Are You Ready To Go P.R.O.?
The P.R.O. series of speakers is designed specifically for those looking to produce some serious sound pressure levels. Inspired by Pioneer’s history of record-breaking SPL competition, the new P.R.O. series line of speakers is constructed with the street enthusiast in mind. With an emphasis on efficiency and power handling, the P.R.O. series lineup consists of bullet tweeters, mid-bass drivers, and a subwoofer that can be mixed and matched to deliver impressive output, without requiring an impressive investment.
The Pioneer P.R.O. series TS-B351PRO bullet tweeters feature aluminum die-cast chassis with titanium diaphragms backed by aggressive magnets and motor assemblies to produce a wide range of crisp, loud, and clear frequencies with up to 300 watts of maximum power handling.
Specifications:
System Type Bullet Tweeter
Frequency Range 3,000 Hz to 22 kHz
Maximum Peak Power Handling 300 Watts
Sound Pressure Level (Sensitivity) 100dB
Continuous Power Handling (RMS) 150 Watt
Nominal Impedance 4 ohms
Type Bullet Tweeter
Diaphragm Material Titanium
Magnet Weight 7.9 oz
Unit Size (mm - in.) 100mm - 4"
Mounting Depth (mm - in.) 44mm - 1-3/4”
Size (mm - in.) 87mm - 3-1/2"
Magnet Material Ferrite
Wave Guides Horn
Cut Out Dimensions (mm - in.) 75mm - 3”
Protrusion (mm - in.) 8mm - 1/4"
Package Contains 1 Pair
Legendary Products & Support From Authorized Dealers
When you choose Pioneer, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Pioneer dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Pioneer's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Pioneer dealer today!
1.5" Punch Pro SPL Tweeter Aluminium Diaphragm, Billet Machined Phase Plug, Die-Cast Aluminium Housing, Built-In 6dB/Octave Crossover. Sold Individually.
Product Overview
The Rockford Fosgate Punch Pro PP4-T is a 1.5" 4-Ohm tweeter engineered specifically for high SPL (Sound Pressure Level) applications competition car audio builds, high-output SPL-oriented systems, and any installation where tweeter sensitivity, power handling, and mechanical robustness take priority. It is sold as an individual unit, not a pair.
The PP4-T uses an aluminium diaphragm rather than the PEI or fabric dome materials used in standard Punch and Prime series tweeters producing a stiffer, lighter diaphragm with high sensitivity. A billet machined aluminium phase plug controls high-frequency dispersion from the diaphragm face, and a die-cast aluminium housing provides structural rigidity that pressed steel cannot match. A High Temp Kapton voice coil former is engineered to withstand the sustained high temperatures generated during high-SPL operation. A built-in 6dB/octave high-pass crossover is integrated into the unit.
Key Specifications
Tweeter size: 1.5 inch
Impedance: 4-Ohm
Power handling (RMS): 50W (confirmed in description)
Diaphragm material: Aluminium
Phase plug: Billet machined aluminium
Voice coil former: High Temp Kapton
Housing: Die-cast aluminium
Input terminals: All-metal spring terminal
Crossover: Built-in 6dB/octave high-pass
Crossover point: Not specified — confirm with Rockford Fosgate
Application: High SPL
Mounting hardware: Included
Sold as: Individual unit (not a pair)
Sensitivity: Not specified — confirm with Rockford Fosgate
Frequency response: Not specified — confirm with Rockford Fosgate
Mounting depth: Not specified — confirm with Rockford Fosgate
Weight: Not specified — confirm with Rockford Fosgate
Warranty: Not specified — confirm with Rockford Fosgate
Features & Benefits
Aluminium Diaphragm — The aluminium dome diaphragm is lighter and stiffer than soft dome or PEI materials — producing high sensitivity and a very fast, controlled high-frequency response suited to high SPL conditions where the tweeter must keep pace with high-output woofers and amplifiers. Aluminium domes produce a bright, forward, detailed treble character.
Billet Machined Aluminium Phase Plug — The phase plug is machined from solid billet aluminium rather than cast or stamped — sitting at the centre of the diaphragm to control the dispersion pattern of high-frequency output and reduce distortion caused by uncontrolled centre-cavity resonance. Billet machining produces a tighter dimensional tolerance than casting.
Die-Cast Aluminium Housing — The housing is die-cast aluminium rather than pressed steel or injection-moulded plastic — providing the structural rigidity and heat dissipation characteristics appropriate for a high-power, high-SPL tweeter operating in sustained competition conditions.
High Temp Kapton Voice Coil Former — Kapton (polyimide film) is the industry-standard high-temperature voice coil former material, chosen for its ability to maintain dimensional stability and mechanical integrity at the elevated temperatures produced by sustained high-power operation — a critical reliability requirement for SPL-oriented applications.
Built-In 6dB/Octave High-Pass Crossover — An integrated 6dB/octave high-pass crossover is built into the tweeter unit — filtering low-frequency content that could damage the 1.5" diaphragm. Crossover point (Hz) is not confirmed in the supplier data — pull from the official Rockford Fosgate PP4-T datasheet.
All-Metal Input Spring Terminal — Metal spring terminals provide a secure, vibration-resistant connection that does not corrode or loosen under the mechanical stress of high-SPL operation.
Oversized Motor Structure — An oversized motor provides greater magnetic flux for the voice coil — contributing to the high sensitivity and power handling characteristics of the PP4-T.
Sold Individually — The PP4-T is sold as a single unit. Two units must be purchased for a stereo left/right tweeter installation.
Technical Specs
Specification
Detail
Brand
Rockford Fosgate
Part Number
PP4-T
Series
Punch Pro
Tweeter Size
1.5 inch
Impedance
4-Ohm ✓
Power Handling (RMS)
50W ✓ (description)
Diaphragm
Aluminium
Phase Plug
Billet Machined Aluminium
Voice Coil Former
High Temp Kapton
Housing
Die-Cast Aluminium
Input Terminals
All-Metal Spring Terminal
Crossover
Built-in 6dB/Octave HP
Crossover Point
Not specified — confirm with Rockford Fosgate
Application
High SPL
Mounting Hardware
Included
Sold As
Individual unit (not a pair) ✓
Sensitivity
Not specified — confirm with Rockford Fosgate
Frequency Response
Not specified — confirm with Rockford Fosgate
Mounting Depth
Not specified — confirm with Rockford Fosgate
Weight
Not specified — confirm with Rockford Fosgate
Warranty
Not specified — confirm with Rockford Fosgate
Compatible With / Goes Well With
Suitable applications:
High SPL and competition car audio builds requiring a robust, high-power tweeter
Front stage systems paired with high-output amplifiers and woofers
Installations where tweeter sensitivity and sustained power handling are the priority
Pairs well with:
High-output 4-channel amplifiers for front stage (T400-4, T600-4, or T1000-4AD)
High SPL woofers matched to the tweeter's operating range
Frequently Asked Questions
Is the PP4-T sold as a pair?
No — the PP4-T is explicitly sold as an individual unit. Two units must be purchased separately for a stereo left/right installation.
What is an aluminium diaphragm tweeter and how does it differ from a PEI or soft dome?
An aluminium dome diaphragm is stiffer and lighter than PEI (rigid thermoplastic) or soft dome (fabric/silk) materials. This produces high sensitivity and fast, precise high-frequency response — well-suited to high SPL conditions where maximum output and impact are priorities. Aluminium domes typically have a bright, forward treble character that suits SPL and competition applications.
What is the confirmed power handling for the PP4-T?
The product description confirms 50W RMS. The product title states 100W, which most likely represents the peak power rating. The 50W RMS figure has been used throughout this listing as the confirmed sustained power rating. Confirm the full 50W RMS / 100W peak interpretation with Rockford Fosgate before publishing.
What does the billet machined aluminium phase plug do?
The phase plug sits at the centre of the tweeter diaphragm and controls the dispersion of high-frequency output — preventing uncontrolled resonance in the cavity behind the dome and improving the evenness of the tweeter's off-axis frequency response. Billet machining produces tighter dimensional tolerances than casting, contributing to more consistent acoustic performance.
What is a Kapton voice coil former?
Kapton is a polyimide film from DuPont, widely used as a voice coil former material in high-power speaker drivers. It maintains dimensional stability and mechanical integrity at the elevated temperatures generated during sustained high-power operation — important for a tweeter designed for high SPL applications where heat build-up can be significant.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Highlights: SPECIFICATIONS: Similar Products Edge EDPRO65XL-E6 6.5" 260 Watts Mid-Range Speaker $69.99 Edge EDSH10000.1D-E6 10000 Watts Ultra Class D Com $3999.00 Edge EDSH7000.1D-E6 7000 Watts Ultra Class D Ampli $2299.00 Highlights: SPECIFICATIONS: RMS POWER: 100W PEAK POWER: 200W MINIMUM INPUT (RMS): 50W TYPE: 2.3" (58 MM) BULLET TWEETER SENSITIVITY: 106DB SINGLE SPEAKER TITANIUM MEMBRANE: YES
Legendary Products & Support From Authorized Dealers
When you choose Edge, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & Training
Only authorized Edge dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty Protection:
We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.
▸ Reliable Customer Support:
If you ever run into an issue, you're backed by Edge's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your Investment:
Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?
Choose wisely. Buy from an authorized Edge dealer today!
1" Aluminium Dome Neodymium Tweeter Kit 75W RMS, Internal Mylar Phase Plug, Audiophile External Crossover with Protection and Bypass Resistor. 3-Level Attenuation.
Product Overview
The Rockford Fosgate Power T2T-S is a 1" aluminium dome tweeter kit rated at 75W RMS designed for listeners who prefer the bright, detailed, forward high-frequency character of an aluminium dome. The kit includes two tweeters with dedicated external crossovers, trim rings, and mounting hardware.
The aluminium dome is driven by a neodymium motor for high sensitivity and responsive transient performance. An internal Mylar phase plug sits behind the dome to control acoustic output from the cavity behind the diaphragm improving off-axis dispersion and reducing undesirable rear-wave resonances. The external audiophile-grade crossover uses 5% tolerance poly-capacitors and air-core inductors, and includes a built-in protection and bypass resistor a circuit that protects the tweeter from overdrive while ensuring the tweeter circuit remains active (never goes completely silent) when protection engages. Three levels of tweeter attenuation and on-axis/off-axis mounting configurations provide installation flexibility.
Key Specifications
Tweeter size: 1 inch (25mm — implied)
Dome material: Aluminium
Motor: Neodymium
Suspension: Integral
Phase plug: Internal Mylar
Power handling (RMS): 75W per tweeter (confirmed)
Peak power: Not specified — confirm with Rockford Fosgate
Impedance: Not specified — confirm with Rockford Fosgate
Sensitivity: Not specified — confirm with Rockford Fosgate
Frequency response: Not specified — confirm with Rockford Fosgate
Crossover: External audiophile grade — 5% poly-capacitors and air-core inductors
Crossover protection: Built-in protection and bypass resistor ("100% playtime")
Tweeter attenuation: 3 levels (dB values not specified — confirm with Rockford Fosgate)
Crossover point: Not specified — confirm with Rockford Fosgate
Crossover slope: Not specified — confirm with Rockford Fosgate
Mounting configurations: On-axis and off-axis
Recessed mount hole size: 1-3/4" hole saw
Trim rings: Included
Mounting hardware: Included
Sold as: Pair (2 tweeters — confirmed in description)
Warranty: Not specified — confirm with Rockford Fosgate
Features & Benefits
1" Aluminium Dome with Neodymium Motor — The aluminium dome diaphragm is stiff and light — producing a bright, highly detailed, and forward high-frequency character with fast transient response. The neodymium motor provides high magnetic flux in a compact assembly for high sensitivity.
Internal Mylar Phase Plug — The Mylar phase plug is positioned behind the dome inside the tweeter cavity. It controls the acoustic output from the rear of the dome — reducing cavity resonances and improving off-axis frequency response consistency. Mylar (polyimide film) is lightweight and dimensionally stable, avoiding acoustic interference with the dome itself.
External Audiophile Crossover with Built-In Protection and Bypass Resistor — The dedicated external crossover uses 5% tolerance poly-capacitors and air-core inductors for transparent, accurate frequency division. The built-in protection circuit safeguards the tweeter from excessive power input. The bypass resistor ensures that when protection engages, the tweeter circuit remains closed — the tweeter does not go silent but instead operates at a reduced, protected level for continuous audio output ("100% playtime").
3 Levels of Tweeter Attenuation — Three selectable attenuation settings allow the tweeter output to be adjusted relative to the woofer level — compensating for sensitivity differences and for tweeter positions closer to the listening position. Specific dB values are not confirmed in the supplier data — pull from the official Rockford Fosgate T2T-S datasheet.
On-Axis and Off-Axis Mounting — The tweeter supports both direct listening position placement (on-axis) and angled mounting for wider dispersion (off-axis) without additional hardware.
1-3/4" Recessed Hole Saw Mount — Standard 1-3/4" hole saw for a clean, flush installation in door panels, A-pillars, and dash trim.
Trim Rings Included — For a finished appearance at the tweeter mounting location.
Sold as a Pair — Two tweeters per kit.
Technical Specs
Specification
Detail
Brand
Rockford Fosgate
Part Number
T2T-S
Series
Power
Tweeter Size
1 inch (25mm implied)
Dome Material
Aluminium
Motor
Neodymium
Suspension
Integral
Phase Plug
Internal Mylar
Power Handling (RMS)
75W per tweeter ✓
Peak Power
Not specified — confirm with Rockford Fosgate
Impedance
Not specified — confirm with Rockford Fosgate
Sensitivity
Not specified — confirm with Rockford Fosgate
Frequency Response
Not specified — confirm with Rockford Fosgate
Crossover
External Audiophile Grade — 5% poly-caps, air-core inductors
Crossover Protection
Built-in protection + bypass resistor (100% playtime) ✓
Tweeter Attenuation
3 levels ✓ (dB values not specified)
Crossover Point
Not specified — confirm with Rockford Fosgate
Crossover Slope
Not specified — confirm with Rockford Fosgate
Mounting Options
On-axis and Off-axis
Recessed Mount
1-3/4" hole saw ✓
Trim Rings
Included ✓
Mounting Hardware
Included ✓
Sold As
Pair (2 tweeters) ✓
Warranty
Not specified — confirm with Rockford Fosgate
Compatible With / Goes Well With
Suitable for:
Power series component system builds requiring a dedicated aluminium dome tweeter
Any front stage installation where a detailed, bright aluminium dome character is the preferred choice
Upgrading existing Power series coaxial installations with independent tweeters
Installations requiring the active tweeter protection of the bypass resistor circuit
Pairs well with:
Rockford Fosgate Power series woofers in a component build
Rockford Fosgate T400-4, T600-4, or T1000-4AD 4-channel amplifiers
Frequently Asked Questions
What is the internal Mylar phase plug and what does it do?
The phase plug is a lightweight Mylar (polyimide film) component positioned inside the tweeter cavity behind the aluminium dome. It controls the acoustic output from the rear of the dome, reducing cavity resonances that can cause uneven frequency response and improving the consistency of the tweeter's off-axis dispersion. The result is a more even frequency response across the listening area beyond the direct on-axis position.
What does the built-in protection and bypass resistor do?
The protection circuit monitors the signal level and activates when the tweeter receives excessive power input. The bypass resistor ensures that when protection engages, the tweeter circuit remains closed rather than going completely silent — the tweeter continues to play at a reduced, protected power level. Rockford Fosgate describes this as "100% playtime" — the tweeter maintains continuous audio output even during protection events.
What are the three levels of tweeter attenuation?
The three attenuation settings reduce the tweeter output level relative to the woofer by selectable amounts, compensating for the sensitivity difference between the drivers or for the tweeter being positioned closer to the listening position. Specific dB values for the three levels are not confirmed in the supplier data — confirm from the official Rockford Fosgate T2T-S datasheet.
What is the confirmed power handling for the T2T-S?
75W RMS per tweeter is confirmed. Impedance, sensitivity, and frequency response must be confirmed from the official Rockford Fosgate T2T-S datasheet.
What is the difference between aluminium dome and fabric dome tweeters?
An aluminium dome tweeter is stiff and light — producing a bright, detailed, forward high-frequency character with fast transient response. A fabric dome tweeter is softer — producing a warmer, smoother, more natural-sounding treble that is generally considered more forgiving for extended listening. Buyers who prefer detail and clarity tend to favour aluminium; buyers who prioritise warmth and long listening comfort tend to prefer fabric.
Legendary Products & Support From Authorized Dealers
When you choose Frankies BrandBeast, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:
▸ Expert Knowledge & TrainingOnly authorized Frankies BrandBeast dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.
▸ Authorized Warranty ProtectionWe offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don’t be misled by unauthorized sellers who can’t provide genuine warranty support.
▸ Reliable Customer SupportIf you ever run into an issue, you’re backed by Frankies BrandBeast’s official manufacturer’s warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.
▸ Protect Your InvestmentBuying from an authorized dealer ensures you’re getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few bucks worth losing all that?
Choose wisely. Buy from Frankies BrandBeast today!
Ideal for Competition Use and for Those Who Wants to Play their Music Loud and Proud Features: 1 Inch titanium plated dome tweeters Supplied with custom fit tweeter mounting brackets included (flush, surface) Power: 60 Watts max Depth: 25mm Diameter: 45mm Pack size: 1 Pair Packaging: DNA colour gift box
