Description
Blacktips BLB070960 9 LED Work Light 60DEG Wide Flood
High-output, marine-grade aluminium rectangular work light delivering a broad 60° wide flood beam with IP68/IP69K dual-rated protection, CISPR25 Class 1 EMC approval, and anti-corrosive coating — engineered for 4WD, marine, agricultural, and heavy industrial applications demanding greater wide-area illumination than 5 LED alternatives.
Product Overview
The Blacktips BLB070960 combines the broad 60° wide flood coverage of the compact 5 LED range with the significantly increased output of a 9 LED array, housed in a larger 145 x 135 x 85mm rectangular aluminium body. Producing a wide flood beam at a crisp 6000 Kelvin colour temperature, the BLB070960 is purpose-built for applications where maximum wide-area illumination is critical — including large reversing zones on heavy trucks, expansive work site lighting on mining equipment, wide-area coverage on large agricultural machinery, and demanding loading dock and equipment bay lighting where the 5 LED configuration falls short. The BLB070960 carries a dual IP68 and IP69K ingress protection rating — the highest combined standard available — confirming full submersion resistance alongside protection against high-pressure, high-temperature washdowns. This makes the light equally at home on offshore marine vessels, agricultural washdown machinery, mining equipment, and construction plant subject to regular high-pressure cleaning. A marine-grade anti-corrosive coating on the aluminium body provides an additional layer of protection against salt spray, moisture, and harsh chemical environments, significantly extending service life in coastal and marine applications. CISPR25 Class 1 EMC approval ensures the light generates minimal electromagnetic interference, protecting sensitive vehicle electronics and communications equipment in trucks, vessels, and modern work vehicles. The DT04-2P deutsch-style connector provides a secure, weatherproof wiring connection that resists vibration-induced loosening — rated to 21.2G vibration resistance. Universal 9–32V input accepts both 12V and 24V vehicle electrical systems without modification, and the multiple bolt mount delivers a stable, vibration-resistant installation platform well suited to the heavier 2.25kg body of this larger configuration.
Features & Benefits
9 LED Array for Greater Wide-Area Output — The step up from 5 to 9 LEDs delivers substantially increased light output across the same broad 60° flood zone, making the BLB070960 the preferred choice for large equipment, heavy machinery, and applications where maximum wide-area illumination intensity is required.
60° Wide Flood Beam Pattern — Broad area illumination spreads light across a wide zone close to the vehicle or equipment, ideal for reversing, work zone lighting, equipment bays, loading areas, and applications where wide near-field coverage takes priority over long-throw spotlighting.
IP68 & IP69K Dual Rating — Full submersion rating combined with high-pressure washdown protection provides the highest available ingress protection standard. Suitable for marine applications, underground mining, and equipment subject to regular high-pressure cleaning.
Marine-Grade Anti-Corrosive Coating — Specialised protective coating on the aluminium body resists salt spray, moisture, and chemical exposure, making the BLB070960 a genuine long-term solution for coastal, offshore, and marine vessel applications.
CISPR25 Class 1 EMC Approved — Meets the highest electromagnetic compatibility standard for vehicle components, ensuring no interference with onboard radios, GPS, communications, or control systems across automotive, marine, and industrial applications.
6000 Kelvin Output — Pure white, daylight-spectrum colour temperature delivers excellent colour rendering and clarity for work tasks, providing fatigue-reducing visibility during extended night operations.
21.2G Vibration Resistance — Engineered to withstand extreme vibration levels from heavy machinery, off-road driving, and industrial equipment without compromising LED connections or optical integrity.
Rectangular Aluminium Body — Larger rectangular form factor provides an extended LED spread for a wider horizontal beam profile, while the thermally efficient aluminium housing maintains consistent output and extended LED lifespan across demanding duty cycles.
Multiple Bolt Mount — Multi-point mounting footprint provides a stable, vibration-resistant installation platform suited to the heavier body of this 9 LED configuration, ideal for heavy machinery, high-vibration equipment, and applications requiring a secure fixed position.
DT04-2P Deutsch Connector — Industry-standard weatherproof connector provides a secure, moisture-resistant wiring termination resistant to vibration loosening and corrosion in harsh environments.
9–32V Universal Input — Compatible with 12V and 24V vehicle electrical systems, covering passenger 4WDs, light commercial vehicles, heavy trucks, agricultural machinery, and marine vessels without voltage adapters.
Technical Specs
| Specification |
Detail |
| Part Number |
BLB070960 |
| Voltage Input |
9–32V (12V or 24V compatible) |
| LEDs |
9 |
| Beam Pattern |
Wide Flood (60°) |
| Colour Temperature |
6000K |
| Lens Material |
Acrylic |
| Body Material |
Aluminium |
| Shape |
Rectangle |
| Mount Type |
Multiple Bolt |
| Connector |
DT04-2P |
| Ingress Protection |
IP68, IP69K |
| EMC Compliance |
CISPR25 Class 1 |
| Vibration Rating |
21.2G |
| Coating |
Marine-Grade Anti-Corrosive |
| Dimensions (W×H×D) |
145 × 135 × 85mm |
| Weight |
2.25kg |
| Warranty |
Two Years |
Compatible With / Goes Well With
The Blacktips BLB070960 suits any 12V or 24V vehicle, vessel, or equipment requiring high-output wide-area flood lighting in demanding environments. Primary applications include large 4WD and off-road vehicles requiring broad reversing or campsite illumination, agricultural tractors, harvesters, and broad-acre machinery needing maximum work zone coverage, construction plant and heavy earthmoving equipment, mining trucks and underground vehicles requiring wide area lighting around the machine, commercial fishing vessels and offshore platforms, tow trucks and heavy recovery vehicles needing wide side and rear illumination, and large trucks requiring powerful supplementary reversing or loading dock lighting.
Pairs well with the Blacktips BLB070925 narrow beam for a high-output combined near/far coverage setup, OEX emergency beacons and strobe lighting for comprehensive vehicle safety configurations, DT04-2P wiring harnesses and switch kits, and heavy-duty bull bar or equipment frame mounting brackets suited to the larger form factor.
Frequently Asked Questions
How does the BLB070960 differ from the BLB070560 5 LED wide flood?
Both lights share the same 60° wide flood beam pattern, IP68/IP69K dual rating, marine-grade coating, and CISPR25 Class 1 compliance. The key difference is output — the BLB070960 uses 9 LEDs versus 5, delivering significantly greater light intensity and wider area coverage in the same flood pattern. The 9 LED model is the better choice for large equipment, heavy machinery, expansive work zones, and applications where the 5 LED configuration does not provide sufficient illumination.
What is the difference between IP68 and IP69K ratings?
IP68 certifies the light can withstand continuous submersion in water beyond 1 metre depth, while IP69K certifies protection against high-pressure, high-temperature water jets at close range (typically 80°C at 80–100 bar). Carrying both ratings simultaneously means the BLB070960 is protected against both prolonged water immersion and harsh pressure-washing — the most comprehensive ingress protection available for a work light.
Is this light suitable for saltwater marine environments?
Yes. The marine-grade anti-corrosive coating on the aluminium body provides specific protection against salt spray, sea mist, and moisture ingress that causes premature corrosion on standard work lights. Combined with the IP68/IP69K dual rating, the BLB070960 is built to withstand the demands of coastal and offshore marine applications.
What does CISPR25 Class 1 EMC approval mean?
CISPR25 is an international standard governing electromagnetic emissions from vehicle components. Class 1 is the strictest level, confirming the BLB070960 produces the minimum possible electromagnetic interference. This ensures the light will not disrupt onboard AM/FM radio, GPS navigation, UHF communications, or sensitive vehicle control electronics — particularly important for trucks, vessels, and work vehicles with complex electrical systems.
Can the BLB070960 be paired with a narrow beam light for a combined setup?
Yes. Pairing the BLB070960 wide flood with the Blacktips BLB070925 narrow beam delivers a high-output combined near/far illumination setup — the flood beam covers the wide work zone close to the vehicle while the narrow beam provides maximum long-throw intensity at distance. Both lights share identical dimensions, mounting, and connector specifications, making them a natural matched pair for large 4WD, agricultural, and heavy industrial vehicle lighting configurations.
