Description
LED Autolamps 200BWM 12-24V Reverse Lamp 25 LEDs 200mm x 50mm x 28mm Black Bracket ADR Approved CTA060095 IP67
The LED Autolamps 200BWM is a 12-24V LED reverse lamp with 25 LEDs in a 200mm x 50mm x 28mm black housing with black bracket. ADR approved (CTA060095), IP67 waterproof. Five-year warranty. Sold individually.
Product overview
The 200BWM is a surface-mount reverse lamp suited to trailers, caravans, trucks, and commercial vehicles. The 25 LED array provides strong white reverse output across the full 200mm lamp face. ADR approval CTA060095 confirms road-legal compliance in Australia. Black bracket included. 12-24V compatible. IP67 rated.
Features and benefits
25 LEDs across a 200mm housing: High-brightness white reverse output across the full lamp face.
Black bracket included: Complete assembly ready for surface mounting.
ADR approved (CTA060095): Compliant for road use in Australia as a reverse lamp.
IP67 fully waterproof and submersible: Suited to trailer, caravan, and off-road environments.
12V and 24V compatible: Suits light vehicle trailers, caravans, trucks, and heavy transport.
Five-year warranty.
Technical specs
| Specification |
Detail |
| SKU |
200BWM |
| Brand |
LED Autolamps |
| Type |
Reverse lamp |
| Light Type |
LED |
| LED Count |
25 |
| Housing Colour |
Black |
| Bracket Colour |
Black |
| Operating Voltage |
12V to 24V |
| Mount Type |
Surface mount |
| Dimensions |
200mm x 50mm x 28mm |
| Waterproof Rating |
IP67 |
| ADR Compliance |
CTA060095 |
| Weight |
0.177kg |
| Manufactured In |
China (Taiwan) |
| Warranty |
Five years |
Frequently asked questions
Is the 200BWM ADR approved?
Yes. The 200BWM holds ADR approval CTA060095, confirming compliance for road use in Australia as a reverse lamp.
What voltage does the 200BWM operate on?
The 200BWM operates on 12V and 24V systems, making it suited to light vehicle trailers, caravans, trucks, and commercial vehicles.
What are the dimensions of the 200BWM?
The 200BWM measures 200mm x 50mm x 28mm including the bracket.
Is there a matched stop/tail or indicator lamp in the same 200 series format?
Yes. The LED Autolamps 200BRM is the stop/tail lamp and the 200BAM is the indicator lamp in the same 200mm black bracket format. The 200BSTIM covers stop, tail, and indicator in a single unit.
Is the 200BWM sold as a single unit or a pair?
Sold individually.
