Description
Rockford Fosgate Punch Marine Grade Media Receiver with 2.3″ Dot Matrix Display: Provides Protection Against Water, Dust, and UV Rays!
The PMX-1 features a scratch-resistant wet-bonded display, superior Bluetooth¬Æ audio, AUX, and USB inputs. The Element Ready™ design also provides protection against water, dust, and UV rays. The PMX-1 features a 9H tempered glass screen optically bonded which allows for optimized viewing of the dot matrix display under all lighting and viewing conditions. The superior Bluetooth¬Æ audio features A2DP and AVRCP for better range, easier device pairing, and glitch-free wireless audio streaming. The flexible AUX and USB inputs enable convenient access to various audio playback formats and charging of your mobile devices.
Features: - Wet bonded 2.3" Full Dot Matrix LCD Display
- 9H Tempered Glass Screen
- A2DP and AVRCP Bluetooth® Wireless Streaming
- AUX and USB Inputs with USB Charging
- Compatible with PMX-BTUR Steering Wheel Remote
- Independent Subwoofer Level Control
- 7-Band Graphic EQ + PEQ
- Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
- Voltage gauge with Low Voltage Warning
- AM / FM / WB Tuner
- Multi-Region Radio Frequencies
- IP6 Marine Grade Front Panel
- FCC, CE, and EN60945 Certified
Specifications: - Bluetooth® (Yes/No) Yes, 3.0+EDR, A2DP 1.3
- Speaker Outputs (Yes/No) Yes
- Device Type Digital-Media Receiver
- Multi-Zone/Multi-Source (Yes/No) No
- Pandora® Internet Radio (Yes/No) No
- SiriusXM-Ready® (Yes/No) No
- AUX Input (Yes/No) Yes (1 RCA pair)
- USB Charging (Yes/No) Yes
- Clock (Yes/No) No
- Steering Wheel Control Ready (Yes/No) No
- TUNER Number Of Presets 18 FM / 12 AM / 6 WB
- AM Tuner Range: 530 - 1710 kHz Sensitivity: 40 dB Frequency Response: 45 to 2.4 KHz
- FM Tuner Range: 87.9 - 107.9 MHz Sensitivity: 8 dB Frequency Response. 20 - 15 KHz
- Power Output (max) CEA-2006 GuidelinesCEA-2006 Power Rating 25W x 4 @ 4Ω RMS 50W x 4 @ 2Ω MAX ≤1.0% THD+N
- Frequency Response RCA: 20 Hz - 20 kHz High-Level: 20 Hz - 20 kHz
- Min. Speaker Impedance e2Ω
- Output Impedance <500 Ω
- Max Output Voltage RCA Front: 2 V RCA Rear/Sub: 2 V
- Media Formats MP3
- WMA
- RCA 2V: >85 dB
- High-Level CEA-2006: >75 dB
- High-Level Max Watts: >85 dB
- Channel Separation RCA: >70 dB
- High-Level: >50 dB
- Compatible Remotes N/A
- Max THD+N High-Level: <1.0 @ 4-Ohm
- USB Output Current 1 A
- Operating Voltage 9 - 16 VDC
- USB Version 2.0
- Idle Current <2 A
- Fuse Rating 20 A
- Width: 4.5" (11.5 cm)
- Face Depth: 1.5" (3.8 cm)
- Mount Depth: 2.9" (7.4 cm)
- Height: 4.2 (10.6 cm)
- Shipping Weight 1.22 Lbs. (0.55 Kg)
- Back Panel Cutout 3" (77 mm)
