Description
Roadvision BR601ARW LED Jumbo Combination Lamp Stop Tail Ind Reverse
A triple module LED jumbo combination lamp from the Roadvision BR601 Series, the BR601ARW combines stop, tail, indicator, and reverse functions with an integrated reflector, 10-30V DC multi-volt input, sealed polycarbonate lenses on a high impact ABS housing, a 100,000 hour rated LED lifespan, ADR/ECE approval for all functions, and a 5-year warranty.
Product Overview
The Roadvision BR601ARW is a complete heavy duty all-in-one rear lighting solution for trucks and trailers, packing stop/tail, indicator, reverse, and reflector functions into a single 604 x 132 x 41mm jumbo lamp. Each function runs 24 LEDs, producing more light output than incandescent lamps while drawing a fraction of the current, at just 0.1A for the indicator, 0.1/0.05A for stop/tail, and 0.2A for reverse at 13.8V.
The unbreakable sealed polycarbonate lenses and extremely tough high impact ABS housing are dust and water proof and totally maintenance free, with a 100,000 hour rated LED lifespan from solid-state technology. The simple surface mount design retro-fits in place of existing jumbo lamps on 501mm and 325mm mounting hole centres, and the lamp is supplied pre-wired with a 300mm LEDLink connector. All functions are ADR/ECE approved. With Roadvision it's fit and forget.
Features & Benefits
All-In-One Heavy Duty Combination Lamp: The BR601ARW combines stop/tail, indicator, reverse, and reflector functions in one triple module jumbo lamp, replacing multiple separate lamps on the rear of trucks and trailers.
Retro-Fits Existing Jumbo Lamps: The simple surface mount design retro-fits in place of existing jumbo combination lamps, making it a straightforward LED upgrade for heavy vehicles.
More Light, Less Current: The BR601 Series produces more light output than conventional incandescent systems while drawing a fraction of the current, with 24 LEDs per function.
100,000 Hour Rated LED Lifespan: Solid-state LED technology delivers a 100,000 hour rated lifespan for totally maintenance-free operation over the life of the vehicle.
Unbreakable Polycarbonate Lenses and High Impact ABS Housing: The sealed polycarbonate lenses and extremely tough high impact ABS housing are dust and water proof, built for heavy duty road exposure.
Multi-Volt 10-30V DC Input: The 10-30V DC multi-volt input makes the BR601ARW compatible with both 12V and 24V vehicle electrical systems without a voltage adaptor.
ADR/ECE Approved for All Functions: The indicator, stop, tail, and reverse functions are all ADR/ECE approved for legal on-road use in Australia.
Pre-Wired with LEDLink Connector: The lamp is supplied pre-wired with a 300mm LEDLink connector for a quick, tidy connection to the vehicle harness.
5-Year Warranty: The BR601ARW is backed by a 5-year Roadvision warranty.
Technical Specs
| Specification |
Detail |
| SKU |
BR601ARW |
| Brand |
Roadvision |
| Series |
BR601 Combination |
| Description |
Rect Stop/Tail/Ind/Rev Lamp Triple Module |
| Functions |
Stop/Tail, Indicator, Reverse and Reflector |
| Voltage Input |
10-30V DC |
| Number of LEDs |
Indicator - 24 LEDs, Stop/Tail - 24 LEDs, Reverse - 24 LEDs |
| Current Draw |
Indicator - 0.1A, Stop/Tail - 0.1/0.05A, Reverse - 0.2A at 13.8V |
| Dimensions |
604 x 132 x 41mm |
| Lens |
Polycarbonate |
| Housing |
ABS High Impact |
| Ingress Protection |
Water and Dust Proof |
| Mounting Type |
Surface Mount |
| Mounting Hole Centres |
501mm and 325mm |
| Cable |
300mm with LEDLink Connector |
| ADR Approval |
Indicator - CRN 46082, Stop - CRN 46121, Tail - CRN 46120, Reverse - CRN 46122 |
| CTA Approval |
CTA-060773 |
| LED Lifespan |
100,000 Hours |
| Warranty |
5 Years |
Compatible With
The BR601ARW is compatible with 10-30V DC electrical systems, covering both 12V and 24V trucks and trailers, and is ADR/ECE approved for all functions for on-road use in Australia. The surface mount design retro-fits in place of existing jumbo lamps. The BR601 Series is also available as a twin module stop/tail/indicator (BR601AR) and a triple module with double stop/tail (BR601ARR). Confirm the 604mm lamp length and 501mm/325mm mounting hole centres fit your intended location before purchase.
Frequently Asked Questions
What functions does the BR601ARW include?
The BR601ARW combines stop/tail, indicator, and reverse functions with an integrated reflector in a single triple module jumbo lamp, with 24 LEDs per function.
Is the BR601ARW ADR approved?
Yes. All functions are ADR/ECE approved, with indicator CRN 46082, stop CRN 46121, tail CRN 46120, reverse CRN 46122, and CTA approval CTA-060773.
Is the BR601ARW compatible with 24V trucks?
Yes. The BR601ARW operates across 10-30V DC, making it compatible with both 12V and 24V vehicle electrical systems.
Can the BR601ARW replace my existing jumbo lamp?
Yes. The simple surface mount design retro-fits in place of existing jumbo combination lamps, with 501mm and 325mm mounting hole centres. Confirm your existing mounting positions before purchase.
What is the difference between the BR601ARW and BR601ARR?
Both are 604mm triple module lamps. The BR601ARW uses its third module for a reverse function, while the BR601ARR uses it for a second stop/tail module with 48 stop/tail LEDs in total.
