Description
Rockford Fosgate T1S1-12 Power 12" T1 Slim Single 1-Ohm Subwoofer T1 Performance, Shallow Depth, 1-Ohm Ready
Product Overview
The Rockford Fosgate T1S1-12 is a 12" slimline single 1-ohm subwoofer from the flagship Power T1 series, rated at 600W RMS and 1200W peak. The 1-ohm stable counterpart to the T1S2-12, it carries the complete T1 slimline technology stack in a single 1-ohm voice coil configuration presenting a direct 1-ohm load to the amplifier for maximum power extraction from 1-ohm stable mono amplifiers without any wiring configuration required.
Like the T1S2-12, the T1S1-12 is purpose-engineered to deliver near-identical performance characteristics to the full-depth Power T1 range from a significantly shallower mounting depth, through the same suite of proprietary and patent-pending technologies: the slotted voice coil assembly with interior and exterior windings enabling long excursion travel, the split yoke pass-through motor technology, high-energy neodymium motor structure, encapsulating voice coil-to-former coupling, integrated copper cap heat-sinking shorting ring (IDHS), dual Nomex progressive spiders with integrated lead wires, and carbon fibre/PMI/glass fibre composite cone. Optimised for sealed enclosures. Detachable die-cast aluminium trim ring included; optional grille insert available separately.
Key Specifications
- Driver size: 12" slimline
- Voice coil configuration: Single 1-ohm
- Power handling: 600W RMS / 1200W peak
- Motor structure: High-temp high-energy neodymium
- Voice coil: Dual wound 2.5"; interior and exterior windings (slotted assembly)
- Cone: Carbon fibre / PMI / glass fibre composite with aluminium dust cap
- Surround: Injection-moulded foam with VAST technology
- Spiders: Dual Nomex progressive with integrated lead wires
- Basket: Aluminium die-cast with integrated heat sink fins
- Shorting ring: Integrated copper cap heat-sinking (IDHS)
- Input terminals: Custom insulated push spring 10 AWG
- Pole piece: Vented
- Trim ring: Detachable die-cast aluminium (included)
- Grille: Optional insert (sold separately)
- Optimised for: Sealed enclosures
- Frequency response: Confirm with supplier
- Sensitivity: Confirm with supplier
- Xmax: Confirm with supplier
- Mounting depth: Confirm with supplier
- Cutout diameter: Confirm with supplier
Features & Benefits
-
Single 1-ohm voice coil direct 1-ohm load, zero wiring complexity: The defining differentiator from the T1S2-12. A single 1-ohm voice coil presents a direct 1-ohm load to any 1-ohm stable mono amplifier no parallel or series wiring decisions, no configuration required. The most direct path to maximum power output from a 1-ohm stable amplifier in a slimline 12" T1 driver.
-
Proprietary slotted voice coil assembly with interior/exterior windings (patent pending): Enables long excursion travel from a reduced mounting depth the fundamental engineering challenge of slimline subwoofer design. The slotted assembly with dual winding configuration allows the voice coil to travel significantly further than a conventional shallow driver, generating the displacement needed for deep, high-output bass from a slim installation profile.
-
Proprietary split yoke pass-through motor technology (patent pending): A motor architecture innovation that enables greater excursion travel within a slimmer overall assembly depth, working in combination with the slotted voice coil to produce T1-level bass performance from a shallow driver.
-
High-temp high-energy neodymium motor structure: Neodymium magnets produce significantly stronger magnetic fields per unit mass than conventional ferrite magnets, enabling high motor force (BL) in the compact, lightweight motor assembly required for a slimline design delivering the sensitivity and power handling of a T1 driver from a reduced physical footprint.
-
Encapsulating voice coil-to-former coupling technology (patent pending): Increases bonding surface area and strength between the voice coil and former, preventing delamination at the high excursion levels and sustained 600W RMS input the T1S1-12 is designed for.
-
Integrated copper cap heat-sinking shorting ring (IDHS): Simultaneously reduces inductance variation across the excursion range (improving linearity and reducing distortion) and draws thermal energy away from the voice coil gap essential for sustained 600W RMS reliability in compact, sealed enclosure environments where heat accumulates rapidly.
-
Carbon fibre/PMI/glass fibre composite cone with aluminium dust cap: A stiff, lightweight multi-material composite significantly stiffer than paper or polypropylene cones, maintaining pistonic accuracy across the extended excursion range the slotted assembly enables. PMI foam core adds internal damping to suppress cone resonances.
-
Injection-moulded foam surround with VAST technology: VAST reclaims cone surface area at the surround attachment, maximising effective piston area in the 12" slimline format. The injection-moulded foam surround provides consistent, repeatable compliance across the full travel range.
-
Dual Nomex progressive spiders with integrated lead wires: Dual progressive spiders provide linear restoring force symmetry across the extended excursion range. Integrated lead wires eliminate the traditional separate tinsel lead removing a common high-excursion failure point that is particularly critical in a slimline driver designed for long voice coil travel.
-
Aluminium die-cast basket with integrated heat sink fins: The basket fins actively dissipate heat from the motor assembly during sustained high-power use a thermal management feature particularly important in compact sealed enclosure installations where back-panel heat accumulation is a reliability concern.
-
Vented pole piece: Air channels through the pole piece reduce thermal compression and back-pressure behind the cone at high excursion levels, improving linearity and power handling consistency in sealed enclosure use.
-
Custom insulated push spring 10 AWG terminals: Appropriate for the high current demands of a 600W RMS, 1-ohm system. Push-spring design allows fast, clean wiring without tools.
-
Optimised for sealed enclosures: The T1S1-12 is specifically tuned for sealed enclosure use. Confirm recommended enclosure volume with Rockford Fosgate documentation before building to ensure the intended bass response is achieved.
-
Detachable die-cast aluminium trim ring included: Provides a clean, finished installation appearance at the cutout. Detachable for bare-driver installations where a trim ring is not required.
-
Optional grille insert available separately: Confirm compatible part number with your supplier for installations where driver protection is required.
Technical Specs
| Specification |
Detail |
| SKU |
T1S1-12 |
| Brand |
Rockford Fosgate |
| Driver Size |
12" slimline |
| Voice Coil Configuration |
Single 1-ohm |
| Power Handling |
600W RMS / 1200W peak |
| Motor Structure |
High-temp high-energy neodymium |
| Voice Coil |
Dual wound 2.5"; interior and exterior windings (slotted assembly) |
| Voice Coil Coupling |
Encapsulating voice coil-to-former technology (patent pending) |
| Motor Technology |
Proprietary split yoke pass-through (patent pending) |
| Cone |
Carbon fibre / PMI / glass fibre composite |
| Dust Cap |
Aluminium |
| Surround |
Injection-moulded foam with VAST technology |
| Spiders |
Dual Nomex progressive with integrated lead wires |
| Basket |
Aluminium die-cast with integrated heat sink fins |
| Shorting Ring |
Integrated copper cap heat-sinking (IDHS) |
| Pole Piece |
Vented |
| Input Terminals |
Custom insulated push spring 10 AWG |
| Trim Ring |
Detachable die-cast aluminium (included) |
| Grille |
Optional insert (sold separately) |
| Enclosure Optimisation |
Sealed |
| Frequency Response |
Confirm with supplier |
| Sensitivity |
Confirm with supplier |
| Xmax |
Confirm with supplier |
| Mounting Depth |
Confirm with supplier |
| Cutout Diameter |
Confirm with supplier |
| Shipping Weight |
Confirm with supplier |
| Warranty |
Confirm with supplier |
Compatible With
- Mono amplifiers stable at 1 ohm, rated at or near 600W RMS
- Rockford Fosgate Power T1 and T2 series mono amplifiers (1-ohm stable)
- Custom sealed enclosures designed for the T1S1-12 confirm recommended sealed enclosure volume with Rockford Fosgate documentation before building
- Vehicles where traditional-depth subwoofers will not fit: behind-seat ute and truck installations, shallow boot floor vehicles, and custom fabrication builds with depth constraints
- Rockford Fosgate T1S-1X12 slim sealed loaded enclosure (purpose-built slim sealed enclosure in the T1 slimline range)
- Rockford Fosgate 10 AWG and heavy-gauge wiring kits for 1-ohm mono amplifier installation
- Rockford Fosgate RCA cables and signal processors
Frequently Asked Questions
What is the difference between the T1S1-12 and T1S2-12? Both are 12" T1 slimline subwoofers with identical 600W RMS power handling and the same complete T1 slimline technology stack. The T1S1-12 has a single 1-ohm voice coil presenting a direct 1-ohm load, while the T1S2-12 has a single 2-ohm voice coil presenting a direct 2-ohm load. Choose the T1S1-12 when your amplifier is 1-ohm stable and 1-ohm wiring is the system target; choose the T1S2-12 for 2-ohm stable amplifier pairings.
What impedance does the T1S1-12 present to the amplifier? The T1S1-12 is a single 1-ohm voice coil driver, presenting a direct 1-ohm load. No wiring configuration is required connect a 1-ohm stable mono amplifier rated at or near 600W RMS directly to the 10 AWG push spring terminals.
How does the T1S1-12 achieve T1-level bass performance in a slimline format? The T1S1-12 uses a proprietary slotted voice coil assembly with interior and exterior windings (patent pending) enabling long excursion travel from a reduced mounting depth, combined with a split yoke pass-through motor technology (patent pending) and high-energy neodymium motor structure. These technologies together allow the T1S1-12 to deliver near-identical performance characteristics to a traditional-depth Power T1 subwoofer from a significantly shallower installation profile.
What enclosure type is the T1S1-12 optimised for? The T1S1-12 is specifically optimised for sealed enclosures. Confirm recommended sealed enclosure volume with official Rockford Fosgate documentation or a qualified installer before designing or building an enclosure to ensure the intended bass response is achieved.
Is a grille included with the T1S1-12? No. The T1S1-12 ships with a detachable die-cast aluminium trim ring only. An optional grille insert is available separately confirm the compatible part number with your supplier before purchasing.
