Rockford Fosgate P3SD4-10 Punch 10" P3S Shallow 4-Ohm DVC Subwoofer

Description

Delivers “Punch” Even When Depth Is Limited

Rockford Fosgate P3S 10" shallow mount subwoofer delivers “Punch” even when depth is limited. The P3SD4-10 features Dual 4-Ohm voice coils for wiring flexibility and 300 Watts RMS power handling. The Rockford Fosgate P3S 10" shallow mount subwoofer delivers Punch, even in depth limited situations. Rockford Fosgate understands all vehicles are not the same, because some cannot accommodate deep subwoofers. In the past, that meant no Bass. Not anymore! Now even depth challenged vehicles can have REAL Bass and the Dual Voice Coil allow configurations for every application. Shallow woofers are specifically designed for spaces where a traditional woofer cannot be used. Features:
  • M-Roll Santoprene™ surround
  • StampCast basket with integrated spider venting
  • Anodized aluminum cone and dustcap
  • Dual linear spider with embedded 16 AWG tinsel leads
  • Diamond cut cast aluminum trim ring with optional grille
  • Shallow Motor Assembly
  • Optimized for both sealed and vented enclosures
Specifications:
  • Magnet Weight (kg) NOT USED 1.32 oz. (47 kg.)
  • Nominal Impedance Dual 4-Ohm
  • Magnet Weight (oz) 47 oz. (1.32 Kg)
  • Voice Coil Diameter 2.5" (65.5 mm)
  • SPL (dB @ 1w/1m) 83
  • Fs (Hz) 42
  • Qms 6.00
  • Vas (Liters) 14.3
  • Cutout Diameter 9.06 in. (230.0 mm)
  • Woofer Displacement 0.074 cu. ft. (2.1 Liters)
  • Sd (cm2) 333
  • Size 10"
  • Speaker Connector Dual 10 AWG Compression
  • Mounting Depth 3.50 in. (89.0 mm)
  • Shipping Weight 11.9 lbs. (5.39 kg.)
  • Qts 0.78
  • Qes 0.90
  • Xmax (mm) 8.1
  • CEA-2031 Compliant
  • Power Handling (Watts RMS) 300 Watts RMS, 600 Watts Max
  • Re (Ohms) 6.80
  • Le (mH) 4.3
  • Subwoofer Type Shallow
  • Voice Coil Type Dual Voice Coil
  • Sealed Box Volume (Vb) 0.5 cu. ft. (14.1 Liters)
  • Vented Box Volume (Vb) 1.0 cu. ft. (28.3 Liters)
