Pioneer GM-D8704 1200W Class-FD 4-Channel Bridgeable Amplifier

Description

Amplify Your Audio Experience with the New Class-D Amplifier!


An amplifier shouldn't take up too much space, especially in your car. The GM-D8704 might just be what you're looking for. It combines a 1-Ohm stable circuit, installation flexibility and a superior high-power output.

Big Power, Small Size
Pioneer's new extra-efficient Class-D digital amplifiers mark a dramatic improvement in power output capability, yet are 50% smaller than the current GM-Series Class-AB amplifiers. That makes them more versatile in terms of installation as well as performance.

Improved Circuit Design
To prevent circuit shutdown, Pioneer's new digital amplifier circuit “Protection Control System” senses its internal temperature and automatically moderates input level accordingly. Stable, durable circuitry lessens the risk of high input power for the unit to achieve 1 Ω connection. This design enhances the flexibility to connect multiple subwoofers to a system

Variable Low Pass & High Pass Filter
For extra flexibility, variable LPF and HPF make audio frequency more adjustable according to subwoofer characteristics and personal listening preferences. The LPF and HPF are adjustable from 40 Hz to 500 Hz.

Speaker Level Inputs
What, you DON'T own a Pioneer head unit? Well, we won't hold it against you. In fact we'll even help you build onto your system. Speaker level inputs allow you to connect your OEM unit (or any unit that doesn't have the typical RCA-type inputs) without having to buy add-on adapters. So, the install goes faster, you save money, and you've got a Pioneer amp in your vehicle.
Features:

  • 1,200 Watts Max Power

  • Compact Design for Versatile Installation Options

  • Refined Class FD Design Offers Extreme Efficiency and High-Quality Sound


Specifications:
General

  • RCA Inputs: 4-CH

  • Amplifier Class: CLASS-D

  • Hi-Res Certified: No

  • Bridgeable: Yes

  • Warranty: 1 Year

  • Speaker Level Input: Yes

  • Fuse Rating: 30A x 2

  • Bass Boost Remote: Yes

  • Automatic Signal Sensing and Turn-On: Yes

  • Hi-Volt Input Level Control: 200 mV to 6.5 V

  • Terminal Type: Block

  • Load Impedance Allowance (Ohms): 1 to 8

  • Protection Control System: Yes

  • Dimensions: 252mm (W) x 60mm (H) x 215mm (D)


Power

  • Continuous Power (RMS) Output @ 1‚Ѷ: 125W RMS x 4

  • Continuous Power (RMS) Output @ 2‚Ѷ: 150W RMS x 4

  • Continuous Power (RMS) Output @ 4‚Ѷ: 100W RMS x 4

  • Continuous Power (RMS) Output - Bridged @ 4‚Ѷ: 300W RMS x 2


Audio Adjustments

  • Low-Pass Crossover Frequency: 40 Hz

  • Low-Pass Slope (dB/octave): -12dB

  • High-Pass Crossover Frequency: 500 Hz

  • Bass Boost Frequency: 50 Hz

  • Bass Boost Level: 0 dB to 18 dB


Audio Specifications

  • Frequency Response: 10 Hz - 50 kHz

  • Total Harmonic Distortion (THD): < 0.5% (100 Hz)

  • Signal-to-Noise (SN) Ratio: > 95dB


Legendary Products & Support From Authorized Dealers

When you choose Pioneer, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:

  • ▸ Expert Knowledge & Training

    Only authorized Pioneer dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.

  • ▸ Authorized Warranty Protection:

    We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.

  • ▸ Reliable Customer Support:

    If you ever run into an issue, you're backed by Pioneer's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.

  • ▸ Protect Your Investment:

    Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?

Choose wisely. Buy from an authorized Pioneer dealer today!

Pioneer GM-D8704 1200W Class-FD 4-Channel Bridgeable Amplifier

Product form

Amplify Your Audio Experience with the New Class-D Amplifier!An amplifier shouldn't take up too much space, especially in your car.... Read more

SKU: GMD8704

  • In Stock

$435.00 Incl. VAT
