Description
ECE Approved 7-Inch LED Headlight Pair 17W High Beam, 4x3W Low Beam, Die Cast Alloy, IP67
Product Overview
The LED Autolamps HL175 is a 7-inch round LED headlight supplied as a pair, combining a 17W high beam LED, four 3W low beam LEDs, and two SMD position lamp LEDs in a die cast alloy housing measuring 175mm x 98mm. The 5-terminal blade connector design covers high beam, low beam, and position lamp functions from a single unit.
ECE road approved across an 11–32V operating range, IP67 rated, and backed by a 5-year warranty. Suited to classic vehicles, 4WD, trucks, and custom builds requiring round headlights.
Features & Benefits
-
17W high beam LED — dedicated single high-power LED for strong, focused high beam output
-
4 x 3W low beam LEDs — four-LED low beam array delivers even, controlled illumination for road use
-
2 x SMD position lamp LEDs — integrated position/DRL lamp function
-
Die cast alloy housing — robust, heat-dissipating alloy construction suited to long-term outdoor and off-road use
-
5-terminal blade connector — covers high beam, low beam, and position functions in a single housing connection
-
ECE road approved — meets international road approval standards for legal on-road use
-
IP67 rated — fully sealed against dust and water immersion
-
Wide voltage range 11–32V — compatible with 12V and 24V vehicle electrical systems
-
5-year warranty — backed by LED Autolamps' full warranty programme
Technical Specs
| Specification |
Detail |
| SKU |
HL175 |
| Pack Contents |
2 headlights |
| Lamp Type |
Round Headlight |
| High Beam |
1 x 17W LED |
| Low Beam |
4 x 3W LED |
| Position Lamp |
2 x SMD LED |
| Terminals |
5 (blade) |
| Voltage Range |
11V – 32V |
| Dimensions |
175mm x 98mm |
| Housing Material |
Die cast alloy |
| Protection Rating |
IP67 |
| Compliance |
ECE |
| Warranty |
5 years |
Compatible With / Goes Well With
- Classic and vintage vehicles, 4WD, trucks, and custom builds requiring 7-inch round headlights
- 12V and 24V vehicle electrical systems
- LED Autolamps wiring accessories
Frequently Asked Questions
Is the HL175 approved for road use in Australia?
Yes. The HL175 is ECE road approved, meeting international road approval standards accepted for legal on-road use in Australia.
What vehicles is the 7-inch round headlight suited to?
The 7-inch round headlight is a standard fitment on many classic vehicles, Land Rover Defenders, Jeep models, older trucks, and custom builds. Confirm the specific mounting dimensions and connector type match your vehicle before ordering.
What does the 5-terminal blade connector cover?
The five terminals provide connections for high beam, low beam, position lamp, and ground — covering all three functions from a single headlight unit without requiring adapters.
What is the advantage of a die cast alloy housing?
Die cast alloy provides a rigid, impact-resistant housing that also dissipates LED heat more effectively than plastic — extending LED lifespan and maintaining performance in the enclosed headlight environment.
What warranty does the HL175 carry?
The HL175 is backed by a 5-year warranty from LED Autolamps.
