Description
LED Autolamps 125BARWM 12-24V LED Stop Tail Indicator Reverse Combination Assembly 153 LEDs 435mm Individual Replaceable Lenses ADR Approved IP67
The LED Autolamps 125BARWM is a 12-24V LED combination lamp assembly covering stop, tail, indicator, and reverse functions across 153 LEDs in a 435mm x 146mm x 31mm black housing. Individual replaceable lenses. ADR approved, IP67 waterproof. Five-year warranty.
Product overview
The 125BARWM adds a reverse lamp function to the 125BARRM assembly, providing four lighting functions across 153 LEDs in a single 435mm unit. Suited to trailers, caravans, and commercial vehicles requiring a complete rear lighting cluster including reversing light. Individual lens replacements allow each lens section to be serviced independently without replacing the full assembly. ADR approved for road use in Australia. 12-24V compatible. IP67 rated.
Features and benefits
Stop, tail, indicator, and reverse in a single 435mm assembly: Four-function LED cluster for trailers, caravans, and commercial vehicles.
153 LEDs: High-output LED array across all four functions.
Individual replaceable lenses: Each lens section can be replaced independently without removing or replacing the full assembly.
ADR approved: Compliant for road use in Australia.
IP67 fully waterproof and submersible: Suited to outdoor and trailer environments.
12V and 24V compatible: Suits light vehicle trailers, caravans, trucks, and heavy transport.
Black housing.
Five-year warranty.
Technical specs
| Specification |
Detail |
| SKU |
125BARWM |
| Brand |
LED Autolamps |
| Type |
Stop/tail/indicator/reverse combination assembly |
| Light Type |
LED |
| LED Count |
153 |
| Operating Voltage |
12V to 24V |
| Housing Colour |
Black |
| Dimensions |
435mm x 146mm x 31mm |
| Lens |
Individual replaceable |
| Waterproof Rating |
IP67 |
| ADR Approved |
Yes |
| Weight |
0.991kg |
| Manufactured In |
China (Taiwan) |
| Warranty |
Five years |
Frequently asked questions
Is the 125BARWM ADR approved? Yes. The 125BARWM carries ADR approval, confirming compliance for road use in Australia as a combination lamp assembly. Contact us to confirm specific ADR CRN approval references before purchasing for compliance documentation purposes.
What is the difference between the 125BARWM and the 125BARRM? The 125BARRM covers stop, tail, and indicator. The 125BARWM adds a reverse lamp function and includes 153 LEDs across the four modules. Both share the same 435mm housing and individual replaceable lens design.
What does individual lens replacement mean? The 125BARWM features individually replaceable lens sections for each lamp function. If one lens is damaged, only that section needs to be replaced rather than the full assembly.
What voltage does the 125BARWM operate on? The 125BARWM operates on 12V and 24V systems, making it suited to light vehicle trailers, caravans, trucks, and commercial vehicles.
How does the 125BARWM compare to the 100BARWM? The 125BARWM measures 435mm x 146mm with 153 LEDs. The 100BARWM measures 350mm x 120mm with 123 LEDs. Both provide stop, tail, indicator, and reverse functions with individual replaceable lenses and 12-24V compatibility. Confirm which size suits your mounting location before purchasing.
