Description
Rockford Fosgate T1S2-10 Power 10" T1 Slim Single 2-Ohm Subwoofer T1 Slimline Performance in a Compact 10" Format
Product Overview
The Rockford Fosgate T1S2-10 is a 10" slimline single 2-ohm subwoofer from the flagship Power T1 series, rated at 500W RMS and 1000W peak. The most compact driver in the T1 slimline range, it delivers the full T1 slimline technology package in a 10" format suited to the tightest space-restricted installations in Australian utes, single-cab trucks, hatchbacks, and compact vehicles where both depth and diameter are constrained.
Like the T1S2-12 and T1S1-12, the T1S2-10 is purpose-engineered through proprietary and patent-pending technologies to deliver near-identical performance characteristics to the full-depth Power T1 range from a significantly shallower mounting depth. The same slotted voice coil assembly with interior and exterior windings enabling long excursion travel, split yoke pass-through motor technology, high-energy neodymium motor structure, encapsulating voice coil-to-former coupling, IDHS copper cap heat-sinking shorting ring, dual Nomex progressive spiders with integrated lead wires, and carbon fibre/PMI/glass fibre composite cone are all present scaled to the 10" slimline format. Single 2-ohm voice coil for direct 2-ohm amplifier connection. Optimised for sealed enclosures. Detachable die-cast aluminium trim ring included; optional grille insert available separately.
Key Specifications
- Driver size: 10" slimline
- Voice coil configuration: Single 2-ohm
- Power handling: 500W RMS / 1000W peak
- Motor structure: High-temp high-energy neodymium
- Voice coil: Dual wound 2.5"; interior and exterior windings (slotted assembly)
- Cone: Carbon fibre / PMI / glass fibre composite with aluminium dust cap
- Surround: Injection-moulded foam with VAST technology
- Spiders: Dual Nomex progressive with integrated lead wires
- Basket: Aluminium die-cast with integrated heat sink fins
- Shorting ring: Integrated copper cap heat-sinking (IDHS)
- Input terminals: Custom insulated push spring 10 AWG
- Pole piece: Vented
- Trim ring: Detachable die-cast aluminium (included)
- Grille: Optional insert (sold separately)
- Optimised for: Sealed enclosures
- Frequency response: Confirm with supplier
- Sensitivity: Confirm with supplier
- Xmax: Confirm with supplier
- Mounting depth: Confirm with supplier
- Cutout diameter: Confirm with supplier
Features & Benefits
-
Most compact T1 slimline driver available 10" format: The T1S2-10 brings the full T1 slimline technology stack to the smallest diameter in the range. Where even the T1S2-12 is too wide for the available space, the T1S2-10 delivers genuine T1 slimline performance from a 10" footprint the most versatile fitment option in the T1 slimline range for Australian compact vehicle installations.
-
500W RMS / 1000W peak power handling: Scaled to the 10" slimline format, the T1S2-10 handles 500W RMS 100W RMS less than the 12" slimline models, reflecting the smaller cone area, while remaining firmly in high-output territory well beyond any generic shallow 10" driver at this diameter.
-
Single 2-ohm voice coil direct 2-ohm load: Presents a direct 2-ohm load to any 2-ohm stable mono amplifier. No wiring configuration required straightforward amplifier pairing for the most common mono amplifier impedance rating in Australian car audio systems.
-
Proprietary slotted voice coil assembly with interior/exterior windings (patent pending): Enables long excursion travel from a reduced mounting depth the engineering solution that makes T1-level bass performance possible in a slimline 10" driver. The slotted assembly with dual winding configuration allows voice coil travel significantly greater than a conventional shallow driver of the same diameter.
-
Proprietary split yoke pass-through motor technology (patent pending): Motor architecture innovation enabling greater excursion travel within a slimmer overall assembly depth, working in combination with the slotted voice coil to produce T1-level bass from a 10" shallow profile.
-
High-temp high-energy neodymium motor structure: Neodymium magnets produce stronger magnetic fields per unit mass than ferrite equivalents, enabling high motor force (BL) in the compact, lightweight motor assembly required for a 10" slimline design delivering T1-level sensitivity and power handling from a reduced physical footprint.
-
Encapsulating voice coil-to-former coupling technology (patent pending): Increases bonding surface area and strength between the voice coil and former, preventing delamination at the high excursion levels and sustained 500W RMS input the T1S2-10 is rated for.
-
Integrated copper cap heat-sinking shorting ring (IDHS): Reduces inductance variation across the excursion range (improving linearity and reducing distortion) while drawing thermal energy away from the voice coil gap critical for sustained power handling reliability in compact sealed enclosure installations where heat accumulates rapidly.
-
Carbon fibre/PMI/glass fibre composite cone with aluminium dust cap: Stiff, lightweight multi-material composite maintaining pistonic accuracy across the extended excursion range the slotted assembly enables. PMI foam core adds internal damping to suppress cone resonances at high excursion.
-
Injection-moulded foam surround with VAST technology: VAST reclaims cone surface area at the surround attachment, maximising effective piston area in the 10" slimline format where every square centimetre of cone area contributes to output. Injection-moulded foam provides consistent, repeatable compliance across the full excursion range.
-
Dual Nomex progressive spiders with integrated lead wires: Dual progressive spiders provide linear restoring force symmetry across the extended excursion range. Integrated lead wires eliminate the separate tinsel lead removing a common high-excursion failure point that is particularly critical in a slimline driver engineered for long voice coil travel.
-
Aluminium die-cast basket with integrated heat sink fins: Active heat dissipation from the motor assembly during sustained high-power use a thermal management feature particularly important for a 10" slimline driver in compact sealed enclosures where back-panel heat accumulation is concentrated.
-
Vented pole piece: Reduces thermal compression and back-pressure behind the cone at high excursion, improving linearity and power handling consistency in sealed enclosure use.
-
Custom insulated push spring 10 AWG terminals: Appropriate for the current demands of a 500W RMS, 2-ohm system. Push-spring design for fast, clean wiring without tools.
-
Optimised for sealed enclosures: Specifically tuned for sealed enclosure alignment. Confirm recommended enclosure volume with Rockford Fosgate documentation before building.
-
Detachable die-cast aluminium trim ring included: Clean, finished installation appearance at the cutout. Detachable for bare-driver installations where a trim ring is not required.
Technical Specs
| Specification |
Detail |
| SKU |
T1S2-10 |
| Brand |
Rockford Fosgate |
| Driver Size |
10" slimline |
| Voice Coil Configuration |
Single 2-ohm |
| Power Handling |
500W RMS / 1000W peak |
| Motor Structure |
High-temp high-energy neodymium |
| Voice Coil |
Dual wound 2.5"; interior and exterior windings (slotted assembly) |
| Voice Coil Coupling |
Encapsulating voice coil-to-former technology (patent pending) |
| Motor Technology |
Proprietary split yoke pass-through (patent pending) |
| Cone |
Carbon fibre / PMI / glass fibre composite |
| Dust Cap |
Aluminium |
| Surround |
Injection-moulded foam with VAST technology |
| Spiders |
Dual Nomex progressive with integrated lead wires |
| Basket |
Aluminium die-cast with integrated heat sink fins |
| Shorting Ring |
Integrated copper cap heat-sinking (IDHS) |
| Pole Piece |
Vented |
| Input Terminals |
Custom insulated push spring 10 AWG |
| Trim Ring |
Detachable die-cast aluminium (included) |
| Grille |
Optional insert (sold separately) |
| Enclosure Optimisation |
Sealed |
| Frequency Response |
Confirm with supplier |
| Sensitivity |
Confirm with supplier |
| Xmax |
Confirm with supplier |
| Mounting Depth |
Confirm with supplier |
| Cutout Diameter |
Confirm with supplier |
| Shipping Weight |
Confirm with supplier |
| Warranty |
Confirm with supplier |
Compatible With
- Mono amplifiers stable at 2 ohms, rated at or near 500W RMS
- Rockford Fosgate Power T1 and T2 series mono amplifiers
- Custom sealed enclosures designed for the T1S2-10 confirm recommended sealed enclosure volume with Rockford Fosgate documentation before building
- Vehicles requiring the most compact T1 slimline footprint: compact hatchbacks, small sedans, single-cab trucks, and utes where 12" slimline width is too large
- Installations where both mounting depth and driver diameter are constrained
- Rockford Fosgate 10 AWG and heavy-gauge wiring kits for 2-ohm mono amplifier installation
- Rockford Fosgate RCA cables and signal processors
Frequently Asked Questions
What is the difference between the T1S2-10 and the T1 12" slimline models? The T1S2-10 uses the same full T1 slimline technology stack as the T1S2-12 and T1S1-12, with the key differences being driver diameter (10" vs 12") and power handling (500W RMS vs 600W RMS). Choose the T1S2-10 when both mounting depth and driver diameter are constrained and a 12" slimline footprint is too wide for the available space.
What impedance does the T1S2-10 present to the amplifier? The T1S2-10 is a single 2-ohm voice coil driver, presenting a direct 2-ohm load. No wiring configuration is required connect a 2-ohm stable mono amplifier rated at or near 500W RMS directly to the 10 AWG push spring terminals.
How does the T1S2-10 achieve T1-level performance in a 10" slimline format? Through the same proprietary and patent-pending technologies as the 12" slimline models a slotted voice coil assembly with interior and exterior windings enabling long excursion travel, split yoke pass-through motor technology, and a high-energy neodymium motor structure. These technologies together allow the T1S2-10 to deliver near-identical performance characteristics to a traditional-depth Power T1 10" subwoofer from a significantly shallower mounting depth.
What enclosure type is the T1S2-10 optimised for? The T1S2-10 is specifically optimised for sealed enclosures. Confirm recommended sealed enclosure volume with official Rockford Fosgate documentation or a qualified installer before designing or building an enclosure.
Is a grille included with the T1S2-10? No. The T1S2-10 ships with a detachable die-cast aluminium trim ring only. An optional grille insert is available separately confirm the compatible part number with your supplier before purchasing.
