Description
LED Autolamps 235BAR12 12V Stop Tail and Indicator Strip Combination Lamp 258mm x 82mm x 17mm Surface Mount Bracket ECE Approved CTA060127 IP67
The LED Autolamps 235BAR12 is a 12V LED stop/tail/indicator strip combination lamp in a 258mm x 82mm x 17mm housing with surface mounting bracket included. ECE approved (CTA060127), IP67 waterproof. Five-year warranty. Sold individually.
Product overview
The 235BAR12 covers stop, tail, and indicator functions in a single 258mm strip lamp unit with an integrated surface mounting bracket for straightforward panel installation on trailers, caravans, trucks, and commercial vehicles. ECE approval CTA060127 confirms road-legal use in Australia. 12V only. IP67 rated.
Features and benefits
Stop, tail, and indicator in one 258mm strip unit: Three-function combination lamp with surface mount bracket included.
258mm x 82mm x 17mm housing: Wider format than the 235AR12 for greater lamp face coverage.
Surface mounting bracket included: Ready for direct panel installation without separate hardware.
ECE approved (CTA060127): Meets international road approval standards accepted for on-road use in Australia.
IP67 fully waterproof and submersible: Suited to trailer, caravan, and off-road environments.
12V only.
Five-year warranty.
Technical specs
| Specification |
Detail |
| SKU |
235BAR12 |
| Brand |
LED Autolamps |
| Type |
Stop/tail/indicator combination strip lamp |
| Light Type |
LED |
| Operating Voltage |
12V |
| Mount Type |
Surface mount (bracket included) |
| Dimensions |
258mm x 82mm x 17mm |
| Waterproof Rating |
IP67 |
| ECE Compliance |
CTA060127 |
| Weight |
0.25kg |
| Manufactured In |
China (Taiwan) |
| Warranty |
Five years |
Frequently asked questions
Is the 235BAR12 ECE approved?
Yes. The 235BAR12 holds ECE approval CTA060127, meeting international road approval standards accepted for on-road use in Australia as a stop/tail/indicator combination lamp.
Is the surface mount bracket included with the 235BAR12?
Yes. The 235BAR12 includes a surface mounting bracket for direct panel installation without sourcing separate hardware.
How does the 235BAR12 differ from the 235AR12?
The 235AR12 is a recessed mount strip lamp measuring 237mm x 25mm x 3mm with a white rubber grommet included. The 235BAR12 is a surface mount strip lamp measuring 258mm x 82mm x 17mm with a surface mounting bracket included. Both carry ECE approval CTA060127.
What voltage does the 235BAR12 operate on?
The 235BAR12 is 12V only and is not suitable for 24V systems.
Is the 235BAR12 sold as a single unit or a pair?
Sold individually.
