Description
Popular Truck Style Amber LED Marker Brushed Stainless Steel Bezel, Clear Lens, Dual ADR Approval.
Product Overview
The LED Autolamps 86AMB is a low-profile amber LED clearance and marker lamp featuring a brushed stainless steel bezel, clear polycarbonate lens with internal amber LEDs, and a slim 10mm depth profile. Part of the well-established 86 series from LED Autolamps, the 86AMB is a popular truck and trailer style marker light that combines understated aesthetics with genuine ADR compliance across two approval categories ADR 74/00 and ADR 45/01.
Measuring just 86mm x 31mm x 10mm, this ultra-slim surface mount lamp suits trailer frames, side rails, and body panels where a low-profile, professional marker is required. The brushed stainless steel bezel provides corrosion resistance for coastal and demanding outdoor environments, while the clear lens with internal amber LEDs maintains colour accuracy over time without UV-related lens discolouration. At just 0.05A current draw at 13.8V, the 86AMB places minimal load on the vehicle's electrical system. Backed by a 5-year warranty and supplied individually.
Key Specifications
-
Function: Clearance / marker lamp side indicator
-
LED colour: Amber
-
Lens: Clear polycarbonate with internal amber LEDs
-
Bezel: Brushed stainless steel
-
Dimensions: 86mm x 31mm x 10mm
-
Mount type: Surface mount pre-wired
-
IP rating: IP67
-
Input voltage: 12–24V DC
-
Current draw: 0.05A @ 13.8V
-
Compliance: ADR 74/00, ADR 45/01
-
Warranty: 5 years
-
Weight: 0.5kg
-
Packaging: Single unit
-
Brand: LED Autolamps
-
SKU: 86AMB
Features & Benefits
-
Dual ADR approval: Certified under both ADR 74/00 and ADR 45/01, covering multiple marker lamp application categories for broad legal compliance across trailer and commercial vehicle types
-
Brushed stainless steel bezel: Corrosion-resistant stainless construction withstands coastal salt spray, outback dust, and road grime, providing lasting durability superior to chrome plastic alternatives
-
Clear lens with internal amber LEDs: Modern design maintains colour accuracy and brightness without UV fading or lens discolouration common to traditional amber-tinted plastic lenses
-
Ultra-slim 10mm profile: Low-profile design sits nearly flush with mounting surfaces, reducing snag risk and maintaining clean aerodynamic lines on modern trailers and caravans
-
Popular truck style: The 86 series lamp profile is a widely recognised and trusted form factor across Australian truck and trailer builds
-
0.05A current draw: Ultra-low electrical load at 12V, placing minimal demand on the vehicle's electrical system across any number of installed units
-
12V and 24V compatible: Multivolt operation suits both passenger vehicle and caravan trailer applications and 24V commercial truck systems
-
IP67 weatherproof: Completely protected against dust ingress and temporary water immersion for reliable outdoor performance year-round
-
Pre-wired connector: Supplied with pre-wired leads for straightforward installation
-
5-year warranty: Backed by LED Autolamps' industry-standard 5-year warranty
Technical Specs
|
Specification
|
Detail
|
|
SKU
|
86AMB
|
|
Brand
|
LED Autolamps
|
|
Type
|
Clearance / Marker Lamp
|
|
Function
|
Side Indicator / Marker
|
|
LED Colour
|
Amber
|
|
Lens
|
Clear polycarbonate (internal amber LEDs)
|
|
Bezel Material
|
Brushed Stainless Steel
|
|
Dimensions
|
86mm x 31mm x 10mm
|
|
Mount Type
|
Surface Mount
|
|
Connector
|
Pre-wired
|
|
IP Rating
|
IP67
|
|
Input Voltage
|
12–24V DC
|
|
Current Draw
|
0.05A @ 13.8V
|
|
ADR Compliance
|
ADR 74/00, ADR 45/01
|
|
Warranty
|
5 Years
|
|
Weight
|
0.5kg
|
|
Packaging
|
Single unit
|
Compatible With
Universal suits all 12V and 24V trailers, caravans, and commercial vehicles requiring ADR-compliant amber marker or clearance lighting including:
-
Box trailers, car trailers, and boat trailers
-
Caravans and camper trailers
-
Light and heavy commercial trucks
-
Agricultural and construction trailers
-
Horse floats and livestock trailers
Pairs well with:
-
LED Autolamps MAXILAMPC3XR or MAXILAMPC3XRWB combination lamps
-
LED Autolamps 42AM amber side direction indicator
-
LED Autolamps 7030R red self-adhesive reflectors
Frequently Asked Questions
What ADR categories is this lamp approved for?
The 86AMB holds dual ADR approval under ADR 74/00 and ADR 45/01, covering clearance/marker and side marker indicator categories for comprehensive legal compliance on Australian road vehicles and trailers.
Why does this lamp have a clear lens if it's amber?
The 86AMB uses a clear polycarbonate lens with internal amber LEDs to produce the amber light output. This approach maintains colour accuracy and brightness over time without the UV fading and discolouration that occurs with traditional amber-tinted plastic lenses.
What is the bezel material and why does it matter?
The 86AMB features a brushed stainless steel bezel providing genuine corrosion resistance against salt spray, moisture, and road chemicals. This makes it more durable in coastal and outback Australian conditions than standard chrome plastic bezels.
What is the current draw of this lamp?
The 86AMB draws 0.05A at 13.8V (12V system), placing minimal load on the vehicle's electrical system ideal for multi-lamp installations across larger trailers and trucks.
What is the return policy for this product?
Return eligibility is subject to the retailer's policy. Contact the seller before ordering if you have any questions about this product.
