LED Autolamps 130WMG 12-24V LED Reverse Lamp with Rubber Grommet and Plug Recessed Mount ADR Approved CTA060300 IP67
The LED Autolamps 130WMG is a 12-24V LED reverse lamp supplied with a rubber grommet and plug for recessed panel mounting. ADR approved (CTA060300), IP67 waterproof, rubber housing, 0.15A at 13.8V. Five-year warranty. Sold individually.
Product overview
The 130WMG is a recessed reverse lamp with rubber grommet and plug included, suited to trailers, caravans, trucks, and commercial vehicles. The rubber housing provides flexibility and durability for recessed panel installation. ADR approval CTA060300 confirms road-legal use as a reverse lamp in Australia. 0.15A current draw at 13.8V. 12-24V compatible. IP67 rated. For the matched stop/tail and indicator lamps in the same mounting format, see the 130RMG and 130AMG.
Features and benefits
Rubber grommet and plug included: Panel mounting hardware supplied for a complete recessed installation.
Rubber housing: Flexible, durable housing suited to recessed panel mount applications.
ADR approved (CTA060300): Compliant for road use in Australia as a reverse lamp.
IP67 fully waterproof and submersible: Suited to trailer, caravan, and off-road environments.
12V and 24V compatible: Suits light vehicle trailers, caravans, trucks, and heavy transport.
0.15A current draw at 13.8V.
Five-year warranty.
Sold individually.
Technical specs
| Specification |
Detail |
| SKU |
130WMG |
| Brand |
LED Autolamps |
| Type |
Reverse lamp |
| Light Type |
LED |
| Housing Material |
Rubber |
| Operating Voltage |
12V to 24V |
| Current Draw |
0.15A at 13.8V |
| Mount Type |
Recessed with grommet |
| Includes |
Rubber grommet and plug |
| Waterproof Rating |
IP67 |
| ADR Compliance |
CTA060300 |
| Weight |
0.345kg |
| Manufactured In |
China (Taiwan) |
| Sold As |
Each |
| Warranty |
Five years |
Frequently asked questions
Is the 130WMG ADR approved? Yes. The 130WMG holds ADR approval CTA060300, confirming compliance for road use in Australia as a reverse lamp.
What is included with the 130WMG? The 130WMG is supplied with a rubber grommet and plug for recessed panel installation.
Are matched stop/tail and indicator lamps available in the same format? Yes. The 130RMG stop/tail lamp and 130AMG indicator lamp use the same recessed grommet mount format, allowing a matched rear lighting set across all three functions.
What is the current draw of the 130WMG? The 130WMG draws 0.15A at 13.8V.
Is the 130WMG sold as a single unit or a pair? Sold individually.
