Oricom DTXTP600 Trade Pack 5 Watt UHF CB Radios

Description

Oricom Trade Pack 5 Watt UHF CB Radios: Featuring One Of The Largest Backlit Lcd Displays In The Australian Handheld Radio Market


The DTX600 is super compact and fits comfortably in the palm of your hand.
Oricom DTXTP600 Features:

  • Compact Radio With Large Backlit LCD Display

  • Switchable Rf Power (High: 5 Watt, Low: 1 Watt)

  • 3 Programmable Instant Channel Buttons

  • 80 Channels

  • High Capacity Lithium-ion Battery

  • With Up To 30hrs Operating Time^

  • Fast Charge Technology Supplied With

  • 240v And 12v Adaptors

  • Open/instant/priority Scan

  • Die Cast Metal Chassis

  • Duplex (Range Extender)

  • Signal Monitoring

  • Triple Watch

  • Audio Scrambler

  • Squelch Tail On/off

  • 38 CTCSS And 104 DCS Codes

  • Rotary Volume Control

  • 2.5mm Jack Socket With Locking

  • Screw For Optional Accessories

  • Designed, Engineered & Made In Korea

  • 3 Year Warranty Excludes Battery*


Oricom DTXTP600 Specifications:
General

  • Compliance AS/NZS 4365:2011 And Nzs2772.1

  • Frequency Range TX/RX 476.425 - 477.4125 MHZ

  • Number Of Channels 80 UHF CB (75 Usable)‚Ć

  • Channel Spacing TX/RX 12.5khz

  • Channel Spacing RX 12.5khz

  • Operating Modes Simplex, Duplex

  • Scanning Speed 150msec/per Channel

  • Antenna Impedance 50 Ohm

  • Battery Capacity 7.4v,2600mahli-ion Battery

  • Operating Time Up To 20hrs On High

  • Tx Power, 30hrs On Low Tx Power

  • With Antenna.

  • Frequency Stability +/- 2.5ppm


TRANSMITTER

  • RF Output Power 5 Watts Max.

  • Modulation Fm

  • Maximum Deviation +/- 2.5khz

  • Spurious Emissions Less Than-30dbm

  • TX Frequency Response +1 To -3db Of 6db/octave From 300hz

  • To 3000hz

  • Audio Signal To Noise Ratio More Than 35db


RECEIVER

  • Circuit Type Direct Conversion By Single DSP Chip

  • Intermediate Frequencies If = 137khz

  • Sensitivity Less Than -122dbm At 12db Sinad

  • Selectivity More Than 70db

  • Intermodulation Immunity More Than 70db

  • Spurious Response Immunity More Than 60db

  • Audio Signal To Noise Ratio More Than 50db

  • Receive Frequency Response +1 To -3db Of 6db/octave

  • From 300hz To 3000hz

  • Conducted Spurious Emissions Less Than -57dbm At 9khz


What's in the Box:

  • 2 X UHF CB Radios

  • 2 X Antennas

  • 2 X Speaker Mics

  • 2 X Charging Pods (With Mains Adaptor And 12v Adaptor)

  • 2 X Belt Clips

  • 2 X Lithium-ion Batteries

  • 1 X Ip67 Waterproof Heavy Duty Carry Case


Optional Accessories:

  • Speaker Mic (Spkmic5000)

  • Throat Mic (Thmic5000)

  • Compact Speaker With In-line Mic (EBVOX5000)


Legendary Products & Support From Authorized Dealers

When you choose ORICOM, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:

  • ▸ Expert Knowledge & Training

    Only authorized ORICOM dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.

  • ▸ Authorized Warranty Protection:

    We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.

  • ▸ Reliable Customer Support:

    If you ever run into an issue, you're backed by ORICOM's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.

  • ▸ Protect Your Investment:

    Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?

Choose wisely. Buy from an authorized ORICOM dealer today!
