SAE Class 2 Amber LED Strobe Beacon with Rotating Effect Fixed Mount, IP67, 11–48V
Product Overview
The LED Autolamps 128AMF is an amber LED strobe beacon with a rotating light pattern effect, designed for permanent fixed mounting on trucks, forklifts, plant equipment, and commercial vehicles. Measuring 130mm x 130mm x 97mm with an amber polycarbonate lens, it delivers 82–92 flashes per minute using 4 LEDs to produce a convincing rotating beacon appearance without moving parts.
SAE/J845 Class 2 compliant and rated IP67, the 128AMF operates across a wide 11–48V input range making it compatible with 12V, 24V, and 48V electrical systems. Backed by a 3-year warranty.
Features & Benefits
Rotating pattern effect — 4 LEDs produce a sweeping rotation effect without moving parts, reducing mechanical wear and maintenance requirements
Amber polycarbonate lens — durable lens material suited to outdoor and industrial environments; amber output for standard hazard and warning applications
SAE/J845 Class 2 compliant — meets SAE standards for vehicle warning beacons
IP67 rated — fully sealed against dust and water immersion, built for exposed outdoor, industrial, and transport environments
Wide voltage range 11–48V — compatible with 12V, 24V, and 48V electrical systems including forklifts and heavy plant equipment
Fixed permanent mount — engineered for stable, permanent installation on vehicle bodies and structures
82–92 FPM flash rate — consistent, attention-grabbing flash rate across the operating voltage range
3-year warranty — backed by LED Autolamps' warranty programme
Technical Specs
Specification
Detail
SKU
128AMF
Lamp Type
Strobe Beacon
LED Quantity
4
LED Colour
Amber
Lens Colour
Amber
Lens Material
Polycarbonate
Voltage Range
11V – 48V
Current Draw
0.39A @ 13.8V
Flash Rate
82–92 FPM
Pattern
Rotating effect
Dimensions
130mm x 130mm x 97mm
Mounting
Fixed permanent
Compliance
SAE/J845 Class 2
Protection Rating
IP67
Warranty
3 years
Weight
1 kg
Compatible With / Goes Well With
Trucks, forklifts, plant equipment, and commercial vehicles requiring a permanent fixed beacon
12V, 24V, and 48V vehicle and equipment electrical systems
Hazard and warning applications requiring SAE Class 2 compliant amber beacon lighting
LED Autolamps wiring harnesses and emergency lighting accessories
Frequently Asked Questions
What voltage systems is the 128AMF compatible with?
The 128AMF operates across 11V to 48V, making it compatible with 12V light vehicles, 24V heavy transport, and 48V forklift and plant equipment electrical systems.
Does the 128AMF have a real rotating mechanism?
No. The rotating effect is produced by the 4 LEDs flashing in sequence to simulate rotation — there are no moving parts, which reduces wear and long-term maintenance requirements.
What compliance standard does the 128AMF meet?
The 128AMF is SAE/J845 Class 2 compliant, meeting SAE standards for vehicle hazard and warning beacons.
What is the IP rating on the 128AMF?
The 128AMF is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed outdoor, industrial, and transport applications.
What warranty does the 128AMF carry?
The 128AMF is backed by a 3-year warranty from LED Autolamps.
Weight
1 kg
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
SAE J595 Class 1 Blue Emergency Lamp 6x3W LEDs, 14 Flash Patterns, Sync Up to 20 Lamps
Product Overview
The LED Autolamps 120035BM is a 12/24V blue emergency warning lamp powered by 6 x 3W LEDs, delivering high-output blue warning flash for law enforcement, emergency services, and authorised vehicle applications. Measuring 131mm x 30mm x 8mm with a clear lens, it produces 120 flashes per minute across 14 selectable patterns including single, double, and quad flash.
The synchronising wire allows up to 20 lamps to be linked and flash in unison suited to large vehicle builds and professional emergency lighting rigs. SAE J595 Class 1 certified, IP67 rated, and supplied in blister pack with 3M tape and screw mounting options. Backed by a 3-year warranty.
Features & Benefits
6 x 3W high-power LEDs — delivers substantially greater output than standard SMD emergency lamps for maximum warning visibility
Blue LED output — suited to law enforcement, emergency services, and authorised vehicle applications where blue warning lights are required
14 selectable flash patterns — single, double, and quad flash configurations at 120 FPM
Synchronise up to 20 lamps — synchronising wire links up to 20 units for coordinated multi-lamp setups
SAE J595 Class 1 certified — meets the highest SAE classification for vehicle warning lamps
IP67 rated — fully sealed against dust and water immersion, built for exposed vehicle-mounted applications
Clear lens — clean appearance when inactive; blue warning output when energised
3M tape and screw fitting — dual mounting options for adhesive or screw-fixed installation
Ultra-slim 8mm profile — 131mm x 30mm footprint suits tight installation spaces on vehicle bodies
12/24V dual voltage — compatible with both 12V light vehicles and 24V heavy transport without modification
3-year warranty — backed by LED Autolamps' warranty programme
Technical Specs
Specification
Detail
SKU
120035BM
Lamp Type
Emergency Warning
LED Configuration
6 x 3W
LED Colour
Blue
Lens Colour
Clear
Voltage Range
12V / 24V
Dimensions
131mm x 30mm x 8mm
Current Draw
0.29A @ 13.8V
Flash Patterns
14 selectable
Flash Rate
120 FPM (single / double / quad)
Sync Capacity
Up to 20 lamps
Synchronising Wire
Included
Mounting
3M tape / screw
Compliance
SAE J595 Class 1
Protection Rating
IP67
Warranty
3 years
Compatible With / Goes Well With
Law enforcement, emergency services, and authorised vehicles requiring blue warning lighting
12V light commercial and passenger vehicles
24V trucks, plant equipment, and heavy transport
Multi-lamp synchronised emergency lighting setups of up to 20 units
LED Autolamps 120035AM amber emergency lamp (same series)
LED Autolamps wiring harnesses and emergency lighting accessories
Frequently Asked Questions
What compliance certification does the 120035BM carry?
The 120035BM is certified to SAE J595 Class 1, the highest SAE classification for vehicle warning lamps, making it suitable for professional emergency and hazard warning applications.
What applications typically use blue warning lamps?
Blue warning lamps are used by law enforcement, emergency services, and other authorised vehicles. The use of blue warning lights is strictly regulated in Australia — always check your state or territory regulations before fitting.
How many lamps can be synchronised with the 120035BM?
Up to 20 lamps can be linked via the synchronising wire to flash in the same pattern simultaneously — suited to large vehicle builds and professional emergency rigs.
What flash patterns and rates does the 120035BM support?
It offers 14 selectable flash patterns at 120 flashes per minute, covering single, double, and quad flash configurations.
What warranty does the 120035BM carry?
The 120035BM is backed by a 3-year warranty from LED Autolamps.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
OEX Underbonnet LED Work Light Extendable Length: Powerful SMD LEDs Producing 1000 Lumens of Light OEX LLX3003 Features: 2 Magnets and 2 soft hooks for mounting to almost any surface Extendable from 1.2m to 2.0m for any job 8-hour battery life on 500 Lumen output, 4 hours on 1000 Approx 3 hour charge time with included USB charge cable OEX LLX3003 Specifications: Type: Inspection Lights Unit of Measure: Each Description: OEX Underbonnet Led Work Light, Extendable Length Warranty: 12 Months Note: 2 Bonnet Mounting Options: Strong Magnets or Hooks Light Type: LED Light Output: 1000 Lumen
Legendary Products & Support From Authorized Dealers
When you choose OEX, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized OEX dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by OEX's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized OEX dealer today!
SAE J595 Class 1 Amber Emergency Lamp 11 Flash Patterns, Sync Wire, Ultra-Slim IP67
Product Overview
The LED Autolamps 120033AM is a 12/24V amber emergency warning lamp built into the same ultra-slim 89mm x 30mm x 8mm Horizon series form factor as the 11AM-2 and 11RM-2 lamps. What sets it apart is its 11 selectable flash patterns and synchronising wire, allowing multiple units to be linked and flash in unison essential for professional emergency and hazard warning installations.
SAE J595 Class 1 certified and rated IP67, it mounts via 3M adhesive tape or screws in horizontal or vertical orientation. Available in five colours, the 120033AM is backed by a 3-year warranty and suited to emergency services, road maintenance, tow trucks, and utility vehicles.
Features & Benefits
11 selectable flash patterns — operators can choose the most appropriate flash mode for their application or local compliance requirements
Synchronising wire — allows multiple units to be wired together and flash in sync for a coordinated, professional emergency lighting setup
SAE J595 Class 1 certified — meets the highest SAE classification for vehicle warning lamps
IP67 rated — fully sealed against dust and water immersion, built for exposed vehicle-mounted applications
3M tape and screw fitting — dual mounting options for adhesive or screw-fixed installation on a wide range of surfaces
Ultra-slim 8mm profile — fits where conventional emergency lamps won't, without compromising warning output
12/24V dual voltage — compatible with both 12V light vehicles and 24V heavy transport without modification
Available in 5 colours — amber, and four additional colour options; confirm available variants with F.A.E.
3-year warranty — backed by LED Autolamps' warranty programme
Technical Specs
Specification
Detail
SKU
120033AM
Lamp Type
Emergency Warning
LED Colour
Amber
Voltage Range
12V – 24V
Dimensions
89mm x 30mm x 8mm
Flash Patterns
11 selectable
Synchronising Wire
Included
Mounting
3M tape / screw
Compliance
SAE J595 Class 1
Protection Rating
IP67
Available Colours
5 (confirm variants with F.A.E.)
Warranty
3 years
Compatible With / Goes Well With
Emergency, warning, and service vehicles requiring SAE J595 Class 1 compliant lighting
12V light commercial and passenger vehicles
24V trucks, plant equipment, and heavy transport
Road maintenance, tow trucks, escort vehicles, and utility fleets
Additional 120033 series lamps for synchronised multi-unit setups
LED Autolamps wiring harnesses and emergency lighting accessories
Frequently Asked Questions
What compliance certification does the 120033AM carry?
The 120033AM is certified to SAE J595 Class 1, the highest SAE classification for vehicle warning lamps, making it suitable for professional emergency and hazard warning applications.
How does the synchronising wire work?
The synchronising wire links multiple 120033AM units together so they flash in the same pattern simultaneously — essential for coordinated emergency lighting setups across a vehicle or fleet.
How many flash patterns does the 120033AM offer?
It features 11 selectable flash patterns, giving operators the flexibility to choose the most appropriate mode for their specific application or local requirements.
What mounting options does the 120033AM support?
It can be mounted using 3M adhesive tape or screws, and installed in either horizontal or vertical orientation — suitable for a wide range of vehicle surfaces and body panels.
What warranty does the 120033AM carry?
The 120033AM is backed by a 3-year warranty from LED Autolamps.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Ultra-Slim Reverse Lamp Twin Pack 8mm Profile, 3M Tape or Screw Mount, 12/24V Dual Voltage.
Product Overview
The LED Autolamps 11WM-2 is a twin pack of ultra-slim reverse lamps measuring just 8mm deep one of the lowest-profile reverse lamp options available for trucks, trailers, caravans, and commercial vehicles. At 89mm long and 30mm wide, each lamp mounts in either horizontal or vertical orientation using 3M adhesive tape or screws, giving installers flexible fitment options across a range of trailer body profiles, caravan rear panels, and vehicle tubs without requiring a dedicated lamp housing or cutout.
Dual voltage operation across 12V and 24V and an IP67 waterproof rating make the 11WM-2 a versatile, low-maintenance solution for both light and heavy vehicle applications. Supplied as a twin blister pack two lamps per purchase making it convenient for pairing left and right reverse positions on a single trailer or vehicle build.
Key Specifications
Pack contents: 2 lamps (twin blister pack)
Light function: Reverse lamp (white output)
Voltage: 12V / 24V (dual voltage)
IP rating: IP67 — fully dust-tight; immersion-resistant to 1m depth for 30 minutes
Compliance: ECE Australian Road Approved
Mount type: 3M tape or screw fitting
Mount orientation: Horizontal or vertical
Dimensions: 89mm (L) × 30mm (W) × 8mm (D)
Warranty: 5 years
Current draw: Not specified — confirm with LED Autolamps
Connector type: Not specified — confirm with LED Autolamps
Lumen output: Not specified — confirm with LED Autolamps
Features & Benefits
8mm Ultra-Slim Profile — At just 8mm deep, the 11WM-2 is one of the slimmest reverse lamps in the LED Autolamps range. The minimal protrusion reduces the risk of impact damage at loading docks and in tight reversing clearance situations, and allows fitment in locations where a standard-depth reverse lamp housing would not fit.
3M Tape or Screw Fitting — The dual-mounting system provides genuine installation flexibility. 3M adhesive tape mounting is ideal for clean panel surfaces on caravans, enclosed trailers, and van bodies where drilling is undesirable. Screw mounting suits exposed or structural mounting positions requiring a mechanically secured connection.
Horizontal and Vertical Mounting — The lamp is designed to function correctly in either horizontal or vertical orientation, giving installers full flexibility to optimise placement based on the vehicle or trailer body geometry.
Twin Pack — Two lamps per blister pack — sufficient for a left/right reverse lamp pair on a single vehicle or trailer in a single purchase. No need to order two separate units.
12V / 24V Dual Voltage — Works natively across both light vehicle and heavy transport electrical systems without modification — suitable for caravans, utes, trucks, and 24V semi-trailers.
IP67 Waterproof — Completely sealed against dust and capable of withstanding water immersion to 1 metre for 30 minutes — protected against rain, wash-downs, and the wet and muddy conditions common to Australian working and touring vehicles.
ECE Australian Road Approved — Confirmed as road approved per the supplier's compliance statement. Specific certification codes have not been provided — see Red-flags for detail.
5-Year Warranty — Backed by a 5-year manufacturer's warranty across both lamps in the twin pack.
Technical Specs
Specification
Detail
Brand
LED Autolamps
Part Number
11WM-2
Pack Contents
2 Lamps (Twin Blister Pack)
Light Function
Reverse Lamp
Light Type
LED
Output Colour
White (reverse lamp application)
Voltage
12V / 24V (Dual Voltage)
IP Rating
IP67
Compliance
ECE Australian Road Approved
Compliance Codes
Not specified — confirm with LED Autolamps
Mount Type
3M Tape or Screw
Mount Orientation
Horizontal or Vertical
Length
89mm
Width
30mm
Depth
8mm
Current Draw
Not specified
Lumen Output
Not specified
Connector Type
Not specified
Weight
Not specified
Warranty
5 Years
Compatible With / Goes Well With
Suitable applications:
Reverse lamp positions on trucks, semi-trailers, and caravans (paired left/right with twin pack)
Caravan and camper trailer rear lighting upgrades
Van body and enclosed trailer reverse lighting
Ute tub and canopy reverse lamp applications
4WD and touring vehicle rear lighting
Any vehicle or trailer currently running a standard reverse lamp where a lower-profile LED alternative is preferred
Pairs well with:
LED Autolamps combination stop/tail/indicator lamp assemblies — the 11WM-2 provides the reverse function not included in 3-in-1 combination lamps (such as the 100BARRM and 150ARM)
LED Autolamps wiring harness and auto electrical accessories
Frequently Asked Questions
How many lamps are included in the 11WM-2 pack?
The 11WM-2 is a twin blister pack containing two reverse lamps — sufficient for a paired left/right reverse installation on a single vehicle or trailer.
Can the 11WM-2 be mounted using 3M tape instead of screws?
Yes. Each lamp can be mounted with either 3M adhesive tape or screws. The tape option is well-suited to smooth, clean panel surfaces on caravans and enclosed trailer bodies where drilling is not preferred. For permanent, structural, or high-vibration mounting positions, screw fitment is recommended.
Does the 11WM-2 work in both horizontal and vertical orientations?
Yes. The lamp is designed for use in either horizontal or vertical mounting positions, giving full flexibility for installation across different trailer body and vehicle panel geometries.
Will the 11WM-2 pair with a 3-in-1 stop/tail/indicator lamp that doesn't include reverse?
Yes. The 11WM-2 is designed to provide the reverse function in a rear lighting setup — making it a natural companion to 3-in-1 combination lamps such as the LED Autolamps 100BARRM and 150ARM that provide stop, tail, and indicator without a reverse function.
Is the 11WM-2 suitable for both 12V caravans and 24V trucks?
Yes. The 11WM-2 operates natively across 12V and 24V without modification, covering both light recreational vehicles and heavy commercial transport in a single product.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
ADR 49/00 Approved 10/30V Stop/Tail Lamp with Grommet and Plug 130mm Recessed, IP67
Product Overview
The LED Autolamps 110RMG is a 10/30V LED stop/tail lamp designed for flush recessed mounting on trailers, trucks, and commercial vehicles. At 130mm round and 12mm deep with a plastic base, it is supplied with a grommet and plug for a complete, sealed recessed installation. The 3-pin connector is not included and must be sourced separately.
ADR 49/00 compliant and rated IP67, drawing 0.31A at 13.8V. The stop/tail companion to the 110AMB indicator lamp in the 130mm round recessed series. Backed by a 5-year warranty.
Features & Benefits
Grommet and plug included — complete sealed installation kit for a weatherproof recessed fit straight out of the pack
Low-profile flush recessed mount — 12mm depth sits flush with the panel for a clean, integrated finish
ADR 49/00 compliant — meets Australian Design Rules for legal on-road use as a stop/tail lamp
IP67 rated — fully sealed against dust and water immersion, built for exposed outdoor and transport environments
3-pin plug and cable connector — note: 3-pin connector not supplied; must be sourced separately
Low current draw — 0.31A at 13.8V for efficient operation across multi-lamp trailer builds
10/30V multi-voltage — compatible with 12V light vehicles through to 24V and 28V heavy transport without modification
Plastic base — lightweight, corrosion-free housing suited to trailer and truck body panel mounting
Technical Specs
Specification
Detail
SKU
110RMG
Lamp Type
Stop / Tail
Voltage Range
10V – 30V
Diameter
130mm
Depth
12mm
Current Draw
0.31A @ 13.8V
Base Material
Plastic
Mounting
Flush recessed
Connector
3-pin plug and cable (connector not supplied)
Included Accessories
Grommet, plug
Protection Rating
IP67
Compliance
ADR 49/00
Weight
0.5 kg
Compatible With / Goes Well With
Trailers, trucks, and commercial vehicles requiring flush-mount stop/tail lamps with grommet
12V light vehicles and 24V/28V heavy transport applications
Trailer builds requiring ADR-approved stop/tail lighting
LED Autolamps 110AMB indicator lamp (same 130mm round recessed form factor)
LED Autolamps 110WMG reverse lamp (same 130mm round recessed form factor)
LED Autolamps wiring harnesses and trailer lighting accessories
Frequently Asked Questions
Is the 110RMG approved for road use in Australia?
Yes. The 110RMG is ADR 49/00 compliant, meeting Australian Design Rules requirements for legal on-road use as a stop/tail lamp.
What accessories are included with the 110RMG?
The pack includes a grommet and plug for a complete, sealed recessed installation. The 3-pin connector is not included and must be sourced separately.
How does the 110RMG compare to the 110RMB stop/tail lamp?
The 110RMG includes a grommet and plug for a sealed recessed installation, making it ready to fit straight out of the pack. The 110RMB is the same lamp in the same form factor without grommet accessories.
What is the IP rating on the 110RMG?
The 110RMG is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed trailer and truck body mounting.
What warranty does the 110RMG carry?
Not specified in available supplier data — confirm with LED Autolamps or F.A.E. before publishing.
Weight
0.5 kg
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
ADR Approved 12/24V Round Stop/Tail Lamp with Clear Lens Low-Profile Recessed Mount
Product Overview
The LED Autolamps 102RCM is a 12/24V round stop/tail lamp with a clear lens, designed for low-profile recessed mounting on trailers, trucks, and commercial vehicles. Measuring 130mm in diameter at just 12mm deep, it delivers a flush, clean finish the red stop/tail output activates via the LEDs when energised, while the lens appears clear when inactive.
Surface bases are available for installations requiring surface mounting rather than a recessed fit. ADR Australian road approved, IP67 rated, and backed by a 5-year warranty, the 102RCM is the multi-voltage counterpart to the 12V-only 102RC.
Features & Benefits
Clear lens when inactive — presents a clean, colourless appearance at rest; red stop/tail colour activates when the lamp is energised
Low-profile recessed mount — 12mm depth sits flush with the mounting panel for a clean, integrated finish
Surface bases available — for installations requiring surface mounting rather than recessed fitting; contact F.A.E. for compatible surface base options
ADR Australian road approved — meets Australian Design Rules for legal on-road use as a stop/tail lamp
IP67 rated — fully sealed against dust and water immersion, built for exposed outdoor and transport environments
12/24V multi-voltage — compatible with both 12V light vehicles and 24V heavy transport without modification
5-year warranty — backed by LED Autolamps' full warranty programme
Technical Specs
Specification
Detail
SKU
102RCM
Lamp Type
Stop / Tail
Lens Colour
Clear
Voltage Range
12V / 24V
Diameter
130mm
Depth
12mm
Mounting
Low-profile recessed (surface base available)
Protection Rating
IP67
Compliance
ADR
Warranty
5 years
Compatible With / Goes Well With
Trailers, caravans, trucks, and commercial vehicles requiring recessed stop/tail lamps
12V light vehicles and 24V heavy transport applications
Trailer builds requiring ADR-approved stop/tail lighting with a clear lens finish
LED Autolamps 102ACM clear lens 12/24V indicator lamp (matching clear lens and voltage range)
Compatible surface mount bases (available separately — confirm with F.A.E.)
LED Autolamps wiring harnesses and trailer lighting accessories
Frequently Asked Questions
Is the 102RCM approved for road use in Australia?
Yes. The LED Autolamps 102RCM is ADR Australian road approved, meeting Australian Design Rules requirements for legal on-road use as a stop/tail lamp.
How does the 102RCM differ from the 102RC?
The 102RCM operates on both 12V and 24V systems, making it suitable for heavy transport as well as light vehicles. The 102RC is a 12V-only lamp. Both share the same 130mm round clear lens recessed mount form factor.
What mounting options are available for the 102RCM?
The 102RCM is designed for low-profile recessed mounting. Surface bases are also available for surface mount installations — contact F.A.E. for compatible options.
What is the IP rating on the 102RCM?
The 102RCM is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed trailer and truck body mounting.
What warranty does the 102RCM carry?
The 102RCM is backed by a 5-year warranty from LED Autolamps.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Crisp Amber Visibility for Trucks, Trailers, and Caravans Clear Lens, Coloured LEDs, ADR Approved.
Product Overview
The LED Autolamps 86AM is a compact, low-profile amber marker light designed for trucks, semi-trailers, caravans, and heavy vehicles. Featuring a clear lens with coloured LEDs, it delivers bold, high-contrast amber illumination that cuts through glare and low-light conditions a cleaner, more modern alternative to traditional coloured-lens markers.
Built for dual-voltage operation across 12V and 24V systems, the 86AM suits light commercials and heavy transport vehicles without modification. The stainless steel bezel and IP67 waterproof rating ensure long-term durability across Australian conditions from coastal humidity to outback heat and corrugated station tracks.
Key Specifications
Voltage range: 12V – 24V DC (dual voltage compatible)
Colour: Amber
Lens type: Clear lens with coloured LEDs
Dimensions: 86mm (L) × 31mm (W) × 10mm (D)
IP rating: IP67 — fully dust-tight; immersion-resistant to 1m depth for 30 minutes
Compliance: ADR Road Approved
Mount type: Permanent mount
Bezel finish: Stainless steel
Light type: LED
Light style: Marker light
Sold as: Each
Features & Benefits
Clear Lens with Coloured LEDs — Delivers sharp, high-contrast amber output while the clear lens maintains a clean, contemporary appearance when unlit — a popular choice for custom truck and trailer builds that prioritise aesthetics alongside compliance.
ADR Road Approved — Meets Australian Design Rules for on-road use. Fit it, connect it, and drive — full road-legal compliance from day one, no third-party sign-off required.
IP67 Waterproof & Dustproof — Completely sealed against dust and capable of withstanding water immersion to 1 metre for 30 minutes. Built for river crossings, heavy rain, and high-pressure workshop wash-downs.
12V – 24V Dual Voltage — Works natively across both light vehicle and heavy transport electrical systems. A single part number covers your entire fleet or mixed-vehicle setup without converters or rewiring.
Low Profile, Permanent Mount Design — At just 10mm deep, the 86AM sits flush against any body panel or trailer rail, minimising wind resistance and snagging risk in tight clearance applications.
Stainless Steel Bezel — Corrosion-resistant finish suited to coastal, marine-adjacent, and high-humidity environments, with a premium truck-style aesthetic to complement modern builds.
Popular Truck Style — Purpose-designed to suit late-model commercial vehicle and custom trailer builds. A go-to for fleet operators and fabricators who want ADR-compliant marker lighting that looks the part.
Technical Specs
Specification
Detail
Voltage
12V – 24V DC
Colour
Amber
Lens Type
Clear lens with coloured LEDs
Length
86mm
Width
31mm
Depth / Thickness
10mm
Light Type
LED
Light Style
Marker Light
Mount Type
Permanent
Bezel Material
Stainless Steel
IP Rating
IP67
Compliance
ADR Road Approved
Sold As
Each
Warranty
Confirm with supplier
Compatible With / Goes Well With
Suitable vehicle and trailer types:
Trucks and semi-trailers (12V and 24V systems)
B-doubles and road trains
Caravans and camper trailers
Box trailers and flatbed trailers
Horse floats and stock trailers
Buses and coaches
Heavy haulage and plant transport vehicles
Custom trailer builds requiring ADR-compliant amber marker lighting
Pairs well with:
Other LED Autolamps marker, clearance, and tail light products
LED Autolamps wiring harness accessories
Frequently Asked Questions
Is the LED Autolamps 86AM ADR compliant for use on Australian roads?
Yes. The 86AM carries full ADR (Australian Design Rules) road approval, making it legal for fitment on vehicles operated on Australian public roads, highways, and national transport corridors.
What is the advantage of a clear lens with coloured LEDs over a coloured lens?
A clear lens with coloured LEDs gives a clean, unlit appearance when the light is off, offering a more modern aesthetic for custom builds while delivering the same compliant amber output when illuminated.
Will the 86AM work on both 12V and 24V electrical systems?
Yes. The 86AM operates natively across the 12V to 24V range, covering passenger vehicles, light commercials, and heavy trucks without any voltage conversion or additional components.
What does the IP67 rating mean in practical terms?
IP67 means the unit is completely sealed against dust and can withstand submersion to 1 metre for up to 30 minutes — suitable for river crossings, heavy downpours, and pressure wash maintenance.
What warranty does the LED Autolamps 86AM carry?
The supplier data contains conflicting warranty information and this has not been confirmed. Please contact LED Autolamps or your authorised reseller directly for accurate warranty terms before purchasing.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
ADR Approved 12V Round Amber Indicator Lamp with Low-Profile Recessed Mount IP67 Rated
Product Overview
The LED Autolamps 102A is a 12V round indicator lamp with an amber lens, designed for low-profile recessed mounting on trailers, trucks, and commercial vehicles. At 130mm in diameter and just 12mm deep, it sits flush with the panel surface for a clean, unobtrusive finish that suits a wide range of trailer and tray body builds.
ADR road approved and rated IP67, the 102A delivers reliable, road-legal indicator output in a compact, weatherproof package suited to exposed outdoor and transport environments.
Features & Benefits
Low-profile recessed mount — 12mm depth sits flush with the mounting panel for a clean, integrated appearance on trailer and truck bodies
130mm round form factor — a widely used size that suits standard recessed cutouts on trailers, caravans, and commercial vehicles
Amber lens — delivers correct amber indicator output for rear and side indicator applications
ADR road approved — meets Australian Design Rules requirements for legal on-road use as an indicator lamp
IP67 rated — fully sealed against dust and water immersion, built for exposed outdoor and transport environments
12V — designed specifically for 12V trailer and vehicle electrical systems
Technical Specs
Specification
Detail
SKU
102A
Lamp Type
Indicator
Lens Colour
Amber
Voltage
12V
Diameter
130mm
Depth
12mm
Mounting
Low-profile recessed
Protection Rating
IP67
Compliance
ADR
Warranty
1 year
Weight
0.4 kg
Compatible With / Goes Well With
Trailers, caravans, trucks, and commercial vehicles requiring recessed indicator lamps
12V trailer and vehicle electrical systems
Trailer builds requiring ADR-approved indicator lighting
LED Autolamps wiring harnesses and trailer lighting accessories
Frequently Asked Questions
Is the 102A approved for road use in Australia?
Yes. The LED Autolamps 102A is ADR road approved, meeting Australian Design Rules requirements for legal on-road use as an indicator lamp.
What mounting style does the 102A use?
The 102A is designed for low-profile recessed mounting, sitting just 12mm deep into the panel for a flush, clean finish on trailer and truck bodies.
What is the IP rating on the 102A?
The 102A is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed trailer and truck body mounting.
Is the 102A compatible with 24V systems?
No. The 102A is a 12V-only lamp and is not rated for 24V applications. For a 12/24V equivalent, check the LED Autolamps 110AMB or similar multi-voltage round indicator lamps.
What warranty does the 102A carry?
The 102A is backed by a 1-year warranty from LED Autolamps.
Weight
0.4 kg
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
ADR Approved 49 LED Square Stop/Tail Lamp with Clip-In Replaceable Lens and 5-Year Warranty
Product Overview
The LED Autolamps 100RM is a compact 12/24V square stop/tail lamp fitted with 49 LEDs, supplied with a surface mount bracket and 30cm wire. The classic square 100 series design measures 122mm x 122mm x 31mm, making it a versatile fit for trailers, trucks, caravans, and tray body applications where a reliable, road-legal stop/tail lamp is needed.
The clip-in replaceable lens allows for quick lens swaps without replacing the full unit, keeping maintenance simple and cost-effective. ADR road approved and rated IP67, the 100RM is backed by a 5-year warranty a strong indicator of the build quality LED Autolamps brings to this proven series.
Features & Benefits
49 LEDs — high LED count delivers bright, consistent stop and tail output for strong rear visibility across all conditions
Original square series design — the proven 100 series form factor suits trailers, caravans, trucks, and tray bodies with a clean, low-profile footprint
Clip-in replaceable lens — lens swaps independently from the housing, reducing replacement costs and keeping downtime minimal when a lens is damaged
ADR road approved — meets Australian Design Rules for legal on-road use across Australia
IP67 rated — fully sealed against dust and water immersion, built for exposed outdoor and transport environments
12/24V multi-voltage — compatible with both 12V light vehicles and 24V heavy transport without modification
Bracket and 30cm wire included — ready to mount straight out of the pack
5-year warranty — backed by LED Autolamps' full warranty programme for confidence in the long-term
Technical Specs
Specification
Detail
SKU
100RM
Lamp Type
Stop / Tail
LED Quantity
49
Voltage Range
12V / 24V
Dimensions
122mm x 122mm x 31mm
Cable Length
300mm
Protection Rating
IP67
Approval
ADR
Lens
Clip-in replaceable
Mounting
Surface mount bracket (included)
Warranty
5 years
Compatible With / Goes Well With
Trailers, caravans, trucks, and tray body applications
12V light vehicles and 24V heavy transport applications
Trailer builds requiring ADR-approved stop/tail lighting
LED Autolamps wiring harnesses and trailer lighting accessories
Frequently Asked Questions
Is the 100RM approved for road use in Australia?
Yes. The LED Autolamps 100RM is ADR road approved, meeting Australian Design Rules requirements for legal on-road use across Australia.
What does the clip-in replaceable lens mean for maintenance?
The lens clips out independently from the housing, so it can be replaced without swapping the entire lamp unit — saving cost and reducing installation time in the field.
What is the IP rating on the 100RM?
The 100RM is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed trailer, caravan, and truck body mounting.
Does the 100RM come with a bracket and wiring?
Yes. The 100RM is supplied with a surface mount bracket and a 30cm wire, making it ready to install straight out of the pack.
What warranty does the 100RM carry?
The 100RM is backed by a 5-year warranty from LED Autolamps, reflecting the quality and durability of the 100 series design.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Similar Products Aerpro SMD16R 16X Super LED Lamp Red Suit Festoon/ $19.99 Aerpro SMD16W 16X Super LED Lamp White Suit Festoo $18.45 Aerpro SMD1MB Flexible SMD LED Strip Lighting 12V $12.99 Aerpro SMD1MW Flexible SMD LED Strip Lighting 12V $12.99 Aerpro SMD3MB Flexible SMD LED Strip Lighting 12V $34.99
Legendary Products & Support From Authorized Dealers
When you choose Aerpro, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Aerpro dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Aerpro's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Aerpro dealer today!
