Description
9" Wireless CarPlay for the Mercedes Vito W447 SWC and Factory Reverse Camera Retained, Gloss Black Finish
Product Overview
The Aerpro AMDMC3 is a complete head unit upgrade kit for the Mercedes-Benz Vito W447 (2015–2021). It replaces the factory unit with a 9" capacitive touchscreen at 1024x600 resolution, adding wireless Apple CarPlay and Android Auto, built-in DAB+ digital radio, and Bluetooth V5 while retaining factory steering wheel controls and the factory reverse camera where equipped.
The kit includes the AM905D multimedia receiver, gloss black facia kit, SWC interface harness, SWC patch lead, antenna adaptor, camera retention adaptor, and a 720P AHD universal rear camera. No dash modification is required, and there is no park brake wire requirement on this kit. Factory amplifier is not retained; USB input, AUX input, parking tones, and vehicle menu are all N/A for this platform.
Features & Benefits
-
Factory reverse camera retained (if equipped) — the camera retention adaptor preserves the factory reverse camera signal via the head unit's reverse camera input for Vito W447 models fitted with one
-
SWC retained — SWC interface harness and patch lead carry over factory steering wheel controls
-
Gloss black vehicle-specific facia kit — matched to the W447 Vito interior trim; no dash modification required
-
Camera retention adaptor and antenna adaptor both included — all necessary integration components are in the box for a complete, clean installation
-
Factory amplifier not retained — the W447 kit does not include an amplifier retention harness; the head unit drives speakers directly after installation
-
No dash modification required — unlike some other Mercedes kits in the Aerpro range, the W447 installation does not require cutting or trimming of factory dash components
-
Wireless Apple CarPlay & Android Auto — a significant connectivity upgrade for a commercial van; connect over Wi-Fi for maps, music, calls, and messages; wired USB also supported for simultaneous phone charging
-
9" capacitive touchscreen at 1024x600 resolution — large, responsive display in the Vito W447 cabin
-
Built-in DAB+ digital radio — digital audio clarity and expanded station access; AM/FM with RDS, 18 FM and 12 AM presets included
-
Bluetooth V5 with HD Voice — hands-free calling, audio streaming, and phonebook access; internal and external microphone included
-
720P AHD universal rear camera included — Sony 225 1/3" CMOS sensor, 150-degree lens; adds or supplements reversing visibility depending on factory camera configuration
-
4 x 50W max output with 5CH 4V RCA preouts — supports external amplifier integration via front/rear/sub preamp channels
Technical Specs
| Specification |
Detail |
| Display size |
9" |
| Resolution |
1024x600 |
| Touchscreen type |
Capacitive |
| OS |
Linux |
| DIN size |
Fixed Screen Style (Trapezoid) |
| Max power output |
4CH x 50W (4 ohm) |
| RCA preouts |
4V, 5-channel (Front / Rear / Subwoofer) |
| Preamp voltage |
4V p-p |
| EQ |
13-band (32/63/125/250/500/1K/2K/4K/8K/10K/12K/14K/16K Hz) |
| Preset EQs |
6 + 2 custom |
| Time alignment |
Yes |
| Subwoofer level control |
Yes |
| Smartphone connectivity |
Apple CarPlay & Android Auto (wireless and wired) |
| Bluetooth version |
V5 (A2DP, AVRCP, HFP 1.6 HD Voice, PBAP) |
| Microphone |
Internal + external (with mount) |
| DAB |
Yes |
| FM tuner range |
87.5–108.0MHz (0.05MHz step) / 18 presets |
| AM tuner range |
522–1710KHz (9KHz step) / 12 presets |
| RDS |
Yes |
| USB1 (rear) |
CarPlay / Android Auto + charging (5V / 1.5A) |
| USB2 (rear) |
Media playback + charging (5V / 1.5A) |
| USB max capacity |
FAT32 / 32GB |
| Media formats |
MP3, MP4, MKV, FLAC, Xvid |
| Rear A/V input |
RCA type (3 pcs) |
| Composite video output |
Yes (x2) |
| Reverse camera input |
Yes (720P AHD compatible) |
| Second camera input |
Yes (720P AHD compatible) |
| Button illumination |
6-colour (Red, Yellow, Green, Blue, Purple, White) |
| OSD language |
English |
| Rear Camera (AHD) |
|
| Image sensor |
Sony 225, 1/3" CMOS AHD |
| Lens angle |
150° |
| Mount type |
Surface mount |
| Feature Retention |
|
| Steering wheel controls |
Yes |
| Factory reverse camera |
Yes (if equipped) — via camera retention adaptor |
| Factory amplifier |
Not retained |
| Factory AUX / USB |
N/A |
| Vehicle menu |
N/A |
| Parking tones |
N/A |
| Dash modification |
Not required |
| Park brake requirement |
Not required |
Compatible With / Goes Well With
- Mercedes-Benz Vito W447 (2015–2021)
-
Not compatible with the older Vito W639 (2006–2014) — see Aerpro AMDMC2 for that generation
- Use the Aerpro What Fits Your Car Guide to confirm fitment before purchasing
- Pairs well with external amplifiers via 4V 5-channel RCA preouts (front/rear/sub)
- Second camera input supports an optional front or towing camera (720P AHD compatible)
Weight
Not specified
Frequently Asked Questions
How does this differ from the AMDMC2, which also covered the Vito?
The AMDMC2 covers the older Vito W639 (2006–2014) alongside several other Mercedes and VW commercial models. The AMDMC3 is specific to the newer W447 Vito (2015–2021). The AMDMC3 adds factory reverse camera retention (via an included camera retention adaptor) that the AMDMC2 does not include, but does not retain the vehicle menu that the AMDMC2 preserved.
Does the Vito W447 have a factory reverse camera?
Some W447 variants are factory-equipped with a reverse camera; others are not. The AMDMC3 includes a camera retention adaptor, which preserves the factory camera signal where fitted. The 720P AHD universal rear camera is also included in the kit, providing reversing visibility on variants without a factory camera.
Is the factory amplifier retained?
No — the AMDMC3 does not include an amplifier retention harness. After installation, the head unit drives the speakers directly. If your W447 has a factory amplified system that you want to retain, check with Aerpro whether an alternative integration solution exists.
Does this suit the older Vito W639?
No — the AMDMC3 is designed for the W447 (2015–2021) only. The older Vito W639 (2006–2014) is covered by the Aerpro AMDMC2 instead.
Does this installation require any dash modification?
No — unlike the Aerpro AMDMC4 (Mercedes C-Class/CLC) which requires sub frame modification, the W447 Vito installation with the AMDMC3 does not require any cutting or trimming of factory dash components.
