LED Autolamps 181WME 12-24V White LED Front End Outline Marker Lamp 28mm Round Mini Recessed Low Profile Rubber Housing ADR Approved CTA060286 IP67
The LED Autolamps 181WME is a 12-24V white LED front end outline marker lamp in a 28mm round, 5mm depth mini recessed rubber housing. ADR approved (CTA060286), IP67 waterproof. Five-year warranty. Sold individually.
Product overview
The 181WME is the white front end outline marker in the LED Autolamps 181 series mini recessed range, completing the set alongside the 181AME amber side marker and 181RME red side marker. The 28mm x 5mm rubber housing sits nearly flush in the panel cutout for a low-profile finish. ADR approval CTA060286 confirms road-legal use in Australia as a front end outline marker. 12-24V compatible. IP67 rated.
Features and benefits
White LED front end outline marker output: Compact white output in a mini 28mm format.
28mm round, 5mm depth: Extremely low-profile recessed mount for discreet panel installation.
Mini recessed design: Suited to trailers, caravans, and commercial vehicles requiring compact front markers.
Rubber housing: Durable and flexible for recessed panel installation in harsh environments.
ADR approved (CTA060286): Compliant for road use in Australia as a front end outline marker lamp.
IP67 fully waterproof and submersible: Suited to trailer, caravan, and off-road environments.
12V and 24V compatible: Suits light vehicles and heavy transport.
Five-year warranty.
Sold individually.
Technical specs
| Specification |
Detail |
| SKU |
181WME |
| Brand |
LED Autolamps |
| Type |
Front end outline marker lamp |
| Light Type |
LED |
| LED Colour |
White |
| Housing Material |
Rubber |
| Housing Colour |
Black |
| Operating Voltage |
12V to 24V |
| Mount Type |
Recessed |
| Diameter |
28mm |
| Depth |
5mm |
| Waterproof Rating |
IP67 |
| ADR Compliance |
CTA060286 |
| Weight |
0.036kg |
| Manufactured In |
China (Taiwan) |
| Sold As |
Each |
| Warranty |
Five years |
Frequently asked questions
Is the 181WME ADR approved? Yes. The 181WME holds ADR approval CTA060286, confirming compliance for road use in Australia as a front end outline marker lamp.
How does the 181WME complete the 181 series mini recessed range? The 181WME is the white front end outline marker, pairing with the 181AME amber side marker (ADR CTA060271) and 181RME red side marker (ADR CTA060272) for a complete mini recessed marker set in the same 28mm rubber housing format.
What panel cutout does the 181WME require? The 181WME is 28mm in diameter and 5mm deep. Confirm your panel cutout suits these dimensions before purchasing.
What voltage does the 181WME operate on? The 181WME operates on 12V and 24V systems, making it suited to light vehicle trailers, caravans, trucks, and commercial vehicles.
Is the 181WME sold as a single unit or a pair? Sold individually.
