Description
LED Autolamps 144AMF Amber LED Strobe Beacon Fixed Permanent Mount 12-30V 6 x 3W LEDs SAE J845 Class 1 IP67 130mm
The LED Autolamps 144AMF is a 12-30V amber LED strobe beacon for fixed permanent mounting. 6 x 3W LEDs, 87 FPM flash rate, amber polycarbonate lens, SAE J845 Class 1 certified, IP67 waterproof, 0.71A at 13.8V, 19cm sheathed cable, nylon base, black housing. 130mm x 97mm. Three-year warranty. Sold individually.
Product overview
The 144AMF is a heavy-duty fixed-mount amber strobe beacon suited to trucks, plant equipment, forklifts, and commercial vehicles requiring a permanently mounted Class 1 warning beacon. SAE J845 Class 1 is the highest SAE certification tier for warning beacons. Six 3W LEDs deliver high-intensity amber output at 87 FPM. The 19cm sheathed cable connects to a hardwired supply. Nylon base. 12-30V operating range. IP67 rated for full waterproof protection.
Features and benefits
SAE J845 Class 1 certified: Highest SAE warning beacon classification for high-intensity emergency and safety applications.
6 x 3W high-brightness LEDs: Maximum output for demanding warning beacon applications.
87 FPM flash rate: Consistent high-visibility amber warning output.
Fixed permanent mount: Suited to permanently installed vehicle warning beacon applications.
Amber polycarbonate lens: Durable lens for outdoor and industrial environments.
Nylon base: Lightweight, durable base material.
19cm sheathed cable: Connects to hardwired vehicle supply.
IP67 fully waterproof and submersible: Suited to outdoor, construction, and transport environments.
12-30V operating range: Covers 12V and 24V electrical systems.
Heavy-duty build.
Three-year warranty.
Sold individually.
Technical specs
| Specification |
Detail |
| SKU |
144AMF |
| Brand |
LED Autolamps |
| Type |
Strobe beacon |
| LED Count |
6 |
| LED Configuration |
6 x 3W |
| LED Colour |
Amber |
| Lens Colour |
Amber |
| Lens Material |
Polycarbonate |
| Housing Colour |
Black |
| Base Material |
Nylon |
| Mount Type |
Fixed permanent |
| Operating Voltage |
12V to 30V |
| Current Draw |
0.71A at 13.8V |
| Flash Rate |
87 FPM |
| Cable |
19cm sheathed |
| Certification |
SAE J845 Class 1 |
| Dimensions |
130mm (diameter) x 97mm (height) |
| Waterproof Rating |
IP67 |
| Weight |
0.435kg |
| Manufactured In |
China (Taiwan) |
| Sold As |
Each |
| Warranty |
Three years |
Frequently asked questions
What compliance certification does the 144AMF carry? The 144AMF is certified to SAE J845 Class 1, the highest SAE classification for vehicle warning beacons, covering amber warning output only at this class level.
How does the 144AMF differ from the 128AMF? The 144AMF is rated SAE J845 Class 1 with 6 x 3W LEDs and 0.71A current draw, making it the higher-output option for demanding applications. The 128AMF is rated SAE J845 Class 2. Choose the 144AMF when Class 1 certification is required.
What voltage systems is the 144AMF compatible with? The 144AMF operates from 12V to 30V, covering 12V and 24V electrical systems.
How is the 144AMF mounted? The 144AMF is designed for permanent fixed mounting. Contact us to confirm the mounting hardware and thread specifications required for your application before purchasing.
Is the 144AMF suitable for outdoor and construction environments? Yes. The IP67 rating confirms the 144AMF is fully sealed against dust and submersible in water up to 1 metre for up to 30 minutes.
