power supplies, dual battery positive runs and heavy accessory feeds in 6mm installations where colour convention supports circuit identification. At 4.59mm² (11AWG) with a 30A continuous rating, this cable handles circuits where the 5mm 20A-rated cable would be undersized. The 65-strand conductor construction provides excellent flexibility for routing through tight spaces and around bends despite the larger gauge. The UV stabilised V90 PVC insulation handles continuous operating temperatures up to 90°C for underbonnet and outdoor-exposed installations. The 100m roll suits workshops and trade installers covering multiple jobs from a single roll. Features and benefits OFHC copper conductor: Oxygen free high conductivity copper minimises resistance and signal loss across the cable run, maintaining reliable electrical performance in high-current automotive and marine applications. Australian owned and made: Premium quality copper cable produced locally to Australian automotive wiring standards. Red colour coding: Red is the conventional positive wiring colour in automotive and marine electrical installations, assisting with circuit identification in high-current positive main feeds, dual battery runs and winch supply wiring. 30A rated at 30°C: A significant step up from the 5mm range, suited to winch feeds, dual battery runs, high-current relay circuits and heavy accessory wiring in 12V and 24V systems drawing up to 30A. UV stabilised PVC insulation: Resists degradation in sun-exposed and underbonnet environments. V90 temperature rating: PVC insulation rated for continuous operation at up to 90°C, the standard automotive-grade insulation specification in Australia. 65-strand construction: The 65-strand conductor provides excellent flexibility and resistance to fatigue during installation and in service, maintaining good routing flexibility despite the larger cable gauge. AS/NZS 3808:2000 compliant: Meets the Australian and New Zealand standard for insulated conductors and cables for internal wiring of equipment. RoHS compliant: Meets hazardous substance restrictions. 100m roll: Trade-length supply for workshops and fleet installers covering multiple jobs from a single roll. Technical specs Specification Detail SKU ACX0763L Brand OEX Cable Type Single Core Automotive Industry Known Size 6mm Conductor Cross Section 4.59mm² Gauge 11AWG Conductor Strands 65 Strand Diameter 0.32mm Conductor Material OFHC Copper Amp Rating 30A at 30°C Voltage Rating Up to 110V Insulation Type PVC Temperature Rating V90 (90°C) UV Stabilised Yes Cable Colour Red Length 100m Weight 4.9kg Compliance AS/NZS 3808:2000, RoHS Warranty One year Sold As 100m roll Frequently asked questions How does 6mm cable compare to the smaller sizes in the OEX range? The 6mm cable has a larger conductor cross-section (4.59mm²) and higher amp rating (30A at 30°C) than the 5mm (2.9mm², 20A), 4mm (1.84mm², 15A), 3mm (1.13mm², 10A) and 2mm (0.5mm², 5A) cables. Select the 6mm where circuits draw up to 30A, such as winch feeds, dual battery runs and high-draw accessory wiring that would exceed the capacity of the 5mm range. What is the amp rating for this cable? This cable is rated at 30A continuous at 30°C. Ampacity decreases as ambient temperature rises, so applications in high-heat environments such as underbonnet installations should be assessed against the expected operating temperature before use. What does V90 mean? V90 is the Australian cable insulation classification indicating the PVC insulation is rated for continuous operation at up to 90°C. It is the standard specification for automotive-grade PVC insulated cable in Australia and confirms suitability for underbonnet and outdoor-exposed installation positions. What does AS/NZS 3808:2000 compliance mean? AS/NZS 3808:2000 is the Australian and New Zealand standard covering insulated conductors and cables for internal wiring of equipment. Compliance confirms the cable meets defined requirements for conductor construction, insulation properties and performance. Is this cable available in other colours or lengths? OEX produces single core automotive cable in a range of colours and roll lengths across the 2mm, 3mm, 4mm, 5mm and 6mm ranges. Contact us for available colour and length options to suit your specific wiring application. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Axis Parking Sensor Extension Lead 5M: Parking Sensor Extension Lead 5M Axis APS5M Specifications: Suits APS series Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Achieved Through a Connection That Is Safer and More Secure Standard grey 50 Amp Anderson plug and a 12~24 volt cigarette accessory socket in a flush mount housing. Designed with a marine grade housing with fitted with a waterproof dust cap over the accessory socket. Specifications: Panel Size: 60mm Wide x 75mm High x 47.5mm Deep Mounting holes: 45mm Wide x 60mm High Terminals: 2 x Terminals supplied . Suits Cable Size: 6mm2 (6 B&S) and smaller. Screws: 4 x M4 stainless steel screws included Accessory Socket Rating: 12V DC 20A or 24V DC 15A (max) Colour: Black Packaging: Poly Bag with barcode sticker Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1980BL 12V 20A Normally Open Micro Relay Japanese Configuration 4 Pin Resistor Spike Protection IP67 Single Unit The OEX ACX1980BL is a 12V, 20A normally open micro relay with resistor spike protection, supplied as a single unit. Smaller than the standard mini relay format, the micro relay suits installations where mounting space is limited or where the vehicle's factory relay socket uses the micro relay footprint common in many Japanese-configuration vehicles. Four-terminal layout with coil connections (85 and 86) and normally open switching contacts (30 and 87) no normally closed contact. Silver tin oxide contacts and IP67 sealed housing. Covered by a one year warranty. Product overview The ACX1980BL is a micro relay physically smaller than the standard mini relay (ACX1940RBL series) and using a different terminal footprint. Micro relays are commonly found in Japanese-market vehicles and are not interchangeable with standard ISO mini relay sockets. The Japanese configuration footprint matches the relay socket used in many vehicles manufactured by Japanese brands. Always confirm the relay format required for your vehicle or application before purchasing using a micro relay in a mini relay socket or vice versa will not produce a secure connection. At 20A the ACX1980BL covers accessory and auxiliary circuit switching in applications where the smaller footprint is required. The resistor spike protection suppresses the voltage spike generated when the relay coil is de-energised, protecting ECU and control module outputs in the triggering circuit. The IP67 sealed housing provides full protection against dust and temporary water immersion. Features and benefits Micro relay format: Physically smaller than the standard mini relay, suited to tight installation spaces and Japanese vehicle configurations where the micro relay footprint is required. Japanese configuration: Terminal layout and footprint matches the relay socket used in many Japanese-brand vehicles. Not interchangeable with standard ISO mini relay sockets. 20A rating: Suited to accessory and auxiliary circuit switching up to 20A in applications requiring the micro relay format. Normally open contact: Circuit is open at rest and closes when the relay coil is energised. 4 pin configuration: Coil connections (85 and 86) and normally open switching contacts (30 and 87). No normally closed contact (87a). Resistor spike protection: Suppresses the voltage spike generated when the relay coil is de-energised, protecting ECU and control module outputs. IP67 sealed housing: Fully protected against dust and temporary water immersion, suited to underbonnet and exposed mounting positions. Silver tin oxide contacts: Reliable switching performance with excellent contact life. Single unit: For individual installations or replacements. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1980BL Brand OEX Type Micro Relay Voltage 12V Current Rating 20A Relay Action Normally Open Terminals 4 Pin Configuration Japanese Spike Protection Resistor Contact Material Silver Tin Oxide IP Rating IP67 Pack Quantity 1 Weight 0.026kg Warranty One year Sold As Single unit Frequently asked questions What is a micro relay and how does it differ from a mini relay? A micro relay is physically smaller than a standard mini relay and uses a different terminal footprint. Micro relays are commonly found in Japanese-market vehicles and are not interchangeable with mini relay sockets. Always confirm the relay format required for your vehicle or application before purchasing. What does "Japanese configuration" mean? Japanese configuration refers to the terminal layout and footprint used in many vehicles manufactured by Japanese brands. This differs from the standard ISO mini relay footprint used in European and most aftermarket applications. Confirm your vehicle's relay socket configuration before purchasing. Why does this relay have 4 terminals instead of 5? As a normally open relay there is no normally closed contact (87a), resulting in 4 terminals: 85 (coil negative), 86 (coil positive), 30 (common) and 87 (normally open). If a change over relay with both NO and NC contacts is required, a 5-terminal relay is needed. What does resistor spike protection do? When a relay coil is de-energised it generates a voltage spike that can damage sensitive electronics. A resistor across the coil terminals suppresses this spike, protecting ECU and control module outputs used to trigger the relay. Is this relay suitable for underbonnet use? Yes. The IP67 sealed housing provides full protection against dust and temporary water immersion, making it suitable for underbonnet and exposed mounting positions. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

10mm Split Corrugated Loom Tube DNA WLT1075 Manufactured from black flame retardent (UL94-V2), polypropylene copolymer, max operating temperature of 90 degrees C Flexible tubing with a split down the centre allowing easy access for entry and exit of cables. Specifications: Inner Diameter: 10.7mm Outer Diameter: 16.0mm Colour: Black Pack Length: 75 Metres Packaging: Euro Heat Sealed Poly Bag With Hang Hole. Legendary Products & Support From Authorized Dealers When you choose DNA, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized DNA dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by DNA's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized DNA dealer today!

Read more less

Parkmate Premium OEM Style 4.3'' Replacement Mirror MonDesigned For Replacing Factory Glass Mount Mirror! 4.3'' Replacement Mirror Monitor (OEM Style) This mirror features an embedded A-grade LCD monitor that captures the camera image in crystal clear viewing. The monitor automatically comes on once reverse in selected, with a Parkmate camera it will capture any blind spots in your path. The monitor also has an auto brightness control, so on bright sunny days the monitor will adjust to full brightness to eliminate sun glare when reversing. Dual video inputs is also available, this is great if you are fitting a front camera as well.  Parkmate RVM-043A Features: High Resolution 4.3'' TFT/LCD Display Designed to replace factory glass mount mirror 400 √ó 234 Resolution 16:9 Aspect Ratio Auto Switching PAL/NTSC Auto Brightness Dual Video Inputs Parkmate RVM-043A Specifications: Screen Size: 4.3‚Äù Display Screen: TFT-LCD Display Resolution: 480 (H) √ó 272 (V) Aspect Ratio: 16:9 Power Consumption: 6W Working Voltage: DC 12V Video Input: Video-In (e.g. GPS / DVD (Default) + Reverse Camera-In Signal System: PAL / Auto / NSTC Dimensions: 29.1 √ó 1.3 √ó 17.0cm Weight: 2.0 kg Legendary Products & Support From Authorized Dealers When you choose ParkMate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized ParkMate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection: We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support. ▸ Reliable Customer Support: If you ever run into an issue, you're backed by ParkMate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment: Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that? Choose wisely. Buy from an authorized ParkMate dealer today!

Read more less

OEX ACX3160 400A Heavy Duty Bus Bar Box Red and Black 8x M10 Stud Terminals Glass Fibre Reinforced Nylon 48V DC The OEX ACX3160 is a 400A heavy duty bus bar box combining a red positive bus bar and a black negative bus bar in a single enclosed unit. Eight M10 (3/8") stud terminals four red and four black provide a structured, high-current distribution point for 12V, 24V and 48V DC electrical systems. Glass fibre reinforced nylon enclosure with three sides open for unobstructed wiring access. 168x80x40mm. Also available in a 600A version as the ACX3162. Covered by a one year warranty. Product overview A bus bar box provides a centralised, organised distribution point for multiple positive supply and negative return connections in a DC electrical system. Rather than stacking multiple ring terminals on a battery terminal or scattering individual stud terminals across the installation, the ACX3160 consolidates up to four positive supply circuits and four negative return circuits at a single purpose-built enclosure, keeping the installation clean, reducing heat at connection points and making future maintenance and troubleshooting easier. The 400A maximum continuous rating and 48V DC voltage rating cover 12V, 24V and 48V systems including lithium battery banks and solar storage installations. The glass fibre reinforced nylon enclosure provides heavy duty mechanical strength, electrical insulation and durability in underbonnet, marine and caravan environments. Three sides of the box are open for unobstructed wiring access from multiple directions. At 168x80x40mm it suits underbonnet, dual battery and caravan electrical panel installations. For higher current requirements, the ACX3162 provides a 600A alternative. Features and benefits 400A maximum continuous rating: Suited to high-current main supply and earth distribution in dual battery systems, inverter installations and multi-circuit accessory panels. Total combined current across all positive (or negative) connections must not exceed 400A continuous. 48V DC maximum operating voltage: Compatible with 12V, 24V and 48V DC systems including lithium battery banks and solar storage installations. 8x M10 (3/8") stud terminals four red, four positive, four black, four negative: Accepts M10-compatible ring terminals (10.5mm ID or larger) for secure, torque-resistant connections across up to four positive and four negative circuits simultaneously. Red and black combined: Both positive and negative bus bars in a single unit for a matched, colour-coded distribution point with instant polarity identification. Glass fibre reinforced nylon construction: High mechanical strength, electrical insulation and resistance to heat and impact in demanding automotive, marine and caravan environments. Three sides open: Unobstructed wiring access from three directions for flexible cable routing and clean cable dressing. 168x80x40mm: Compact footprint suited to underbonnet, panel and caravan installation spaces. Also available in 600A: The ACX3162 is a 600A version for higher-current applications. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX3160 Brand OEX Type Bus Bar Box Maximum Continuous Rating 400A Maximum Operating Voltage 48V DC Terminal Studs 8x M10 (3/8") 4 red positive, 4 black negative Enclosure Material Glass fibre reinforced nylon Dimensions 168mm x 80mm x 40mm Wiring Access Three sides open Pack Quantity 1 Warranty One year Sold As Single unit Goes well with OEX ACX3057 Ring Crimp Terminal 10.5mm ID Blue, suits M10 stud, pack of 100 OEX ACX3057BL Ring Crimp Terminal 10.5mm ID Blue, suits M10 stud, pack of 14 OEX ACX3162 600A Heavy Duty Bus Bar Box (higher current alternative) Frequently asked questions What is a bus bar box used for? A bus bar box provides a centralised, organised distribution point for multiple positive supply and negative return connections in a DC electrical system. Rather than stacking ring terminals on a battery terminal or using individual stud terminals, a bus bar box accepts multiple cables at a purpose-built enclosure, keeping the installation clean and making future maintenance and troubleshooting easier. How many circuits can this bus bar support? The ACX3160 has four red positive studs and four black negative studs, allowing up to four positive supply circuits and four negative return circuits to be connected simultaneously. The total combined current across all positive (or all negative) connections must not exceed 400A continuous. What ring terminal size suits the M10 studs? The M10 studs are 10mm in nominal diameter and require ring terminals with a 10.5mm or larger ID hole. The OEX ACX3057 (10.5mm ID, blue, pack of 100) and ACX3057BL (pack of 14) are suitable options. Always confirm the ring terminal ID matches the stud diameter before purchasing. What is the maximum voltage for this bus bar? The ACX3160 is rated to 48V DC maximum operating voltage, making it suitable for 12V, 24V and 48V systems including lithium battery banks and solar storage installations. Is a higher current version available? Yes. The OEX ACX3162 is a 600A version of this bus bar box for applications requiring higher continuous current capacity. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX3162 600A Heavy Duty Bus Bar Box Red and Black 4x M10 Stud Terminals Glass Fibre Reinforced Nylon 48V DC The OEX ACX3162 is a 600A heavy duty bus bar box combining a red positive bus bar and a black negative bus bar in a single enclosed unit. Four M10 (3/8") stud terminals two red and two black provide a structured, high-current distribution point for 12V, 24V and 48V DC electrical systems. The highest current rating in the OEX bus bar range, suited to high-capacity inverters, large lithium battery banks, commercial vehicle power systems and applications where the combined circuit current approaches or exceeds the 400A limit of the ACX3160. Same 168x80x40mm footprint as the ACX3160 for a like-for-like upgrade. Also available in a 400A version with 8 studs as the ACX3160. Covered by a one year warranty. Product overview The ACX3162 is the highest-rated bus bar box in the OEX range at 600A continuous, stepping up from the 400A ACX3160 for the most demanding installations. There is an important trade-off between the two models: the ACX3162 provides a higher continuous current rating but fewer connection points two red positive and two black negative studs versus four of each on the ACX3160. For installations requiring maximum current capacity with a smaller number of high-current main feeds, the ACX3162 is the correct choice. For installations requiring more individual circuit connections at a lower total current, the ACX3160 with eight studs is more appropriate. The 48V DC voltage rating covers 12V, 24V and 48V systems including lithium battery banks and solar storage installations. Glass fibre reinforced nylon provides heavy duty mechanical strength, electrical insulation and heat and impact resistance. Three sides of the box are open for unobstructed wiring access from multiple directions. At 168x80x40mm it shares the same footprint as the ACX3160, allowing a like-for-like upgrade without changing the mounting arrangement. Features and benefits 600A maximum continuous rating: The highest current rating in the OEX bus bar range, suited to high-capacity inverter installations, large lithium battery banks and commercial vehicle power distribution where the 400A ACX3160 is undersized. 48V DC maximum operating voltage: Compatible with 12V, 24V and 48V DC systems including lithium battery banks and solar storage installations. 4x M10 (3/8") stud terminals two red, two black: Two positive and two negative connection points accepting M10-compatible ring terminals (10.5mm ID or larger). Fewer connection points than the ACX3160 (8 studs) in exchange for higher current capacity. Red and black combined: Both positive and negative bus bars in a single unit for a matched, colour-coded distribution point with instant polarity identification. Glass fibre reinforced nylon construction: High mechanical strength, electrical insulation and resistance to heat and impact in demanding automotive, marine and caravan environments. Three sides open: Unobstructed wiring access from three directions for flexible cable routing and clean cable dressing. 168x80x40mm: Same footprint as the ACX3160 for a like-for-like upgrade without changing the mounting arrangement. Also available in 400A with 8 studs: The ACX3160 provides more individual circuit connections at a lower total current rating. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX3162 Brand OEX Type Bus Bar Box Maximum Continuous Rating 600A Maximum Operating Voltage 48V DC Terminal Studs 4x M10 (3/8") 2 red positive, 2 black negative Enclosure Material Glass fibre reinforced nylon Dimensions 168mm x 80mm x 40mm Wiring Access Three sides open Pack Quantity 1 Warranty One year Sold As Single unit Goes well with OEX ACX3057 Ring Crimp Terminal 10.5mm ID Blue, suits M10 stud, pack of 100 OEX ACX3057BL Ring Crimp Terminal 10.5mm ID Blue, suits M10 stud, pack of 14 OEX ACX3160 400A Heavy Duty Bus Bar Box with 8 studs (lower current, more connection points) Frequently asked questions What is a bus bar box used for? A bus bar box provides a centralised, organised distribution point for multiple positive supply and negative return connections in a DC electrical system. Rather than stacking ring terminals at a battery terminal or using individual stud terminals, a bus bar box accepts multiple cables at a purpose-built enclosure, keeping the installation clean and making future maintenance easier. How does the ACX3162 differ from the 400A ACX3160? The ACX3162 is rated at 600A continuous versus 400A for the ACX3160. However, the ACX3162 has 4 stud terminals (2 red, 2 black) while the ACX3160 has 8 (4 red, 4 black). Select the ACX3162 for maximum current capacity with fewer connection points, and the ACX3160 for more individual circuit connections at a lower total current. What ring terminal size suits the M10 studs? The M10 studs are 10mm in nominal diameter and require ring terminals with a 10.5mm or larger ID hole. The OEX ACX3057 (10.5mm ID, blue, pack of 100) and ACX3057BL (pack of 14) are suitable options. Always confirm the ring terminal ID matches the stud diameter before purchasing. What is the maximum voltage for this bus bar? The ACX3162 is rated to 48V DC maximum operating voltage, making it suitable for 12V, 24V and 48V systems including lithium battery banks and solar storage installations. How many circuits can this bus bar support? The ACX3162 has two red positive studs and two black negative studs, allowing up to two positive supply circuits and two negative return circuits to be connected simultaneously. The total combined current across all connections must not exceed 600A continuous. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

OEX ACX1837 12-Way Negative Bus Bar for ACX1836 Fuse Box 32V DC 100A Stainless Steel Hardware The OEX ACX1837 is a 12-way negative bus bar designed to pair with the ACX1836 fuse box to create a complete, compliant fuse distribution and grounding system. The ACX1837 is not a standalone product it is the negative side companion to the ACX1836. Rated to 32V DC and 100A, it features 12x M4 stainless steel grounding screws for individual circuit ground connections and 1x M5 stainless steel common recessed mounting point. Supplied as a single unit. Covered by a one year warranty. Product overview A properly wired fuse distribution system requires both a positive fuse distribution point and a corresponding negative grounding point. The ACX1837 provides the negative side of the ACX1836 system, giving each of the 12 circuits a dedicated M4 grounding screw for a clean, organised negative return path rather than routing all negative leads back to a single chassis ground point separately. The M5 common recessed mounting point connects the bus bar to the main negative feed, while each of the 12 M4 terminals provides an individual ground connection for the corresponding circuit. All hardware is stainless steel for corrosion resistance in automotive, marine and caravan environments. The 32V DC rating covers both 12V and 24V vehicle electrical systems. The 100A total current rating handles the combined load across all 12 circuits. Features and benefits Designed for the ACX1836 fuse box: Pairs with the ACX1836 to create a complete positive fuse distribution and negative grounding solution. Not suitable for standalone use. 12x M4 stainless steel grounding screws: Individual M4 grounding point for each of the 12 circuits for a clean, organised negative return path. 1x M5 stainless steel common recessed mount: Single M5 common connection point for the main negative feed. 32V DC rated: Suits both 12V and 24V vehicle electrical systems. 100A total current rating: Handles the combined load across all 12 circuit terminals. Stainless steel hardware: Corrosion-resistant hardware for long-term reliability in automotive, marine and caravan environments. One year warranty: Covered by a one year OEX warranty. Technical specs Specification Detail SKU ACX1837 Brand OEX Type Negative Bus Bar Compatible With OEX ACX1836 Fuse Box Number of Terminals 12 x M4 Common Mount 1 x M5 stainless steel recessed Voltage Rating 32V DC Current Rating 100A Hardware Stainless steel Pack Quantity 1 Warranty One year Sold As Single unit Frequently asked questions Can the ACX1837 be used without the ACX1836? No. The ACX1837 is specifically designed to connect with the ACX1836 fuse box to create a complete, compliant fuse distribution and grounding system. It is not suitable for standalone use. What size screws does this bus bar use? The ACX1837 features 12x M4 stainless steel grounding screws for individual circuit connections and 1x M5 stainless steel for the common recessed mounting point. What voltage systems does this suit? The ACX1837 is rated to 32V DC, covering both 12V and 24V vehicle electrical systems. What is the total current rating? The ACX1837 is rated at 100A combined across all 12 terminals. Why use a dedicated negative bus bar instead of individual chassis grounds? A dedicated negative bus bar provides a single, organised negative return path for all circuits, reducing the number of individual chassis ground connections and simplifying wiring. It also makes fault finding easier since each circuit's negative return is clearly identified and terminated at a single point. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!
