LED Autolamps 120035AM 12-24V Amber LED Emergency Warning Lamp 6 x 3W LEDs 14 Flash Patterns SAE J595 Class 1 IP67 Sync Up to 20 Lamps
The LED Autolamps 120035AM is a 12-24V amber LED emergency warning lamp with 6 x 3W LEDs, 14 selectable flash patterns, and a synchronising wire that links up to 20 lamps. SAE J595 Class 1 certified, IP67 waterproof, 0.29A at 13.8V, clear lens, 3M tape or screw mount. 131mm x 30mm x 8mm. Three-year warranty. Sold individually.
Product overview
The 120035AM is a higher-output emergency warning lamp compared to the 120033 and 120034 ranges, featuring 6 x 3W high-power LEDs and 14 flash patterns rather than 11. The synchronising wire can link up to 20 lamps simultaneously for large vehicle or fleet warning lighting setups. Flash rate is 120 FPM in single, double, and quad modes. The clear lens housing maintains a neutral appearance when inactive. SAE J595 Class 1 certification confirms high-intensity warning lamp compliance. The 3M tape or screw fixing allows mounting on flat and curved surfaces. IP67 rated. 12-24V compatible. 131mm x 30mm x 8mm form factor.
Features and benefits
6 x 3W amber LEDs: High-power LED array for strong emergency warning output.
14 selectable flash patterns: More pattern options than the 120033 and 120034 ranges.
Sync up to 20 lamps: Synchronising wire links up to 20 units for large coordinated warning lighting setups.
120 FPM flash rate: Single, double, and quad flash modes at 120 flashes per minute.
SAE J595 Class 1 certified: Highest SAE classification for vehicle warning lamps.
Clear lens: Neutral appearance when inactive.
IP67 fully waterproof and submersible: Suited to outdoor and exposed vehicle body mounting.
3M tape or screw fixing: Flexible mounting on flat and curved surfaces.
131mm x 30mm x 8mm ultra-slim profile.
12V and 24V compatible: Suits light vehicles and heavy transport.
Three-year warranty.
Sold individually.
Technical specs
| Specification |
Detail |
| SKU |
120035AM |
| Brand |
LED Autolamps |
| Type |
Emergency warning lamp |
| LED Colour |
Amber |
| LED Configuration |
6 x 3W |
| Lens Colour |
Clear |
| Operating Voltage |
12V to 24V |
| Current Draw |
0.29A at 13.8V |
| Flash Patterns |
14 selectable |
| Flash Rate |
120 FPM (single/double/quad) |
| Sync Capacity |
Up to 20 lamps |
| Synchronising Wire |
Included |
| Certification |
SAE J595 Class 1 |
| Mount Type |
3M tape or screw |
| Dimensions |
131mm x 30mm x 8mm |
| Waterproof Rating |
IP67 |
| Weight |
0.05kg |
| Manufactured In |
China (Taiwan) |
| Sold As |
Each |
| Warranty |
Three years |
Frequently asked questions
What compliance certification does the 120035AM carry? The 120035AM carries SAE J595 Class 1 certification, the highest SAE classification for vehicle warning lamps.
How does the 120035AM differ from the 120033AM and 120034AM? The 120035AM uses 6 x 3W high-power LEDs and offers 14 flash patterns with sync capacity for up to 20 lamps. The 120033AM has 11 flash patterns and SAE J595 Class 1 certification. The 120034AM has 11 flash patterns and dual SAE J595 Class 1 and 2 certification. The 120035AM is suited to applications requiring higher output and greater synchronisation capacity.
How many lamps can be synchronised with the 120035AM? The synchronising wire on the 120035AM can link up to 20 lamps simultaneously for coordinated flash patterns across a vehicle or fleet setup.
What mounting options does the 120035AM support? The 120035AM can be mounted using 3M adhesive tape or screws in either horizontal or vertical orientation, suited to a wide range of vehicle surfaces and body panels.
