Description
SAE J595 Class 1 Blue Emergency Lamp 6x3W LEDs, 14 Flash Patterns, Sync Up to 20 Lamps
Product Overview
The LED Autolamps 120035BM is a 12/24V blue emergency warning lamp powered by 6 x 3W LEDs, delivering high-output blue warning flash for law enforcement, emergency services, and authorised vehicle applications. Measuring 131mm x 30mm x 8mm with a clear lens, it produces 120 flashes per minute across 14 selectable patterns including single, double, and quad flash.
The synchronising wire allows up to 20 lamps to be linked and flash in unison suited to large vehicle builds and professional emergency lighting rigs. SAE J595 Class 1 certified, IP67 rated, and supplied in blister pack with 3M tape and screw mounting options. Backed by a 3-year warranty.
Features & Benefits
-
6 x 3W high-power LEDs — delivers substantially greater output than standard SMD emergency lamps for maximum warning visibility
-
Blue LED output — suited to law enforcement, emergency services, and authorised vehicle applications where blue warning lights are required
-
14 selectable flash patterns — single, double, and quad flash configurations at 120 FPM
-
Synchronise up to 20 lamps — synchronising wire links up to 20 units for coordinated multi-lamp setups
-
SAE J595 Class 1 certified — meets the highest SAE classification for vehicle warning lamps
-
IP67 rated — fully sealed against dust and water immersion, built for exposed vehicle-mounted applications
-
Clear lens — clean appearance when inactive; blue warning output when energised
-
3M tape and screw fitting — dual mounting options for adhesive or screw-fixed installation
-
Ultra-slim 8mm profile — 131mm x 30mm footprint suits tight installation spaces on vehicle bodies
-
12/24V dual voltage — compatible with both 12V light vehicles and 24V heavy transport without modification
-
3-year warranty — backed by LED Autolamps' warranty programme
Technical Specs
| Specification |
Detail |
| SKU |
120035BM |
| Lamp Type |
Emergency Warning |
| LED Configuration |
6 x 3W |
| LED Colour |
Blue |
| Lens Colour |
Clear |
| Voltage Range |
12V / 24V |
| Dimensions |
131mm x 30mm x 8mm |
| Current Draw |
0.29A @ 13.8V |
| Flash Patterns |
14 selectable |
| Flash Rate |
120 FPM (single / double / quad) |
| Sync Capacity |
Up to 20 lamps |
| Synchronising Wire |
Included |
| Mounting |
3M tape / screw |
| Compliance |
SAE J595 Class 1 |
| Protection Rating |
IP67 |
| Warranty |
3 years |
Compatible With / Goes Well With
- Law enforcement, emergency services, and authorised vehicles requiring blue warning lighting
- 12V light commercial and passenger vehicles
- 24V trucks, plant equipment, and heavy transport
- Multi-lamp synchronised emergency lighting setups of up to 20 units
- LED Autolamps 120035AM amber emergency lamp (same series)
- LED Autolamps wiring harnesses and emergency lighting accessories
Frequently Asked Questions
What compliance certification does the 120035BM carry?
The 120035BM is certified to SAE J595 Class 1, the highest SAE classification for vehicle warning lamps, making it suitable for professional emergency and hazard warning applications.
What applications typically use blue warning lamps?
Blue warning lamps are used by law enforcement, emergency services, and other authorised vehicles. The use of blue warning lights is strictly regulated in Australia — always check your state or territory regulations before fitting.
How many lamps can be synchronised with the 120035BM?
Up to 20 lamps can be linked via the synchronising wire to flash in the same pattern simultaneously — suited to large vehicle builds and professional emergency rigs.
What flash patterns and rates does the 120035BM support?
It offers 14 selectable flash patterns at 120 flashes per minute, covering single, double, and quad flash configurations.
What warranty does the 120035BM carry?
The 120035BM is backed by a 3-year warranty from LED Autolamps.
