Description
LED Autolamps 100RM 12-24V Stop Tail Lamp 49 LEDs 122mm Square with Bracket and 30cm Wire ADR Approved IP67
The LED Autolamps 100RM is a 12-24V LED stop/tail lamp with 49 LEDs in a 122mm square housing. Part of the Original Square Series. Clip-in replaceable lens, ADR approved, IP67 waterproof. Includes mounting bracket and 30cm wire. Five-year warranty. Sold individually.
Product overview
The 100RM is part of the LED Autolamps Original Square Series stop/tail range, providing a traditional 122mm square format suited to trailers, caravans, trucks, and commercial vehicles. The clip-in replaceable lens allows the lens to be swapped without replacing the full lamp assembly. The mounting bracket and 30cm wire are included for straightforward surface mounting. 12-24V compatible across light vehicle and heavy transport applications. ADR approved for road use in Australia.
Features and benefits
49 LEDs in a 122mm square housing: Original Square Series stop/tail lamp format.
Clip-in replaceable lens: Lens can be replaced without removing or replacing the full lamp assembly.
ADR approved: Compliant for road use in Australia.
IP67 fully waterproof and submersible: Suited to trailer, caravan, and off-road environments.
Mounting bracket and 30cm wire included: Ready for surface mounting installation.
12V and 24V compatible: Suits light vehicle trailers, caravans, trucks, and heavy transport.
Black housing.
Five-year warranty.
Sold individually.
Technical specs
| Specification |
Detail |
| SKU |
100RM |
| Brand |
LED Autolamps |
| Series |
Original Square Series |
| Type |
Stop/tail lamp |
| Light Type |
LED |
| LED Count |
49 |
| Operating Voltage |
12V to 24V |
| Housing Colour |
Black |
| Dimensions |
122mm x 122mm x 31mm |
| Lens |
Clip-in replaceable |
| Waterproof Rating |
IP67 |
| ADR Approved |
Yes |
| Includes |
Mounting bracket, 30cm wire |
| Weight |
0.28kg |
| Manufactured In |
China (Taiwan) |
| Sold As |
Each |
| Warranty |
Five years |
Frequently asked questions
Is the 100RM ADR approved? Yes. The 100RM carries ADR approval, confirming compliance for road use in Australia as a stop/tail lamp.
What voltage does the 100RM operate on? The 100RM operates on 12V and 24V systems, making it suited to light vehicle trailers, caravans, trucks, and commercial vehicles.
What is the clip-in replaceable lens? The 100RM features a clip-in lens that can be removed and replaced without removing or replacing the full lamp body, simplifying servicing if the lens is damaged.
What is included with the 100RM? The 100RM includes the lamp, a mounting bracket, and a 30cm wire for straightforward surface mounting installation.
Is the 100RM sold as a single unit or a pair? Sold individually.
