Description
Complete 10" Head Unit Upgrade Kit for Toyota LandCruiser 200 Series GXL/VX/Altitude 2012–2016 Wireless Apple CarPlay, Android Auto, DAB+, Bluetooth 5, SWC, USB, AUX & Factory Reverse Camera Retained (Model Dependent), Rear Camera Included.
Product Overview
The Aerpro AMDTO18 is a complete head unit upgrade kit designed for the Toyota LandCruiser 200 Series GXL, VX, and Altitude (2012–2016) the more comprehensive follow-on to the AMDTO17 (2007–2011). The AMDTO18 adds USB and AUX input retention to the feature set while maintaining SWC and factory reverse camera retention. All three retention features are model dependent.
Everything required for installation is included the AM1005D multimedia receiver, matte black fascia kit, steering wheel control interface harness, SWC patch lead, antenna adaptor, camera retention adaptor, USB retention adaptor, and a 720P AHD universal rear camera.
Important: Does not suit Sahara models. Reverse camera, USB, and AUX input retention are all model dependent. Reverse camera retention uses the reverse camera input. USB retention uses the rear USB input. AUX retention uses the RCA AUX input on the rear of the head unit. Factory amplifier is not supported.
Kit Inclusions
- AM1005D 10" Multimedia Receiver
- Matte Black Fascia Kit
- Steering Wheel Control Interface Harness
- SWC Patch Lead
- Antenna Adaptor
- Camera Retention Adaptor
- USB Retention Adaptor
- 720P AHD Universal Rear Camera
Vehicle Feature Retention
| Feature |
Retained |
| Steering Wheel Controls |
Yes |
| Factory Reverse Camera |
Yes (if equipped, model dependent) |
| USB Input |
Yes (if equipped, model dependent) |
| AUX Input |
Yes (if equipped, model dependent) |
| Factory Amplifier |
No |
| Vehicle Menu |
N/A |
LandCruiser 200 Series Kit Comparison (this session)
| Model |
Suits |
USB |
AUX |
Camera |
| AMDTO17 |
200 Series GXL/VX 2007–2011 |
N/A |
N/A |
Yes (model dep.) |
| AMDTO18 |
200 Series GXL/VX/Altitude 2012–2016 |
Yes (model dep.) |
Yes (model dep.) |
Yes (model dep.) |
Key Specifications
- Screen: 10" capacitive touchscreen 1024x600 resolution
- Wireless CarPlay & Android Auto: Yes (wired also supported)
- DAB+ digital radio: Yes (AM/FM with RDS also included)
- Bluetooth: V5 (A2DP, AVRCP, HFP 1.6 HD Voice, PBAP)
- Max power output: 4 x 50W
- RCA preouts: 4V / 5-channel (Front/Rear/Subwoofer)
- 13-band EQ and time alignment: Yes
- USB inputs: 2 x rear USB (FAT32 / 32GB max)
- Reverse camera input: Yes (720P AHD compatible)
- Second camera input: Yes (720P AHD compatible)
- LED button illumination: 6-colour selectable
- Rear camera: 720P AHD universal included
Features & Benefits
-
Suits GXL, VX and Altitude not Sahara: Specifically for 2012–2016 LandCruiser 200 Series GXL, VX, and Altitude variants; does not suit Sahara
-
Factory reverse camera retained: If equipped and model dependent uses the reverse camera input of the head unit
-
Factory USB input retained: If equipped and model dependent uses the rear USB input of the head unit
-
Factory AUX input retained: If equipped and model dependent uses the RCA AUX input on the rear of the head unit
-
Steering wheel controls retained:Â Full SWC retained via the included harness and patch lead
-
10" touchscreen:Â Large AM1005D 10" display
-
Wireless Apple CarPlay & Android Auto:Â Wire-free phone integration; wired connection also supported
-
DAB+ digital radio built-in:Â Crystal-clear digital radio plus AM/FM and RDS
-
Bluetooth 5 with HD Voice:Â Crisp hands-free calling and wireless audio streaming
-
720P AHD rear camera included: Immediate reversing visibility additional front or tow camera input also available
Technical Specs
| Specification |
Detail |
| SKU |
AMDTO18 |
| Brand |
Aerpro |
| Receiver Model |
AM1005D |
| Screen Size |
10" |
| Resolution |
1024x600 |
| Touchscreen |
Capacitive |
| OS |
Linux |
| DIN Format |
Fixed Screen Trapezoid |
| Max Power |
4CH x 50W |
| RCA Preouts |
4V / 5-channel |
| Wireless CarPlay/Android Auto |
Yes |
| DAB+ |
Yes |
| AM/FM Presets |
AM 12 / FM 18 |
| Bluetooth |
V5 (A2DP, AVRCP, HFP 1.6, PBAP) |
| USB Inputs |
2 x Rear (FAT32 / 32GB max) |
| Reverse Camera Input |
Yes (720P AHD compatible) |
| Second Camera Input |
Yes (720P AHD compatible) |
| EQ |
13-band |
| Time Alignment |
Yes |
| LED Illumination |
6-colour selectable |
| SWC Retained |
Yes |
| Factory Reverse Camera |
Yes (if equipped, model dependent) |
| USB Input Retained |
Yes (if equipped, model dependent) |
| AUX Input Retained |
Yes (if equipped, model dependent) |
| Factory Amplifier |
No |
| Kit Includes Rear Camera |
Yes 720P AHD universal |
| Suits |
Toyota LandCruiser 200 Series GXL/VX/Altitude 2012–2016 |
Compatible Vehicles
- Toyota LandCruiser 200 Series GXL 2012–2016
- Toyota LandCruiser 200 Series VX 2012–2016
- Toyota LandCruiser 200 Series Altitude 2012–2016
Frequently Asked Questions
Does this kit suit the LandCruiser 200 Series Sahara?
No the AMDTO18 does not suit Sahara models. It suits GXL, VX, and Altitude variants only.
Are USB, AUX, and reverse camera retention guaranteed?
No all three are model dependent. Confirm your specific model is equipped with these features before purchasing. Retention of each uses the corresponding input on the rear of the head unit.
Is the factory amplifier retained?
No factory amplifier is not supported by the AMDTO18.
How does the AMDTO18 differ from the AMDTO17?
The AMDTO18 adds USB and AUX input retention, suits the Altitude variant, and covers 2012–2016 models. The AMDTO17 suits GXL and VX 2007–2011 models only and does not include USB or AUX retention.
What is the return policy for this product?
Return eligibility is subject to the retailer's policy. Always verify vehicle and system compatibility before purchasing.
