Description
JL Audio JLA-010-03339-00 MVi Marine Amplifier - 8 Channel Full-Range Marine Amplifier
Premium marine amplification with intelligent DSP control and IPX2 weather protection for ultimate boat audio performance.
Product Overview
The JL Audio MVi 8-Channel Marine Amplifier (JLA-010-03339-00) represents the pinnacle of marine audio engineering, delivering 800 watts of clean, efficient Class D power across eight independent channels. Designed specifically for the demanding marine environment, this amplifier combines advanced digital signal processing with IPX2 weather protection to provide exceptional sound quality and reliability on the water. The compact chassis houses sophisticated circuitry that powers everything from full-range speakers to tower speakers, with bridging capability for added flexibility. With USB connectivity for advanced tuning via JL Audio's TüN software and compatibility with the JLid network bridge, the MVi system transforms marine audio into a fully integrated, professionally tuned sound system that thrives in harsh saltwater conditions.
Features & Benefits
The 8-channel MVi amplifier delivers 100 watts RMS per channel at 2 ohms (90W at 12.5V input), providing ample power for comprehensive marine audio systems including helm stations, cockpit zones, tower speakers, and cabin areas. The Class D design ensures maximum efficiency with minimal heat generation, critical for enclosed marine installations. Advanced digital signal processing through USB connectivity allows precise tuning of crossovers, equalization, time alignment, and output levels for each channel individually. The amplifier's bridging capability creates four 200-watt channels for driving larger speakers or dedicated zones. IPX2 water and dust rating protects against splashing and marine moisture when mounted vertically with connections downward. The compact footprint (13.96" x 2.05" x 6.93") simplifies installation in space-constrained marine environments. Marine-grade construction with conformal-coated circuit boards and corrosion-resistant hardware ensures long-term reliability in saltwater conditions.
Technical Specifications
| Specification |
Details |
| Model |
JLA-010-03339-00 MVi Marine Amplifier |
| Configuration |
8-Channel Full-Range |
| Amplifier Class |
Class D |
| Power @ 14.4V / 4Ω |
75W RMS x 8 channels |
| Power @ 14.4V / 2Ω |
100W RMS x 8 channels |
| Power @ 12.5V / 2Ω |
90W RMS x 8 channels |
| Bridged Power |
200W x 4 @ 4Ω |
| Total System Power |
800 watts |
| Frequency Response |
12 Hz - 21 kHz (+0/-1dB) |
| Signal-to-Noise Ratio |
99 dB (analog inputs) |
| THD+N @ Rated Power |
<1% @ 2Ω per channel |
| Damping Factor |
>100 @ 4Ω, >50 @ 2Ω (50 Hz) |
| Input Voltage Range |
250 mV - 16V RMS (RCA) |
| Operating Voltage |
10-15 VDC |
| Water/Dust Rating |
IPX2 (vertical mount) |
| Fuse Rating |
80A |
| Recommended Fuse Type |
AFS, AGU, or MaxiFuse™ |
| Min. Wire Gauge |
4 AWG (power/ground) |
| Dimensions (W x H x D) |
355 x 52 x 176 mm (13.96" x 2.05" x 6.93") |
| Weight |
2.54 kg (5.6 lbs) |
| Warranty |
3 years |
| Included Accessories |
Power connector, speaker harnesses, 6ft USB cable, RCA covers, mounting hardware, Allen wrenches |
Compatible With / Goes Well With
JL Audio Marine Speakers: M3 Marine Speakers, M6 Marine Speakers, M3/M6/M7 Marine Subwoofers, M6 Thin-Line Subwoofers, M3/M6 Enclosed Tower Speakers, VeX Enclosed Systems
JL Audio Source Units: MediaMaster 55 Stereo, MediaMaster 105 Stereo, JL Audio Receivers
System Components: JLid Communication and Network Bridge (MVi-HUB) for multi-amplifier networking and advanced system control
Installation Requirements: 4 AWG copper power and ground wiring, 80A fuse (AFS/AGU/MaxiFuse), vertical mounting location with downward-facing connections for IPX2 rating, PC/Mac with USB for TüN software tuning
Frequently Asked Questions
Can this amplifier run a complete 8-speaker marine audio system with tower speakers? Yes, the 8-channel configuration is ideal for comprehensive marine systems. Use channels 1-4 for helm/cockpit speakers, channels 5-8 for tower speakers or additional zones. Alternatively, bridge channels in pairs (creating four 200W channels) to power larger tower speakers while using remaining channels for cabin or transom areas.
What makes the MVi series suitable for saltwater environments compared to standard car amplifiers? MVi amplifiers feature IPX2 water/dust rating, conformal-coated circuit boards that resist corrosion, marine-grade stainless steel hardware, and UV-resistant construction. The vertical mounting requirement ensures connections face downward, preventing water ingress. Standard car amplifiers lack these protections and will corrode rapidly in marine environments.
Do I need the JLid hub to use this amplifier or can it operate standalone? The amplifier operates independently without the JLid hub. However, the hub (MVi-HUB) enables networking multiple MVi amplifiers, source switching between multiple head units, zone control, and advanced system management. For single-amplifier installations, connect directly via USB to a PC/Mac for tuning with JL Audio's TüN software.
What's the advantage of Class D amplification in marine applications? Class D amplifiers achieve 80-90% efficiency compared to 50-60% for Class AB designs, generating significantly less heat. This is crucial for marine installations where amplifiers are often mounted in enclosed, poorly ventilated spaces. The reduced heat generation improves reliability, extends component lifespan, and eliminates the need for large heat sinks or external cooling fans.
Can I bridge all eight channels to create four high-power outputs for larger speakers? Yes, bridging pairs of channels creates four bridged outputs delivering 200 watts each at 4 ohms. This configuration is perfect for powering four large tower speakers or four separate zones with high-output requirements. Bridge channels 1-2, 3-4, 5-6, and 7-8 by connecting positive to one channel and negative to the adjacent channel, ensuring 4-ohm minimum load per bridged pair.
