Description
LED Autolamps 135CAT1 12-24V Front Direction Indicator and Position Lamp 18 Square LEDs 135mm Black Surface Mount ADR Approved CTA060203 IP67
The LED Autolamps 135CAT1 is a 12-24V front direction indicator and position lamp with 18 square amber LEDs in a 135mm x 38mm x 24mm black housing. ADR approved (CTA060203, CRN 39340), IP67 waterproof, pre-wired, surface mount, 0.4A current draw. Five-year warranty. Sold individually.
Product overview
The 135CAT1 provides combined front direction indicator and position lamp functions in a single surface-mount unit, suited to 4WD bullbars, trucks, and commercial vehicles requiring ADR-compliant front indicator and position lighting. The 18 square LED array delivers a distinctive, high-visibility amber output. ADR approval CTA060203 with CRN 39340 confirms road-legal compliance in Australia. Pre-wired for straightforward surface mounting. 12-24V compatible. IP67 rated.
Features and benefits
Combined front direction indicator and position lamp: Two functions in a single surface-mount unit.
18 square amber LEDs: Distinctive square LED array for high-visibility front indicator and position output.
ADR approved (CTA060203, CRN 39340): Compliant for road use in Australia as a front direction indicator and position lamp.
IP67 fully waterproof and submersible: Suited to bullbar, truck, and off-road vehicle mounting.
Pre-wired surface mount: Ready for direct installation without additional wiring preparation.
12V and 24V compatible: Suits 4WD vehicles, light commercial vehicles, and heavy transport.
0.4A current draw.
Black housing.
Five-year warranty.
Sold individually.
Technical specs
| Specification |
Detail |
| SKU |
135CAT1 |
| Brand |
LED Autolamps |
| Type |
Front direction indicator and position lamp |
| Light Type |
LED |
| LED Count |
18 square |
| LED Colour |
Amber |
| Housing Colour |
Black |
| Operating Voltage |
12V to 24V |
| Current Draw |
0.4A |
| Mount Type |
Surface mount |
| Connector |
Pre-wired |
| Dimensions |
135mm x 38mm x 24mm |
| Waterproof Rating |
IP67 |
| ADR Compliance |
CTA060203, CRN 39340 |
| Weight |
0.134kg |
| Manufactured In |
China (Taiwan) |
| Sold As |
Each |
| Warranty |
Five years |
Frequently asked questions
Is the 135CAT1 ADR approved? Yes. The 135CAT1 holds ADR approval CTA060203 with CRN 39340, confirming compliance for road use in Australia as a front direction indicator and position lamp.
What functions does the 135CAT1 cover? The 135CAT1 provides both front direction indicator and position lamp functions in a single unit, reducing the number of separate front lamps required.
What voltage does the 135CAT1 operate on? The 135CAT1 operates on 12V and 24V systems, making it suited to 4WD vehicles, light commercial vehicles, and heavy transport applications.
What are the dimensions of the 135CAT1? The 135CAT1 measures 135mm x 38mm x 24mm.
Is there a matched rear lamp in the same 135 series format? Yes. The LED Autolamps 135AM rear indicator and 135ARM/2 stop/tail/indicator combination use the same 135mm surface-mount format with square LEDs.
