Description
ADR Approved Stop/Tail/Indicator/Reflector Lamp 275mm, PMMA Lens, ABS Base, IP67
Product Overview
The LED Autolamps 275MAR is a 12/24V rear combination lamp covering stop, tail, indicator, and integrated reflex reflector functions in a 275mm x 100mm x 22mm surface-mount unit. The PMMA (acrylic) lens provides good optical clarity and UV resistance, while the ABS base keeps the housing lightweight and impact-resistant. Supplied with a 28cm pre-wired cable and ADR road approved.
IP67 rated and backed by a 5-year warranty.
Features & Benefits
-
Stop, tail, indicator, and reflex reflector in one lamp — four functions in a single 275mm unit
-
Inbuilt reflex reflector — integrated passive reflective element for additional rear visibility and compliance
-
PMMA lens — UV-resistant acrylic optical material for good clarity and long-term durability
-
ABS base — lightweight, impact-resistant thermoplastic housing
-
28cm pre-wired cable — ready to connect straight out of the blister pack
-
ADR road approved — meets Australian Design Rules for legal on-road use across all functions
-
IP67 rated — fully sealed against dust and water immersion
-
12/24V dual voltage — compatible with both 12V light vehicles and 24V heavy transport without modification
-
5-year warranty — backed by LED Autolamps' full warranty programme
Technical Specs
| Specification |
Detail |
| SKU |
275MAR |
| Lamp Type |
Stop / Tail / Indicator / Reflector |
| Voltage Range |
12V / 24V |
| Dimensions |
275mm x 100mm x 22mm |
| Cable Length |
280mm |
| Lens Material |
PMMA (acrylic) |
| Base Material |
ABS |
| Mounting |
Surface mount |
| Connector |
Pre-wired |
| Protection Rating |
IP67 |
| Compliance |
ADR |
| Warranty |
5 years |
Compatible With / Goes Well With
- Trailers, trucks, and commercial vehicles requiring a wide-format rear combination lamp
- 12V light vehicles and 24V heavy transport applications
- Trailer builds requiring ADR-approved rear combination lighting
- LED Autolamps 275ARWM (same 275 series form factor, adds reverse function)
- LED Autolamps wiring harnesses and trailer lighting accessories
Frequently Asked Questions
Is the 275MAR approved for road use in Australia?
Yes. The LED Autolamps 275MAR is ADR road approved, meeting Australian Design Rules requirements for legal on-road use across stop, tail, indicator, and reflector functions.
What is PMMA and why is it used for the lens?
PMMA (polymethyl methacrylate), commonly known as acrylic, offers good optical clarity, UV resistance, and impact resistance — a practical choice for outdoor trailer lamp lenses that need to withstand sun exposure and road debris over time.
How does the 275MAR differ from the 275ARWM?
The 275ARWM includes a reverse function in addition to stop, tail, indicator, and reflector. The 275MAR covers stop, tail, indicator, and reflector only. Both share the same 275mm x 100mm x 22mm form factor.
What is the IP rating on the 275MAR?
The 275MAR is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed trailer and truck body mounting.
What warranty does the 275MAR carry?
The 275MAR is backed by a 5-year warranty from LED Autolamps.
