Aerpro AVK10S1 10in Heavy Duty AHD Quad View Smart AI Monitor and Camera Kit
The Aerpro AVK10S1 is a commercial-grade 10-inch AHD quad view monitor and camera kit featuring Smart AI human and vehicle detection, blind spot detection, built-in DVR recording, and wireless CarPlay and Android Auto integration. Rated IP69 on the camera and operating across 12 to 24V DC, it suits cars, 4WDs, vans, trucks, buses, trailers, agricultural vehicles, and heavy machinery. A five-year warranty is included.
Product overview
The AVK10S1 is engineered for demanding commercial and fleet applications where driver visibility, situational awareness, and safety are priorities. The 10-inch IPS display with 1600 x 600 resolution supports quad-view monitoring across four independent camera inputs, with individual trigger, latch, and delay functions for flexible system integration. The included 1080P AHD camera delivers clear imagery across a 150-degree diagonal field of view, and the 10-metre extension cable suits a wide range of vehicle configurations.
Smart AI detection covers pedestrians (static and moving), vehicles including trucks, vans, cars, and motorbikes, and blind spot alerts, with audio and visual warnings triggered up to 7 metres from detected objects. The built-in DVR records at 720P at 15 frames per second and supports up to 256GB storage. Wireless CarPlay and Android Auto bring navigation, media, and apps directly to the monitor display. Note that the AVK10S1 is not compatible with AI cameras such as the AVC10 or AVC11.
Features and benefits
10-inch IPS display: A 1600 x 600 resolution IPS panel with 450cd/m² luminance delivers a bright and clear quad-view monitoring display in all lighting conditions including direct sunlight.
1080P AHD camera: The included AVC1 camera captures 1080P footage across a 150-degree diagonal field of view, providing wide-angle coverage for reversing, side monitoring, and forward-facing applications.
Smart AI human and vehicle detection: Detects static and moving pedestrians, trucks, vans, cars, and motorbikes up to 7 metres away, providing audio and visual alerts to the driver before a collision risk develops.
Blind spot detection: Warns the driver of vehicles or objects in blind spots, reducing the risk of lane-change incidents in heavy traffic and tight environments.
Wireless CarPlay and Android Auto: Built-in wireless smartphone connectivity brings Apple CarPlay and Android Auto directly to the monitor for navigation, media, and hands-free communication without cable clutter.
Built-in DVR recording: Records footage at 720P at 15 frames per second with support for up to 256GB storage, providing a continuous record for incident review and fleet management.
Quad camera inputs with individual triggers: Four independent video inputs with three trigger channels, latch, and delay functions allow flexible multi-camera configurations across a wide range of vehicle types.
Multiple viewing modes: Switchable between single, dual, and quad camera views for comprehensive monitoring across different driving scenarios.
IP69 camera rating: The camera is rated IP69, providing full protection against dust ingress and high-pressure water jets for reliable performance in harsh outdoor and agricultural environments.
PCB encapsulation: Enhanced protection against moisture, vibration, and mechanical stress extends the service life of the camera in demanding conditions.
10-metre camera cable: The included AVEC10 10-metre 4-pin extension cable provides generous reach for routing across larger vehicles and machinery.
12V/24V DC compatibility: Operates across 12 to 24V DC, covering passenger vehicles, commercial fleets, and heavy-duty applications from a single system.
Five-year warranty: Backed by a five-year warranty covering the complete kit for long-term confidence in commercial and fleet applications.
What's in the box
- 1 x 10" IPS Heavy Duty Quad View Monitor (AVM10S)
- 1 x 1080P Heavy Duty Camera (AVC1)
- 1 x 10-metre Heavy Duty 4-pin Extension Cable (AVEC10)
Technical specs
| Specification |
Detail |
| SKU |
AVK10S1 |
| Brand |
Aerpro |
| Barcode |
9317114952004 |
| Display Size |
10 inches |
| Display Type |
IPS |
| Monitor Resolution |
1600 x 600 |
| Camera Resolution |
1080P |
| Lens Angle (Horizontal) |
120 degrees |
| Lens Angle (Vertical) |
65 degrees |
| Lens Angle (Diagonal) |
150 degrees |
| AI Detection |
Pedestrian, vehicle, blind spot |
| AI Detection Range |
Up to 7 metres |
| Video Inputs |
4 |
| Video Triggers |
3 (CH1 Priority) |
| Display Modes |
Single, dual, quad |
| Luminance |
450cd/m² |
| DVR Recording |
720P at 15fps, supports up to 256GB |
| Smartphone Connectivity |
Wireless CarPlay and Android Auto |
| Video System |
PAL/NTSC Auto |
| Camera IP Rating |
IP69 |
| Power Supply |
12-24V DC (hardwired) |
| Monitor Dimensions |
245 x 98 x 32mm (excluding mount) |
| Camera Dimensions |
40 x 31 x 34mm (excluding bracket) |
| Camera Cable Length |
10 metres |
| Warranty |
Five years |
Compatible with
The Aerpro AVK10S1 suits cars, 4WDs, vans, trucks, buses, trailers, agricultural vehicles, and heavy machinery operating on 12V or 24V DC electrical systems. Note that this system is not compatible with AI cameras such as the AVC10 or AVC11. Contact us if you are unsure whether this kit suits your specific vehicle or fleet application.
Frequently asked questions
Is the AVK10S1 compatible with the AVC10 or AVC11 AI cameras?
No. The AVK10S1 is not compatible with AI cameras such as the AVC10 or AVC11. Contact us for guidance on compatible camera options for this system.
What AI detection features does the AVK10S1 include?
The AVK10S1 includes Smart AI detection for pedestrians (static and moving), vehicles including trucks, vans, cars, and motorbikes, and blind spot detection, with audio and visual alerts triggered up to 7 metres from detected objects.
Does the AVK10S1 support wireless CarPlay and Android Auto?
Yes. The AVK10S1 features built-in wireless connectivity supporting both Apple CarPlay and Android Auto for navigation, media, and hands-free communication directly on the monitor.
What storage capacity does the built-in DVR support?
The built-in DVR records at 720P at 15 frames per second and supports storage cards up to 256GB. Contact us for guidance on compatible storage cards for this system.
What warranty is included with the AVK10S1?
The Aerpro AVK10S1 is backed by a five-year warranty. Contact us for further information on warranty terms and conditions.
