Description
ADR 48/00 and ECE Approved 12/24V Licence Plate Lamp Black Housing, Two Required for Compliance
Product Overview
The LED Autolamps 41BLM is a 12/24V LED licence plate lamp with a black housing measuring 70mm x 42mm x 40mm, supplied with a 0.25m cable lead and a 45mm centre-to-centre mount. Both ADR 48/00 and ECE approved two lamps are required for a compliant installation.
Drawing 0.05A at 13.8V and rated IP67, backed by a 5-year warranty.
Features & Benefits
-
Black housing — clean, unobtrusive finish suits a wide range of trailer and vehicle rear panel aesthetics
-
ADR 48/00 and ECE approved — dual compliance meets both Australian and international road approval standards; two lamps required for compliance
-
IP67 rated — fully sealed against dust and water immersion
-
0.25m pre-wired cable — ready to connect on installation
-
Very low current draw — 0.05A at 13.8V for minimal electrical system impact
-
12/24V dual voltage — compatible with both 12V light vehicles and 24V heavy transport
-
5-year warranty — backed by LED Autolamps' full warranty programme
Technical Specs
| Specification |
Detail |
| SKU |
41BLM |
| Lamp Type |
Licence Plate Light |
| Voltage Range |
12V – 24V |
| Dimensions |
70mm x 42mm x 40mm |
| Mount Centre-to-Centre |
45mm |
| Current Draw |
0.05A @ 13.8V |
| Cable Length |
0.25m |
| Housing Colour |
Black |
| Mounting |
Surface mount |
| Protection Rating |
IP67 |
| Compliance |
ADR 48/00 / ECE |
| ADR Note |
Two lamps required for compliance |
| Warranty |
5 years |
| Weight |
0.14 kg |
Compatible With / Goes Well With
- Trailers, trucks, and commercial vehicles requiring ADR 48/00 compliant licence plate illumination
- 12V light vehicles and 24V heavy transport applications
- LED Autolamps 30BLM (smaller 65mm black licence plate lamp — also two-lamp compliance)
- LED Autolamps 35BLM (single-lamp ADR compliance alternative)
- LED Autolamps wiring harnesses and trailer lighting accessories
Frequently Asked Questions
How many 41BLM lamps are required for ADR compliance?
Two lamps are required to meet ADR 48/00 compliance. Purchase two units for a fully compliant number plate light installation.
Is the 41BLM approved for road use in Australia?
Yes. The 41BLM is approved under both ADR 48/00 and ECE, meeting Australian and international road approval standards for legal on-road use as a licence plate lamp.
How does the 41BLM compare to the 30BLM?
The 41BLM is larger at 70mm x 42mm x 40mm with a 45mm centre-to-centre spacing and 0.25m cable, while the 30BLM is 65mm x 30mm x 24mm with a 65mm spacing and 0.14m cable. Both require two lamps for ADR compliance and are black housing variants.
What is the IP rating on the 41BLM?
The 41BLM is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion — suitable for exposed outdoor trailer and vehicle mounting.
What warranty does the 41BLM carry?
The 41BLM is backed by a 5-year warranty from LED Autolamps.
Weight
0.14 kg
