Description
Finest-Ever Automotive Component Speakers in a 3-Way System from JBL!
JBL Arena X is the flagship automotive loudspeaker from our ARENA series, expect to be finest-ever automotive component speakers in a 3-way system including pair Beryllium tweeter with special Revel Performa waveguide and require with 3.5” midrange , 6.5” woofer optimized for car audio applications for smooth, off-axis response, dynamic stability and low distortion.
The gorgeous cosmetic grills and innovative custom mounting rings allow for a seamless elegant install hiding all midrange fasteners behind a magnetic trim ring and grill.
Features:
- Arena X Tweeter had optimized oval waveguide Beryllium tweeter of Luxury Revel Performa design, and optimized to powerful ND magnet for the ultimate in lightweight performance (weight be reduced 69% from1,300g to 400g/pc) and to make it thinner and smaller (Motor size be reduced 70% to 12cm^2) for car aftermarket installation market
- New 3.5” carbon fiber midrange to bridge smoothly deeper bass woofer and high frequency extend TW in 3-way system. The 6.5-inch / 165mm woofer performance more deeper bass than GTI 670 with new carbon fiber material and new grille, New CMF
- High Res Audio Certification
- Supply more easier installation accessories included customized plastic rings, Metal Tweeter plates, etc.
Benefits:
- Be tweeter provides smooth extended up to 40KHz frequency response and well-behaved off-axis response throughout the entire operating range
- Removable grills and fantastic decoration rings supply multi-options visual
- Luxury audio of “Revel Performa” design joint with JBL Flagship product
Specifications:
- Type Active 3-way system
- Woofer Pair 6.5” woofer, 4ohm
- Woofer Bandwidth 60Hz-6Khz (-6dB)
- Woofer Power 100Wrms/600W peak
- Woofer Sensitivity 91dB (2.83V/1m)
- Woofer Fs 60Hz
- WF mounting depth/cutout 69mm/128mm
- Tweeter Pair 1” tweeter, 4ohm
- Tweeter Bandwidth 1KHz-40KHz
- Tweeter Power 50Wrms w/o filtering/200W peak
- Tweeter Sensitivity >95dB (2.83V/1m)
- Tweeter Dome Beryllium dome
- Tweeter Fs 1.35K Hz
- TW mounting depth/cutout 20mm X 52mm
- Midrange Pair 3.5” midrange
- Midrange Power 50W RMS/200W peak
- Midrange Fs 125Hz
- Midrange Sensitivity >87dB (2.83V/1m)
- Midrange Bandwidth 200Hz – 6KHz (-6dB)
- MR mounting depth/cutout 37mm max /73mm (Ref)
