Description
Rockford Fosgate PEQ Remote Punch EQ Bass and Treble Control from the Dash, Built for 2007+ Punch & Power Amplifiers
Product Overview
The Rockford Fosgate PEQ is a wired remote Punch equalisation controller designed for select 2007 and newer Rockford Fosgate Punch and Power amplifiers. Providing remote control of both bass and treble boost from a convenient dash, console, or glovebox mounting location, the PEQ gives the driver real-time tonal adjustment without accessing the amplifier particularly useful in systems where the amplifier is mounted in the boot, under the seat, or in another location where in-car adjustment is impractical.
The PEQ offers up to +18 dB of bass boost at 45 Hz the signature Rockford Fosgate Punch EQ frequency and up to +12 dB of treble boost at 12.5 kHz, with bass and treble filtering behaviour determined by the in-board amplifier crossover setting. On 4-channel amplifiers, the PEQ controls bass on the rear outputs. The complete installation kit includes the bass/treble knob unit, cable, mounting clip, and mounting screws everything needed for a clean dash or console installation.
Key Specifications
- Type: Wired remote bass and treble EQ controller
- Bass boost: 0 dB to +18 dB @ 45 Hz
- Treble boost: 0 dB to +12 dB @ 12.5 kHz
- Filter behaviour: Based on in-board amplifier crossover setting (HP / LP / AP)
- 4-channel amplifier use: Controls bass on rear outputs
- Compatible amplifiers: Select 2007 and newer Rockford Fosgate Punch and Power amplifiers
- Mounting options: Under-dash / centre console / glovebox
- Kit contents: Bass/treble knob unit, cable, mounting clip, mounting screws
- Cable length: Confirm with supplier
- Shipping weight: Confirm with supplier
Features & Benefits
-
Remote bass boost 0 dB to +18 dB @ 45 Hz: The signature Rockford Fosgate Punch EQ frequency, adjustable from flat to a maximum +18 dB boost at 45 Hz from the driver's seat. Adjust bass emphasis on the fly to suit music genre, road noise, and passenger preference without leaving the seat or accessing the amplifier.
-
Remote treble boost 0 dB to +12 dB @ 12.5 kHz: Independent treble boost control up to +12 dB at 12.5 kHz, complementing the bass control for comprehensive tonal adjustment from a single remote unit. Useful for compensating for high-frequency loss at elevated listening volumes or in acoustically challenging vehicle cabin environments.
-
Filter behaviour linked to in-board amplifier crossover: The PEQ's bass and treble filtering operates in conjunction with the amplifier's internal crossover setting HP (high-pass), LP (low-pass), or AP (all-pass). This ensures the remote EQ adjustments remain appropriate to the speaker configuration connected to the amplifier rather than boosting frequencies outside the speaker's operating range.
-
Controls rear output bass on 4-channel amplifiers: When used with a compatible 4-channel Rockford Fosgate Punch or Power amplifier, the PEQ provides dedicated bass control of the rear channel outputs useful for systems where the rear channels drive subwoofers or bass-emphasis speakers independently of the front channels.
-
Convenient remote mounting under-dash, console, or glovebox: The compact PEQ unit installs cleanly under the dashboard, inside the centre console, or in the glovebox using the included mounting clip and screws keeping the driver's reach-zone tidy while providing accessible real-time tonal control.
-
Complete installation kit included: Bass/treble knob unit, cable, mounting clip, and mounting screws are all included. No additional accessory purchases required for a clean installation in most standard Australian vehicles.
-
Wired reliability: A hardwired connection to the amplifier provides consistent, noise-free signal transmission without the latency or pairing issues of wireless remote solutions appropriate for a signal-path EQ control where accuracy and consistency matter.
Technical Specs
| Specification |
Detail |
| SKU |
PEQ |
| Brand |
Rockford Fosgate |
| Type |
Wired remote bass and treble EQ controller |
| Bass Boost |
0 dB to +18 dB @ 45 Hz |
| Treble Boost |
0 dB to +12 dB @ 12.5 kHz |
| Filter Behaviour |
Based on in-board amplifier crossover (HP / LP / AP) |
| 4-Channel Use |
Controls bass on rear outputs |
| Compatible Amplifiers |
Select 2007 and newer Rockford Fosgate Punch and Power amplifiers |
| Mounting Options |
Under-dash / centre console / glovebox |
| Kit Contents |
Bass/treble knob, cable, mounting clip, mounting screws |
| Cable Length |
Confirm with supplier |
| Shipping Weight |
Confirm with supplier |
| Warranty |
Confirm with supplier |
Compatible With
- Select 2007 and newer Rockford Fosgate Punch series amplifiers with PEQ input
- Select 2007 and newer Rockford Fosgate Power series amplifiers with PEQ input
- Amplifier installations where the amplifier is mounted in the boot, under the seat, or in another location away from the driver
- 4-channel amplifier builds where independent rear output bass control is required
- Vehicles where real-time tonal adjustment from the driver's position is a priority
Frequently Asked Questions
Which amplifiers is the PEQ compatible with? The PEQ is designed for select 2007 and newer Rockford Fosgate Punch and Power amplifiers. Not all amplifiers in these ranges include a PEQ input confirm that your specific amplifier model has a dedicated PEQ connector with your supplier before purchasing.
What is the difference between the PEQ and the PLC2 remote level control? The PLC2 is a single-function remote subwoofer level control it adjusts output level only. The PEQ provides both bass boost (0 dB to +18 dB @ 45 Hz) and treble boost (0 dB to +12 dB @ 12.5 kHz) from a single wired remote unit, making it a more comprehensive tonal control solution. Confirm which remote accessory is compatible with your specific amplifier model before purchasing.
How does the PEQ's filter behaviour interact with the amplifier's crossover? The PEQ's bass and treble boost operates within the frequency boundaries established by the amplifier's internal crossover setting. In low-pass mode, only the bass boost is active; in high-pass mode, only the treble boost is active; in all-pass mode, both bass and treble controls operate across the full frequency range. This prevents the remote EQ from boosting frequencies outside the speaker's crossover-defined operating range.
Where can the PEQ be mounted in the vehicle? The PEQ includes a mounting clip and screws for under-dash, centre console, or glovebox installation. The compact form factor suits most standard Australian vehicle dash and console environments without custom fabrication.
Does the PEQ kit include everything needed for installation? Yes. The PEQ ships with the bass/treble knob unit, cable, mounting clip, and mounting screws covering all hardware required for a standard installation. Confirm cable length with your supplier to ensure it reaches your amplifier from your intended mounting location.
