Description
ADR Approved 12/24V Side Direction Indicator 3 LEDs, Clip-In Replaceable Lens, IP67
Product Overview
The LED Autolamps 58AM is a 12/24V amber side direction indicator lamp with 3 LEDs and a clip-in replaceable lens, measuring 58mm x 35mm x 21mm in a black housing with a 28mm centre-to-centre mount. The same compact form factor as the 58ARM, it is purpose-built for side indicator use and approved under CRN38277 and ADR 6/00.
Pre-wired, IP67 rated, and backed by a 5-year warranty.
Features & Benefits
-
3 LED amber indicator output — clean, compliant amber side direction indicator function
-
Clip-in replaceable lens — lens swaps independently without removing the full lamp housing from the panel
-
Compact 58mm x 35mm form factor — low-profile surface mount suits a wide range of trailer and truck body side positions
-
ADR approved — certified under CRN38277 and ADR 6/00 for legal on-road use as a side direction indicator
-
IP67 rated — fully sealed against dust and water immersion
-
Pre-wired — ready to connect on installation
-
12/24V dual voltage — compatible with both 12V light vehicles and 24V heavy transport
-
5-year warranty — backed by LED Autolamps' full warranty programme
Technical Specs
| Specification |
Detail |
| SKU |
58AM |
| Lamp Type |
Side Direction Indicator |
| LED Quantity |
3 |
| LED Colour |
Amber |
| Housing Colour |
Black |
| Voltage Range |
12V / 24V |
| Dimensions |
58mm x 35mm x 21mm |
| Mount Centre-to-Centre |
28mm |
| Current Draw |
0.1A @ 13.8V |
| Lens |
Clip-in replaceable |
| Mounting |
Surface mount |
| Connector |
Pre-wired |
| Protection Rating |
IP67 |
| Compliance |
ADR 6/00 — CRN38277 |
| Warranty |
5 years |
Compatible With / Goes Well With
- Trailers, trucks, and commercial vehicles requiring side direction indicator lamps
- 12V light vehicles and 24V heavy transport applications
- LED Autolamps 58ARM red/amber side marker (same 58mm x 35mm form factor)
- LED Autolamps wiring harnesses and trailer lighting accessories
Frequently Asked Questions
Is the 58AM approved for road use in Australia?
Yes. The 58AM is ADR approved under CRN38277 and ADR 6/00, meeting Australian Design Rules requirements for legal on-road use as a side direction indicator lamp.
How does the 58AM differ from the 58ARM?
The 58AM is an amber-only side direction indicator certified under ADR 6/00, while the 58ARM is a red/amber dual-colour side marker certified under ADR 45/01. Both share the same 58mm x 35mm x 21mm form factor, clip-in lens, and 0.1A current draw.
What does the clip-in lens mean for maintenance?
The lens clips out independently, allowing replacement without removing the full lamp housing — reducing maintenance time and cost.
What is the IP rating on the 58AM?
The 58AM is rated IP67, meaning it is fully sealed against dust and capable of withstanding water immersion.
What warranty does the 58AM carry?
The 58AM is backed by a 5-year warranty from LED Autolamps.
