Description
LED Autolamps 100AMB 12-24V Replacement Amber Indicator Lamp for 100 Series Square Lamp Brackets Clip-In Lens ADR Approved IP67
The LED Autolamps 100AMB is a 12-24V replacement amber indicator lamp for the LED Autolamps 100 series square lamp range. Clips directly into existing 100 series brackets without replacing the full assembly. Clip-in replaceable lens, ADR approved (CTA060221), IP67 rated. Lamp only bracket not included.
Product overview
The 100AMB is the direct replacement lamp for 100 series indicator installations, allowing the lamp unit to be swapped out independently when the original lamp fails or requires replacement. The clip-in design means the 100AMB snaps into the existing 100 series bracket without tools. The lens is also clip-in replaceable for independent field servicing. ADR approval CTA060221 confirms road-legal use as a rear indicator lamp. Operates across 12V and 24V systems.
For a complete assembly with bracket included, see the LED Autolamps 100AM.
Features and benefits
Direct replacement for 100 series indicator lamp units: Clips into existing 100 series brackets no need to replace the full bracket assembly.
Clip-in replaceable lens: Lens snaps in and out independently for easy field replacement.
Amber LED output: Correct amber indicator output matching the 100 series specification.
ADR approved (CTA060221): Certified for road-legal use as a rear indicator lamp in Australia.
IP67 rated: Fully sealed against dust and water immersion.
12V and 24V compatible: Suits light vehicles and heavy transport.
Lamp only bracket not included.
Technical specs
| Specification |
Detail |
| SKU |
100AMB |
| Brand |
LED Autolamps |
| Type |
Rear indicator lamp (replacement) |
| Lens Colour |
Amber |
| Operating Voltage |
12V to 24V |
| Lens |
Clip-in replaceable |
| Mounting |
Clip-in to existing 100 series bracket |
| Waterproof Rating |
IP67 |
| ADR Compliance |
CTA060221 |
| Weight |
0.15kg |
| Bracket Included |
No |
Compatible with
- LED Autolamps 100 series square lamp brackets (indicator position)
- LED Autolamps 100AM indicator lamp assembly
Frequently asked questions
What is the 100AMB designed to replace? The 100AMB is a replacement amber indicator lamp unit for the LED Autolamps 100 series square lamp range. It clips into existing 100 series brackets without replacing the full assembly.
Is the 100AMB approved for road use in Australia? Yes. The 100AMB is ADR approved under CTA060221, meeting Australian Design Rules requirements for road-legal use as a rear indicator lamp.
What is the IP rating on the 100AMB? The 100AMB is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion up to 1 metre for up to 30 minutes.
Does the 100AMB come with a bracket? No. The 100AMB is a replacement lamp unit only and is designed to clip into an existing 100 series bracket. For a complete assembly with bracket included, see the LED Autolamps 100AM.
What warranty does the 100AMB carry? Warranty is not confirmed in the available product data. Contact us to confirm the warranty before purchasing.
