Description
LED Autolamps 175AW/2 12V Front Indicator and Position Lamp Clear Lens 175mm x 50mm ADR Approved CTA060239 IP67 Twin Blister Pack for Bullbars
The LED Autolamps 175AW/2 is a 12V front indicator and position lamp with a clear lens, designed for popular bullbar installations. 175mm x 50mm x 24mm, 158mm mounting centres, pre-wired, ADR approved (CTA060239, indicator ADR 6/00, park ADR 49/00), IP67 waterproof, 0.32A at 13.8V. Sold as a twin blister pack. Five-year warranty.
Product overview
The 175AW/2 provides combined front indicator and park light functions in a single clear lens unit designed to fit the lamp positions of most popular bullbars on 4WD and light commercial vehicles. The clear lens delivers a clean appearance when inactive. Mounting centres are 158mm. Refer to ADR 13/00 for correct mounting instructions and compliance requirements. Pre-wired for straightforward installation. 12V only. IP67 rated. Twin blister pack contains two lamps for a complete left and right front installation.
Features and benefits
Combined front indicator and position lamp: Two functions in a single 175mm unit designed for bullbar lamp positions.
Clear lens: Clean appearance when inactive; indicator and park output produced by LEDs when energised.
Designed for most popular bullbars: Suits the lamp positions of common 4WD and light commercial vehicle bullbar setups.
ADR approved (CTA060239): Indicator ADR 6/00, park ADR 49/00. Refer to ADR 13/00 for mounting compliance.
IP67 fully waterproof and submersible: Suited to outdoor and off-road environments.
158mm mounting centres.
Pre-wired.
12V only.
Twin blister pack: Two lamps per pack for a complete left and right front installation.
Five-year warranty.
Technical specs
| Specification |
Detail |
| SKU |
175AW/2 |
| Brand |
LED Autolamps |
| Type |
Front indicator and position lamp |
| Light Type |
LED |
| Lens |
Clear |
| Operating Voltage |
12V |
| Current Draw |
0.32A at 13.8V |
| Dimensions |
175mm x 50mm x 24mm |
| Mounting Centres |
158mm |
| Connector |
Pre-wired |
| Base Material |
Plastic |
| Waterproof Rating |
IP67 |
| ADR Indicator |
ADR 6/00 |
| ADR Park |
ADR 49/00 |
| ADR Mounting |
Refer to ADR 13/00 |
| CTA Approval |
CTA060239 |
| Weight |
0.33kg |
| Manufactured In |
China (Taiwan) |
| Sold As |
Twin blister pack (2 lamps) |
| Warranty |
Five years |
Frequently asked questions
Is the 175AW/2 ADR approved? Yes. The 175AW/2 holds ADR approval CTA060239, with indicator compliance under ADR 6/00 and park compliance under ADR 49/00. Refer to ADR 13/00 for correct mounting instructions and compliance requirements.
What bullbars does the 175AW/2 suit? The 175AW/2 is designed to suit the lamp positions of most popular 4WD and light commercial vehicle bullbars. The 158mm mounting centres and 175mm x 50mm lamp dimensions are the key fitment measurements. Confirm that these suit your specific bullbar lamp position before purchasing.
How many lamps are included in the pack? The 175AW/2 is sold as a twin blister pack containing two lamps for a complete left and right front installation.
Is the 175AW/2 suitable for 24V systems? No. The 175AW/2 is 12V only.
What is the current draw of the 175AW/2? The 175AW/2 draws 0.32A at 13.8V.
