Description
Blacktips BLB070925 9 LED Work Light 25DEG Narrow Beam
High-output, marine-grade aluminium rectangular work light delivering a precise 25° narrow beam with IP68/IP69K dual-rated protection, CISPR25 Class 1 EMC approval, and anti-corrosive coating — engineered for 4WD, marine, agricultural, and heavy industrial applications demanding greater long-throw intensity than 5 LED alternatives.
Product Overview
The Blacktips BLB070925 steps up from the compact 5 LED range to deliver significantly greater long-throw output through a 9 LED array, housed in a larger 145 x 135 x 85mm rectangular aluminium body. Producing a focused 25° narrow beam at a crisp 6000 Kelvin colour temperature, the BLB070925 is purpose-built for applications where maximum forward-throw intensity is critical — including heavy plant spotlighting, long-range forward work lighting on large agricultural machinery, forward illumination on mining trucks, and demanding off-road night driving where the 5 LED configuration falls short. The BLB070925 carries a dual IP68 and IP69K ingress protection rating — the highest combined standard available — confirming full submersion resistance alongside protection against high-pressure, high-temperature washdowns. This makes the light equally at home on offshore marine vessels, agricultural washdown machinery, mining equipment, and construction plant subject to regular high-pressure cleaning. A marine-grade anti-corrosive coating on the aluminium body provides an additional layer of protection against salt spray, moisture, and harsh chemical environments, significantly extending service life in coastal and marine applications. CISPR25 Class 1 EMC approval ensures the light generates minimal electromagnetic interference, protecting sensitive vehicle electronics and communications equipment in trucks, vessels, and modern work vehicles. The DT04-2P deutsch-style connector provides a secure, weatherproof wiring connection that resists vibration-induced loosening — rated to 21.2G vibration resistance. Universal 9–32V input accepts both 12V and 24V vehicle electrical systems without modification, and the multiple bolt mount delivers a stable, vibration-resistant installation platform suited to the heavier 2.25kg body of this larger configuration.
Features & Benefits
9 LED Array for Greater Output — The step up from 5 to 9 LEDs delivers substantially increased light output and throw distance in the same focused 25° narrow beam, making the BLB070925 the preferred choice for large equipment, heavy machinery, and applications where maximum long-throw intensity is required.
25° Narrow Beam Pattern — Focused long-throw illumination concentrates light output at distance for spotlighting, forward work lighting, and machinery applications where precision targeting is required rather than wide flood coverage.
IP68 & IP69K Dual Rating — Full submersion rating combined with high-pressure washdown protection provides the highest available ingress protection standard. Suitable for marine applications, underground mining, and equipment subject to regular high-pressure cleaning.
Marine-Grade Anti-Corrosive Coating — Specialised protective coating on the aluminium body resists salt spray, moisture, and chemical exposure, making the BLB070925 a genuine long-term solution for coastal, offshore, and marine vessel applications.
CISPR25 Class 1 EMC Approved — Meets the highest electromagnetic compatibility standard for vehicle components, ensuring no interference with onboard radios, GPS, communications, or control systems across automotive, marine, and industrial applications.
6000 Kelvin Output — Pure white, daylight-spectrum colour temperature delivers excellent colour rendering and clarity for work tasks, providing fatigue-reducing visibility during extended night operations.
21.2G Vibration Resistance — Engineered to withstand extreme vibration levels from heavy machinery, off-road driving, and industrial equipment without compromising LED connections or optical integrity.
Rectangular Aluminium Body — Larger rectangular form factor provides an extended LED spread for a wider vertical beam profile than square compact units, while the thermally efficient aluminium housing maintains consistent output and extended LED lifespan across demanding duty cycles.
Multiple Bolt Mount — Multi-point mounting footprint provides a stable, vibration-resistant installation platform suited to the heavier body of this 9 LED configuration, ideal for heavy machinery, high-vibration equipment, and applications requiring a secure fixed position.
DT04-2P Deutsch Connector — Industry-standard weatherproof connector provides a secure, moisture-resistant wiring termination resistant to vibration loosening and corrosion in harsh environments.
9–32V Universal Input — Compatible with 12V and 24V vehicle electrical systems, covering passenger 4WDs, light commercial vehicles, heavy trucks, agricultural machinery, and marine vessels without voltage adapters.
Technical Specs
| Specification |
Detail |
| Part Number |
BLB070925 |
| Voltage Input |
9–32V (12V or 24V compatible) |
| LEDs |
9 |
| Beam Pattern |
Narrow (25°) |
| Colour Temperature |
6000K |
| Lens Material |
Acrylic |
| Body Material |
Aluminium |
| Shape |
Rectangle |
| Mount Type |
Multiple Bolt |
| Connector |
DT04-2P |
| Ingress Protection |
IP68, IP69K |
| EMC Compliance |
CISPR25 Class 1 |
| Vibration Rating |
21.2G |
| Coating |
Marine-Grade Anti-Corrosive |
| Dimensions (W×H×D) |
145 × 135 × 85mm |
| Weight |
2.25kg |
| Warranty |
Two Years |
Compatible With / Goes Well With
The Blacktips BLB070925 suits any 12V or 24V vehicle, vessel, or equipment requiring high-output focused narrow-beam work lighting in demanding environments. Primary applications include large 4WD and off-road vehicles requiring maximum long-throw auxiliary lighting, agricultural tractors, harvesters, and broad-acre machinery, construction plant and heavy earthmoving equipment, mining trucks and underground vehicles requiring strong forward illumination, commercial fishing vessels and offshore platforms, tow trucks and heavy recovery vehicles, and large trucks requiring powerful supplementary forward or work lighting.
Pairs well with complementary Blacktips wide flood work lights such as the BLB070560 or BLB070960 for combined narrow/wide coverage setups, OEX emergency beacons and strobe lighting for comprehensive vehicle safety configurations, DT04-2P wiring harnesses and switch kits, and heavy-duty bull bar or equipment frame mounting brackets suited to the larger form factor.
Frequently Asked Questions
How does the BLB070925 differ from the BLB070525 5 LED narrow beam?
Both lights share the same 25° narrow beam pattern, IP68/IP69K dual rating, marine-grade coating, and CISPR25 Class 1 compliance. The key difference is output — the BLB070925 uses 9 LEDs versus 5, delivering significantly greater light intensity and throw distance in the same focused beam. The 9 LED model is the better choice for large equipment, heavy machinery, long-range forward illumination, and applications where the 5 LED configuration does not provide sufficient output.
What is the difference between IP68 and IP69K ratings?
IP68 certifies the light can withstand continuous submersion in water beyond 1 metre depth, while IP69K certifies protection against high-pressure, high-temperature water jets at close range (typically 80°C at 80–100 bar). Carrying both ratings simultaneously means the BLB070925 is protected against both prolonged water immersion and harsh pressure-washing — the most comprehensive ingress protection available for a work light.
Is this light suitable for saltwater marine environments?
Yes. The marine-grade anti-corrosive coating on the aluminium body provides specific protection against salt spray, sea mist, and moisture ingress that causes premature corrosion on standard work lights. Combined with the IP68/IP69K dual rating, the BLB070925 is built to withstand the demands of coastal and offshore marine applications.
What does CISPR25 Class 1 EMC approval mean?
CISPR25 is an international standard governing electromagnetic emissions from vehicle components. Class 1 is the strictest level, confirming the BLB070925 produces the minimum possible electromagnetic interference. This ensures the light will not disrupt onboard AM/FM radio, GPS navigation, UHF communications, or sensitive vehicle control electronics — particularly important for trucks, vessels, and work vehicles with complex electrical systems.
Can the BLB070925 be paired with a flood beam light for a combined setup?
Yes. Pairing the BLB070925 narrow beam with a Blacktips wide flood variant such as the BLB070960 delivers a versatile combined near/far illumination setup — the flood beam covers the wide work zone close to the vehicle while the narrow beam provides maximum long-throw intensity at distance. This dual-light configuration is widely used on large 4WD, agricultural, and heavy industrial vehicles for comprehensive night operation coverage.
