Rockford Fosgate T3S1-19 Power 19" T3 Single 1-Ohm Superwoofer 19 Inches, 1-Ohm Ready, Maximum Output Product Overview The Rockford Fosgate T3S1-19 is a 19" single 1-ohm superwoofer from the flagship Power T3 series the 1-ohm stable counterpart to the T3S2-19, and equally the largest, most powerful subwoofer Rockford Fosgate has ever built. Sharing every technology, construction specification, and performance characteristic of the T3S2-19, the T3S1-19 is differentiated solely by its single 1-ohm voice coil configuration presenting a direct 1-ohm load to the amplifier for maximum power extraction from 1-ohm stable mono amplifiers without any wiring configuration required. The complete T3 superwoofer technology stack is present: 19 inches of effective radiating cone area, dual gap multi-pole neodymium push/pull motor structure, single layer edge wound aluminium 5" voice coil with push/pull dual windings, three-layer glass fibre/Aramid honeycomb/glass fibre composite cone, injection-moulded foam surround with VAST technology, proprietary surround mechanical clamping ring, dual Nomex progressive spiders with integrated lead wires, aluminium die-cast basket with integrated heat sink fins and venting, and custom 4 AWG push spring terminals. Integrated die-cast aluminium trim ring included. Key Specifications Driver size: 19" Voice coil configuration: Single 1-ohm Motor structure: Dual gap multi-pole neodymium push/pull Voice coil: Single layer edge wound aluminium 5"; push/pull dual windings Cone: Three-layer glass fibre / Aramid honeycomb / glass fibre composite Dust cap: Aluminium Surround: Injection-moulded foam with VAST technology Surround retention: Proprietary mechanical clamping ring Spiders: Dual Nomex progressive with integrated lead wires Basket: Aluminium die-cast with integrated heat sink fins and venting Input terminals: Custom push spring insulated 4 AWG Trim ring: Integrated die-cast aluminium Power handling: Confirm with supplier Frequency response: Confirm with supplier Sensitivity: Confirm with supplier Xmax: Confirm with supplier Mounting depth: Confirm with supplier Cutout diameter: Confirm with supplier Features & Benefits Single 1-ohm voice coil direct 1-ohm load, maximum amplifier power: The defining differentiator from the T3S2-19. A single 1-ohm voice coil presents a direct 1-ohm load to any 1-ohm stable mono amplifier no parallel or series wiring required. For builds where a 1-ohm stable high-output mono amplifier is already specified, the T3S1-19 is the direct T3 superwoofer choice, extracting maximum rated power from the amplifier in the simplest possible wiring configuration. 19" effective radiating cone area the largest Rockford Fosgate has ever built: At 19 inches, the T3S1-19 produces more cone surface area than any subwoofer Rockford Fosgate has ever manufactured. More cone area means more air displaced per unit of excursion delivering deeper, higher-output bass from a single driver than any smaller-diameter subwoofer can match at equivalent excursion levels. Dual gap multi-pole neodymium push/pull motor structure: The push/pull motor configuration places voice coil windings in two magnetic gaps simultaneously one pushing and one pulling the cone effectively doubling the active motor force contribution relative to a single-gap design. Neodymium magnets provide the strongest magnetic field per unit mass available, enabling an exceptionally powerful and efficient motor assembly within the physical constraints of a 19" driver. Single layer edge wound aluminium 5" voice coil with push/pull dual windings: Edge winding positions the aluminium ribbon flat against the former with no air gaps between turns the most thermally efficient winding method available, allowing heat generated during high-power input to transfer rapidly to the former and dissipate. The 5" diameter voice coil provides a large surface area for heat dissipation and a long winding length for high motor force. Push/pull dual windings in the dual-gap motor work in concert to maximise driving force and linearity across the full excursion range. Three-layer glass fibre/Aramid honeycomb/glass fibre composite cone: A sandwich composite structure combining two stiff glass fibre skins with an Aramid (Kevlar-family) honeycomb core. The honeycomb core provides an extremely high stiffness-to-mass ratio the cone behaves as a true piston at the high excursion levels a 19" driver operates at, without the mass penalty of a solid composite. Aramid honeycomb is the same structural concept used in aerospace panel applications. Injection-moulded foam surround with VAST technology: The injection-moulded process produces a foam surround with consistent cell structure and density throughout, delivering the compliance uniformity of a precision rubber surround with the lighter mass of foam. VAST repositions the surround attachment to maximise effective radiating cone area across the full 19" diameter. Proprietary surround mechanical clamping ring: Physically secures the surround to the cone and basket simultaneously, providing a retention system beyond adhesive bonding alone. At the excursion levels and driving forces a 19" push/pull motor generates, the clamping ring ensures surround attachment integrity over the long term. Dual Nomex progressive spiders with integrated lead wires: Dual progressive spiders provide linear restoring force symmetry across the full, considerable excursion range of a 19" push/pull motor driver. Integrated lead wires eliminate the separate tinsel lead removing a common failure point in a driver engineered for extreme excursion. Aluminium die-cast basket with integrated heat sink fins and venting: Active heat dissipation from the motor and voice coil during sustained high-power use. At the power levels the T3S1-19 is designed to handle, passive thermal management at the basket level is a meaningful contributor to long-term reliability. Custom push spring insulated 4 AWG terminals: The heaviest terminal gauge in the Rockford Fosgate subwoofer range, appropriate for the extraordinary current demands of a 1-ohm superwoofer at high power input. 4 AWG push spring terminals allow fast, secure wiring for the cable gauges a system of this scale demands. Integrated die-cast aluminium trim ring: Provides a finished, professional installation appearance at the cutout. Integrated into the basket casting for a permanent, rigid finish. Technical Specs Specification Detail SKU T3S1-19 Brand Rockford Fosgate Driver Size 19" Voice Coil Configuration Single 1-ohm Motor Structure Dual gap multi-pole neodymium push/pull Voice Coil Single layer edge wound aluminium 5"; push/pull dual windings Cone Three-layer glass fibre / Aramid honeycomb / glass fibre composite Dust Cap Aluminium Surround Injection-moulded foam with VAST technology Surround Retention Proprietary mechanical clamping ring Spiders Dual Nomex progressive with integrated lead wires Basket Aluminium die-cast with integrated heat sink fins and venting Input Terminals Custom push spring insulated 4 AWG Trim Ring Integrated die-cast aluminium Power Handling Confirm with supplier Frequency Response Confirm with supplier Sensitivity Confirm with supplier Xmax Confirm with supplier Mounting Depth Confirm with supplier Cutout Diameter Confirm with supplier Shipping Weight Confirm with supplier Warranty Confirm with supplier Compatible With The highest-output mono amplifiers available, stable at 1 ohm confirm recommended amplifier power with Rockford Fosgate T3S1-19 documentation Rockford Fosgate Power T3 series mono amplifiers (1-ohm stable) Custom ported and sealed enclosures designed specifically for the T3S1-19 enclosure volume and port specifications must be confirmed with Rockford Fosgate documentation before building Dedicated audio vehicles, show builds, and competition SPL installations with purpose-built enclosure bays Rockford Fosgate 4 AWG and heavy-gauge power wiring kits appropriate for high-current 1-ohm superwoofer installations High-capacity capacitors and upgraded electrical systems appropriate for the current demands of a 1-ohm superwoofer at rated power Frequently Asked Questions What is the difference between the T3S1-19 and T3S2-19? Both are 19" T3 superwoofers with identical construction, motor technology, and performance specifications. The T3S1-19 has a single 1-ohm voice coil presenting a direct 1-ohm load, while the T3S2-19 has a single 2-ohm voice coil presenting a direct 2-ohm load. Choose the T3S1-19 when your amplifier is 1-ohm stable and 1-ohm wiring is the system target; choose the T3S2-19 for 2-ohm stable amplifier pairings. What amplifier does the T3S1-19 require? The T3S1-19 presents a direct 1-ohm load and requires the highest-output mono amplifier available that is stable at 1 ohm. Confirm the recommended amplifier power rating with Rockford Fosgate's official T3S1-19 documentation or a qualified installer before specifying an amplifier power handling figures for this driver must be confirmed with the supplier before system design. What is the push/pull motor structure and why does it matter for a 19" superwoofer? The dual gap push/pull motor places voice coil windings in two separate magnetic gaps simultaneously one gap's field pushes the cone while the other pulls, effectively doubling the active driving force compared to a single-gap design. For a 19" cone that requires significantly more motor force to control and drive than a standard subwoofer, the push/pull architecture is fundamental to achieving the output and linearity the T3S1-19 is designed to deliver. What enclosure does the T3S1-19 require? The T3S1-19 requires a custom enclosure built specifically to Rockford Fosgate's published enclosure specifications for this driver. Standard subwoofer box calculators and generic designs are not appropriate for a 19" superwoofer with a push/pull motor. Confirm sealed and ported enclosure volumes and port tuning with Rockford Fosgate documentation or a qualified installer before building. Is the T3S1-19 suitable for a street-driven Australian vehicle? The T3S1-19 is designed for dedicated audio vehicles, show builds, and competition SPL installations where a purpose-built enclosure bay and upgraded electrical system can be properly engineered. It can be installed in a street-driven vehicle with appropriate professional fabrication, but demands a complete purpose-designed system build professional installation and system design are strongly recommended. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

1" Aluminium Dome Neodymium Tweeter Kit 75W RMS, Internal Mylar Phase Plug, Audiophile External Crossover with Protection and Bypass Resistor. 3-Level Attenuation. Product Overview The Rockford Fosgate Power T2T-S is a 1" aluminium dome tweeter kit rated at 75W RMS designed for listeners who prefer the bright, detailed, forward high-frequency character of an aluminium dome. The kit includes two tweeters with dedicated external crossovers, trim rings, and mounting hardware. The aluminium dome is driven by a neodymium motor for high sensitivity and responsive transient performance. An internal Mylar phase plug sits behind the dome to control acoustic output from the cavity behind the diaphragm improving off-axis dispersion and reducing undesirable rear-wave resonances. The external audiophile-grade crossover uses 5% tolerance poly-capacitors and air-core inductors, and includes a built-in protection and bypass resistor a circuit that protects the tweeter from overdrive while ensuring the tweeter circuit remains active (never goes completely silent) when protection engages. Three levels of tweeter attenuation and on-axis/off-axis mounting configurations provide installation flexibility. Key Specifications Tweeter size: 1 inch (25mm — implied) Dome material: Aluminium Motor: Neodymium Suspension: Integral Phase plug: Internal Mylar Power handling (RMS): 75W per tweeter (confirmed) Peak power: Not specified — confirm with Rockford Fosgate Impedance: Not specified — confirm with Rockford Fosgate Sensitivity: Not specified — confirm with Rockford Fosgate Frequency response: Not specified — confirm with Rockford Fosgate Crossover: External audiophile grade — 5% poly-capacitors and air-core inductors Crossover protection: Built-in protection and bypass resistor ("100% playtime") Tweeter attenuation: 3 levels (dB values not specified — confirm with Rockford Fosgate) Crossover point: Not specified — confirm with Rockford Fosgate Crossover slope: Not specified — confirm with Rockford Fosgate Mounting configurations: On-axis and off-axis Recessed mount hole size: 1-3/4" hole saw Trim rings: Included Mounting hardware: Included Sold as: Pair (2 tweeters — confirmed in description) Warranty: Not specified — confirm with Rockford Fosgate Features & Benefits 1" Aluminium Dome with Neodymium Motor — The aluminium dome diaphragm is stiff and light — producing a bright, highly detailed, and forward high-frequency character with fast transient response. The neodymium motor provides high magnetic flux in a compact assembly for high sensitivity. Internal Mylar Phase Plug — The Mylar phase plug is positioned behind the dome inside the tweeter cavity. It controls the acoustic output from the rear of the dome — reducing cavity resonances and improving off-axis frequency response consistency. Mylar (polyimide film) is lightweight and dimensionally stable, avoiding acoustic interference with the dome itself. External Audiophile Crossover with Built-In Protection and Bypass Resistor — The dedicated external crossover uses 5% tolerance poly-capacitors and air-core inductors for transparent, accurate frequency division. The built-in protection circuit safeguards the tweeter from excessive power input. The bypass resistor ensures that when protection engages, the tweeter circuit remains closed — the tweeter does not go silent but instead operates at a reduced, protected level for continuous audio output ("100% playtime"). 3 Levels of Tweeter Attenuation — Three selectable attenuation settings allow the tweeter output to be adjusted relative to the woofer level — compensating for sensitivity differences and for tweeter positions closer to the listening position. Specific dB values are not confirmed in the supplier data — pull from the official Rockford Fosgate T2T-S datasheet. On-Axis and Off-Axis Mounting — The tweeter supports both direct listening position placement (on-axis) and angled mounting for wider dispersion (off-axis) without additional hardware. 1-3/4" Recessed Hole Saw Mount — Standard 1-3/4" hole saw for a clean, flush installation in door panels, A-pillars, and dash trim. Trim Rings Included — For a finished appearance at the tweeter mounting location. Sold as a Pair — Two tweeters per kit. Technical Specs Specification Detail Brand Rockford Fosgate Part Number T2T-S Series Power Tweeter Size 1 inch (25mm implied) Dome Material Aluminium Motor Neodymium Suspension Integral Phase Plug Internal Mylar Power Handling (RMS) 75W per tweeter ✓ Peak Power Not specified — confirm with Rockford Fosgate Impedance Not specified — confirm with Rockford Fosgate Sensitivity Not specified — confirm with Rockford Fosgate Frequency Response Not specified — confirm with Rockford Fosgate Crossover External Audiophile Grade — 5% poly-caps, air-core inductors Crossover Protection Built-in protection + bypass resistor (100% playtime) ✓ Tweeter Attenuation 3 levels ✓ (dB values not specified) Crossover Point Not specified — confirm with Rockford Fosgate Crossover Slope Not specified — confirm with Rockford Fosgate Mounting Options On-axis and Off-axis Recessed Mount 1-3/4" hole saw ✓ Trim Rings Included ✓ Mounting Hardware Included ✓ Sold As Pair (2 tweeters) ✓ Warranty Not specified — confirm with Rockford Fosgate Compatible With / Goes Well With Suitable for: Power series component system builds requiring a dedicated aluminium dome tweeter Any front stage installation where a detailed, bright aluminium dome character is the preferred choice Upgrading existing Power series coaxial installations with independent tweeters Installations requiring the active tweeter protection of the bypass resistor circuit Pairs well with: Rockford Fosgate Power series woofers in a component build Rockford Fosgate T400-4, T600-4, or T1000-4AD 4-channel amplifiers Frequently Asked Questions What is the internal Mylar phase plug and what does it do? The phase plug is a lightweight Mylar (polyimide film) component positioned inside the tweeter cavity behind the aluminium dome. It controls the acoustic output from the rear of the dome, reducing cavity resonances that can cause uneven frequency response and improving the consistency of the tweeter's off-axis dispersion. The result is a more even frequency response across the listening area beyond the direct on-axis position. What does the built-in protection and bypass resistor do? The protection circuit monitors the signal level and activates when the tweeter receives excessive power input. The bypass resistor ensures that when protection engages, the tweeter circuit remains closed rather than going completely silent — the tweeter continues to play at a reduced, protected power level. Rockford Fosgate describes this as "100% playtime" — the tweeter maintains continuous audio output even during protection events. What are the three levels of tweeter attenuation? The three attenuation settings reduce the tweeter output level relative to the woofer by selectable amounts, compensating for the sensitivity difference between the drivers or for the tweeter being positioned closer to the listening position. Specific dB values for the three levels are not confirmed in the supplier data — confirm from the official Rockford Fosgate T2T-S datasheet. What is the confirmed power handling for the T2T-S? 75W RMS per tweeter is confirmed. Impedance, sensitivity, and frequency response must be confirmed from the official Rockford Fosgate T2T-S datasheet. What is the difference between aluminium dome and fabric dome tweeters? An aluminium dome tweeter is stiff and light — producing a bright, detailed, forward high-frequency character with fast transient response. A fabric dome tweeter is softer — producing a warmer, smoother, more natural-sounding treble that is generally considered more forgiving for extended listening. Buyers who prefer detail and clarity tend to favour aluminium; buyers who prioritise warmth and long listening comfort tend to prefer fabric. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

Rockford Fosgate T2S2-16 Power 16" T2 Single 2-Ohm Subwoofer 16 Inches, Ground-Up Engineering, Built for Serious Output Product Overview The Rockford Fosgate T2S2-16 is a 16" single 2-ohm subwoofer from the Power T2 series, featuring 16 inches of effective radiating cone area and purpose-designed ground-up engineering developed to out-perform its predecessors in every measurable dimension. Not a parts-bin driver the T2S2-16 was designed from scratch by one of the leading loudspeaker engineers in the world, incorporating dealer and enthusiast feedback to produce a larger, more capable, and more comprehensively specified 16" subwoofer than anything preceding it in the T2 lineage. The T2S2-16 is built around a triple stack segmented ferrite motor structure a high-force motor architecture that delivers exceptional linearity across the full excursion range. Dual Nomex progressive spiders manage the cone travel demands of a 16" driver, while the integrated aluminium heat-sinking shorting ring (IDHS) provides both inductive linearisation and active thermal management for sustained high-power use. The three-layer glass fibre/Aramid honeycomb/glass fibre composite cone, injection-moulded foam surround with VAST technology, proprietary surround mechanical clamping ring, aluminium die-cast basket with integrated heat sink fins, and custom 8 AWG push spring terminals complete a 16" driver built without compromise. A detachable die-cast aluminium trim ring is included. Installation note: this driver is exceptionally heavy two-person installation is strongly recommended. Key Specifications Driver size: 16" Voice coil configuration: Single 2-ohm Motor structure: Triple stack segmented ferrite Voice coil: Single layer edge wound aluminium 4" Cone: Three-layer glass fibre / Aramid honeycomb / glass fibre composite Dust cap: Aluminium Surround: Injection-moulded foam with VAST technology Surround retention: Proprietary mechanical clamping ring Spiders: Dual Nomex progressive with integrated lead wires Basket: Aluminium die-cast with integrated heat sink fins Shorting ring: Integrated aluminium heat-sinking (IDHS) Pole piece: Vented Input terminals: Custom push spring insulated 8 AWG Trim ring: Detachable die-cast aluminium (included) Power handling: Confirm with supplier Frequency response: Confirm with supplier Sensitivity: Confirm with supplier Xmax: Confirm with supplier Mounting depth: Confirm with supplier Cutout diameter: Confirm with supplier Features & Benefits 16" effective radiating cone area ground-up engineered for serious output: At 16 inches, the T2S2-16 delivers substantially more cone surface area than a 12" or 15" driver, moving proportionally more air per unit of excursion. Designed from the ground up by a leading loudspeaker engineer not assembled from existing components to deliver a clear performance step above the T2 series predecessors. Triple stack segmented ferrite motor structure: Three stacked ferrite magnet segments provide a powerful, high-force motor assembly with exceptional linearity across the full excursion range. The segmented architecture reduces eddy current losses and inductance variation compared to a solid single-magnet ferrite motor, contributing to lower distortion and more accurate bass reproduction at high output levels. Integrated aluminium heat-sinking shorting ring (IDHS): The aluminium shorting ring performs two functions simultaneously: it reduces inductance variation across the excursion range (improving linearity and reducing distortion), and it acts as a heat sink to draw thermal energy away from the voice coil gap during sustained high-power use. A critical reliability feature for a driver designed for sustained high-output operation. Single layer edge wound aluminium 4" voice coil: Edge winding positions the aluminium ribbon flat against the former with no air gaps between turns the most thermally efficient winding method, allowing heat from high-power input to transfer rapidly to the former and dissipate. The 4" diameter provides a large surface area for heat dissipation and a long winding length for high motor force. Three-layer glass fibre/Aramid honeycomb/glass fibre composite cone: A sandwich composite combining two stiff glass fibre skins with an Aramid (Kevlar-family) honeycomb core. The honeycomb core delivers an extremely high stiffness-to-mass ratio, maintaining pistonic cone behaviour at the excursion levels a 16" driver produces without the mass penalty of a solid composite cone. Injection-moulded foam surround with VAST technology: Injection-moulding produces a foam surround with consistent cell structure and density throughout, delivering precision compliance uniformity across the full excursion range. VAST repositions the surround attachment to maximise effective radiating area across the full 16" diameter. Proprietary surround mechanical clamping ring: Physically secures the surround to the cone and basket simultaneously, providing surround retention beyond adhesive bonding alone essential at the excursion levels and motor forces a 16" triple stack ferrite driver generates during sustained high-output use. Dual Nomex progressive spiders with integrated lead wires: Dual progressive spiders provide linear restoring force symmetry across the considerable excursion range of a 16" driver. Integrated lead wires eliminate the separate tinsel lead, removing a common failure point in a driver engineered for large cone travel. Aluminium die-cast basket with integrated heat sink fins: Active heat dissipation from the motor assembly during sustained high-power use. The heat sink fins increase surface area for passive thermal management a meaningful contributor to long-term reliability at the power levels this driver is designed to handle. Vented pole piece: Air channels through the pole piece reduce thermal compression and back-pressure behind the cone at high excursion, improving linearity and power handling consistency across the operating range. Custom push spring insulated 8 AWG terminals: Heavy-gauge 8 AWG terminals appropriate for the significant current demands of a 16" high-output subwoofer. Push-spring design allows fast, clean wiring for the cable gauges a system of this scale requires. Single 2-ohm voice coil simplified wiring: Presents a direct 2-ohm load to the amplifier. No wiring configuration required connect a 2-ohm stable high-output mono amplifier directly to the 8 AWG terminals. Detachable die-cast aluminium trim ring included: Provides a clean, finished installation appearance at the cutout. Detachable for bare-driver installations where a trim ring is not required. Technical Specs Specification Detail SKU T2S2-16 Brand Rockford Fosgate Driver Size 16" Voice Coil Configuration Single 2-ohm Motor Structure Triple stack segmented ferrite Voice Coil Single layer edge wound aluminium 4" Shorting Ring Integrated aluminium heat-sinking (IDHS) Cone Three-layer glass fibre / Aramid honeycomb / glass fibre composite Dust Cap Aluminium Surround Injection-moulded foam with VAST technology Surround Retention Proprietary mechanical clamping ring Spiders Dual Nomex progressive with integrated lead wires Basket Aluminium die-cast with integrated heat sink fins Pole Piece Vented Input Terminals Custom push spring insulated 8 AWG Trim Ring Detachable die-cast aluminium (included) Power Handling Confirm with supplier Frequency Response Confirm with supplier Sensitivity Confirm with supplier Xmax Confirm with supplier Mounting Depth Confirm with supplier Cutout Diameter Confirm with supplier Shipping Weight Confirm with supplier Warranty Confirm with supplier Compatible With High-output mono amplifiers stable at 2 ohms confirm recommended amplifier power with Rockford Fosgate T2S2-16 documentation Rockford Fosgate Power T2 and T3 series mono amplifiers Custom ported and sealed enclosures designed specifically for the T2S2-16 confirm enclosure volume and port specifications with Rockford Fosgate documentation before building Dedicated audio vehicles, show builds, and high-output SPL installations with purpose-built enclosure bays Rockford Fosgate 8 AWG and heavy-gauge power wiring kits appropriate for high-current 16" subwoofer installations High-capacity capacitors and upgraded electrical systems appropriate for the current demands of a 16" high-output driver at rated power Frequently Asked Questions What is the difference between the T2S2-16 and the T3 19" superwoofers? The T2S2-16 uses a triple stack segmented ferrite motor structure with an 8 AWG terminal and a detachable trim ring, while the T3S2-19 and T3S1-19 use a dual gap multi-pole neodymium push/pull motor, 4 AWG terminals, and an integrated trim ring. The T3 19" models are the largest drivers Rockford Fosgate has ever built; the T2S2-16 is the step below in the large-format range. Both require purpose-built custom enclosures and high-output mono amplifiers. What amplifier does the T2S2-16 require? The T2S2-16 presents a direct 2-ohm load and requires a high-output mono amplifier stable at 2 ohms. Confirm the recommended amplifier power rating with Rockford Fosgate's official T2S2-16 documentation or a qualified installer before specifying an amplifier power handling figures are not provided in the supplier data and must be confirmed before system design. What is the IDHS shorting ring and what does it do? The integrated aluminium heat-sinking shorting ring (IDHS) performs two functions: it reduces inductance variation across the voice coil's excursion range, improving linearity and lowering distortion, and it acts as a heat sink to draw thermal energy away from the voice coil gap during sustained high-power use directly contributing to long-term power handling reliability. What enclosure does the T2S2-16 require? The T2S2-16 requires a custom enclosure built to Rockford Fosgate's published specifications. Standard subwoofer enclosure calculators and generic designs are not appropriate for a 16" high-output ferrite motor driver. Confirm sealed and ported enclosure volumes and port tuning with Rockford Fosgate documentation or a qualified installer before designing or building. How heavy is the T2S2-16? Exact shipping weight is not provided in the supplier data confirm with your supplier before purchase. Rockford Fosgate explicitly notes this driver is exceptionally heavy, and two-person installation is strongly recommended to avoid injury or damage during handling and fitting. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

13" Power T2 Single 2-Ohm Subwoofer Glass Fibre/Aramid Honeycomb Sandwich Cone, 4" Edge-Wound Aluminium Voice Coil, Triple-Stack Ferrite Motor, IDHS, 8-AWG Terminals. Product Overview The Rockford Fosgate Power T2S2-13 is a 13" effective radiating area Single Voice Coil (SVC) subwoofer the 2-Ohm variant of the T2S1-13 platform. The construction is identical to the T2S1-13 with the sole difference being the 2-Ohm voice coil impedance, which provides broader amplifier compatibility than the 1-Ohm T2S1-13. All confirmed T2 platform construction applies: three-layer glass fibre/aramid honeycomb/glass fibre sandwich cone, aluminium dustcap, VAST injection-moulded foam surround with mechanical clamping ring, dual Nomex progressive spiders, die-cast aluminium frame with integrated heat sink fins, single-layer edge-wound aluminium 4" voice coil, triple-stack segmented ferrite motor, integrated aluminium IDHS shorting ring, vented pole piece, and 8-AWG push spring terminals. Key Specifications Effective radiating diameter: 13 inch (cone + surround) Physical basket diameter: Not confirmed — confirm with Rockford Fosgate Voice coil configuration: Single Voice Coil (SVC) Impedance: Title and SKU indicate 2-Ohm — description says 1-Ohm — confirm with Rockford Fosgate Power handling (RMS): Not stated  Voice coil: Single-layer edge-wound aluminium, 4" Cone: Three-layer glass fibre / aramid honeycomb / glass fibre sandwich Dustcap: Aluminium Surround: Injection-moulded VAST foam, proprietary mechanical clamping ring Spider: Dual Nomex progressive with integrated lead wires Frame: Die-cast aluminium with integrated heat sink fins Motor: Triple-stack segmented ferrite Shorting ring: Integrated aluminium IDHS Pole piece: Vented Input terminals: Custom push spring insulated 8-AWG Trim ring: Detachable die-cast aluminium Enclosure type: Not specified Sensitivity / Fs / Xmax / Qts: Not confirmed Mounting depth: Not confirmed Cutout diameter: Not confirmed Enclosure volume: Not confirmed Sold as: Individual unit Weight: 42.5 kg Warranty: Not confirmed Features & Benefits 13" Effective Radiating Area — Total effective piston area (cone plus surround). Physical basket and cutout dimensions must be confirmed from the official T2S2-13 datasheet. 2-Ohm SVC — Broader Amplifier Compatibility Than T2S1-13 — A 2-Ohm SVC is supported by a wider range of high-output mono amplifiers than the 1-Ohm T2S1-13, which requires amplifiers specifically rated stable at 1-Ohm. Two T2S2-13 units in series = 4-Ohm; two in parallel = 1-Ohm (confirm amplifier stability before using 1-Ohm parallel). Glass Fibre / Aramid Honeycomb / Glass Fibre Sandwich Cone — Aerospace-grade structural composite for maximum stiffness and minimum mass — identical construction to T2S1-13. 4" Edge-Wound Aluminium Voice Coil — Largest voice coil in the catalogue; flat-wound conductor for maximum BL product and thermal capacity. Triple-Stack Segmented Ferrite Motor — Deep, high-flux magnetic gap for the 4" voice coil; segmented construction reduces eddy current losses. IDHS Aluminium Shorting Ring — Dual-function: distortion reduction (inductance variation) and heat conduction through the frame's heat sink fins. Die-Cast Aluminium Frame with Integrated Heat Sink Fins — Direct thermal management from motor gap to air. Dual Nomex Progressive Spiders — Progressive compliance for controlled high-excursion operation. Proprietary Surround Mechanical Clamping Ring — Long-term surround durability under sustained large-amplitude movement. 8-AWG Push Spring Terminals — Heaviest gauge wiring in this catalogue. Technical Specs Specification Detail Brand Rockford Fosgate Part Number T2S2-13 Series Power T2 Effective Radiating Area 13 inch ✓ Physical Basket Diameter Not confirmed Voice Coil Single Voice Coil (SVC) Impedance Title/SKU: 2-Ohm / Description: 1-Ohm — confirm with Rockford Fosgate Power Handling (RMS) Not confirmed Voice Coil Single-layer edge-wound aluminium 4" ✓ Cone Glass Fibre / Aramid Honeycomb / Glass Fibre Sandwich ✓ Dustcap Aluminium ✓ Surround VAST Injection-Moulded Foam + Mechanical Clamping Ring ✓ Spider Dual Nomex Progressive, Integrated Lead Wires ✓ Frame Die-Cast Aluminium + Integrated Heat Sink Fins ✓ Motor Triple-Stack Segmented Ferrite ✓ Shorting Ring Integrated Aluminium IDHS ✓ Pole Piece Vented ✓ Input Terminals Push Spring 8-AWG ✓ Trim Ring Detachable Die-Cast Aluminium ✓ Enclosure Type Not specified All Other Specs Not confirmed Sold As Individual Unit Warranty Not confirmed Weight 42.5 kg Frequently Asked Questions What is the impedance of the T2S2-13? The product title states 2-Ohm and the SKU designation "S2" indicates Single 2-Ohm. The product description text states "a single 1-ohm voice coil" — this appears to be copied from the T2S1-13 (1-Ohm) description without updating the impedance reference. Confirm the correct impedance with Rockford Fosgate before purchasing. What is the difference between T2S2-13 and T2S1-13? Assuming the T2S2-13 is the 2-Ohm variant as indicated by the title and SKU: both are identical 13" T2 subwoofers in construction. The T2S2-13's 2-Ohm impedance suits a broader range of mono amplifiers than the T2S1-13's 1-Ohm, which requires amplifiers specifically rated stable at 1-Ohm. What is the power handling? Not confirmed in the supplier data — same blocker as T2S1-13. Confirm from the official T2S2-13 datasheet. What enclosure is required? Enclosure type not specified. Confirm from the official T2S2-13 datasheet. What amplifier is appropriate? Amplifier guidance cannot be published until the impedance conflict is resolved and the RMS power is confirmed. Confirm both with Rockford Fosgate before purchasing. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

13" Power T2 Single 1-Ohm Subwoofer Glass Fibre/Aramid Honeycomb Sandwich Cone, 4" Edge-Wound Aluminium Voice Coil, Triple-Stack Ferrite Motor, IDHS, 8-AWG Push Spring Terminals. Product Overview The Rockford Fosgate Power T2S1-13 is a 13" effective radiating area Single Voice Coil (SVC) subwoofer with a 1-Ohm impedance from the Power T2 series, designed from the ground up as a high-performance large-format driver. The "13 inches" designation describes the total effective radiating cone area, which includes both the cone and surround assembly the physical basket and cutout dimensions must be confirmed from the official Rockford Fosgate T2S1-13 datasheet. The T2S1-13 introduces several constructions not found elsewhere in this catalogue: a three-layer glass fibre/aramid honeycomb/glass fibre sandwich cone; a single-layer edge-wound aluminium 4" voice coil; a triple-stack segmented ferrite motor structure; a proprietary surround mechanical clamping ring; and 8-AWG custom push spring terminals the heaviest gauge wiring connection in any subwoofer in this batch. The die-cast aluminium frame has integrated heat sink fins and an integrated aluminium IDHS shorting ring. Key Specifications Effective radiating diameter: 13 inch (cone + surround combined) Physical basket diameter: Not confirmed — confirm with Rockford Fosgate Voice coil configuration: Single Voice Coil (SVC) Impedance: 1-Ohm Power handling (RMS): Not stated Voice coil: Single-layer edge-wound aluminium, 4" diameter Cone: Three-layer glass fibre / aramid honeycomb / glass fibre sandwich Dustcap: Aluminium Surround: Injection-moulded foam with VAST, proprietary mechanical clamping ring Spider: Dual Nomex progressive with integrated lead wires Frame: Die-cast aluminium with integrated heat sink fins Motor: Triple-stack segmented ferrite Shorting ring: Integrated aluminium IDHS Pole piece: Vented Input terminals: Custom push spring insulated 8-AWG Trim ring: Detachable die-cast aluminium Enclosure type: Not specified — confirm with Rockford Fosgate Sensitivity: Not specified — confirm with Rockford Fosgate Fs / Xmax / Qts: Not specified — confirm with Rockford Fosgate Mounting depth: Not specified — confirm with Rockford Fosgate Cutout diameter: Not specified — confirm with Rockford Fosgate Enclosure volume: Not specified — confirm with Rockford Fosgate Sold as: Individual unit Weight: Not specified Warranty: Not specified — confirm with Rockford Fosgate Features & Benefits 13" Effective Radiating Area — The T2S1-13's 13" rating describes the total effective piston area (cone plus surround), rather than the conventional cone-only diameter measurement. This is a non-standard format — confirm the physical basket dimensions, cutout diameter, and mounting depth from the official Rockford Fosgate T2S1-13 datasheet before building an enclosure or purchasing a pre-built box. Glass Fibre / Aramid Honeycomb / Glass Fibre Sandwich Cone — A three-layer structural composite cone: glass fibre outer and inner skins provide rigidity, while an aramid honeycomb core (a grid structure of hexagonal cells made from aramid fibre) provides the shear stiffness to resist the out-of-plane forces that cause cone breakup. Aramid honeycomb is used in aerospace and motorsport structural panels. This construction produces a very stiff, low-mass cone for high-excursion bass reproduction. 4" Edge-Wound Aluminium Single Voice Coil — A 4" voice coil is the largest in any subwoofer in this catalogue. Edge-wound construction winds the aluminium conductor wire on its edge (flat-wound), maximising the amount of conductor per unit of axial winding height and increasing the voice coil's force factor (BL). This contributes to the motor's ability to drive the large cone assembly to high excursion levels. Triple-Stack Segmented Ferrite Motor — Three ferrite magnet plates stacked to produce a deep, high-flux magnetic gap suitable for the 4" voice coil. The segmented design uses separate magnet segments rather than a continuous ring — reducing eddy current losses. Ferrite rather than neodymium — selected for the thermal stability and deep magnetic gap appropriate to a sustained high-power, large-format application. Integrated Aluminium IDHS Shorting Ring — The aluminium cap on the pole piece serves dual functions: reducing voice coil inductance variation (distortion reduction) and conducting heat from the magnetic gap into the frame's heat sink fins. Die-Cast Aluminium Frame with Integrated Heat Sink Fins — Direct thermal conduction from the motor gap to the surrounding air through the aluminium frame's heat sink fins — critical for a driver of this power level. Dual Nomex Progressive Spiders — Two progressive-compliance spiders provide controlled suspension across a wide excursion range — the progressive spring rate increases stiffness as the cone approaches excursion limits, protecting the voice coil at high output levels. Proprietary Surround Mechanical Clamping Ring — A mechanical clamping ring is used to secure the surround at the basket edge — a physical fastening method rather than standard adhesive bonding, chosen for long-term durability under the mechanical stress of large-amplitude, high-power cone movement. 8-AWG Push Spring Terminals — The heaviest gauge input terminals in this catalogue — 8-AWG push spring type, accommodating very thick wiring appropriate for the expected high current demand at the T2S1-13's power level. VAST Foam Surround — Injection-moulded foam with VAST geometry for increased effective cone area. Technical Specs Specification Detail Brand Rockford Fosgate Part Number T2S1-13 Series Power T2 Effective Radiating Area 13 inch (cone + surround) ✓ Physical Basket Diameter Not confirmed — confirm with Rockford Fosgate Voice Coil Single Voice Coil (SVC) Impedance 1-Ohm ✓ Power Handling (RMS) Not confirmed Voice Coil Size 4" edge-wound aluminium ✓ Cone Glass Fibre / Aramid Honeycomb / Glass Fibre Sandwich ✓ Dustcap Aluminium ✓ Surround Injection-Moulded VAST Foam, Mechanical Clamping Ring ✓ Spider Dual Nomex Progressive, Integrated Lead Wires ✓ Frame Die-Cast Aluminium with Integrated Heat Sink Fins ✓ Motor Triple-Stack Segmented Ferrite ✓ Shorting Ring Integrated Aluminium IDHS ✓ Pole Piece Vented ✓ Input Terminals Push Spring 8-AWG ✓ Trim Ring Detachable Die-Cast Aluminium ✓ Enclosure Type Not specified — confirm with Rockford Fosgate Sensitivity Not confirmed Fs / Xmax / Qts Not confirmed Mounting Depth Not confirmed Cutout Diameter Not confirmed Enclosure Volume Not confirmed Sold As Individual Unit Weight Not confirmed Warranty Not confirmed   Frequently Asked Questions What does "13 inches effective radiating area" mean? Unlike standard subwoofer diameter measurements (which typically measure the cone only), the T2S1-13's 13" measurement describes the total effective piston area — the combined diameter of both the cone and the surround that contributes to acoustic output. The physical basket is likely larger than 13". Confirm the actual basket diameter and cutout dimensions from the official Rockford Fosgate T2S1-13 datasheet. What is aramid honeycomb and why is it used in the cone? Aramid honeycomb is a grid of hexagonal cells made from aramid fibre (the same material as Kevlar). When sandwiched between glass fibre skins, the honeycomb core provides exceptional structural rigidity against the out-of-plane bending forces that cause cone breakup during high-excursion bass reproduction. The honeycomb structure achieves this with extremely low mass — a key property for a large cone that must move quickly and accurately. What is edge-wound voice coil construction? In a standard voice coil, round wire is wound in circular loops. In an edge-wound (flat-wound) design, the conductor is a flat ribbon wound on its edge — packing more conductor material per unit of winding height. This increases the voice coil's force factor (BL product) and power-handling capacity in the same coil height, contributing to the motor's ability to drive the large 13" cone assembly. What is the power handling of the T2S1-13? Power handling (RMS) is not stated in the supplier description or features list. Confirm from the official Rockford Fosgate T2S1-13 datasheet before purchasing any amplifier or publishing any power matching guidance. What enclosure does the T2S1-13 require? Enclosure type (sealed or vented) is not specified in the supplier data — unlike all other subwoofers in this batch. Confirm from the official Rockford Fosgate T2S1-13 datasheet before building or selecting an enclosure. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less

2,500 Watts, Dual-Amp PowerSync, and MasterSync Control Rockford Fosgate's Flagship Class-BD Constant Power Mono Amplifier. Product Overview The Rockford Fosgate Power T2500-1BDCP is a 2,500W mono amplifier that steps beyond the T1500-1BDCP with two features absent from the lower-wattage models: PowerSync and MasterSync. PowerSync allows two T2500-1BDCP units to be bridged together, delivering a combined 5,000W from a single synchronised pair. MasterSync extends this further one amplifier acts as the master controller for an array of T2500-1BDCP amplifiers, enabling large-format multi-amplifier installations for competition and extreme high-output builds. The core Constant Power, Class-BD, and MOSFET platform is shared with the T1000-1BDCP and T1500-1BDCP adding 1/0 AWG (rather than 4-gauge) power and ground connectors to match the higher current demands of a 2,500W amplifier, a 0°/180° phase switch for precise subwoofer-to-system integration, and blue LED simulated VU signal and power meters for real-time output monitoring. A 24dB/octave crossover, infrasonic filter, and RCA pass-thru complete the subwoofer-dedicated control set. Key Specifications Power output: 2,500W (mono — rated power at specific impedance not confirmed — see Red-flags) Amplifier class: Class-BD Configuration: Monoblock (subwoofer dedicated) Constant Power technology: Yes — up to 25% more power across all impedance loads (supplier-stated) PowerSync: Yes — 2 amplifiers bridged for combined 5,000W output MasterSync: Yes — 1 amplifier controls an array of amplifiers Crossover: 24dB/octave Infrasonic filter: Yes Phase switch: 0°/180° Power supply: MOSFET Output stage: MOSFET Speaker connections: Audiophile grade Power/ground connectors: 1/0 AWG RCA pass-thru outputs: Yes LED meters: Blue LED simulated VU signal and power meters Frequency response: Subwoofer optimised (specific Hz range not confirmed) Signal-to-noise ratio: Not specified — confirm with Rockford Fosgate THD: Not specified — confirm with Rockford Fosgate Input voltage range: Not specified — confirm with Rockford Fosgate Dimensions: Not specified — confirm with Rockford Fosgate Weight: Not specified — confirm with Rockford Fosgate Warranty: Not specified — confirm with Rockford Fosgate Features & Benefits PowerSync — Two Amplifiers, One Combined 2,500W Output — Two T2500-1BDCP amplifiers in PowerSync mode operate as a single synchronised unit, delivering a combined 5,000W. For installations where a single 2,500W amplifier falls short of the subwoofer system's demands, PowerSync provides a clean, factory-supported solution — no external bridging issues or incompatibility risks. MasterSync — Array Control for Multi-Amplifier Builds — In MasterSync configuration, one T2500-1BDCP acts as the master unit and controls the volume and settings of an array of additional amplifiers. This enables large-format high-output installations — competition SPL vehicles, extreme builds — to be managed coherently from a single control point. 1/0 AWG Power and Ground Connectors — Stepping up from the 4-gauge connectors on the 1,000W and 1,500W models, the T2500-1BDCP takes 1/0 AWG (approximately 53mm²) wiring — matching the substantially higher current demands of a 2,500W amplifier. Proper 1/0 AWG wiring is essential to prevent voltage drop and power delivery limitations at full output. 0°/180° Phase Switch — Allows the subwoofer output to be switched between in-phase and out-of-phase relative to the main speakers, enabling precise time-alignment and acoustic integration in complex multi-driver subwoofer systems or when compensating for enclosure placement. Blue LED Simulated VU Signal and Power Meters — Real-time visual feedback of signal level and output power — allowing gain structure optimisation during system setup and providing a visual indication of output activity during use. Constant Power Technology — Up to 25% More Power Across All Impedance Loads — The same Constant Power platform as the T1000-1BDCP and T1500-1BDCP, applied here to 2,500W — maintaining maximum output more consistently across 1Ω, 2Ω, and 4Ω loads than a standard amplifier design. (Supplier-stated performance claim.) Class-BD Topology — Rockford Fosgate's proprietary Class-BD delivers high-current efficiency for subwoofer loads, combining characteristics of Class-B/AB and Class-D. MOSFET Power Supply and Output Stage — Dual MOSFET implementation provides the fast switching speed and thermal stability needed for sustained 2,500W operation. 24dB/Octave Crossover — Steep crossover slope tightly limits the subwoofer frequency band for clean integration in multi-amplifier car audio systems. Infrasonic Filter — At 2,500W, removing inaudible sub-20Hz content that could over-excite subwoofer cone excursion is particularly important for driver protection. RCA Pass-Thru Outputs — Signal looping for downstream amplifiers in multi-amp builds. Technical Specs Specification Detail Brand Rockford Fosgate Part Number T2500-1BDCP Series Power Power Output 2,500W Amplifier Class Class-BD Configuration Monoblock Application Subwoofer Dedicated Constant Power Yes — up to 25% more across all impedance loads (supplier-stated) PowerSync Yes — 2 amps = combined 5,000W MasterSync Yes — 1 amp controls array Crossover 24dB/Octave Infrasonic Filter Yes Phase Switch 0° / 180° Power Supply MOSFET Output Stage MOSFET Speaker Connections Audiophile Grade Power/Ground Connectors 1/0 AWG RCA Pass-Thru Yes LED Meters Blue LED Simulated VU Signal and Power Meters Rated Power (per impedance) Not specified — confirm with Rockford Fosgate Frequency Response Subwoofer optimised — Hz range not specified Signal-to-Noise Ratio Not specified THD Not specified Input Voltage Range Not specified Dimensions Not specified Weight Not specified Warranty Not specified — confirm with Rockford Fosgate Compatible With / Goes Well With Suitable subwoofer configurations: Single or multiple subwoofer setups requiring a high-output dedicated mono amplifier 1Ω, 2Ω, and 4Ω impedance loads (confirm RMS power per impedance with Rockford Fosgate) High-efficiency ported, sealed, and bandpass subwoofer enclosures Competition SPL and extreme high-output car audio builds Dual-amplifier builds using PowerSync (2× T2500-1BDCP = 5,000W combined) Choosing between T1000, T1500, and T2500: T1000-1BDCP (1,000W): Suited to most quality subwoofer builds and daily use systems T1500-1BDCP (1,500W): Larger subwoofers, dual-sub builds, high-efficiency ported enclosures T2500-1BDCP (2,500W): Competition and extreme builds; PowerSync and MasterSync for multi-amp systems Pairs well with: A second T2500-1BDCP (PowerSync for 5,000W combined) 1/0 AWG amplifier wiring kits Rockford Fosgate Power series T2 and T3 subwoofers Rockford Fosgate or aftermarket RCA signal cables Frequently Asked Questions What does PowerSync allow the T2500-1BDCP to do? PowerSync allows two T2500-1BDCP amplifiers to be electronically bridged together and operate as a single synchronised unit, combining their output for a total of 5,000W. This is a factory-supported configuration — confirm specific wiring and impedance requirements for PowerSync operation with Rockford Fosgate or your authorised installer. What is MasterSync and when would I use it? MasterSync designates one T2500-1BDCP as a master controller for an array of T2500-1BDCP amplifiers. Volume and settings are controlled from the master unit, coordinating multiple amplifiers in large-format installations — competition vehicles, extreme builds, or installations with multiple subwoofer arrays requiring unified control. Why does the T2500-1BDCP require 1/0 AWG wiring when the T1000 and T1500 use 4-gauge? A 2,500W amplifier draws substantially more current than a 1,000W or 1,500W amplifier. 1/0 AWG cable (approximately 53mm²) has significantly lower resistance and higher current carrying capacity than 4-gauge — essential for preventing voltage drop, maintaining full power delivery, and protecting the wiring from overheating at the T2500-1BDCP's peak current draw. What does the 0°/180° phase switch do? The phase switch allows the subwoofer's acoustic output to be inverted 180° relative to the main speakers. This compensates for acoustic cancellation that can occur when a subwoofer is positioned out of phase with the main speakers — either due to enclosure placement, vehicle acoustics, or driver polarity — ensuring maximum bass output at the listening position. What is the difference between the T2500-1BDCP and the T1500-1BDCP? The T2500-1BDCP delivers 2,500W versus the T1500's 1,500W, and adds PowerSync (two-amp bridging for 5,000W), MasterSync (array control), a 0°/180° phase switch, blue LED VU meters, and 1/0 AWG wiring connectors. The T1500-1BDCP uses 4-gauge connectors and does not include these features. Legendary Products & Support From Authorized Dealers When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice: ▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations. ▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support. ▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently. ▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that? Choose wisely. Buy from Frankies BrandBeast today!

Read more less
