Description
Heavy Duty Amber Side Direction Indicator with Female 2-Pin Plug AS2809 DG Compliant, RoHS, IP67.
Product Overview
The LED Autolamps 42AMCSB is an amber side direction indicator lamp from the LED Autolamps Heavy Duty Lighting & Harness System the truck and transport-specific variant of the classic 42 Series amber indicator featuring a female 2-pin plug connector and 20cm cable for integration into the LED Autolamps heavy duty plug-and-play harness system.
Sharing the same heavy duty system specifications as the 42ARMCSB (red/amber marker, previously listed), the 42AMCSB provides amber side direction indicator function. The heavy duty harness system features heavy duty waterproof cable, plugs and connectors, cable system compliance with Dangerous Goods (AS2809), RoHS compliant cables, plugs and lights, and plug covers. Suited to B-doubles, rigid trucks, tankers, dangerous goods vehicles, and livestock transport where the plug-and-play harness system is used. Backed by LED Autolamps' 5-year warranty (1 year for livestock transport).
Key Specifications
- Function: Amber side direction indicator
- Connector: Female 2-pin plug
- Cable: 20cm
- Compliance: AS2809 Dangerous Goods, RoHS
- IP rating: IP67
- Warranty: 5 years (1 year livestock transport)
- Pack quantity: Single unit
- Brand: LED Autolamps
- SKU: 42AMCSB
Features & Benefits
-
Female 2-pin plug connector: Integrates directly into the LED Autolamps Heavy Duty Harness System for fast, tool-free lamp replacement
-
AS2809 Dangerous Goods compliant: Cable system meets AS2809 for dangerous goods transport
-
RoHS compliant: Cables, plugs, and lights all meet RoHS requirements
-
Heavy duty waterproof connectors: Heavy duty waterproof cable, plugs, and connectors with plug covers
-
Amber side direction indicator: Dedicated amber indicator function for AS2809-compliant harness installations
-
20cm cable: Short fly-lead with 2-pin plug for direct connection to the harness system
-
IP67 waterproof: Completely sealed against dust and temporary water immersion
-
5-year warranty: 5 years standard; 1 year for livestock transport applications
Technical Specs
| Specification |
Detail |
| SKU |
42AMCSB |
| Brand |
LED Autolamps |
| System |
Heavy Duty Lighting & Harness System |
| Function |
Amber Side Direction Indicator |
| Connector |
Female 2-pin plug |
| Cable Length |
20cm |
| IP Rating |
IP67 |
| DG Compliance |
AS2809 Dangerous Goods |
| RoHS |
Yes |
| Warranty |
5 Years (1 Year Livestock Transport) |
| Pack Quantity |
Single unit |
Compatible With
Suits all heavy duty trucks, B-doubles, tankers, and commercial vehicles using the LED Autolamps Heavy Duty Harness System:
- B-double and multi-combination vehicles
- Dangerous goods tankers and chemical carriers
- Rigid trucks and semi-trailers using the LED Autolamps harness system
- Livestock transport (1-year warranty applies)
Frequently Asked Questions
What system does this lamp connect to?
The 42AMCSB connects to the LED Autolamps Heavy Duty Lighting & Harness System via a female 2-pin plug not for standard hardwired installation.
What is the difference between the 42AMCSB and the 42ARMCSB?
Both are 42 Series heavy duty harness system lamps with female 2-pin plugs. The 42AMCSB provides amber side direction indicator function while the 42ARMCSB provides red/amber side marker function.
Is this lamp AS2809 compliant for dangerous goods transport?
Yes the cable system is compliant with Dangerous Goods AS2809, making it suitable for use on dangerous goods vehicles including tankers and chemical carriers.
Why is the livestock transport warranty only 1 year?
The LED Autolamps Heavy Duty system carries a 5-year warranty for standard applications and a 1-year warranty for livestock transport reflecting the harsher operating conditions in that application.
What is the return policy for this product?
Return eligibility is subject to the retailer's policy. Contact the seller before ordering if you have any questions.
