Description
LED Autolamps 125AM 12-24V Amber LED Indicator Lamp 64 LEDs 147mm Square with 30cm Wire Clip-In Replaceable Lens ADR Approved IP67
The LED Autolamps 125AM is a 12-24V amber LED indicator lamp with 64 LEDs in a 147mm square housing. ADR approved (CRN 33165), IP67 waterproof, clip-in replaceable lens, pre-wired with 30cm wire, surface mount. 0.4A current draw. Black housing. Five-year warranty.
Product overview
The 125AM is part of the LED Autolamps Original Square Series, providing a larger 147mm square format suited to trailers, caravans, trucks, and commercial vehicles requiring a more prominent indicator lamp. The 64 LEDs draw 0.4A across a 12V to 24V operating range. The clip-in replaceable lens simplifies servicing without replacing the full lamp assembly. Pre-wired with a 30cm wire for surface mounting. ADR approved CRN 33165 confirms Australian road compliance as an indicator lamp.
Features and benefits
64 amber LEDs: High-brightness indicator output in a 147mm square format.
12V and 24V compatible: Suits trailers, caravans, trucks, and commercial vehicles across both system voltages.
ADR approved (CRN 33165): Compliant for road use in Australia as an indicator lamp.
IP67 fully waterproof and submersible: Suited to trailer, caravan, and off-road applications.
Clip-in replaceable lens: Lens can be replaced without removing or replacing the full lamp assembly.
Pre-wired with 30cm wire: Ready for surface mounting installation.
Black housing.
Five-year warranty.
Technical specs
| Specification |
Detail |
| SKU |
125AM |
| Brand |
LED Autolamps |
| Series |
Original Square Series |
| Type |
Indicator lamp |
| LED Count |
64 |
| LED Colour |
Amber |
| Operating Voltage |
12V to 24V |
| Current Draw |
0.4A |
| Housing Colour |
Black |
| Dimensions |
147mm x 147mm x 31mm |
| Mount Type |
Surface mount |
| Connector |
Pre-wired, 30cm wire |
| Lens |
Clip-in replaceable |
| Waterproof Rating |
IP67 |
| ADR Compliance |
CRN 33165 |
| Weight |
0.347kg |
| Manufactured In |
China (Taiwan) |
| Warranty |
Five years |
Frequently asked questions
Is the 125AM ADR approved? Yes. The 125AM holds ADR approval CRN 33165, confirming compliance for road use in Australia as an indicator lamp.
What voltage does the 125AM operate on? The 125AM operates on 12V and 24V systems, making it suited to light vehicle trailers, caravans, trucks, and commercial vehicles.
How does the 125AM compare to the 100AM? The 125AM is 147mm x 147mm with 64 LEDs. The 100AM is 122mm x 122mm with 49 LEDs. Both are Original Square Series indicator lamps with clip-in replaceable lenses and 12-24V compatibility. The 125AM suits applications requiring a larger, more prominent indicator lamp.
What is the clip-in replaceable lens? The 125AM features a clip-in lens that can be removed and replaced without removing or replacing the full lamp body, simplifying servicing if the lens is damaged.
Is the 125AM sold as a single unit or a pair? Sold individually.
