LED Autolamps 128AMF Amber LED Strobe Beacon Fixed Permanent Mount 11-48V 4 LED Rotating Effect SAE J845 Class 2 IP67 130mm
The LED Autolamps 128AMF is an 11-48V amber LED strobe beacon with a rotating pattern effect for permanent fixed mounting. 4 LEDs, 82-92 FPM flash rate, amber polycarbonate lens, SAE J845 Class 2 certified, IP67 waterproof, 0.39A at 13.8V. 130mm x 97mm. Three-year warranty. Sold individually.
Product overview
The 128AMF is a fixed-mount amber strobe beacon suited to trucks, plant equipment, forklifts, and commercial vehicles requiring a permanently mounted warning beacon. The rotating LED pattern simulates a traditional rotating beacon effect using LEDs. The 11-48V operating range is broad enough to suit 12V, 24V, and 48V electrical systems. SAE J845 Class 2 certification confirms warning beacon compliance. The amber polycarbonate lens and black housing are rated IP67 for full waterproof and submersion protection. Flash rate is 82-92 FPM.
Features and benefits
Rotating LED pattern: Simulates a rotating beacon effect for high-visibility amber warning output.
11-48V operating range: Compatible with 12V, 24V, and 48V electrical systems — suits trucks, plant equipment, and forklifts.
SAE J845 Class 2 certified: Warning beacon compliance for commercial and industrial applications.
Fixed permanent mount: Suited to permanently mounted vehicle warning beacon installations.
Amber polycarbonate lens: Durable lens for demanding outdoor and industrial environments.
IP67 fully waterproof and submersible: Suited to outdoor, construction, and transport environments.
82-92 FPM flash rate.
0.39A current draw at 13.8V.
130mm x 97mm housing.
Three-year warranty.
Sold individually.
Technical specs
| Specification |
Detail |
| SKU |
128AMF |
| Brand |
LED Autolamps |
| Type |
Strobe beacon |
| LED Count |
4 |
| LED Colour |
Amber |
| Lens Colour |
Amber |
| Lens Material |
Polycarbonate |
| Housing Colour |
Black |
| Operating Voltage |
11V to 48V |
| Current Draw |
0.39A at 13.8V |
| Flash Rate |
82-92 FPM |
| Flash Pattern |
Rotating effect |
| Mount Type |
Fixed permanent |
| Certification |
SAE J845 Class 2 |
| Dimensions |
130mm (diameter) x 97mm (height) |
| Waterproof Rating |
IP67 |
| Weight |
0.4kg |
| Manufactured In |
China (Taiwan) |
| Sold As |
Each |
| Warranty |
Three years |
Frequently asked questions
What compliance certification does the 128AMF carry? The 128AMF is certified to SAE J845 Class 2, a standard for vehicle warning beacons specifying photometric output requirements for amber strobe and rotating beacons.
What does the rotating pattern effect mean? The 128AMF uses LEDs to simulate a rotating beacon effect producing a sweeping amber warning pattern without a mechanical rotating mechanism, providing the visual appearance of a traditional rotating beacon with the durability and efficiency of LED technology.
What voltage systems is the 128AMF compatible with? The 128AMF operates from 11V to 48V, covering 12V passenger and light commercial vehicles, 24V trucks and heavy transport, and 48V plant and industrial equipment.
How is the 128AMF mounted? The 128AMF is designed for permanent fixed mounting. Contact us to confirm the mounting hardware and thread specifications required for your application before purchasing.
Is the 128AMF suitable for outdoor and construction environments? Yes. The IP67 rating confirms the 128AMF is fully sealed against dust and submersible in water up to 1 metre for up to 30 minutes, suited to outdoor, construction, transport, and industrial environments.
