Aerpro AP442 8GA to 8GA Dual AGU Fuse Distribution Block The AP442 is an 8GA x2 to 8GA x2 fused distribution block from Aerpro, accepting two 8GA input cables and distributing to two 8GA output connections via two AGU glass fuses. Features spring steel fuse clips, gold-plated contacts, and hex set screw terminals. AGU fuses are not included. Product overview The Aerpro AP442 provides a fused distribution point for two 8GA cable runs, suitable for in-line circuit protection in car audio power distribution applications. The spring steel fuse clips retain AGU glass fuses securely under vibration, and the gold-plated contact surfaces maintain low-resistance connections at the fuse interface. Hex set screw terminals secure the 8GA cable connections without requiring specialist tools. AGU glass fuses are not included and must be sourced separately to the appropriate rating for the connected circuit. Features and benefits 8GA x2 to 8GA x2 distribution: Accepts two 8GA input cable connections and distributes to two 8GA output connections, providing a fused split point for dual 8GA circuit runs in car audio power distribution installations. Spring steel AGU fuse clips: Spring steel fuse clips hold two AGU glass fuses securely in position, maintaining reliable fuse contact under the vibration conditions common in vehicle audio installations. Gold-plated contacts: Gold-plated contact surfaces at the fuse interface provide low-resistance, corrosion-resistant connections for reliable long-term current transfer. Hex set screw terminals: Hex set screw cable connections secure 8GA cables firmly without requiring specialist crimping tools, allowing straightforward installation with standard hex key hardware. Technical specs Specification Detail SKU AP442 Brand Aerpro Input Cable Size 8GA x2 Output Cable Size 8GA x2 Fuse Type AGU glass (x2) Fuse Clip Material Spring steel Contact Plating Gold-plated Terminal Type Hex set screw Fuses Included No Frequently asked questions Are AGU fuses included with the AP442?No. The AP442 holds two AGU glass fuses but they are not included. AGU fuses of the correct rating for your connected circuit must be sourced separately. Contact us for guidance on compatible AGU fuse ratings for your application. What cable size does the AP442 accept?The AP442 accepts 8GA cable on both the input and output connections, with two input connections and two output connections secured by hex set screw terminals. What type of fuse does the AP442 use?The AP442 uses AGU glass fuses, held in position by spring steel fuse clips. Two AGU fuses are required to complete the circuit, one for each output run. What applications is the AP442 suited to?The AP442 is suited to fused power distribution in car audio installations where two 8GA circuits require in-line AGU fuse protection from a common source. Contact us for guidance on whether the AP442 suits your specific installation requirements. Can the AP442 be used with cable sizes other than 8GA?The AP442 is rated and designed for 8GA cable connections. Using cable sizes outside this rating is not recommended and may result in inadequate clamping force at the set screw terminals or insufficient current capacity for the connected circuit. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer Support If you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment Buying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Aerpro AP413A 2AWG to 4x 4AWG 4-Way Power Distribution Block The AP413A is a 4-way power distribution block from Aerpro with one 2AWG input and four 4AWG outputs, designed for multi-amplifier car audio installations. Solid brass connectors with a satin chrome finish, a high-temperature polycarbonate base and cover, and 3-point base mounting are included as standard. Product overview The Aerpro AP413A distributes power from a single 2AWG supply cable to four separate 4AWG output connections, making it suited to installations running multiple amplifiers from a common power feed. The low-resistance solid brass connector construction minimises voltage drop across the distribution point, maintaining consistent power delivery to each connected amplifier. The high-temperature polycarbonate base and cover protect against accidental short circuits and provide a clean, finished appearance in the installation. Three-point base mounting allows the block to be secured firmly to the vehicle chassis or amplifier rack without movement under vibration. Features and benefits 1x 2AWG input to 4x 4AWG outputs: Distributes a single 2AWG power supply to four separate 4AWG output connections, providing a clean, low-resistance power split point for multi-amplifier installations. Solid brass connectors with satin chrome finish: Solid brass construction provides low-resistance current transfer at each connection point, with a satin chrome finish for a clean, professional appearance in the installation. High-temperature polycarbonate base and cover: The high-temp PC base and cover protect against accidental short circuits at the distribution block terminals and provide a finished appearance, rated to withstand the elevated temperatures common in enclosed vehicle installations. 3-point base mounting: Three mounting points secure the block firmly to the vehicle chassis or amplifier rack, preventing movement under vibration during normal vehicle operation. Low-resistance construction: The solid brass connector design minimises resistance at the distribution point, maintaining consistent voltage delivery to each connected amplifier output. Technical specs Specification Detail SKU AP413A Brand Aerpro Input 1x 2AWG Outputs 4x 4AWG Connector Material Solid brass, satin chrome finish Base and Cover Material High-temperature polycarbonate Mounting 3-point base mounting Frequently asked questions What is the AP413A designed for?The AP413A is designed for multi-amplifier car audio installations where a single 2AWG power supply needs to be distributed to four separate amplifiers or accessories via 4AWG output connections. Does the AP413A include a cover to prevent short circuits?Yes. A high-temperature polycarbonate cover is included, protecting the terminals from accidental short circuits and providing a clean, finished appearance in the installation. What cable sizes does the AP413A accept?The AP413A accepts one 2AWG input cable and four 4AWG output cables. Using cable sizes outside these ratings may result in inadequate clamping force at the terminals or insufficient current capacity for the connected circuit. How is the AP413A mounted in the vehicle?The AP413A uses a 3-point base mounting system, allowing the block to be secured firmly to the vehicle chassis, boot floor, or amplifier rack using three mounting points to prevent movement under vibration. Is the AP413A suitable for running multiple amplifiers?Yes. The AP413A is specifically designed for multi-amplifier installations, distributing power from a single 2AWG supply to four 4AWG output connections with low-resistance solid brass connectors to maintain consistent power delivery across all connected amplifiers. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer Support If you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment Buying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Aerpro AP410 0GA to 4x 4GA Power Distribution Block The AP410 is a power distribution block from Aerpro with one 0GA input and four 4GA outputs. Constructed from solid brass with gold-plated contacts, clear Perspex covers, and hex set screw terminals, it is designed for multi-amplifier car audio installations requiring a low-resistance power distribution point from a large-gauge supply cable. Product overview The Aerpro AP410 distributes power from a single 0GA supply cable to four separate 4GA output connections, suited to high-current multi-amplifier installations where a large-gauge power feed needs to be split cleanly to multiple amplifiers or accessories. The solid brass construction with gold-plated contacts provides low-resistance current transfer at each connection point. Clear Perspex covers protect the terminals from accidental short circuits while allowing visual inspection of the connections without removing the cover. Hex set screw terminals secure cable connections firmly without requiring specialist crimping tools. Features and benefits 1x 0GA input to 4x 4GA outputs: Distributes a single 0GA high-current power supply to four separate 4GA output connections, providing a clean, low-resistance power split point for multi-amplifier installations requiring a large-gauge supply feed. Solid brass construction with gold-plated contacts: Solid brass provides low-resistance current transfer at each connection point, with gold plating for corrosion resistance and reliable long-term contact performance. Clear Perspex covers: Clear Perspex terminal covers protect against accidental short circuits at the distribution block terminals while allowing visual inspection of the cable connections without removing the cover. Hex set screw terminals: Hex set screw cable connections secure cables firmly without requiring specialist crimping tools, allowing straightforward installation with standard hex key hardware. Technical specs Specification Detail SKU AP410 Brand Aerpro Input 1x 0GA Outputs 4x 4GA Connector Material Solid brass, gold-plated Cover Material Clear Perspex Terminal Type Hex set screw Frequently asked questions What is the AP410 designed for?The AP410 is designed for high-current multi-amplifier car audio installations where a single 0GA power supply needs to be distributed to four separate amplifiers or accessories via 4GA output connections. Do the Perspex covers need to be removed to inspect the connections?No. The clear Perspex covers allow visual inspection of the terminal connections without removing the cover, while still protecting the terminals from accidental short circuits. What cable sizes does the AP410 accept?The AP410 accepts one 0GA input cable and four 4GA output cables. Using cable sizes outside these ratings may result in inadequate clamping force at the terminals or insufficient current capacity for the connected circuit. What is the difference between the AP410, AP412A, and AP413A?The AP410 accepts a larger 0GA input cable and distributes to four 4GA outputs, suited to higher-current installations. The AP412A accepts a 2AWG input and distributes to two 4AWG outputs. The AP413A accepts a 2AWG input and distributes to four 4AWG outputs. The correct choice depends on your total system current draw and the number of amplifiers being powered. Is the AP410 suitable for ground distribution as well as power distribution?The AP410 is designed as a power distribution block for car audio installations. Contact us for guidance on whether it is suitable for ground distribution in your specific installation before purchasing. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer Support If you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment Buying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Aerpro AP406 4GA x2 to 8GA x4 Power Distribution Block The AP406 is a power distribution block from Aerpro with two 4GA inputs and four 8GA outputs. Constructed from solid brass with gold-plated contacts, clear Perspex covers, and hex set screw terminals, it is designed for multi-amplifier car audio installations requiring a fused distribution point from medium-gauge supply cables. Product overview The Aerpro AP406 distributes power from two 4GA supply cables to four separate 8GA output connections, suited to installations running multiple amplifiers or accessories from a common 4GA power feed. The solid brass construction with gold-plated contacts provides low-resistance current transfer at each connection point. Clear Perspex covers protect the terminals from accidental short circuits while allowing visual inspection of the connections without removing the cover. Hex set screw terminals secure cable connections firmly without requiring specialist crimping tools. Features and benefits 4GA x2 input to 8GA x4 outputs: Accepts two 4GA input cables and distributes to four separate 8GA output connections, providing a clean, low-resistance power split point for multi-amplifier car audio installations. Solid brass construction with gold-plated contacts: Solid brass provides low-resistance current transfer at each connection point, with gold plating for corrosion resistance and reliable long-term contact performance. Clear Perspex covers: Clear Perspex terminal covers protect against accidental short circuits while allowing visual inspection of the cable connections without removing the cover. Hex set screw terminals: Hex set screw cable connections secure cables firmly without requiring specialist crimping tools, allowing straightforward installation with standard hex key hardware. Technical specs Specification Detail SKU AP406 Brand Aerpro Inputs 2x 4GA Outputs 4x 8GA Connector Material Solid brass, gold-plated Cover Material Clear Perspex Terminal Type Hex set screw Frequently asked questions What is the AP406 designed for?The AP406 is designed for multi-amplifier car audio installations where two 4GA power supply cables need to be distributed to four separate amplifiers or accessories via 8GA output connections. Do the Perspex covers need to be removed to inspect the connections?No. The clear Perspex covers allow visual inspection of the terminal connections without removing the cover, while still protecting the terminals from accidental short circuits. What cable sizes does the AP406 accept?The AP406 accepts two 4GA input cables and four 8GA output cables. Using cable sizes outside these ratings may result in inadequate clamping force at the terminals or insufficient current capacity for the connected circuit. How does the AP406 differ from the AP410, AP412A, and AP413A?The AP406 accepts two 4GA inputs and distributes to four 8GA outputs. The AP410 accepts a single 0GA input and distributes to four 4GA outputs. The AP412A accepts a single 2AWG input and distributes to two 4AWG outputs. The AP413A accepts a single 2AWG input and distributes to four 4AWG outputs. The correct choice depends on your total system current draw, cable gauge, and number of components being powered. Is the AP406 suitable for ground distribution as well as power distribution?The AP406 is designed as a power distribution block for car audio installations. Contact us for guidance on whether it is suitable for ground distribution in your specific installation before purchasing. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer Support If you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment Buying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Aerpro AP404 8GA x2 to 8GA x2 Dual Isolated Bar Distribution Block The AP404 is a distribution block from Aerpro with two isolated bars, each accepting two 8GA connections, providing a clean dual-bar power and ground distribution point for car audio installations. Constructed from solid brass with gold-plated contacts, clear Perspex covers, and hex set screw terminals. Product overview The Aerpro AP404 features two isolated brass bars, each accepting two 8GA cable connections via hex set screw terminals. The isolated bar configuration allows the AP404 to serve as both a power and ground distribution point in a single block, with each bar kept electrically separate. The solid brass construction with gold-plated contacts provides low-resistance current transfer at each connection point. Clear Perspex covers protect the terminals from accidental short circuits while allowing visual inspection without removing the cover. Features and benefits Two isolated bars for power and ground distribution: The dual isolated bar configuration allows the AP404 to serve as both a power distribution and ground distribution point in a single block, with each bar kept electrically separate from the other. 8GA x2 per bar: Each isolated bar accepts two 8GA cable connections, providing two input and two output connection points per bar for flexible distribution in car audio installations. Solid brass construction with gold-plated contacts: Solid brass provides low-resistance current transfer at each connection point, with gold plating for corrosion resistance and reliable long-term contact performance. Clear Perspex covers: Clear Perspex terminal covers protect against accidental short circuits while allowing visual inspection of the cable connections without removing the cover. Hex set screw terminals: Hex set screw cable connections secure cables firmly without requiring specialist crimping tools, allowing straightforward installation with standard hex key hardware. Technical specs Specification Detail SKU AP404 Brand Aerpro Cable Size 8GA x2 per bar Bar Configuration Two isolated bars Connector Material Solid brass, gold-plated Cover Material Clear Perspex Terminal Type Hex set screw Frequently asked questions What does the two isolated bars configuration mean?The AP404 has two separate brass bars, each electrically isolated from the other. This allows one bar to be used for power distribution and the other for ground distribution in the same block, keeping positive and negative connections physically separated and electrically independent. What cable sizes does the AP404 accept?The AP404 accepts 8GA cable on all connections, with two connections per bar. Using cable sizes outside this rating may result in inadequate clamping force at the set screw terminals or insufficient current capacity for the connected circuit. Do the Perspex covers need to be removed to inspect the connections?No. The clear Perspex covers allow visual inspection of the terminal connections without removing the cover, while still protecting the terminals from accidental short circuits. How does the AP404 differ from the AP406 and AP410?The AP404 features two isolated bars each accepting two 8GA connections, suited to combined power and ground distribution in a single block. The AP406 accepts two 4GA inputs and distributes to four 8GA outputs on a single bar. The AP410 accepts a single 0GA input and distributes to four 4GA outputs. The correct choice depends on your cable gauge requirements and whether you need combined power and ground distribution in a single block. Is the AP404 suitable for both power and ground distribution?Yes. The two isolated bar configuration makes the AP404 suited to use as a combined power and ground distribution block, with one bar for positive connections and one bar for ground connections, kept electrically separate. Contact us for guidance on your specific installation requirements before purchasing. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & Training Only authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty Protection We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer Support If you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your Investment Buying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Stinger SPD570 Dual Power and Ground Distribution Block Two Independent 1-In 2-Out Sections in Chrome Finish with Clear Perspex Cover The SPD570 from Stinger is a chrome finish dual distribution block that combines two independent power distribution sections in a single unit, allowing power and ground distribution to be handled from one compact block. Each section accepts 1x 4GA or 8GA input and distributes to 2x 4GA or 8GA outputs. A clear Perspex cover is included. Product overview Running separate power and ground distribution blocks in an installation takes up space and adds complexity to the cable routing. The SPD570 solves this by housing two independent distribution sections in a single block, allowing one section to handle positive power distribution and the other to handle ground distribution in the same unit. Both sections can also be used for power or both for ground depending on the installation requirements. Each of the two sections accepts a 4GA or 8GA input and distributes to two 4GA or 8GA outputs, providing a total of two inputs and four outputs across the full unit. The chrome finish and clear Perspex cover deliver a clean, professional appearance in any installation, and the dual-block design significantly reduces the space and cable management required compared to running two separate distribution blocks. Features and benefits Dual distribution block in one unit: Two independent 1-in 2-out distribution sections are housed in a single block, allowing power and ground distribution to be handled from one compact unit and simplifying installation cable management. Flexible positive and negative configuration: Each section can be used independently for positive power or negative ground distribution, or both sections can be used for the same polarity depending on the installation requirements. 4GA and 8GA cable compatibility: Each section accepts 4GA or 8GA input and distributes to 4GA or 8GA outputs, covering a range of car audio and accessory installation power requirements. Chrome finish: The chrome finish provides a clean, professional appearance suited to visible installations in custom builds and car audio setups. Clear Perspex cover: The included clear Perspex cover protects the terminal connections from exposure and debris while maintaining visibility of the connection points. Compact space-saving design: Combining two distribution sections in a single unit reduces the installation footprint compared to using two separate distribution blocks for power and ground. What's in the box 1x SPD570 Dual Distribution Block 1x Clear Perspex Cover Technical specs Specification Detail SKU SPD570 Brand Stinger Finish Chrome Sections 2 independent distribution sections Input Per Section 1x 4GA or 8GA Output Per Section 2x 4GA or 8GA Total Inputs 2 Total Outputs 4 Cover Clear Perspex Polarity Suitable for positive or negative distribution Frequently asked questions How does the SPD570 work as a combined power and ground distribution block?The SPD570 houses two completely independent distribution sections in a single unit. One section can be used for positive power distribution and the other for ground distribution, allowing both power and ground cables to be distributed from the same block. Both sections can also be configured for the same polarity if required. What cable gauges does the SPD570 accept?Each section of the SPD570 accepts 4GA or 8GA input and distributes to 4GA or 8GA outputs across both output ports. Contact us if you need guidance on selecting the correct cable gauge for your specific installation power requirements. How does the SPD570 compare to the SHD20 or SHD21 distribution blocks?The SHD20 and SHD21 are single-polarity distribution blocks with a Shoc-Krome finish and grub screw allen key fittings. The SPD570 combines two independent distribution sections in one chrome finished unit, specifically designed to handle both power and ground distribution from a single block. The SPD570 is the more practical choice when a compact combined power and ground distribution solution is needed. Is the SPD570 covered by a warranty?Warranty details are not confirmed in the available source data for this product. Contact us for further information on warranty coverage before ordering. Can both sections of the SPD570 be used for the same polarity?Yes. While the SPD570 is designed to simplify combined power and ground distribution, both sections can be configured for positive power or negative ground distribution depending on the specific requirements of the installation. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Stinger SHD21 HPM Multi Port Power Distribution Block High Current Brass Core with Shoc-Krome Finish and Acrylic Cover The SHD21 from Stinger is a high current brass core power distribution block with a Shoc-Krome finish, providing 2 input ports and 4 output ports for car audio amplifier power distribution and a wide range of automotive and 4WD accessory applications. It accepts 0 or 4AWG inputs with 4 or 8AWG outputs, uses grub screw allen key fittings for secure cable locking, and includes a clear acrylic cover and silver-backed acrylic mounting base. A lifetime warranty against manufacturer defects is included. Product overview Stacking multiple ring terminals on a single post is a common but unreliable approach to power distribution in vehicle installations. The SHD21 replaces this with a high current brass core distribution block that locks each cable in place individually via grub screw allen key fittings, providing a secure and reliable connection for each port without the risk of terminals shifting or losing contact under vibration. The Shoc-Krome plating delivers excellent conductivity and corrosion resistance across all connection points. With two input ports and four output ports, the SHD21 suits multi-amplifier car audio installations and complex 4WD accessory setups where multiple power draws need to be distributed from a central point. Like the SHD20, it is equally suited to air suspension systems, air compressor systems, winches, fridges, lights, compressors, and battery power management applications beyond its original car audio design intent. Features and benefits High current brass core with Shoc-Krome finish: The high current brass core provides excellent power handling and conductivity, with Shoc-Krome plating delivering corrosion resistance and superior contact quality at each connection point. 2 input and 4 output port configuration: The 2x input and 4x output configuration suits multi-amplifier car audio installations and complex accessory setups requiring multiple power draws from a single distribution point. Grub screw allen key fittings: Individual grub screw fittings lock each cable securely in place, eliminating the unreliable stacked ring terminal approach and providing a vibration-resistant connection at every port. Suits 0AWG, 4AWG, and 8AWG cable: The input ports accept 0AWG or 4AWG cable and the output ports accept 4AWG or 8AWG cable, covering a range of installation power requirements. Clear acrylic cover and silver-backed mounting base: The clear acrylic cover protects the terminal connections and provides a clean, finished appearance. The silver-backed acrylic mounting base provides a secure platform for installation. Suitable as positive or negative distribution: The SHD21 can be used for either positive or negative power distribution, providing flexibility in installation layout and configuration. Lifetime warranty against manufacturer defects: The SHD21 is covered by Stinger's lifetime performance warranty against manufacturer defects. What's in the box 1x SHD21 Multi Distribution Block (2x 0 or 4AWG input, 4x 4 or 8AWG output) 1x Clear Acrylic Cover 1x Silver-Backed Acrylic Mounting Base Technical specs Specification Detail SKU SHD21 Brand Stinger Construction High current brass core Finish Shoc-Krome Input Ports 2x 0AWG or 4AWG Output Ports 4x 4AWG or 8AWG Fitting Type Grub screw allen key Includes Clear acrylic cover, silver-backed acrylic mounting base Polarity Suitable for positive or negative distribution Warranty Lifetime against manufacturer defects Frequently asked questions What is the difference between the SHD21 and the SHD20?Both are Shoc-Krome finished power distribution blocks with grub screw allen key fittings, a clear acrylic cover, and a lifetime warranty. The SHD20 provides 1 input and 2 output ports, suited to simpler single or dual amplifier installations. The SHD21 provides 2 input and 4 output ports, suited to more complex multi-amplifier or multi-accessory installations requiring greater distribution capacity. What cable gauges does the SHD21 accept?The SHD21 input ports accept 0AWG or 4AWG cable, and the output ports accept 4AWG or 8AWG cable, covering a range of power distribution configurations for car audio and accessory installations. Can the SHD21 be used for negative as well as positive power distribution?Yes. The SHD21 is suitable for use as either a positive or negative power distribution block, providing flexibility in installation layout and ground distribution configurations. What applications is the SHD21 suited to beyond car audio?The SHD21 is suited to air suspension systems, air compressor systems, 4WD accessories including winches, fridges, lights, and compressors, and battery power management applications. Contact us if you need guidance on suitability for a specific application. Does the SHD21 include a warranty?Yes. The SHD21 is covered by Stinger's lifetime performance warranty against manufacturer defects. Contact us for further details on warranty claims and conditions. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Stinger SHD20 HPM Multi Port Power Distribution Block Solid Copper with Shoc-Krome Finish and Acrylic Cover The SHD20 from Stinger is a solid copper power distribution block with a Shoc-Krome finish, designed for car audio amplifier power distribution and a wide range of automotive and 4WD accessory applications. It accepts 0 or 4AWG input with 4 or 8AWG outputs, uses grub screw allen key fittings for secure cable locking, and includes a clear acrylic cover and silver-backed acrylic mounting base. A lifetime warranty against manufacturer defects is included. Product overview Stacking multiple ring terminals on a single post is a common but unreliable approach to power distribution in vehicle installations. The SHD20 replaces this with a solid copper distribution block that locks each cable in place individually via grub screw allen key fittings, providing a secure and reliable connection for each output without the risk of terminals shifting or losing contact under vibration. The solid copper core with Shoc-Krome plating delivers superior power transfer compared to aluminium or lower-grade distribution blocks. Originally designed for car audio amplifier power distribution, the SHD20 is equally suited to air suspension systems, air compressor systems, 4WD accessories including winches, fridges, lights, and compressors, and battery power management applications. The clear acrylic cover provides protection for the terminal connections and adds a clean, finished appearance in any installation. Features and benefits Solid copper core with Shoc-Krome finish: The solid copper construction provides superior power transfer compared to aluminium alternatives, and the Shoc-Krome plating delivers excellent conductivity and corrosion resistance at each connection point. Grub screw allen key fittings: Individual grub screw fittings lock each cable securely in place, eliminating the unreliable stacked ring terminal approach and providing a vibration-resistant connection at every port. Suits 0AWG, 4AWG, and 8AWG cable: Compatible with 0AWG (11mm), 4AWG (7mm), and 8AWG (3mm) cable sizes, providing flexibility across a range of installation power requirements. Clear acrylic cover and silver-backed mounting base: The clear acrylic cover protects the terminal connections and provides a clean, finished appearance. The silver-backed acrylic mounting base provides a secure platform for installation. Suitable as positive or negative distribution: The SHD20 can be used for either positive or negative power distribution, providing flexibility in installation layout and configuration. Broad application suitability: Suited to car audio amplifier power distribution, air suspension systems, air compressor systems, 4WD accessories, and battery power management applications. Lifetime warranty against manufacturer defects: The SHD20 is covered by Stinger's lifetime performance warranty against manufacturer defects. What's in the box 1x SHD20 Multi Distribution Block (1x 0 or 4AWG input, 2x 4 or 8AWG output) 1x Clear Acrylic Cover 1x Silver-Backed Acrylic Mounting Base Technical specs Specification Detail SKU SHD20 Brand Stinger Construction Solid copper core Finish Shoc-Krome Input 1x 0AWG or 4AWG Output 2x 4AWG or 8AWG Compatible Cable Sizes 0AWG (11mm), 4AWG (7mm), 8AWG (3mm) Fitting Type Grub screw allen key Includes Clear acrylic cover, silver-backed acrylic mounting base Polarity Suitable for positive or negative distribution Warranty Lifetime against manufacturer defects Frequently asked questions What is the advantage of a distribution block over stacking ring terminals?Stacking multiple ring terminals on a single post creates an unreliable connection that can shift or lose contact under vibration. A distribution block like the SHD20 locks each cable individually via grub screw fittings, providing a secure and independent connection for each output that remains stable in demanding vehicle applications. What cable gauges does the SHD20 accept?The SHD20 is compatible with 0AWG (11mm), 4AWG (7mm), and 8AWG (3mm) cable, covering a range of input and output configurations suited to car audio and accessory installations of varying power requirements. Can the SHD20 be used for negative as well as positive power distribution?Yes. The SHD20 is suitable for use as either a positive or negative power distribution block, providing flexibility in installation layout and ground distribution configurations. What applications is the SHD20 suited to beyond car audio?The SHD20 is suited to air suspension systems, air compressor systems, 4WD accessories including winches, fridges, lights, and compressors, and battery power management applications. Contact us if you need guidance on suitability for a specific application. Does the SHD20 include a warranty?Yes. The SHD20 is covered by Stinger's lifetime performance warranty against manufacturer defects. Contact us for further details on warranty claims and conditions. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

1/0 AWG Distribution Block 1 Input, 2 Outputs, Accepts 1/0 AWG or 4 AWG. Custom Tooled Solid Brass with HPP Platinum Finish. Product Overview The Rockford Fosgate RFD1 is a 1/0 AWG distribution block with one input and two outputs splitting one main power or ground cable into two separate runs. Both the input and each output accept 1/0 AWG or 4 AWG wire, providing wiring flexibility for systems where the main run is 1/0 AWG and secondary runs are either 1/0 AWG or the smaller 4 AWG gauge. Constructed from custom-tooled solid brass with HPP (High Performance Plating) platinum finish for superior corrosion resistance. Key Specifications Part number: RFD1 Configuration: 1 input / 2 outputs Input wire size: 1/0 AWG or 4 AWG ✓ Output wire sizes: 1/0 AWG or 4 AWG per output ✓ Construction: Custom tooled solid brass ✓ Plating: HPP (High Performance Plating) — platinum finish ✓ Corrosion resistance: Superior (HPP confirmed) ✓ Terminal type: Not specified — confirm with Rockford Fosgate (set screw or bolt) Mounting: Not specified — confirm with Rockford Fosgate Maximum current rating: Not specified — confirm with Rockford Fosgate Dimensions: Not specified — confirm with Rockford Fosgate Weight: Not specified Features & Benefits 1 In / 2 Out Configuration — Splits one main power or ground cable into two independent output runs — suitable for powering two amplifiers from a single main cable, or routing power to an amplifier and a secondary distribution point. 1/0 AWG or 4 AWG Input and Output Flexibility — Both the input and each output accept either 1/0 AWG or 4 AWG wire, allowing the block to be used across different system configurations: 1/0 AWG main to two 1/0 AWG outputs, 1/0 AWG main to two 4 AWG outputs, or mixed configurations. Custom Tooled Solid Brass — The block body is machined from solid brass rather than cast or stamped — providing precise dimensional tolerances, high current capacity, and better thermal performance than lower-grade materials. Solid brass construction also provides the mechanical strength to hold high-torque terminal screws securely. HPP Platinum Plating — Superior Corrosion Resistance — HPP plating protects the brass body against oxidation and corrosion in vehicle environments, maintaining low contact resistance at the conductor interface over time. Technical Specs Specification Detail Brand Rockford Fosgate Part Number RFD1 Configuration 1 Input / 2 Outputs Input Wire Size 1/0 AWG or 4 AWG ✓ Output Wire Sizes 1/0 AWG or 4 AWG (per output) ✓ Construction Custom Tooled Solid Brass ✓ Plating HPP Platinum ✓ Terminal Type Not specified — confirm with Rockford Fosgate Current Rating Not specified — confirm with Rockford Fosgate Mounting Not specified Dimensions Not specified Weight Not specified Warranty Not specified Compatible With / Goes Well With Suitable for: Splitting a 1/0 AWG main power run to two amplifiers Power distribution in multi-amplifier systems using 1/0 AWG or 4 AWG secondary runs Ground distribution from a single chassis ground point Pairs well with: Rockford Fosgate RFW1R-51 / RFW1B-51 (1/0 AWG wire for main run) Rockford Fosgate RFT4 / RFTS4 (4 AWG terminals for output runs) Rockford Fosgate amplifiers requiring distributed power supply Frequently Asked Questions What is a distribution block and why is it used? A distribution block connects one main power or ground cable to multiple output cables — allowing a single 1/0 AWG battery-to-boot run to supply two or more amplifiers independently. Without a distribution block, each amplifier would require its own full-length power run from the battery. Can the RFD1 mix 1/0 AWG and 4 AWG wires? Yes — both input and output ports accept either 1/0 AWG or 4 AWG, providing flexibility to mix gauges. For example, a 1/0 AWG main input can be distributed to two 4 AWG outputs for a pair of smaller amplifiers, or to one 1/0 AWG and one 4 AWG output. What is the maximum current capacity? Maximum current rating is not confirmed in the supplier data. Given solid brass construction and 1/0 AWG input capacity, the block is designed for high-current applications. Confirm the rated current from the official Rockford Fosgate RFD1 product page. How is the RFD1 mounted? Mounting method is not specified in the supplier data. Confirm from the official Rockford Fosgate RFD1 product page — typical distribution block mounting uses screws through the block body or a bracket. What terminal type (set screw or bolt) does the RFD1 use? Terminal type is not specified. Confirm from the official Rockford Fosgate RFD1 product page before purchasing. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less
