LED Autolamps 131RM 12-24V LED Stop Tail Lamp Red Lens with Internal Chrome Reflector 134mm ADR Approved CTA046431 IP67
The LED Autolamps 131RM is a 12-24V LED stop/tail lamp with a red lens and internal chrome reflector. ADR approved (CTA046431), IP67 waterproof, horizontal or vertical mount. 134mm x 87mm x 12mm. Five-year warranty. Sold individually.
Product overview
The 131RM is the red lens stop/tail version of the 131 series chrome reflector lamp range. The internal chrome reflector maximises LED output across the red lens for strong stop/tail visibility. Mounts in horizontal or vertical orientation. ADR approval CTA046431 confirms road-legal use in Australia as a stop/tail lamp. 12-24V compatible. IP67 rated. For the matched indicator lamp in the same series, see the 131AM. For a clear lens version with the same function, see the 131CRM.
Features and benefits
Red lens with internal chrome reflector: Chrome reflector maximises LED output across the red lens for strong stop/tail visibility.
ADR approved (CTA046431): Compliant for road use in Australia as a stop/tail lamp.
Horizontal or vertical mount: Flexible installation orientation suited to a range of vehicle and trailer body positions.
IP67 fully waterproof and submersible: Suited to trailer, caravan, and off-road environments.
12V and 24V compatible: Suits light vehicle trailers, caravans, trucks, and heavy transport.
134mm x 87mm x 12mm housing.
Five-year warranty.
Sold individually.
Technical specs
| Specification |
Detail |
| SKU |
131RM |
| Brand |
LED Autolamps |
| Type |
Stop/tail lamp |
| Light Type |
LED |
| Lens Colour |
Red |
| Reflector |
Internal chrome |
| Operating Voltage |
12V to 24V |
| Mount Type |
Horizontal or vertical |
| Dimensions |
134mm x 87mm x 12mm |
| Waterproof Rating |
IP67 |
| ADR Compliance |
CTA046431 |
| Weight |
0.201kg |
| Manufactured In |
China (Taiwan) |
| Sold As |
Each |
| Warranty |
Five years |
Frequently asked questions
Is the 131RM ADR approved? Yes. The 131RM holds ADR approval CTA046431, confirming compliance for road use in Australia as a stop/tail lamp.
What is the difference between the 131RM and the 131CRM? The 131RM has a red lens. The 131CRM has a clear lens with red LEDs behind it, appearing neutral when inactive. Both share the same ADR approval, chrome reflector, 12-24V range, and 134mm x 87mm x 12mm housing.
Is there a matched indicator lamp in the same series? Yes. The LED Autolamps 131AM is the red lens indicator lamp and the 131CAM is the clear lens indicator lamp in the same 131 series format.
What voltage does the 131RM operate on? The 131RM operates on 12V and 24V systems, making it suited to light vehicle trailers, caravans, trucks, and commercial vehicles.
Is the 131RM sold as a single unit or a pair? Sold individually.
