Description
ECE Approved Mini Jumbo Stop/Tail/Indicator Lamp 282x95mm, 1.2m Cable, IP67, 5-Year Warranty
Product Overview
The LED Autolamps 280ARRM is a 12/24V Mini Jumbo rear combination lamp covering stop, tail, and indicator functions in a 282mm x 95mm x 28mm surface-mount unit. Fitted with 1.2m of pre-wired cable and a 116mm centre-to-centre mount, it carries individual ECE certifications for stop/tail (ECE R1-S1-02) and indicator (ECE 2A-E9-01) providing thorough road approval compliance for trailer and truck body applications.
Drawing 0.3A on stop, 0.04A on tail, and 0.14A on indicator at 13.8V. Rated IP67 and backed by a 5-year warranty.
Features & Benefits
-
Mini Jumbo design — 282mm x 95mm form factor for a prominent, high-visibility rear lighting presence on trailers and truck bodies
-
ECE approved across all functions — stop/tail ECE R1-S1-02, indicator ECE 2A-E9-01
-
1.2m pre-wired cable — long cable lead for flexible routing on larger trailers and truck bodies
-
Stop, tail, and indicator in one lamp — three functions with individual ECE certifications
-
116mm centre-to-centre mount — confirm against your panel before installation
-
IP67 rated — fully sealed against dust and water immersion
-
12/24V dual voltage — compatible with both 12V light vehicles and 24V heavy transport without modification
-
5-year warranty — backed by LED Autolamps' full warranty programme
Technical Specs
| Specification |
Detail |
| SKU |
280ARRM |
| Lamp Type |
Stop / Tail / Indicator |
| Voltage Range |
12V – 24V |
| Dimensions |
282mm x 95mm x 28mm |
| Mount Centre-to-Centre |
116mm |
| Stop Current Draw |
0.3A @ 13.8V |
| Tail Current Draw |
0.04A @ 13.8V |
| Indicator Current Draw |
0.14A @ 13.8V |
| Cable Length |
1.2m |
| Mounting |
Surface mount |
| Connector |
Pre-wired |
| Protection Rating |
IP67 |
| Stop/Tail Compliance |
ECE R1-S1-02 |
| Indicator Compliance |
ECE 2A-E9-01 |
| Warranty |
5 years |
Compatible With / Goes Well With
- Trailers, trucks, and commercial vehicles requiring a prominent Mini Jumbo rear combination lamp
- 12V light vehicles and 24V heavy transport applications
- Trailer builds requiring ECE-approved stop/tail/indicator lighting
- LED Autolamps 280ARWM (same 280 series, adds reverse function)
- LED Autolamps 280AM amber replacement lamp unit (same 280 series)
- LED Autolamps wiring harnesses and trailer lighting accessories
Frequently Asked Questions
Is the 280ARRM approved for road use in Australia?
Yes. The 280ARRM carries individual ECE certifications for stop/tail (ECE R1-S1-02) and indicator (ECE 2A-E9-01), meeting international road approval standards accepted for legal on-road use in Australia.
Why does the 280ARRM have a 1.2m cable?
The 1.2m pre-wired cable gives a generous reach for routing to the trailer or truck body wiring connection, reducing the need for cable extensions on larger vehicles or longer trailers.
What is the centre-to-centre mounting distance?
The 280ARRM has a 116mm centre-to-centre mount spacing. Confirm this measurement against your panel or bracket before installation.
What is the IP rating on the 280ARRM?
The 280ARRM is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed trailer and truck body mounting.
What warranty does the 280ARRM carry?
The 280ARRM is backed by a 5-year warranty from LED Autolamps.
