DNA RVS79FM01 Premium 7.9" OEM Replacement Mirror - Ford Ranger/Mazda BT-50
Professional OEM-style replacement mirror with 7.9" full screen display and multi-camera capability
The DNA RVS79FM01 Premium OEM Style 7.9" Replacement Mirror delivers professional-grade rear vision with crystal-clear full screen display designed specifically for Ford Ranger 2019+, Mazda BT-50, and Ford Transit series vehicles. This premium replacement mirror features auto brightness control, 4 video inputs, and illuminated smart touchscreen controls providing seamless integration with existing vehicle mirror mounts.
Engineered for Australian conditions with 4mm thick glass and high-quality PC+ABS housing, this mirror offers PAL/NTSC/AHD/HD-TVI compatibility for maximum camera system flexibility. Perfect for commercial operators, tradies, and 4WD enthusiasts requiring professional rear vision systems with OEM appearance and multi-camera monitoring capability.
DNA RVS79FM01 Key Features & Benefits:
-
OEM Integration: Direct replacement using existing mirror mount - no dashboard modifications required
-
Auto Brightness Control: Intelligent ambient light sensing adjusts display brightness for day/night/dusk conditions
-
4-Camera Capability: Multiple video inputs support vehicle, caravan, trailer, and auxiliary camera monitoring
-
Smart Touchscreen: Hidden illuminated controls automatically activate when touched, hide after 10 seconds
-
Australian-Built Tough: 4mm thick glass and reinforced housing withstand harsh Australian conditions
-
Universal Compatibility: PAL/NTSC/AHD/HD-TVI selectable formats work with all camera types
Technical Specifications:
-
Model: DNA RVS79FM01
-
SKU: RVS79FM01
-
Screen Size: 7.9" TFT-LCD full screen display
-
Aspect Ratio: 16:9 widescreen
-
Resolution: 1280 x 370 pixels
-
Video Systems: PAL/NTSC/AHD/HD-TVI selectable
-
Video Inputs: 4 channels with individual triggers
-
Operating Voltage: 12V DC automotive
-
Mirror Dimensions: 213mm W x 83.8mm H x 49.2mm D
-
Glass Thickness: 4mm premium glass
-
Housing Material: High-quality PC + ABS plastic
-
Mount: Large diameter tube with internal spring
-
Auto Features: Brightness control, reverse activation
-
Controls: Smart touchscreen with 10-second auto-hide
-
Packaging: Premium display box
Vehicle Compatibility:
-
Ford Ranger: 2019 onwards models with OEM mirror mount
-
Mazda BT-50: All models with standard mirror mounting
-
Ford E-Transit: 2022 onwards commercial vehicles
-
Ford Focus: 2015-2018 model years
-
Ford Transit Connect: 2014-2023 model years
-
Ford Transit: 2015 onwards commercial van series
Installation Applications:
-
Dual-Cab Utes: Ford Ranger and Mazda BT-50 trade and commercial applications
-
Commercial Fleets: Ford Transit series vans and commercial vehicle monitoring
-
Caravan Towing: Multi-camera setup for vehicle and caravan rear vision
-
Tradie Vehicles: Professional installation for work vehicles requiring multiple camera angles
-
4WD Touring: Off-road applications with auxiliary camera monitoring capability
Frequently Asked Questions
Will this fit my 2020 Ford Ranger? Yes, includes specific mounting bracket for Ford Ranger 2019 onwards models.
Can I connect multiple cameras? Yes, supports up to 4 cameras with individual trigger inputs for different applications.
Does it work with AHD cameras? Yes, selectable PAL/NTSC/AHD/HD-TVI compatibility works with all camera types.
How do I adjust the brightness? Auto brightness control automatically adjusts based on ambient light conditions.
Is installation plug-and-play? Uses existing mirror mount but requires professional installation for camera connections.
