Description
Blacktips BLB070525 5 LED Work Light 25DEG Narrow Beam
Compact, marine-grade aluminium work light delivering a precise 25° narrow beam with IP68/IP69K dual-rated protection, CISPR25 Class 1 EMC approval, and anti-corrosive coating engineered for 4WD, marine, agricultural, and heavy industrial applications.
Product Overview
The Blacktips BLB070525 is a purpose-built narrow beam LED work light designed for demanding environments where precision illumination, rugged durability, and corrosion resistance are non-negotiable. Housing 5 high-output LEDs in a compact 116 x 100 x 75mm aluminium body, this work light produces a focused 25° narrow beam at a crisp 6000 Kelvin colour temperature, delivering long-throw, high-definition white light ideal for forward-facing work lighting, machinery spotlights, and long-distance task illumination. The BLB070525 carries a dual IP68 and IP69K ingress protection rating — the highest combined standard available — confirming full submersion resistance alongside protection against high-pressure, high-temperature washdowns. This makes the light equally at home on offshore marine vessels, agricultural washdown machinery, mining equipment, and construction plant subject to regular high-pressure cleaning. A marine-grade anti-corrosive coating on the aluminium body provides an additional layer of protection against salt spray, moisture, and harsh chemical environments, significantly extending service life in coastal and marine applications. CISPR25 Class 1 EMC approval ensures the light generates minimal electromagnetic interference, protecting sensitive vehicle electronics and communications equipment in trucks, vessels, and modern work vehicles. The DT04-2P deutsch-style connector provides a secure, weatherproof wiring connection that resists vibration-induced loosening — rated to 21.2G vibration resistance. Universal 9–32V input accepts both 12V and 24V vehicle electrical systems without modification, and the single bolt mount allows flexible positioning on roll bars, bull bars, equipment frames, and machinery guards.
Features & Benefits
25° Narrow Beam Pattern — Focused long-throw illumination concentrates light output at distance for spotlighting, forward work lighting, and machinery applications where precision targeting is required rather than wide flood coverage.
IP68 & IP69K Dual Rating — Full submersion rating combined with high-pressure washdown protection provides the highest available ingress protection standard. Suitable for marine applications, underground mining, and equipment subject to regular high-pressure cleaning.
Marine-Grade Anti-Corrosive Coating — Specialised protective coating on the aluminium body resists salt spray, moisture, and chemical exposure, making the BLB070525 a genuine long-term solution for coastal, offshore, and marine vessel applications.
CISPR25 Class 1 EMC Approved — Meets the highest electromagnetic compatibility standard for vehicle components, ensuring no interference with onboard radios, GPS, communications, or control systems across automotive, marine, and industrial applications.
6000 Kelvin Output — Pure white, daylight-spectrum colour temperature delivers excellent colour rendering and clarity for work tasks, providing fatigue-reducing visibility during extended night operations.
21.2G Vibration Resistance — Engineered to withstand extreme vibration levels from heavy machinery, off-road driving, and industrial equipment without compromising LED connections or optical integrity.
Aluminium Body Construction — Lightweight yet thermally efficient aluminium housing draws heat away from LEDs effectively, supporting consistent output and extended LED lifespan across demanding duty cycles.
DT04-2P Deutsch Connector — Industry-standard weatherproof connector provides a secure, moisture-resistant wiring termination resistant to vibration loosening and corrosion in harsh environments.
9–32V Universal Input — Compatible with 12V and 24V vehicle electrical systems, covering passenger 4WDs, light commercial vehicles, heavy trucks, agricultural machinery, and marine vessels without voltage adapters.
Technical Specs
| Specification |
Detail |
| Part Number |
BLB070525 |
| Voltage Input |
9–32V (12V or 24V compatible) |
| LEDs |
5 |
| Beam Pattern |
Narrow (25°) |
| Colour Temperature |
6000K |
| Lens Material |
Acrylic |
| Body Material |
Aluminium |
| Shape |
Square |
| Mount Type |
Single Bolt |
| Connector |
DT04-2P |
| Ingress Protection |
IP68, IP69K |
| EMC Compliance |
CISPR25 Class 1 |
| Vibration Rating |
21.2G |
| Coating |
Marine-Grade Anti-Corrosive |
| Dimensions (W×H×D) |
116 × 100 × 75mm |
| Weight |
1.3kg |
| Warranty |
Two Years |
Compatible With / Goes Well With
The Blacktips BLB070525 suits any 12V or 24V vehicle, vessel, or equipment requiring focused narrow-beam work lighting in demanding environments. Primary applications include 4WD and off-road vehicles requiring long-throw auxiliary lighting, agricultural tractors and harvesters, construction plant and earthmoving equipment, mining trucks and underground machinery, commercial fishing vessels and offshore platforms, tow trucks and roadside assistance vehicles, and heavy trucks requiring supplementary work lighting.
Pairs well with complementary Blacktips flood beam work lights for combined narrow/wide coverage setups, OEX emergency beacons and strobe lighting for comprehensive vehicle safety configurations, DT04-2P wiring harnesses and switch kits, and bull bar or roll cage mounting brackets for flexible positioning.
Frequently Asked Questions
What is the difference between IP68 and IP69K ratings?
IP68 certifies the light can withstand continuous submersion in water beyond 1 metre depth, while IP69K certifies protection against high-pressure, high-temperature water jets at close range (typically 80°C at 80–100 bar). Carrying both ratings simultaneously means the BLB070525 is protected against both prolonged water immersion and harsh pressure-washing — the most comprehensive ingress protection available for a work light.
What does the 25° beam angle mean in practice?
A 25° narrow beam concentrates light output into a tight, long-throw column rather than spreading it wide. This is ideal for spotlighting tasks at distance, forward-facing machinery lighting, and applications where you need to illuminate a specific area far ahead rather than illuminate a broad area close to the vehicle. For wide flood coverage, pair with a Blacktips flood beam variant.
Is this light suitable for saltwater marine environments?
Yes. The marine-grade anti-corrosive coating on the aluminium body provides specific protection against salt spray, sea mist, and moisture ingress that causes premature corrosion on standard work lights. Combined with the IP68/IP69K dual rating, the BLB070525 is built to withstand the demands of coastal and offshore marine applications.
What does CISPR25 Class 1 EMC approval mean?
CISPR25 is an international standard governing electromagnetic emissions from vehicle components. Class 1 is the strictest level, confirming the BLB070525 produces the minimum possible electromagnetic interference. This ensures the light will not disrupt onboard AM/FM radio, GPS navigation, UHF communications, or sensitive vehicle control electronics — particularly important for trucks, vessels, and work vehicles with complex electrical systems.
Can two BLB070525 lights be paired for a wider combined coverage setup?
Yes. Running two BLB070525 narrow beam lights angled slightly outward provides excellent forward coverage with greater depth and intensity than a single flood beam alternative. Alternatively, pairing one BLB070525 narrow beam with a Blacktips flood beam variant of the same series delivers a versatile combined near/far illumination setup ideal for 4WD, agricultural, and work vehicle applications.
