A Complete 9" Wireless CarPlay Upgrade for the Hyundai Accent RB Plug In and Drive Smarter
Product Overview
The Aerpro AMDHY22 is a complete head unit upgrade kit designed for the Hyundai Accent RB (2011–2015) without a factory reverse camera in the OEM head unit. It replaces the factory unit with a 9" capacitive touchscreen at 1024x600 resolution and brings wireless Apple CarPlay and Android Auto, built-in DAB+ digital radio, and Bluetooth V5 to a vehicle that originally shipped without them while retaining the factory steering wheel controls.
The kit includes the AM905D multimedia receiver, a silver vehicle-specific facia kit, SWC interface harness, and a 720P AHD universal rear camera to add reversing visibility the factory unit never provided. Audio is covered by 4 x 50W max output, a 13-band EQ, time alignment, and 4V/5-channel RCA preouts for future amplifier integration.
Features & Benefits
-
Wireless Apple CarPlay & Android Auto — a significant capability upgrade for the Accent RB; connect over Wi-Fi for hands-free maps, music, calls, and messages without any cables; wired connection also supported for USB charging
-
9" capacitive touchscreen at 1024x600 resolution — transforms the Accent's cabin with a large, responsive display for navigation, media, and Bluetooth management
-
Built-in DAB+ digital radio — digital audio quality and expanded station access that the factory Accent radio can't match; AM/FM with RDS and 18 FM / 12 AM presets also included
-
Bluetooth V5 with HD Voice — hands-free calling, audio streaming, and phonebook access; internal and external microphone options for clear call quality
-
Factory steering wheel controls retained — SWC interface harness included for seamless retention of the factory SWC buttons
-
720P AHD universal rear camera included — Sony 225 1/3" CMOS sensor, 150-degree wide-angle lens; adds a reversing view to an Accent model not equipped with factory reverse camera capability
-
Silver vehicle-specific facia kit — matched to the Accent RB interior for a clean factory-finish installation; all mounting hardware included
-
Second camera input available — additional AHD-compatible input for an optional front or towing camera
-
4 x 50W max output with 5CH 4V RCA preouts — front, rear, and subwoofer channels at 4V peak for clean amplifier integration
-
13-band EQ and time alignment — 6 preset EQ modes plus 2 custom slots; calibrate the soundstage to the Accent cabin
-
6-colour button illumination — red, yellow, green, blue, purple, or white to suit your preference
Technical Specs
| Specification |
Detail |
| Display size |
9" |
| Resolution |
1024x600 |
| Touchscreen type |
Capacitive |
| OS |
Linux |
| DIN size |
Fixed Screen Style (Trapezoid) |
| Max power output |
4CH x 50W (4 ohm) |
| RCA preouts |
4V, 5-channel (Front / Rear / Subwoofer) |
| Preamp voltage |
4V p-p |
| EQ |
13-band (32/63/125/250/500/1K/2K/4K/8K/10K/12K/14K/16K Hz) |
| Preset EQs |
6 + 2 custom |
| Time alignment |
Yes |
| Subwoofer level control |
Yes |
| Smartphone connectivity |
Apple CarPlay & Android Auto (wireless and wired) |
| Bluetooth version |
V5 (A2DP, AVRCP, HFP 1.6 HD Voice, PBAP) |
| Microphone |
Internal + external (with mount) |
| DAB |
Yes |
| FM tuner range |
87.5–108.0MHz (0.05MHz step) / 18 presets |
| AM tuner range |
522–1710KHz (9KHz step) / 12 presets |
| RDS |
Yes |
| USB1 (rear) |
CarPlay / Android Auto + charging (5V / 1.5A) |
| USB2 (rear) |
Media playback + charging (5V / 1.5A) |
| USB max capacity |
FAT32 / 32GB |
| Media formats |
MP3, MP4, MKV, FLAC, Xvid |
| Rear A/V input |
RCA type (3 pcs) |
| Composite video output |
Yes (x2) |
| Reverse camera input |
Yes (720P AHD compatible) |
| Second camera input |
Yes (720P AHD compatible) |
| Button illumination |
6-colour (Red, Yellow, Green, Blue, Purple, White) |
| OSD language |
English |
| Rear Camera (AHD) |
|
| Image sensor |
Sony 225, 1/3" CMOS AHD |
| Lens angle |
150° |
| Mount type |
Surface mount |
| Feature Retention |
|
| Steering wheel controls |
Yes |
| Factory reverse camera |
N/A (suits models without factory reverse camera) |
| Factory USB input |
Not retained |
| Factory AUX input |
Not retained |
| Factory amplifier |
N/A |
| Vehicle menu |
N/A |
Compatible With / Goes Well With
- Hyundai Accent RB (2011–2015) without factory reverse camera in OEM head unit
-
Not compatible with Accent RB variants that have a factory reverse camera integrated into the OEM head unit — a different kit is required for those models
- Pairs well with external amplifiers via 4V 5-channel RCA preouts (front/rear/sub)
- Second camera input supports an optional front or towing camera (720P AHD compatible)
Weight
Not specified
Frequently Asked Questions
Which Hyundai Accent models does this fit?
The AMDHY22 suits the Hyundai Accent RB (2011–2015) in variants without a factory reverse camera integrated into the OEM head unit. Use the Aerpro What Fits Your Car Guide to confirm your specific build.
What if my Accent has a factory reverse camera in the OEM head unit?
A different kit is required for Accent RB models with a factory reverse camera in the OEM unit. The AMDHY22 is not compatible with those variants — check the Aerpro What Fits Your Car Guide for the correct match.
Does the kit add reverse camera capability to the Accent?
Yes — a 720P AHD universal rear camera is included and connects via the head unit's reverse camera input, adding reversing visibility to a model not originally equipped with it.
Are the factory USB and AUX inputs retained?
No — factory USB and AUX inputs are not retained on this kit. CarPlay, Android Auto, and the head unit's rear USB ports serve as the primary input options after installation.
Does it support wireless CarPlay or does the phone need to plug in?
Both — wireless Apple CarPlay and Android Auto connect over Wi-Fi without cables, or plug in via USB for wired operation and simultaneous phone charging.
