Rockford Fosgate PM1000X5 Punch Marine 1,000 Watt Class-bd 5-Channel Amplifier

Description

Designed for Motorsport and Marine Applications

The PM1000X5 is a 1000 Watt 5-channel amplifier with high dynamic power using Class-a/b technology on the front/rear channels, Class-bd for the subwoofer channel, and a conformal coated pc board designed for motorsport and marine applications. The PM1000X5 1,000 Watt full-range 5-channel is the one-and-only amplifier you will need to run your entire system. Run dash speakers off the front channels, run back speakers off the rear channels and run subwoofer(s) off the 5th channel! Known world-wide for brute power, this amplifier offers a higher level of efficiency along with a tri-stage protection that covers thermal, over-current and short circuits. Features:
  • High level input capable with Auto Turn-On circuit
  • Features C.L.E.A.N. Set-up
  • Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)
  • 12dB/octave Butterworth crossover
  • On-board Punch EQ with +18dB boost @ 45Hz
  • Muted turn on
  • Stealth top mounted control panel
  • Cast aluminum heatsink
  • Short circuit protection
  • Over current protection
  • Infrasonic filter
  • 2/4 channel input switch
  • Marine grade two part epoxy coating on circuit boards
  • Marine grade stainless steel hardware
Specifications:
  • Input Sensitivity 150 mV - 12 V
  • Operating Voltage 9 - 16 VDC
  • Number of Channels 5
  • CEA-2006 Compliant
  • CEA-2006 Power Rating 75Wx4 + 150Wx1 @ 4‚Ѷ, ‚â§1.0% THD+N
  • Tone Controls Sub: 0dB to +18dB @ 45Hz
  • Signal InputI nput Switch: Hi/Low level input / Input Switch: 2/4 channel input / Hi/Low Level: 3 RCA Pair / Sub: front/sub input switch
  • Power Input Connector Block
  • Power Wire Gauge 4 AWG
  • Speaker Output Connector Block
  • Speaker Wire Gauge 12 AWG
  • Visual Indicators Power/Protect/Thermal LED, Input Clip LED3, Output Clip LED1,2,3 / LED Color Legend: 1BLUE: <0.5% THD, 2VIOLET: 1% THD, 3RED: 10%+ THD
  • Dimensions (H x W x D) 2.38 x 7.76 x 15.03 (in) 6.05 x 19.71 x 38.18 (cm)
  • Total Harmonic Distortion (THD+Noise) <1.0%
  • Average Current Draw (13.8V Music) 75 A
  • Max. Current Draw (13.8V Sinewave) 150 A
  • Recommended Fuse (not included) 150 A
  • Suggested Alternator 100 A
  • Rated Power (RMS Continuous Power) 75 Watts x 4 + 150 Watts x 1 @ 4-Ohm / 125 Watts x 4 + 300 Watts x 1 @ 2-Ohm / N/A + 500 Watts @ 1-Ohm
  • Total Power (Sum of Rated Power) 1000 Watts
  • Bridgeable Yes (front/rear channels)
  • Crossover Controls Front: 50Hz - 250Hz High-Pass @ 12dB/Octave / Rear: 50Hz - 250Hz High-Pass @ 12dB/Octave / Sub: 50Hz - 250Hz Low-Pass / Sub: 28Hz infrasonic filter @ 12dB/Octave
  • Heat Sink Type Cast
  • Cooling Convection
  • Remote Controls Optional Punch Level Control (PLC2) Ready
  • Circuit Topology Class Class A/B + Class BD (Sub)
  • Frequency Response Front/Rear: 20Hz - 20kHz +/-3dB / Sub: 20Hz - 500Hz +/-3dB
  • Shipping Weight 15.3 lbs. (6.93 Kg.)
  • Dynamic Power (PVC/PowerCube¬Æ) 115 Watts x 4 + 299 Watts x 1 @ 4-Ohms 0¬∞ Res / 190 Watts x 4 + 540 Watts x 1 @ 2-Ohms 0¬∞ Res / N/A + 863 Watts x 1 @ 1-Ohm 0¬∞ Res
  • Efficiency (average) Front/Rear: 66% @ 4-Ohm / Sub Channel: 80% @ 4-Ohm

Legendary Products & Support From Authorized Dealers

When you choose Rockford Fosgate, you're choosing quality and performance. But just as important as what you buy is where you buy it from. Here's why purchasing from an authorized dealer is always the right choice:

  • ▸ Expert Knowledge & Training

    Only authorized Rockford Fosgate dealers are factory-trained to sell and install our products. They have the expertise to ensure your purchase is set up correctly and meets your expectations.

  • ▸ Authorized Warranty Protection:

    We offer one of the best warranties in the industry, but only purchases made through authorized dealers are covered. Don't be misled by unauthorized sellers who can't provide genuine warranty support.

  • ▸ Reliable Customer Support:

    If you ever run into an issue, you're backed by Rockford Fosgate's official manufacturer's warranty. No need to deal with overseas returns—our local team takes care of everything quickly and efficiently.

  • ▸ Protect Your Investment:

    Buying from an authorized dealer ensures you're getting genuine products, full warranty coverage, and expert support. Ask yourself—is saving a few dollars worth losing all that?

Choose wisely. Buy from an authorized Rockford Fosgate dealer today!
