Description
GME PSM1215 Switch Mode Power Supply 15 Amp Peak
The GME PSM1215 is a regulated switch mode power supply converting 240V 50Hz AC to a regulated 13.8V DC output, delivering 15 amp peak and 12 amp continuous current, with high efficiency switch mode technology and a thermally controlled in-built fan.
Product Overview
For over 60 years GME has designed and manufactured an extensive range of high quality accessories to suit a wide variety of applications. The GME PSM Series of regulated power supplies offer quality and superior performance rarely found in competitor power supplies. All PSM Series power supplies feature rugged steel construction, superior performance, and unparalleled reliability with less than 20mV ripple at the continuous rating, making them ideal for all RF and computer applications.
With a vented wrap-around steel cover, high efficiency heat sinks, heavy duty construction, and PC board mounted regulator circuitry, the PSM series are quality power supplies with solid performance and high reliability. The PSM1215 delivers 15 amp peak and 12 amp continuous current at a regulated 13.8V DC from a 240V 50Hz AC input, suited to communication equipment or any application requiring stable regulated DC voltage.
Features & Benefits
15 Amp Peak, 12 Amp Continuous: Delivers up to 15 amps peak and a sustained 12 amp continuous current, suited to moderate power communication equipment.
240V 50Hz AC Input: Runs from a standard 240V 50Hz AC mains supply, converting to a regulated 13.8V DC output.
Less Than 20mV Ripple: Ripple of less than 20mV at the continuous rating provides clean, stable power ideal for RF and computer applications.
Compact and Lightweight Aluminium Heat Sink: A compact, lightweight aluminium heat sink helps manage heat while keeping the unit manageable to install.
Thermally Controlled In-Built Fan: An in-built fan with thermal control cools the unit as needed, helping maintain reliable long-term operation.
High Efficiency Switch Mode Technology: High efficiency switch mode technology allows for cooler operation and a longer service life compared to older linear power supply designs.
Suitable for Most Communication Equipment: Suited to most communication equipment or any application requiring stable regulated DC voltage.
Rugged Steel Construction: Rugged steel construction with a vented wrap-around cover and heavy duty build provides durability and reliable long-term use.
Technical Specs
| Specification | Detail |
| SKU | PSM1215 |
| Brand | GME |
| Description | Switch Mode Power Supply, 15 Amp Peak |
| Input Voltage | 240V 50Hz AC |
| Output Voltage | 13.8V DC Regulated |
| Peak Current | 15A |
| Continuous Current | 12A |
| Ripple | Less Than 20mV at Continuous Rating |
| Cooling | Thermally Controlled In-Built Fan |
| Heat Sink | Compact, Lightweight Aluminium |
| Construction | Rugged Steel, Vented Wrap-Around Cover |
| Technology | High Efficiency Switch Mode |
| In the Box | Power Supply with Lead |
Compatible With
The PSM1215 is suitable for most communication equipment or any application requiring stable regulated 13.8V DC voltage from a 240V 50Hz AC supply, including RF and computer applications. Confirm your equipment's current draw is within the 15 amp peak and 12 amp continuous rating before purchase.
Frequently Asked Questions
What does the PSM1215 do?
The PSM1215 is a regulated switch mode power supply that converts a 240V 50Hz AC input into a stable 13.8V DC output, delivering up to 15 amps peak and 12 amps continuous for communication equipment.
What is the difference between the PSM1215 and PSM1235?
Both share the same design and features, but the PSM1215 delivers 15 amps peak with 12 amps continuous current, while the PSM1235 delivers a higher 35 amps peak for more demanding equipment.
Does the PSM1215 need active cooling?
Yes. The PSM1215 uses a thermally controlled in-built fan alongside its aluminium heat sink to manage heat during operation.
How much ripple does the PSM1215 produce?
The PSM1215 produces less than 20mV of ripple at the continuous rating, providing clean, stable power for sensitive equipment.
What's included with the PSM1215?
The PSM1215 comes with the power supply and lead.
