Description
Dynamat 11102 Dynaliner 6mm High Performance Thermal and Acoustic Insulation Matting One 813mm x 1372mm Self-Adhesive Closed Cell Rubber Sheet 1.11sqm Coverage
The Dynamat 11102 is one 813mm x 1372mm (32" x 54") sheet of Dynaliner at 6.35mm (1/4") thickness, giving 1.11sqm (12 sq ft) of coverage. The 1/4" version of Dynaliner in the same closed cell rubber formula as the 11101, delivering greater thermal resistance where panel clearance allows a thicker insulator.
Product overview
Dynaliner is a self-adhesive closed cell rubber thermal and acoustic insulator designed to be used on top of Dynamat Xtreme for combined vibration damping and heat blocking performance. The 11102 is the mid-thickness option in the Dynaliner range at 6.35mm, providing greater thermal resistance than the 3.175mm 11101 in applications where the available space permits a thicker layer. The tightly packed closed cell structure gives near-zero air infiltration, which is the basis of Dynaliner's heat-blocking capability and its resistance to oil and water absorption. Because it does not hold water, Dynaliner will not promote rust or mildew against the panel surface the way conventional under-carpet padding can. Crush and tear resistant, lightweight and flexible, it conforms to roof, firewall, floor, quarter panel, and door surfaces.
Features and benefits
6.35mm (1/4") closed cell rubber: Greater thermal resistance than the 3.175mm 11101 for applications with more available panel clearance.
One 813mm x 1372mm sheet: 1.11sqm (12 sq ft) for targeted treatment.
Used on top of Dynamat Xtreme: Combined with Dynamat, nearly doubles total thermal resistance of the installation.
Highest heat-blocking properties of any single-layer synthetic foam insulator.
Does not absorb water: Will not promote rust or mildew.
Oil resistant.
Crush and tear resistant.
Ultra lightweight and flexible.
Self-adhesive installation: Peel and press directly onto Dynamat or bare panels.
Isolates vibration and reduces unwanted noise.
What's in the box
- 1 x Dynaliner sheet (813mm x 1372mm x 6.35mm / 32" x 54" x 1/4")
- Total coverage: 12 sq ft (1.11sqm)
Technical specs
| Specification |
Detail |
| SKU |
11102 |
| Brand |
Dynamat |
| Type |
Thermal and acoustic insulation matting |
| Product Line |
Dynaliner |
| Sheets Per Pack |
1 |
| Sheet Size |
813mm x 1372mm (32" x 54") |
| Thickness |
6.35mm (1/4") |
| Total Coverage |
1.11sqm (12 sq ft) |
| Material |
Closed cell rubber |
| Application |
Self-adhesive |
Frequently asked questions
What is the difference between the Dynaliner 11102 and the 11101?
The 11102 is 6.35mm (1/4") thick. The 11101 is 3.175mm (1/8") thick. Both share the same 813mm x 1372mm sheet size and 1.11sqm coverage. The thicker 11102 provides greater thermal resistance where panel clearance allows for it. Dynamat recommends using the thickest Dynaliner that the available space will allow.
What is Dynaliner and how does it work with Dynamat Xtreme?
Dynaliner is a closed cell rubber thermal and acoustic insulator. Dynamat Xtreme is applied to the bare metal panel first to damp vibration, then Dynaliner is applied on top to add thermal insulation and acoustic absorption. Combined, the two layers nearly double total thermal resistance compared to Dynamat alone.
Why does Dynaliner not promote rust or mildew?
Dynaliner's closed cell structure has near-zero air infiltration, so water cannot be absorbed into the material. Unlike conventional under-carpet padding that traps moisture against the panel, Dynaliner stays dry and does not create conditions for rust or mildew.
What areas of the vehicle is the 11102 suited to?
The 11102 is suited to roof, firewall, floor, quarter panels, doors, and under-hood areas where a 6.35mm layer of thermal and acoustic insulation fits within the available panel clearance.
Does the 11102 require surface preparation?
No. The self-adhesive backing bonds directly to Dynamat Xtreme or bare panel surfaces without adhesive preparation. A Dynaroller tool is recommended to ensure complete contact.
